Wiring Diagram VW JETTA 2010 - Footwell light switch - warning buzzer switch
https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO
| E20 | Switches and instruments illumination regulator |
| E295 | Footwell light switch |
| E296 | Warning buzzer switch |
 ">J519 | ">Onboard supply control unit |
| T3g | 3-pin connector |
| T6ao | 6-pin connector |
| T6ap | 6-pin connector |
| T8e | 8-pin connector |
| U1 | Cigarette lighter |
| 47 | Earth point, in front right footwell |
| 374 | Earth connection 9, in main wiring harness |
| 436 | Earth connection 1 in driving school wiring harness |
| 468 | Earth connection 2 in driving school wiring harness |
| B238 | Positive connection 2 (58b), in interior wiring harness |
| B547 | Connection 1, in driving school vehicle wiring harness |
| B548 | Connection (58), in driving school vehicle wiring harness |
Wiring Diagram VW JETTA 2010 - Accelerator switch for driving school vehicle - warning buzzer for pedal switch on front passenger side - engine speed governor control unit - terminal 15 voltage supply relay 2
| E494 | Accelerator switch for driving school vehicle |
| F349 | Warning buzzer for pedal switch on front passenger side |
| ">J519 | ">Onboard supply control unit |
| J542 | engine speed governor control unit, on doble pedal system |
| J681 | Terminal 15 voltage supply relay 2 |
| J682 | Terminal 50 voltage supply relay |
| SC21 | Fuse 21 on fuse holder C |
| T3ap | 3-pin connector |
| T9b | 9-pin connector |
| T18f | 18-pin connector |
| A2 | Positive connection (15), in dash panel wiring harness |
| B545 | Positive connection (15a), in driving school vehicle wiring harness |
| B547 | Connection 1, in driving school vehicle wiring harness |
Wiring Diagram VW JETTA 2010 - Accelerator position sender - accelerator position sender 2 - engine speed governor control unit
| G79 | Accelerator position sender |
| G185 | Accelerator position sender 2 |
| ">J519 | ">Onboard supply control unit |
| J542 | engine speed governor control unit, on doble pedal system |
| J623 | Engine control unit |
| T6h | 6-pin connector |
| * | the assignment on the engine control unit can be found in the respective current flow diagram |
Wiring Diagram VW JETTA 2010 - Onboard supply control unit - driving school mode relay - driving school vehicle footwell illumination
| ">J519 | ">Onboard supply control unit |
| J746 | Driving school mode relay, under switch cover, centre console |
| W3 | Luggage compartment light |
| W56 | Driving school vehicle footwell illumination |
| 436 | Earth connection 1 in driving school wiring harness |
| B150 | Positive connection 2 (30a), in interior wiring harness |
| B560 | Positive connection 1 (30g), in driving school wiring harness |
| B667 | Connection 2, in driving school vehicle wiring harness |
VW JETTA 2010 Control units overview
Control units overview | | | | q | Connector assigment, 50 pin |
| q | Connector assigment, 75 pin |
| Jetta | Fitting Locations | No. 806 / 2 |
|
| Jetta | Fitting Locations | No. 806 / 3 |
|
Location:
| Under front centre console -arrow- |
| | Connector assigment:
| A - | Airbag control unit -J234- |
| Jetta | Fitting Locations | No. 806 / 6 | | | A - | Airbag control unit -J234- | | Jetta | Fitting Locations | No. 806 / 7 | |
VW JETTA 2010 Convenience system central control unit -J393-Location: |
| Below the dash panel, behind the glove box -arrow- | | | | Connector assigment: | | A - | Convenience system central control unit - J393 | | Jetta | Fitting Locations | No. 806 / 9 | |
VW JETTA 2010 - G384 - Vehicle inclination sender- G384 - Vehicle inclination sender |
| Below the dash panel on right, behind the front passenger airbag ⇒ -arrow- | | | | VW JETTA 2010 Headlight range control, control unit -J431- | Headlight range control, control unit -J431- | | | |
| On glove compartment right ⇒ -arrow- | | | |
Connector assigment:
| A - | Headlight range control, control unit - J431 |
| Jetta | Fitting Locations | No. 806 / 12 | |
VW JETTA 2010 Front passenger side door control unit -J387-Location: |
| On door inner part on front right -arrow- | Note: | The illustration shows the left side. The right side is similar. | | | | Connector assigment: |
| A - | Front passenger side door control unit -J387- |
| Jetta | Fitting Locations | No. 806 / 14 | |
VW JETTA 2010 Mobile telephone operating electronics control unit -J412-Location: |
| Under seat on front right ⇒ -arrow- | | | | Connector assigment: |
| A - | Mobile telephone operating electronics control unit -J412- |
| Jetta | Fitting Locations | No. 806 / 16 | |
VW JETTA 2010 Heated front passenger seat control unit -J132-Heated front passenger seat control unit -J132- |
| | | | On seat frame on front right -arrow- |
VW JETTA 2010 Aerial selection control unit -J515-Aerial selection control unit -J515- |
| | | | On seat frame on front right -arrow- | | | | VW JETTA 2010 Rear right door control unit -J389- | Rear right door control unit -J389- |
| | | On door inner part on rear right -arrow- | Note: | The illustration shows the left side. The right side is similar. | | | |
Connector assigment:
| A - | Rear right door control unit -J389- |
| Jetta | Fitting Locations | No. 806 / 19 | |
VW JETTA 2010 Fuel pump control unit -J538-Location: |
| Under rear seat, right, on fuel delivery unit -arrow- | | | | Connector assigment: |
| A - | Fuel pump control unit -J538- |
| Jetta | Fitting Locations | No. 806 / 21 | |
VW JETTA 2010 Rear left door control unit -J388-Location: |
| On door inner part on rear left -arrow- | | | | Connector assigment: |
| A - | Rear left door control unit -J388- |
| Jetta | Fitting Locations | No. 806 / 23 | |
VW JETTA 2010 Heated driver seat control unit -J131-Heated driver seat control unit -J131- |
| | | | On seat frame on front left -arrow- | | | | VW JETTA 2010 Driver door control unit -J386- | Driver door control unit -J386- |
| | | On door inner part on front left -arrow- | | | |
Connector assigment:
| A - | Driver door control unit -J386- |
| Jetta | Fitting Locations | No. 806 / 26 | |
VW JETTA 2010 Steering column electronics control unit -J527-Steering column electronics control unit -J527- |
| | | | Under steering column, near steering column switch -arrow- | | | | Connector assigment: |
| A - | | Jetta | Fitting Locations | No. 806 / 28 | | | 11 - | Diagnostic interface for CAN data bus drive, low | | 12 - | Diagnostic interface for CAN data bus drive, high | | 13 - | Cruise control system, output |
| Jetta | Fitting Locations | No. 806 / 29 | | | 14 - | Diagnostic interface for convenience CAN data bus, low | | 15 - | Diagnostic interface for convenience CAN data bus, high | | 16 - | Multifunction switch (automatic or direct shift gearbox only) |
F = Ignition/starter switch and ignition key withdrawal lock support: |
| 3 - | Ignition key withdrawal lock terminal 30 |
| 4 - | Ignition key withdrawal lock earth |
| 7 - | Ignition/starter switch output terminal 50 |
| 8 - | Ignition/starter switch terminal 30 |
| 9 - | Ignition/starter switch output terminal S |
| 10 - | Ignition/starter switch output terminal X |
| 11 - | Ignition/starter switch output terminal P |
| 12 - | Ignition/starter switch output terminal 15 |
| Jetta | Fitting Locations | No. 806 / 31 |
|
| G = Wiper support, interval potentiometer and multifunction system: |
| 3 - | Rear lid wash/wipe signal |
| 6 - | Earth MFA, interval potentiometer |
| 7 - | Intermittent operation speeds signal |
| H= Steering angle sensor support: |
| 4 - | 12 Volt voltage supply |
| 5 - | 5 Volt voltage supply |
| Jetta | Fitting Locations | No. 806 / 32 |
|
| 10 - | Photoelectric beam 7 |
| I = Coil connector support: |
| 7 - | Earth for coil connector, multifunction steering wheel and signal horn |
| 9 - | LIN bus, heated steering wheel temperature sensor |
| 10 - | Multifunction steering wheel voltage supply terminal 15 |
Connector assigment:
| - | Dash panel insert -J285- |
| Jetta | Fitting Locations | No. 806 / 34 | | | 13 - | Diagnostic interface for combi CAN data bus, high | | 15 - | Diagnostic interface for combi CAN data bus exciter wire | | 16 - | Fuel gauge sender (4 Motion) | | 17 - | Fuel gauge sender (full) | | 18 - | Fuel gauge sender (empty) | | 22 - | Front left brake pad wear sender | | 24 - | Fuel tank flap lock warning lamp |
| Jetta | Fitting Locations | No. 806 / 35 | | | 25 - | Oil pressure warning lamp | | 26 - | Oil level and oil temperature sender | | 28 - | Speed signal, sliding sunroof adjustment control unit output, control unit with display for radio and navigation system | | 33 - | Terminal 31, sensor earth | | 34 - | Washer fluid level warning lamp | | 35 - | Coolant temperature and coolant shortage warning lamp | | 36 - | Ambient temperature sensor |
VW JETTA 2010 Onboard power supply control unit -J519- | Location: |
| On left under dash panel, under relay carrier -arrow- |
| | Connector assigment:
| - | Onboard power supply control unit -J519- |
| Jetta | Fitting Locations | No. 806 / 38 | | | 1 - | Right reversing light bulb | | 4 - | Rear left fog light bulb | | 5 - | Right brake and tail light bulb | | 7 - | Front left entry light, front right entry light | | 9 - | Right tail light bulb | | 10 - | Rear right turn signal bulb | | 11 - | Front interior light | | 1 - | Heated driver seat control unit, heated front passenger seat control unit | | 2 - | Left brake and tail light bulb |
| Jetta | Fitting Locations | No. 806 / 39 | | | 9 - | High level brake light bulb | | 10 - | Left tail light bulb | | 11 - | Rear left turn signal bulb | | 4 - | Left dipped beam bulb | | 6 - | Left gas discharge (xenon) bulb | | 7 - | Terminal 15 voltage supply relay | | 8 - | Headlight washer system relay |
| Jetta | Fitting Locations | No. 806 / 40 | | | 10 - | Right side light bulb | | 11 - | Front left turn signal bulb | | 1 - | Lighting switch terminal 58 | | 7 - | Earth (for manual gearbox only), mechatronics for direct shift gearbox (direct shift gearbox only), multifunction switch (for automatic gearbox only) | | 8 - | Lighting switch terminal 56 |
| Jetta | Fitting Locations | No. 806 / 41 | | | 13 - | Light switch (rear fog light) | | 14 - | Light switch (assistance driving light) | | 16 - | Light switch (day driving light) | | 1 - | Terminal 50 voltage supply relay | | 2 - | Terminal 15 voltage supply relay | | 3 - | Windscreen wiper motor, rain and light detector sensor (LIN bus) | | 5 - | Bonnet contact switch | | 6 - | Reversing light switch |
| Jetta | Fitting Locations | No. 806 / 42 | | | 1 - | Steering column electronics control unit terminal 50 | | 2 - | Hazard warning light system warning lamp | | 4 - | Illumination regulators, switches, instruments | | 6 - | Heated rear window button | | 7 - | Convenience CAN bus low | | 8 - | Convenience CAN bus high | | 9 - | Hazard warning light switch | | 10 - | Illumination regulators, switches, instruments | | 11 - | Steering column electronics control unit terminal 15 | | 12 - | Illumination regulators, switches, instruments | Note:
| Jetta | Fitting Locations | No. 806 / 43 | | | 1 - | Fuse, windscreen washer pump | | 4 - | Windscreen washer pump motor | | 6 - | Treble tone horn, bass tone horn |
| Jetta | Fitting Locations | No. 806 / 44 | | | 6 - | Heated rear window fuse |
VW JETTA 2010 Data bus diagnostic interface -J533- | Location: |
| In left footwell, near centre console -arrow- |
| | Connector assigment:
| A - | Data bus diagnostic interface -J533- |
VW JETTA 2010 Overview of relay carrier | Overview of relay carrier |
| | | q | Position of relays of electronics box with 30 fuses |
| 3 - | Relay carrier on onboard power supply control unit, under left dash panel |
Relay position assignment on additional relay carrier under electronics box in left engine compartment
| C2 - | Automatic glow period control unit -J179- (461) |
Note:
| The additional relay carrier is located under the electronics box and is only visible when it is removed. |
VW JETTA 2010 Position of relays of electronics box with 54 fuses
Position of relays of electronics box with 54 fuses | | A1 - | Motronic current supply relay -J271- (100) |
| A2 - | Continued coolant circulation relay -J151- (100) |
| A4 - | Engine component current supply relay -J757- (167) |
VW JETTA 2010 Position of relays of electronics box with 30 fuses
Position of relays of electronics box with 30 fuses | | A1 - | Motronic current supply relay -J271- (100) |
| - | Terminal 30 voltage supply relay -J317- (458) |
| q | Engine codes AZV, BKC, BKD, BLS, BMM |
| - | Current supply relay for Simos control unit -J363- (458) |
| A2 - | Secondary air pump relay -J299- (100) |
VW JETTA 2010 Position of relays, relay carrier on onboard power supply control unit, under left dash panel
Position of relays, relay carrier on onboard power supply control unit, under left dash panel | | B1 - | Terminal 15 voltage supply relay -J329- (460) |
| B4 - | Terminal 30 voltage supply relay -J317- (449) |
| B5 - | Heated rear window relay -J9- (53) |
| B6 - | Dual tone horn relay -J4- (449) |
| B8 - | Double washer pump relay 2 -J730- (404) |
| B9 - | X-contact relief relay -J59- (460) |
VW JETTA 2010 Relay carrier on left under dash panel
Relay carrier on left under dash panel | VW JETTA 2010 Overview of fuses (SC) in fuse holder left dash panel | Overview of fuses (SC) in fuse holder left dash panel |
| | | q | Position of fuses, from November 2004 |
| q | Position of fuses, from May 2005 |
| q | Position of fuses, engine code BWA, from July 2006 |
| q | Position of fuses, from July 2006 |
Fuses (SC) in fuse holder, left dash panel
| Fuses (SC) in fuse holder, left dash panel |
VW JETTA 2010 Position of fuses, from November 2004
| Jetta | Fitting Locations | No. 803 / 4 | | | No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal | | 3 | - | SC3 - Fuse 3 on fuse holder | 5A | - | J234 - Airbag control unit
K145 - Front passenger side airbag deactivated warning lamp | 15 | | 4 | - | SC4 - Fuse 4 on fuse holder | 5A | - | E256-TCS and ESP button
E492 - Tyre pressure monitor display button
F4 - Reversing light switch
G65 - High-pressure sender
G226 -Oil level and oil temperature sender
J255 - Climatronic control unit
Y7 - Automatic anti-dazzle interior mirror
Z20 - Left washer jet heater element
Z21 - Right washer jet heater element | 15 | | 5 | - | SC5 - Fuse 5 on fuse holder | - | - | Vacant | 15 | | 6 | - | SC6 - Fuse 6 on fuse holder | - | - | Vacant | 15 | | 7 | - | SC7 - Fuse 7 on fuse holder | - | - | Vacant | 15 | | 8 | - | SC8 - Fuse 8 on fuse holder | - | - | Vacant | 15 | | 9 | - | SC9 - Fuse 9 on fuse holder | - | - | Vacant | - | | 10 | - | SC10 - Fuse 10 on fuse holder | - | - | Vacant | 15 | | 11 | - | SC11 - Fuse 11 on fuse holder | - | - | Vacant | 15 |
| Jetta | Fitting Locations | No. 803 / 6 | | | No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal | | 20 | - | SC20 - Fuse 20 on fuse holder | - | - | Vacant | 30 | | 21 | - | SC21 - Fuse 21 on fuse holder | - | - | Vacant | - | | 22 | - | SC22 - Fuse 22 on fuse holder | 30A | - | V2 - Fresh air blower | 30 | | 23 | - | SC23 - Fuse 23 on fuse holder | 30A | - | J386 - Driver door control unit
J387 - Front passenger side door control unit | 30 | | 24 | - | SC24 - Fuse 24 on fuse holder | 20A | - | J388 - Rear left door control unit
J389 - Rear right door control unit
J393 - Convenience system central control unit | 30 | | 25 | - | SC25 - Fuse 25 on fuse holder | 25A | - | J485 - Auxiliary heater operation relay
J519-Onboard power supply control unit | 30 | | 26 | - | SC26 - Fuse 26 on fuse holder | 30A | - | J388 - Rear left door control unit
J389 - Rear right door control unit | 30 | | 27 | - | SC27 - Fuse 27 on fuse holder | 15A | - | J538 - Fuel pump control unit | 30 | | 28 | - | SC28 - Fuse 28 on fuse holder | - | - | Vacant | 30 | | 29 | - | SC29 - Fuse 29 on fuse holder | - | - | Vacant | 15 | | 30 | - | SC30 - Fuse 30 on fuse holder | - | - | Vacant | 15 | | 31 | - | SC31 - Fuse 31 on fuse holder | - | - | Vacant | 15 |
| Jetta | Fitting Locations | No. 803 / 8 | | | No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal | | 42 | - | SC42 - Fuse 42 on fuse holder | 20A | - | J29 - Blocking diode
U1-Cigarette lighter
U5 - 12 V socket
U9 - Rear cigarette lighter | 75 | | 43 | - | SC43 - Fuse 43 on fuse holder | 15A | - | J345 - Trailer detector control unit | 30 | | 44 | - | SC44 - Fuse 44 on fuse holder | 20A | - | J345 - Trailer detector control unit | 30 | | 45 | - | SC45 - Fuse 45 on fuse holder | 15A | - | J345 - Trailer detector control unit | 30 | | 46 | - | SC46 - Fuse 46 on fuse holder | - | - | Vacant | 75 | | 47 | - | SC47 - Fuse 47 on fuse holder | - | - | Vacant | 15 | | 48 | - | SC48 - Fuse 48 on fuse holder | - | - | Vacant | - | | 49 | - | SC49 - Fuse 49 on fuse holder | - | - | Vacant | 75 |
VW JETTA 2010 Position of fuses, from July 2005 | Position of fuses, from July 2005 | | No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
| 1 | - | SC1 - Fuse 1 on fuse holder | 10A | - | E20 - Switches and instruments illumination regulator
G42 - Intake air temperature sender, engine codes AZV, BKD, BKC, BLS, BMM, BMN
G70 - Air mass meter BMY, BLG, AZV, BKD, BKC, BLS, BMM, BMN
J31 - Automatic intermittent wash and wipe relay
J431 - Headlight range control, control unit
N79 - Heater element for crankcase breather, engine codes BMY, BLG, BSE BSF, AZV, BKD
T16 - Diagnosis connection (T16/1) | 15 |
| Jetta | Fitting Locations | No. 803 / 11 |
|
| No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
| 4 | - | SC4 - Fuse 4 on fuse holder | 5A | - | E16 - Heater/heat output switch
E256-TCS and ESP button
E492 - Tyre pressure monitor display button
F4 - Reversing light switch
G65 - High-pressure sender
G226 -Oil level and oil temperature sender
J255 - Climatronic control unit
Y7 - Automatic anti-dazzle interior mirror
Z20 - Left washer jet heater element
Z21 - Right washer jet heater element | 15 |
| 5 | - | SC5 - Fuse 5 on fuse holder | - | - | Vacant | 15 |
| 6 | - | SC6 - Fuse 6 on fuse holder | - | - | Vacant | 15 |
| 7 | - | SC7 - Fuse 7 on fuse holder | - | - | Vacant | 15 |
| 8 | - | SC8 - Fuse 8 on fuse holder | - | - | Vacant | 15 |
| 9 | - | SC9 - Fuse 9 on fuse holder | - | - | Vacant | - |
| 10 | - | SC10 - Fuse 10 on fuse holder | - | - | Vacant | 15 |
| 11 | - | SC11 - Fuse 11 on fuse holder | - | - | Vacant | 15 |
| 12 | - | SC12 - Fuse 12 on fuse holder | 10A | - | J386 - Driver door control unit
J387 - Front passenger side door control unit | 30 |
| 13 | - | SC13 - Fuse 13 on fuse holder | 10A | - | E1 - Lighting switch
G397 - Rain and light detector sensor
T16 - Diagnosis connection (T16/16) | 30 |
| Jetta | Fitting Locations | No. 803 / 13 |
|
| No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
| 27 | - | SC27 - Fuse 27 on fuse holder | 15A | - | J17 - Fuel pump relay, engine codes BLF, BSE, BSF, AZV, BKD, BKC, BLS, BMM, BMN
J49 - Electric fuel pump 2 relay, engine codes BSE, BSF
J538 - Fuel pump control unit, engine codes BLF, BVY, BVZ | 30 |
| 28 | - | SC28 - Fuse 28 on fuse holder | - | - | Vacant | 30 |
| 29 | - | SC29 - Fuse 29 on fuse holder | - | - | Vacant | 15 |
| 30 | - | SC30 - Fuse 30 on fuse holder | 20A | - | F125 -Multifunction switch
J217 - Automatic gearbox control unit | 15 |
| 31 | - | SC31 - Fuse 31 on fuse holder | 20A | - | V192 - Vacuum pump for brakes, engine codes BLF, BSE, BSF, BVY, BVZ | 15 |
| 32 | - | SC32 - Fuse 32 on fuse holder | 30A | - | U11 - Interior socket, 230 V, 110 V | 30 |
| Jetta | Fitting Locations | No. 803 / 15 |
|
| No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
| 40 | - | SC40 - Fuse 40 on fuse holder | 40A | - | J13 - Fresh air blower relay
J301 - Air conditioning system control unit | 75 |
| 41 | - | SC41 - Fuse 41 on fuse holder | 20A | - | J519-Onboard power supply control unit
V5 - Washer pump | - |
| 42 | - | SC42 - Fuse 42 on fuse holder | 20A | - | J29 - Blocking diode
U1-Cigarette lighter
U5 - 12 V socket
U9 - Rear cigarette lighter | 75 |
| 43 | - | SC43 - Fuse 43 on fuse holder | 15A | - | J345 - Trailer detector control unit | 30 |
| 44 | - | SC44 - Fuse 44 on fuse holder | 20A | - | J345 - Trailer detector control unit | 30 |
| 45 | - | SC45 - Fuse 45 on fuse holder | 15A | - | J345 - Trailer detector control unit | 30 |
| 46 | - | SC46 - Fuse 46 on fuse holder | - | - | Vacant | 75 |
| 47 | - | SC47 - Fuse 47 on fuse holder | - | - | Vacant | 15 |
| 48 | - | SC48 - Fuse 48 on fuse holder | - | - | Vacant | - |
| 49 | - | SC49 - Fuse 49 on fuse holder | - | - | Vacant | 75 |
VW JETTA 2010 Position of fuses, engine code BWA, from July 2006
Position of fuses, engine code BWA, from July 2006 | | No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
| 1 | - | SC1 - Fuse 1 on fuse holder | 10A | - | E20 - Switches and instruments illumination regulator
G42 - Intake air temperature sender
G70 - Air mass meter
J31 - Automatic intermittent wash and wipe relay
J431 - Headlight range control, control unit
T16 - Diagnosis connection (T16/1) | 15 |
| 2 | - | SC2 - Fuse 2 on fuse holder | 10A | - | E1 - Lighting switch
F - Brake light switch
F47-Brake pedal switch
F189 - Tiptronic switch
J104 - ABS control unit
J285 - Control unit in dash panel insert
J500 - Power steering control unit
J530 - Garage door operation control unit
J533 - Data bus diagnostic interface
J538 - Fuel pump control unit
J587 - Selector lever sensors control unit
J623 - Engine control unit
J743 -Mechatronic unit for dual clutch gearbox
V48 - Left headlight range control motor
V49 - Right headlight range control motor | 15 |
| Jetta | Fitting Locations | No. 803 / 18 |
|
| No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
| 12 | - | SC12 - Fuse 12 on fuse holder | 10A | - | J386 - Driver door control unit
J387 - Front passenger side door control unit | 30 |
| 13 | - | SC13 - Fuse 13 on fuse holder | 10A | - | E1 - Lighting switch
G397 - Rain and light detector sensor
T16 - Diagnosis connection (T16/16) | 30 |
| 14 | - | SC14 - Fuse 14 on fuse holder | 10A | - | J255 - Climatronic control unit
J301 - Air conditioning system control unit
J446 - Parking aid control unit
J587 - Selector lever sensors control unit
R149 - Remote control receiver for auxiliary coolant heater | 30 |
| 15 | - | SC15 - Fuse 15 on fuse holder | 7,5A | - | J519-Onboard power supply control unit | 30 |
| 16 | - | SC16 - Fuse 16 on fuse holder | - | - | Vacant | 30 |
| 17 | - | SC17 - Fuse 17 on fuse holder | 5A | - | G273 - Interior monitoring sensor
H12-Alarm horn | 30 |
| 18 | - | SC18 - Fuse 18 on fuse holder | - | - | Vacant | 30 |
| 19 | - | SC19 - Fuse 19 on fuse holder | - | - | Vacant | - |
| Jetta | Fitting Locations | No. 803 / 20 |
|
| No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
| 35 | - | SC35 - Fuse 35 on fuse holder | - | - | Vacant | 30 |
| 36 | - | SC36 - Fuse 36 on fuse holder | 20A | - | J39 - Headlight washer system relay | 30 |
| 37 | - | SC37 - Fuse 37 on fuse holder | 30A | - | J131 - Heated driver seat control unit
J132 - Heated front passenger seat control unit | 30 |
| 38 | - | SC38 - Fuse 38 on fuse holder | - | - | Vacant | 15 |
| 39 | - | SC39 - Fuse 39 on fuse holder | - | - | Vacant | 15 |
| 40 | - | SC40 - Fuse 40 on fuse holder | 40A | - | J13 - Fresh air blower relay
J301 - Air conditioning system control unit | 75 |
| 41 | - | SC41 - Fuse 41 on fuse holder | 20A | - | J519-Onboard power supply control unit
V5 - Washer pump | - |
| 42 | - | SC42 - Fuse 42 on fuse holder | 20A | - | J29 - Blocking diode
U1-Cigarette lighter
U5 - 12 V socket
U9 - Rear cigarette lighter | 75 |
| 43 | - | SC43 - Fuse 43 on fuse holder | 15A | - | J345 - Trailer detector control unit | 30 |
| 44 | - | SC44 - Fuse 44 on fuse holder | 20A | - | J345 - Trailer detector control unit | 30 |
| 45 | - | SC45 - Fuse 45 on fuse holder | 15A | - | J345 - Trailer detector control unit | 30 |
| 46 | - | SC46 - Fuse 46 on fuse holder | - | - | Vacant | 75 |
| 47 | - | SC47 - Fuse 47 on fuse holder | - | - | Vacant | 15 |
| 48 | - | SC48 - Fuse 48 on fuse holder | - | - | Vacant | - |
| 49 | - | SC49 - Fuse 49 on fuse holder | - | - | Vacant | 75 |
VW JETTA 2010 Position of fuses, from July 2006
Position of fuses, from July 2006 | | No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
| 1 | - | SC1 - Fuse 1 on fuse holder | 10A | - | E20 - Switches and instruments illumination regulator
E102 - Headlight range control regulator (T8e/1)
G42 - Intake air temperature sender (T5d/2), engine codes AZV, BKD, BKC, BLS, BMN, BMM
G70 - Air mass meter (T5d/2), engine codes AZV, BKD, BKC, BLS, BMN, BMM, BMY, BLG
J13 - Fresh air blower relay
J31 - Automatic intermittent wash and wipe relay
J431 - Headlight range control, control unit (T26c/23)
N79-Heater element for crankcase breather
T16 - Diagnosis connection (T16/1) | 15 |
| Jetta | Fitting Locations | No. 803 / 23 |
|
| No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
| 3 | - | SC3 - Fuse 3 on fuse holder | 5A | - | J234 - Airbag control unit (T50/1), (T50/31), (T75/1), (T75/26)
K145 - Front passenger side airbag deactivated warning lamp | 15 |
| 4 | - | SC4 - Fuse 4 on fuse holder | 5A | - | E16 - Heater/heat output switch
E256 - TCS and ESP button (T6ad/4)
E284 - Garage door operating unit
E492 - Tyre pressure monitor display button (T6aj/5)
F4 - Reversing light switch
G65 - High-pressure sender (T3c/3)
G226 -Oil level and oil temperature sender
J255 - Climatronic control unit (T20c/16), (T20c/20)
J301 - Air conditioning system control unit
Y7 - Automatic anti-dazzle interior mirror (T6am/5)
Z20 - Left washer jet heater element (T2t/1)
Z21 - Right washer jet heater element (T2u/1) | 15 |
| 5 | - | SC5 - Fuse 5 on fuse holder | - | - | Vacant | 15 |
| 6 | - | SC6 - Fuse 6 on fuse holder | - | - | Vacant | 15 |
| 7 | - | SC7 - Fuse 7 on fuse holder | - | - | Vacant | 15 |
| 8 | - | SC8 - Fuse 8 on fuse holder | - | - | Vacant | 15 |
| 9 | - | SC9 - Fuse 9 on fuse holder | - | - | Vacant | - |
| 10 | - | SC10 - Fuse 10 on fuse holder | - | - | Vacant | 15 |
| 11 | - | SC11 - Fuse 11 on fuse holder | - | - | Vacant | 15 |
| Jetta | Fitting Locations | No. 803 / 25 |
|
| No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
| 22 | - | SC22 - Fuse 22 on fuse holder | 30A | - | V2 - Rear fresh air blower (T6t/4), Climatronic only | 30 |
| 23 | - | SC23 - Fuse 23 on fuse holder | 30A | - | J386 - Driver door control unit (T20a/20)
J387 - Front passenger door control unit (T20b/20) | 30 |
| 24 | - | SC24 - Fuse 24 on fuse holder | 20A | - | J388 - Rear left door control unit (T18b/11)
J389 - Rear right door control unit (T18c/11)
J393 - Convenience system central control unit (T18/2) | 30 |
| 25 | - | SC25 - Fuse 25 on fuse holder | 25A | - | J485 - Auxiliary heater operation relay
J519 - Onboard power supply control unit (K/6) | 30 |
| 26 | - | SC26 - Fuse 26 on fuse holder | 30A | - | J388 - Rear left door control unit (T18b/10)
J389 - Rear right door control unit (T18c/10) | 30 |
| 27 | - | SC27 - Fuse 27 on fuse holder | 15A | - | J17 - Fuel pump relay, engine codes AZV, BKC, BKD, BLS, BMN, BMM, BLF, BSE , BSF
J49 - Electric fuel pump 2 relay, engine codes BSE, BSF
J538 - Fuel pump control unit, engine codes BLF, BVY, BVZ | 30 |
| 28 | - | SC28 - Fuse 28 on fuse holder | - | - | Vacant | 30 |
| 29 | - | SC29 - Fuse 29 on fuse holder | - | - | Vacant | 15 |
| Jetta | Fitting Locations | No. 803 / 27 |
|
| No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
| 37 | - | SC37 - Fuse 37 on fuse holder | 30A | - | J131 - Heated driver seat control unit
J132 - Heated front passenger seat control unit | 30 |
| 38 | - | SC38 - Fuse 38 on fuse holder | - | - | Vacant | 15 |
| 39 | - | SC39 - Fuse 39 on fuse holder | - | - | Vacant | 15 |
| 40 | - | SC40 - Fuse 40 on fuse holder | 40A | - | J13 - Fresh air blower relay
J301 - Air conditioning system control unit | 75 |
| 41 | - | SC41 - Fuse 41 on fuse holder | 20A | - | J519 - Onboard power supply control unit (J/1)
V5 - Washer pump | - |
| 42 | - | SC42 - Fuse 42 on fuse holder | 20A | - | J29 - Blocking diode
U1 - Cigarette lighter (T3g/2)
U5 - 12 V socket (T3j/2)
U9 - Rear cigarette lighter (T3h/2) | 75 |
| 43 | - | SC43 - Fuse 43 on fuse holder | 15A | - | J345 - Trailer detector control unit | 30 |
| 44 | - | SC44 - Fuse 44 on fuse holder | 20A | - | J345 - Trailer detector control unit | 30 |
| 45 | - | SC45 - Fuse 45 on fuse holder | 15A | - | J345 - Trailer detector control unit | 30 |
| 46 | - | SC46 - Fuse 46 on fuse holder | - | - | Vacant | 75 |
| 47 | - | SC47 - Fuse 47 on fuse holder | - | - | Vacant | 15 |
| 48 | - | SC48 - Fuse 48 on fuse holder | - | - | Vacant | - |
| 49 | - | SC49 - Fuse 49 on fuse holder | - | - | Vacant | 75 |
VW JETTA 2010 Thermal fuse under left dash panel
Thermal fuse under left dash panel | | A - | Driver seat adjustment thermal fuse 1 -S44- 30A |
VW JETTA 2010 Position of fuses, from July 2009
Position of fuses, from July 2009 | | No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
| 1 | - | SC1 - Fuse 1 on fuse holder | 10A | - | E102 - Headlight range control regulator (T8e/1)
G42 - Intake air temperature sender (T5d/2)
G70 - Air mass meter (T5d/5), (T5d/3)
J13 - Fresh air blower relay
J431 - Headlight range control, control unit (T26c/23)
N79-Heater element for crankcase breather
T16 - 16-pin connector, diagnosis connection, under left dash panel
V48 - Left headlight range control motor (T10i/1)
V49 - Right headlight range control motor (T10j/1) | 15 |
| Jetta | Fitting Locations | No. 803 / 31 |
|
| No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
| 3 | - | SC3 - Fuse 3 on fuse holder | 5A | - | J234 - Airbag control unit (T50/1), (T50/31), (T75/1), (T75/26)
K145 - Front passenger side airbag deactivated warning lamp (T4g/3) | 15 |
| 4 | - | SC4 - Fuse 4 on fuse holder | 5A | - | E256 - TCS and ESP button (T6ad/4)
E492 - Tyre pressure monitor display button (T6aj/5)
F4 - Reversing light switch
G65 - High-pressure sender (T3c/3)
G238 - Air quality sensor (T3an/1)
G226 -Oil level and oil temperature sender
J446 - Parking aid control unit (T16m/1)
J530 - Garage door operation control unit
Y7 - Automatic anti-dazzle interior mirror (T6am/1) | 15 |
| 5 | - | SC5 - Fuse 5 on fuse holder | - | - | Vacant | 15 |
| 6 | - | SC6 - Fuse 6 on fuse holder | - | - | Vacant | 15 |
| 7 | - | SC7 - Fuse 7 on fuse holder | - | - | Vacant | 15 |
| 8 | - | SC8 - Fuse 8 on fuse holder | - | - | Vacant | 15 |
| 9 | - | SC9 - Fuse 9 on fuse holder | - | - | Vacant | - |
| 10 | - | SC10 - Fuse 10 on fuse holder | - | - | Vacant | 15 |
| 11 | - | SC11 - Fuse 11 on fuse holder | - | - | Vacant | 15 |
| Jetta | Fitting Locations | No. 803 / 33 |
|
| No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
| 22 | - | SC22 - Fuse 22 on fuse holder | 40A | - | V2 - Rear fresh air blower (T6t/4), Climatronic only | 30 |
| 23 | - | SC23 - Fuse 23 on fuse holder | 30A | - | J386 - Driver door control unit (T20a/20)
J387 - Front passenger door control unit (T20b/20) | 30 |
| 24 | - | SC24 - Fuse 24 on fuse holder | 20A | - | J519 - Onboard power supply control unit (N/42) | 30 |
| 25 | - | SC25 - Fuse 25 on fuse holder | 25A | - | J9 - Heated rear window relay (T9n/2)
J485 - Auxiliary heater operation relay | 30 |
| 26 | - | SC26 - Fuse 26 on fuse holder | 30A | - | J388 - Rear left door control unit (T18b/10)
J389 - Rear right door control unit (T18c/10) | 30 |
| 27 | - | SC27 - Fuse 27 on fuse holder | 15A | - | J17 - Fuel pump relay, engine codes BSE, CCSA, BSF, CAYC, CAYB
J49 - Electric fuel pump 2 relay, engine codes BSE, CCSA, BSF, CAYC, CAYB
J538 - Fuel pump control unit, engine codes CAVD, CAWB, CAXA | 30 |
| 27 | - | SC27 - Fuse 27 on fuse holder | 15A | - | J17 - Fuel pump relay, engine codes BXE, CBDA, CBDB, CEGA
J49 - Electric fuel pump 2 relay, engine codes BXE, CBDA, CBDB, CEGA | 30 |
| 28 | - | SC28 - Fuse 28 on fuse holder | - | - | Vacant | 30 |
| 29 | - | SC29 - Fuse 29 on fuse holder | - | - | Vacant | 15 |
| Jetta | Fitting Locations | No. 803 / 35 |
|
| No. | | Current Flow Diagram designation | Nominal value | | Function/component | Terminal |
| 37 | - | SC37 - Fuse 37 on fuse holder | 30A | - | J774 - Heated front seats control unit (T8v/3) | 30 |
| 38 | - | SC38 - Fuse 38 on fuse holder | - | - | Vacant | 15 |
| 39 | - | SC39 - Fuse 39 on fuse holder | - | - | Vacant | 15 |
| 40 | - | SC40 - Fuse 40 on fuse holder | 40A | - | J13 - Fresh air blower relay
J301 - Air conditioning system control unit (T5/5) | 75 |
| 41 | - | SC41 - Fuse 41 on fuse holder | 20A | - | Vacant | - |
| 42 | - | SC42 - Fuse 42 on fuse holder | 20A | - | J29 - Blocking diode
U1 - Cigarette lighter (T3g/2)
U5 - 12 V socket (T3j/2) | 75 |
| 43 | - | SC43 - Fuse 43 on fuse holder | 15A | - | J345 - Trailer detector control unit (T12h/9) | 30 |
| 44 | - | SC44 - Fuse 44 on fuse holder | 20A | - | J345 - Trailer detector control unit (T12h/11) | 30 |
| 45 | - | SC45 - Fuse 45 on fuse holder | 15A | - | J345 - Trailer detector control unit (T12h/12) | 30 |
| 46 | - | SC46 - Fuse 46 on fuse holder | - | - | Vacant | 75 |
| 47 | - | SC47 - Fuse 47 on fuse holder | - | - | Vacant | 15 |
| 48 | - | SC48 - Fuse 48 on fuse holder | - | - | Vacant | - |
| 49 | - | SC49 - Fuse 49 on fuse holder | - | - | Vacant | 75 |
VW JETTA 2010 Thermal fuse under left dash panel
Thermal fuse under left dash panel | | A - | Driver seat adjustment thermal fuse 1 -S44- 30A |
Čeština
Dansk
Deutsch
Ελληνικά
English
Español
Suomi
Français
Français
עברית
Hrvatski
Magyar
Italiano
日本語
한국어
Nederlands
Polski
Português
Português
Română
Русский
Slovenčina
Slovenščina
Svenska
Türkçe
中文 (中国)
