VW GOLF CABRIOLET 2014

Wiring Diagram VW GOLF CABRIOLET 2014 - Convertible roof actuation button - Central switch for window regulators - Convertible roof actuation control unit - Convertible roof actuation hydraulic pump

Get access to all wiring diagrams of the car

E137	Convertible roof actuation button
E643	Central switch for window regulators
J256	Convertible roof actuation control unit
J386	Driver door control unit
L76	Button illumination bulb
SB28	Fuse 28 on fuse holder B
SC33	Fuse 33 on fuse holder C
SB54	Fuse 54 on fuse holder B
T2cd	2-pin connector
T10aj	10-pin connector
T12ad	12-pin connector
T20o	20-pin connector
T28	28-pin connector, in left A-pillar coupling station
T32a	32-pin connector
T40	40-pin connector
V118	Convertible roof actuation hydraulic pump

366	Earth connection 1, in main wiring harness
388	Earth connection 23, in main wiring harness

B340	Connection 1 (58d), in main wiring harness
*	E-box high
*2	E-box low
*3	Only left-hand drive models
*4	Only right-hand drive models
*5	From May 2012
*6	Only models with no start/stop system
*7	Only models with start/stop system
*8	Up to April 2012
*9	From May 2013
*10	Up to April 2013

Wiring Diagram VW GOLF CABRIOLET 2014 - Left latch switch for convertible roof - Right latch switch for convertible roof - Convertible roof latch open switch - Convertible roof latch closed switch - Convertible roof actuation control unit

Get access to all wiring diagrams of the car

F169	Left latch switch for convertible roof
F170	Right latch switch for convertible roof
F294	Convertible roof latch open switch
F295	Convertible roof latch closed switch
J256	Convertible roof actuation control unit
T2cg	2-pin connector
T2ch	2-pin connector
T4cn	4-pin connector
T4cp	4-pin connector
T10ak	10-pin connector
T20o	20-pin connector
197	Earth connection 4, in rear wiring harness
202	Earth connection, in convertible roof wiring harness

Wiring Diagram VW GOLF CABRIOLET 2014 - Convertible roof stowed switch - Convertible roof front switch - Convertible roof actuation control unit - Data bus diagnostic interface - Convertible roof lock motor

Get access to all wiring diagrams of the car

F171	Convertible roof stowed switch
F202	Convertible roof front switch
J256	Convertible roof actuation control unit
J519	Onboard supply control unit
J533	Data bus diagnostic interface
T10aj	10-pin connector
T10ak	10-pin connector
T16	16-pin connector
T20	20-pin connector
T20o	20-pin connector
T52b	52-pin connector
T52c	52-pin connector
V223	Convertible roof lock motor
202	Earth connection, in convertible roof wiring harness
B397	Connection 1 (convenience CAN bus, high), in main wiring harness
B406	Connection 1 (convenience CAN bus, low), in main wiring harness
*	Diagnostic connection
*2	From May 2012
*3	Up to April 2012

VW GOLF CABRIOLET 2014 Overview of control units

Overview of control units

Get access to all wiring diagrams of the car

q	Connector assignment

6 -	Mobile telephone operating electronics control unit -J412-

q	Only models with multimedia socket MEDIA-IN

q	Fitting location and / assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

q	Connector assignment

VW GOLF CABRIOLET 2014 Emergency call module control unit and communication unit J949

Emergency call module control unit and communication unit -J949-

Fitting location:

under seat on front right

VW GOLF CABRIOLET 2014 Emergency call module control unit and communication unit J949

Get access to all wiring diagrams of the car

1 -	Emergency call module control unit and communication unit -J949-

A -	26-pin connector -T26i, schwarz-

B -	Aerial connection

VW GOLF CABRIOLET 2014 Remote control receiver for auxiliary coolant heater R149

Remote control receiver for auxiliary coolant heater -R149-

Fitting location: under seat on front right

Get access to all wiring diagrams of the car

1 -	Remote control receiver for auxiliary coolant heater -R149-

A -	Connector -Antenne-

B -	6-pin connector -T6j-

Back to overview

VW GOLF CABRIOLET 2014 Aerial filter R87

Aerial filter -R87-

Fitting location: under seat on front right

Get access to all wiring diagrams of the car

1 -	Aerial filter -R87-

A -	Connector -Antenne-

B -	Connector -Antenne-

C -	Connector -Antenne-

Back to overview

VW GOLF CABRIOLET 2014 Mobile telephone operating electronics control unit J412

Mobile telephone operating electronics control unit -J412-

Note

Only models with no multimedia socket MEDIA-IN

Fitting location: under seat on front right

VW GOLF CABRIOLET 2014 Mobile telephone operating electronics control unit J412

Get access to all wiring diagrams of the car

1 -	Mobile telephone operating electronics control unit -J412-

A -	54-pin connector -T54-

B -	Connector -Antenne-

Back to overview

VW GOLF CABRIOLET 2014 Multimedia system control unit J650

Multimedia system control unit -J650-

Fitting location: under centre armrest, front

Get access to all wiring diagrams of the car

1 -	Multimedia system control unit -J650-

A -	12-pin connector -T12t-

Back to overview

VW GOLF CABRIOLET 2014 Mobile telephone operating electronics control unit J412

Mobile telephone operating electronics control unit -J412-

Note

Only models with multimedia socket MEDIA-IN

Fitting location: under centre armrest, front

Get access to all wiring diagrams of the car

1 -	Mobile telephone operating electronics control unit -J412-

A -	54-pin connector -T54b-

Back to overview

VW GOLF CABRIOLET 2014 Heated front seats control unit J774

Heated front seats control unit -J774-

Fitting location:

under seat pan -arrow-

Left-hand drive models: under driver seat

Right-hand drive models: under front passenger seat

VW GOLF CABRIOLET 2014 Heated front seats control unit J774

Get access to all wiring diagrams of the car

Connector assignment:

Get access to all wiring diagrams of the car

1 -	Heated front seats control unit -J774-

A -	8-pin connector -T8z- on wiring harness

Back to overview

VW GOLF CABRIOLET 2014 Rear right window regulator motor V27

Rear right window regulator motor -V27-

Get access to all wiring diagrams of the car

A -	Rear right window regulator motor -V27-

Connector:

B -	18-pin connector -T18a- on wiring harness

Back to overview

VW GOLF CABRIOLET 2014 Fuel pump control unit J538

Fuel pump control unit -J538-

Get access to all wiring diagrams of the car

-	Under right rear seat, -auf der Kraftstofffördereinheit-

-	10-pin connector -T10n- , on wiring harness

Back to overview

VW GOLF CABRIOLET 2014 Electronically controlled damping control unit J250

Electronically controlled damping control unit -J250-

Fitting location:

in rear right side panel -arrow-

VW GOLF CABRIOLET 2014 Electronically controlled damping control unit J250

Get access to all wiring diagrams of the car

Electronically controlled damping control unit -J250-

Get access to all wiring diagrams of the car

1 -	Electronically controlled damping control unit -J250-

A -	47-pin connector -T47d- , on wiring harness

Back to overview

VW GOLF CABRIOLET 2014 Trailer detector control unit J345

Trailer detector control unit -J345-

Fitting location:

in rear right side panel -arrow-

VW GOLF CABRIOLET 2014 Trailer detector control unit J345

Get access to all wiring diagrams of the car

Connector assignment:

Get access to all wiring diagrams of the car

A -	Trailer detector control unit -J345-

Connector:

B -	16-pin connector -T16i- , on wiring harness

C -	12-pin connector -T12h- , on wiring harness

Back to overview

VW GOLF CABRIOLET 2014 Blind spot monitor control unit J1086

Blind spot monitor control unit -J1086-

Fitting location:

behind rear bumper on right

VW GOLF CABRIOLET 2014 Blind spot monitor control unit J1086

Get access to all wiring diagrams of the car

1 -	Blind spot monitor control unit -J1086-

A -	8-pin connector -T8ap, schwarz-

Connector assignment

Blind spot monitor control unit -J1086-

-T8ap- (A)	Designation
1
2
3	Data bus diagnostic interface -J533- (can-h)
4	Data bus diagnostic interface -J533- (can-l)
5	Terminal 31
6	CAN bus (can-h)
7	CAN bus (can-l)
8	Terminal 15

Back to overview

VW GOLF CABRIOLET 2014 Blind spot monitor control unit 2 J1087

Blind spot monitor control unit 2 -J1087-

Fitting location:

behind rear bumper on left

VW GOLF CABRIOLET 2014 Blind spot monitor control unit 2 J1087

Get access to all wiring diagrams of the car

1 -	Blind spot monitor control unit 2 -J1087-

A -	8-pin connector -T8ao, schwarz-

Connector assignment

Blind spot monitor control unit 2 -J1087-

-T8ao- (A)	Designation
1
2
3	Blind Spot Monitor warning lamp in right exterior mirror -K304- (+)
4	Blind Spot Monitor warning lamp in left exterior mirror -K303- (+)
5	Terminal 31
6	CAN bus (can-h)
7	CAN bus (can-l)
8	Terminal 15

Back to overview

VW GOLF CABRIOLET 2014 Convertible roof actuation control unit J256

Convertible roof actuation control unit -J256-

1 -	Convertible roof actuation control unit -J256-

2 -	Convertible roof actuation hydraulic pump -V118-

3 -	10-pin connector -T10ak-

Fitting location:

in rear left side panel -1-

Back to overview

VW GOLF CABRIOLET 2014 Convertible roof actuation control unit J256

Get access to all wiring diagrams of the car

VW GOLF CABRIOLET 2014 Rear left window regulator motor V26

Rear left window regulator motor -V26-

Get access to all wiring diagrams of the car

A -	Rear left window regulator motor -V26-

B -	18-pin connector -T18-

Back to overview

VW GOLF CABRIOLET 2014 Amplifier R12

Amplifier -R12-

Fitting location: under seat on front left

Get access to all wiring diagrams of the car

-	Amplifier -R12-

A -	24-pin connector -T24-

B -	23-pin connector -T23-

Back to overview

VW GOLF CABRIOLET 2014 Overview of control units

Overview of control units

Get access to all wiring diagrams of the car

-	Main beam assist control unit -J844-

-	Control unit in dash panel insert -J285-

q	Connector assignment of 52-pin connector -T52 A--black-

q	Connector assignment of 52-pin connector -T52 B--white-

q	Connector assignment of 52-pin connector -T52 C--brown-

q	Connector assignment from November 2011

q	Connector assignment from November 2014

q	Connector assignment from November 2011

q	Connector assignment from November 2014

q	Connector assignment

VW GOLF CABRIOLET 2014 Auxiliary heater control unit J364

Auxiliary heater control unit -J364-

Fitting location:

under front bumper on right

VW GOLF CABRIOLET 2014 Auxiliary heater control unit J364

Get access to all wiring diagrams of the car

1 -	Auxiliary heater control unit -J364-

A -	8-pin connector -T8f-

B -	2-pin connector -T2g-

Back to overview

VW GOLF CABRIOLET 2014 Airbag control unit J234

Airbag control unit -J234-

Fitting location:

under centre console, front

VW GOLF CABRIOLET 2014 Airbag control unit J234

Get access to all wiring diagrams of the car

1 -	Airbag control unit -J234-

A -	100-pin connector -T100-

Back to overview

VW GOLF CABRIOLET 2014 Control unit for cornering light and headlight range control J745

Control unit for cornering light and headlight range control -J745-

Fitting location:

Left-hand drive models: on right of glove compartment

Right-hand drive models: on left of glove compartment

Note

Figure shows left-hand drive model. The view for a RHD model is basically a mirror image.

VW GOLF CABRIOLET 2014 Control unit for cornering light and headlight range control J745

Get access to all wiring diagrams of the car

1 -	Control unit for cornering light and headlight range control -J745-

A -	26-pin connector -T26h-

Back to overview

VW GOLF CABRIOLET 2014 Voltage stabiliser J532

Voltage stabiliser -J532-

Fitting location:

Left-hand drive models: on left under dash panel, near onboard supply control unit

Right-hand drive models: on right under dash panel, near onboard supply control unit

Note

Figure shows left-hand drive model. The view for a RHD model is basically a mirror image.

VW GOLF CABRIOLET 2014 Voltage stabiliser J532

Get access to all wiring diagrams of the car

1 -	Voltage stabiliser -J532-

2 -	12-pin connector -T12ac-

Back to overview

VW GOLF CABRIOLET 2014 Fresh air blower control unit J126

Fresh air blower control unit -J126-

Fitting location:

on heater and air conditioner unit, front passenger footwell

VW GOLF CABRIOLET 2014 Fresh air blower control unit J126

Get access to all wiring diagrams of the car

1 -	Fresh air blower control unit -J126-

A -	2-pin connector -T2-

B -	6-pin connector -T6t-

Back to overview

VW GOLF CABRIOLET 2014 Front passenger door control unit J387

Front passenger door control unit -J387-

Fitting location:

behind door trim -arrow-

Left-hand drive models: behind front right door trim

Right-hand drive models: behind front left door trim

Note

Figure shows left-hand drive model. The view for a RHD model is basically a mirror image.

VW GOLF CABRIOLET 2014 Front passenger door control unit J387

Get access to all wiring diagrams of the car

1 -	Front passenger door control unit -J387-

A -	32-pin connector -T32b-

B -	16-pin connector -T16g-

C -	20-pin connector -T20b-

Back to overview

Light sensor -G399- / main beam assist control unit -J844- / automatic anti-dazzle interior mirror -Y7-

Fitting location:

on front of interior mirror

Get access to all wiring diagrams of the car

1 -	Light sensor -G399-

-	Main beam assist control unit -J844-

-	Automatic anti-dazzle interior mirror -Y7-

A -	8-pin connector -T8ak-

Back to overview

VW GOLF CABRIOLET 2014 Data bus diagnostic interface J533

Data bus diagnostic interface -J533-

Fitting location:

Left-hand drive models: on left under dash panel, near centre console

Right-hand drive models: on right under dash panel, near onboard supply control unit -J519-

Note

Figure shows left-hand drive model. The view for a RHD model is basically a mirror image.

VW GOLF CABRIOLET 2014 Data bus diagnostic interface J533

Get access to all wiring diagrams of the car

1 -	Data bus diagnostic interface -J533-

A -	20-pin connector -T20-

Back to overview

VW GOLF CABRIOLET 2014 Driver door control unit J386

Driver door control unit -J386-

Fitting location:

behind door trim -arrow-

Left-hand drive models: behind front left door trim

Right-hand drive models: behind front right door trim

Note

Figure shows left-hand drive model. The view for a RHD model is basically a mirror image.

VW GOLF CABRIOLET 2014 Driver door control unit J386

Get access to all wiring diagrams of the car

1 -	Driver door control unit -J386-

A -	32-pin connector -T32a-

B -	16-pin connector -T16a-

C -	20-pin connector -T20a-

Back to overview

VW GOLF CABRIOLET 2014 Steering column electronics control unit J527

Steering column electronics control unit -J527-

Get access to all wiring diagrams of the car

1 -	Steering column electronics control unit -J527-

Fitting location:

q	at top of steering column

Connectors:

q	-A-16-pin connector -T16r-

q	-B-4-pin connector -T4k-

Connector assignment -T16r-

1 -	Terminal -30a-

2 -	Terminal -31-

3 -	Connection 1 (convenience CAN bus, low), in main wiring harness -B406-

4 -	Connection 1 (convenience CAN bus, high), in main wiring harness -B397-

5 -	Engine control unit -J623- (CCS)

6 -	Engine control unit -J623- , models with start/stop system, (terminal 50)

-	Onboard supply control unit -J519- , models with no start/stop system, (terminal 50)

7 -

8 -

9 -

10 -

11 -	Selector lever locked in position P switch -F319-

12 -	Connection 1 (powertrain CAN bus, low), in main wiring harness -B390-

13 -	Connection 6 (powertrain CAN bus, high), in main wiring harness -B388-

14 -	Terminal -15a-

15 -

16 -

Connector assignment -T4k-

1 -	Airbag control unit -J234- +

2 -	Airbag control unit -J234- -

3 -

4 -

Back to overview

VW GOLF CABRIOLET 2014

Dash panel insert -K- / control unit in dash panel insert -J285- / immobiliser control unit -J362-

Get access to all wiring diagrams of the car

1 -	Dash panel insert -K-

Connector assignment:

q	-A-32-pin connector -T32-

Connector assignment -T32-

1 -	Fuel gauge sender -G- (full), fuel pump control unit -J538-

2 -	Fuel gauge sender -G- (empty), fuel pump control unit -J538-

3 -

4 -

5 -

6 -

7 -	Immobiliser reader coil -D2-

8 -	Immobiliser reader coil -D2-

9 -	Output for speed signal

10 -

11 -	Oil level and oil temperature sender -G266-

12 -

13 -

14 -

15 -	Front left brake pad wear sender -G34-

16 -	Terminal 31

17 -	Windscreen washer fluid level sender -G33-

18 -	Coolant shortage indicator sender -G32-

19 -	Ambient temperature sensor -G17-

20 -	Earth connection 1 (sender earth) in main wiring harness -410-

21 -

22 -

23 -

24 -

25 -	Handbrake warning switch -F9-

26 -	Brake fluid level warning contact -F34-

27 -	Oil pressure switch -F1-

28 -	Data bus diagnostic interface -J533- (CAN bus, high)

29 -	Data bus diagnostic interface -J533- (CAN bus, low)

30 -

31 -	Terminal 15a

32 -	Terminal 30a

Back to overview

VW GOLF CABRIOLET 2014 Onboard supply control unit J519

52-pin connector -T52 B- black -A-

Get access to all wiring diagrams of the car

1 -	Terminal 30a

2 -

3 -	Luggage compartment light -W3- (from November 2011)

4 -	Left washer jet heater element -Z20-

-	Right washer jet heater element -Z21-

5 -	Left headlight main beam bulb -M30-

-	Front left headlight -MX1-

-	Output module for left headlight -J667- (from November 2011)

6 -	Front left headlight -MX1-

-	Control unit for left daytime running light and side light -J860-

-	Left daytime running light bulb -L174-

7 -

8 -

9 -	Rear right turn signal bulb -M8-

10 -	Front left turn signal bulb -M5-

11 -	Front left headlight -MX1-

-	Left gas discharge bulb control unit -J343-

-	Left gas discharge (xenon) bulb -L13-

-	Left headlight dipped beam bulb -M29-

12 -

13 -	Rear lid handle release button -E234-

14 -	Bonnet contact switch -F266-

15 -

16 -	Reversing light switch -F4-

17 -	Rear fog light switch -E18-

18 -	Light switch -E1- Daytime running light

19 -	Light switch -E1- Side light terminal 58

20 -	Light switch -E1- Driving light assist

21 -	Fog light switch -E7-

22 -	Light switch -E1- Dipped beam terminal 56

23 -	Terminal 31

24 -	Terminal 30a

25 -	Left fog light bulb -L22-

-	Left cornering light bulb -L148-

26 -	Right brake and tail light bulb -M22-

27 -	Left tail light bulb -M4- (left-hand drive models)

-	Right tail light bulb -M2- (right-hand drive models)

28 -	Front right headlight -MX2-

-	Control unit for right daytime running light and side light -J861-

-	Right daytime running light bulb -L175-

-	Right LED module for daytime running light and side light -L177-

29 -	Rear lid lock unit -F256-

30 -

31 -

32 -

33 -

34 -

35 -	Heater/heat output switch -E16-

36 -	Interior monitoring deactivation switch -E267-

37 -

38 -

39 -

40 -

41 -

42 -	Terminal 31

43 -	Windscreen and rear window washer pump -V59-

44 -	Right side light bulb -M3-

45 -	High-level brake light bulb -M25-

46 -	Tank filler flap locking motor -V155-

47 -

48 -

49 -

50 -

51 -

52 -

Back to overview

52-pin connector -T52 B- white-B-

Get access to all wiring diagrams of the car

1 -	Terminal 30a

2 -	Windscreen and rear window washer pump -V59-

3 -

4 -

5 -	Tank filler flap locking motor -V155-

6 -

7 -

8 -

9 -

10 -

11 -	Rear lid release motor -V139-

12 -	Terminal 15 voltage supply relay -J329-

13 -

14 -	Heater/heat output switch -E16-

-	Heated rear window warning lamp -K10-

15 -	Switch and instrument illumination regulator -E20-

16 -

17 -

18 -

19 -

20 -

21 -	Heated front seats control unit -J774-

22 -	Heated rear window relay -J9-

23 -

24 -	Indicator lamp for hazard warning light -K6-

25 -

26 -

27 -

28 -	X-contact relief relay -J59-

29 -	Engine control unit -J623- (vehicles with no start/stop system)

-	Terminal 50 voltage supply relay -J682- (vehicles with no start/stop system)

30 -	Switch and instrument illumination regulator -E20-

31 -

32 -

33 -	Wiper motor control unit -J400-

-	Rain and light sensor -G397- LIN bus

34 -

35 -

36 -	Interior monitoring sensor -G273- (LIN)

-	Vehicle inclination sender -G384- (LIN)

-	Anti-theft alarm sensor -G578- (LIN)

-	Alarm horn -H12-

37 -	Interior monitoring off warning lamp -K162-

38 -	Fuel pump control unit -J538-

-	Fuel supply relay -J643-

39 -

40 -	Headlight washer system relay -J39-

41 -	Dual tone horn relay -J4-

42 -	Terminal 30a

43 -	Positive connection 1 (30g), in main wiring harness -B559-

44 -

45 -

46 -

47 -

48 -

49 -

50 -	Left footwell light -W9-

-	Right footwell light -W10-

51 -	Terminal 58d

52 -	Terminal 31

Back to overview

52-pin connector -T52 C- brown -C-

Get access to all wiring diagrams of the car

1 -

2 -

3 -	Right tail light bulb -M2-

4 -	Left brake and tail light bulb -M21-

5 -	Terminal 31

6 -

7 -	Hazard warning lights button -E229-

8 -

9 -

10 -	Front interior light -W1- Terminal TK

11 -

12 -

13 -	Terminal 15a

14 -	Terminal 15a

15 -	Connection 1 (convenience CAN bus, high), in main wiring harness -B397-

-	Data bus diagnostic interface -J533-

16 -	Connection 1 (convenience CAN bus, low), in main wiring harness -B407-

-	Data bus diagnostic interface -J533-

17 -	Brake light switch -F-

18 -

19 -

20 -

21 -

22 -

23 -

24 -

25 -	Right fog light bulb -L23-

-	Right cornering light bulb -L149-

26 -	Front left headlight -MX1-

-	Left side light bulb -M1-

-	Control unit for left daytime running light and side light -J860-

-	Left LED module for daytime running light and side light -L176-

27 -	Left number plate light -X4-

-	Right number plate light -X5-

28 -	Connection (RL), in dash panel wiring harness -A87-

-	Right reversing light bulb -E234-

-	Left reversing light bulb -M16-

-	Right reversing light bulb -M17-

-	Reversing camera -R189-

29 -

30 -	Clutch position sender -G476-

-	Mechatronic unit for dual clutch gearbox -J743-

-	Terminal 31 (models with start/stop system)

31 -	Terminal 15a

32 -	Connection (61), in interior wiring harness -B177-

-	Alternator -C-

-	Heater/heat output switch -E16- (models with start/stop system)

33 -

34 -	Voltage stabiliser -J532- (models with start/stop system)

-	Starter relay 2 -J907- (models with start/stop system)

-	Engine control unit -J623- (models with start/stop system)

35 -	Switch and instrument illumination regulator -E20-

36 -

37 -

38 -

39 -

40 -

41 -

42 -	Terminal 15a

43 -

44 -

45 -

46 -	Front right headlight -MX2-

-	Output module for right headlight -J668- (from November 2011)

-	Right headlight main beam bulb -M32-

47 -	Rear left fog light bulb -L46-

-	Rear right fog light bulb -L47-

48 -	Front left headlight -MX1-

-	Output module for left headlight -J667- (up to October 2011)

49 -	Front right headlight -MX2- (up to October 2011)

-	Output module for right headlight -J668- (up to October 2011)

50 -	Front right headlight -MX2-

-	Front right turn signal bulb -M7-

51 -	Rear left turn signal bulb -M6-

52 -	Right gas discharge bulb control unit -J344-

-	Right gas discharge (xenon) bulb -L14-

-	Right headlight dipped beam bulb -M31-

Back to overview

VW GOLF CABRIOLET 2014 Parking aid control unit J446

Parking aid control unit -J446-

Fitting location:

Left-hand drive models: on left under dash panel, behind relay carrier above onboard supply control unit

Right-hand drive models: on right under dash panel, behind relay carrier above onboard supply control unit

1 -	Connectors on parking aid control unit -J446-

2 -	Onboard supply control unit -J519-

3 -	Securing bolt

VW GOLF CABRIOLET 2014 Parking aid control unit J446

Get access to all wiring diagrams of the car

Connector assignment, from November 2011

Get access to all wiring diagrams of the car

A -	Parking aid control unit -J446-

Connector assignment:

B -	16-pin connector -T16m-

Connector assignment:

1 -	Positive connection 8 (15a) in dash panel wiring harness -A217-

2 -	Rear parking aid warning buzzer -H15-

3 -

4 -	Parking aid button -E266-

5 -

6 -	Data bus diagnostic interface -J533-Connection 1 (powertrain CAN bus, high), in main wiring harness -B383-

7 -

8 -	Terminal 31

9 -

10 -	Rear parking aid warning buzzer -H15-

11 -

12 -

13 -	Parking aid warning lamp -K136-

14 -

15 -	Data bus diagnostic interface -J533-

-	Connection 1 (powertrain CAN bus, low), in main wiring harness -B390-

16 -

C -	12-pin connector -T12v-

Connector assignment:

1 -	Voltage supply sender negative

2 -	Voltage supply sender positive

3 -	Front parking aid warning buzzer -H22-

4 -	Front parking aid warning buzzer -H22-

5 -	Front left parking aid sender -G255-

6 -	Front centre left parking aid sender -G254-

7 -	Front centre right parking aid sender -G253-

8 -	Front right parking aid sender -G252-

9 -

10 -

11 -

12 -

D -	12-pin connector -T12n-

Connector assignment:

1 -

2 -	Rear centre right parking aid sender -G205-

3 -	Rear centre left parking aid sender -G204-

4 -	Rear right parking aid sender -G206-

5 -	Rear left parking aid sender -G203-

6 -

7 -

8 -	Voltage supply sender negative

9 -

10 -

11 -	Voltage supply sender positive

12 -

Back to overview

Connector assignment, from November 2014

Get access to all wiring diagrams of the car

1 -	Parking aid control unit -J446-

Connector assignment:

A -	18-pin connector -T18i- , black

B -	26-pin connector -T26k- , black

Connector assignment of parking aid control unit -J446-

-T18i- (A)	Designation	-T26k- (B)	Designation
1		1
2		2	Front parking aid warning buzzer -H22- (+)
3	Front centre left parking aid sender -G254- , signal	3	Park assist steering button -E581-
4	Front right parking aid sender -G252- , signal	4	Warning light for park assist steering -K241-
5		5
6		6	Rear left parking aid sender -G203- , signal
7		7	Rear centre right parking aid sender -G205- , signal
8		8	Rear right park assist steering sender -G717- , signal
9		9	Rear parking aid warning buzzer -H15- (-)
10	Front right parking aid sender -G252- (GND) Front centre right parking aid sender -G253- (GND) Front centre left parking aid sender -G254- (GND) Front left parking aid sender -G255- (GND)	10	Front parking aid warning buzzer -H22- (-)
11	Front left parking aid sender -G255- , signal	11
12	Front centre right parking aid sender -G253- , signal	12
13		13	Terminal 31
14	Front right parking aid sender -G252- (U+) Front centre right parking aid sender -G253- (U+) Front centre left parking aid sender -G254- (U+) Front left parking aid sender -G255- (U+)	14	Terminal 15
15		15	Rear parking aid warning buzzer -H15- (+)
16		16	Parking aid button -E266-
17		17	Parking aid warning lamp -K136-
18		18	Rear left parking aid sender -G203- (U+) Rear centre left parking aid sender -G204- (U+) Rear centre right parking aid sender -G205- (U+) Rear right parking aid sender -G206- (U+)
		19
		20	Rear centre left parking aid sender -G204- , signal
		21	Rear right parking aid sender -G206- , signal
		22	Rear left parking aid sender -G203- (GND) Rear centre left parking aid sender -G204- (GND) Rear centre right parking aid sender -G205- (GND) Rear right parking aid sender -G206- (GND)
		23	B390 Connection 1 (powertrain CAN bus, low), in main wiring harness
		24	B383 Connection 1 (powertrain CAN bus, high), in main wiring harness
		25
		26

Back to overview

VW GOLF CABRIOLET 2014 Park assist steering control unit J791

Park assist steering control unit -J791-

Fitting location:

Left-hand drive models: on left under dash panel, behind relay carrier above onboard supply control unit

Right-hand drive models: on right under dash panel, behind relay carrier above onboard supply control unit

1 -	Connectors on park assist steering control unit -J791-

2 -	Onboard supply control unit -J519-

3 -	Securing bolt

VW GOLF CABRIOLET 2014 Park assist steering control unit J791

Get access to all wiring diagrams of the car

Connector assignment, from November 2011

Get access to all wiring diagrams of the car

A -	Park assist steering control unit -J791-

Connector assignment:

B -	16-pin connector -T16m-

Connector assignment:

1 -	Positive connection 8 (15a) in dash panel wiring harness -A217-

2 -	Rear parking aid warning buzzer -H15-

3 -

4 -	Parking aid button -E266-

5 -

6 -	Data bus diagnostic interface -J533-Connection 1 (powertrain CAN bus, high), in main wiring harness -B383-

7 -

8 -	Terminal 31

9 -	Warning light for park assist steering -K241-

10 -	Rear parking aid warning buzzer -H15-

11 -

12 -

13 -	Parking aid warning lamp -K136-

14 -

15 -	Data bus diagnostic interface -J533-

-	Connection 1 (powertrain CAN bus, low), in main wiring harness -B390-

16 -	Park assist steering button -E581-

C -	12-pin connector -T12v-

Connector assignment:

1 -	Voltage supply sender negative

2 -	Voltage supply sender positive

3 -	Front parking aid warning buzzer -H22-

4 -	Front parking aid warning buzzer -H22-

5 -	Front left parking aid sender -G255-

6 -	Front centre left parking aid sender -G254-

7 -	Front centre right parking aid sender -G253-

8 -	Front right parking aid sender -G252-

9 -	Front left sender for park assist steering on left side of vehicle -G568-

10 -	Front right sender for park assist steering on right side of vehicle -G569-

11 -

12 -

D -	12-pin connector -T12n-

Connector assignment:

1 -

2 -	Rear centre right parking aid sender -G205-

3 -	Rear centre left parking aid sender -G204-

4 -	Rear right parking aid sender -G206-

5 -	Rear left parking aid sender -G203-

6 -	Rear right park assist steering sender -G717-

7 -

8 -	Voltage supply sender negative

9 -

10 -	Rear left park assist steering sender -G716-

11 -	Voltage supply sender positive

12 -

Back to overview

Connector assignment, from November 2014

Get access to all wiring diagrams of the car

1 -	Park assist steering control unit -J791-

Connector assignment:

A -	18-pin connector -T18i- , black

B -	26-pin connector -T26k- , black

Connector assignment of park assist steering control unit -J791-

-T18i- (A)	Designation	-T26k- (B)	Designation
1		1
2	Front left sender for park assist steering on left side of vehicle -G568- , signal	2	Front parking aid warning buzzer -H22- (+)
3	Front centre left parking aid sender -G254- , signal	3	Park assist steering button -E581-
4	Front right parking aid sender -G252- , signal	4	Warning light for park assist steering -K241-
5		5
6		6	Rear left parking aid sender -G203- , signal
7		7	Rear centre right parking aid sender -G205- , signal
8		8	Rear right park assist steering sender -G717- , signal
9		9	Rear parking aid warning buzzer -H15- (-)
10	Front right parking aid sender -G252- (GND) Front centre right parking aid sender -G253- (GND) Front centre left parking aid sender -G254- (GND) Front left parking aid sender -G255- (GND) Front left sender for park assist steering on left side of vehicle -G568- (GND) Front right sender for park assist steering on right side of vehicle -G569- (GND)	10	Front parking aid warning buzzer -H22- (-)
11	Front left parking aid sender -G255- , signal	11
12	Front centre right parking aid sender -G253- , signal	12
13	Front right sender for park assist steering on right side of vehicle -G569- , signal	13	Terminal 31
14	Front right parking aid sender -G252- (U+) Front centre right parking aid sender -G253- (U+) Front centre left parking aid sender -G254- (U+) Front left parking aid sender -G255- (U+) Front left sender for park assist steering on left side of vehicle -G568- (U+) Front right sender for park assist steering on right side of vehicle -G569- (U+)	14	Terminal 15
15		15	Rear parking aid warning buzzer -H15- (+)
16		16	Parking aid button -E266-
17		17	Parking aid warning lamp -K136-
18		18	Rear left parking aid sender -G203- (U+) Rear centre left parking aid sender -G204- (U+) Rear centre right parking aid sender -G205- (U+) Rear right parking aid sender -G206- (U+) Rear left park assist steering sender -G716- (U+) Rear right park assist steering sender -G717- (U+)
		19	Rear left park assist steering sender -G716- , signal
		20	Rear centre left parking aid sender -G204- , signal
		21	Rear right parking aid sender -G206- , signal
		22	Rear left parking aid sender -G203- (GND) Rear centre left parking aid sender -G204- (GND) Rear centre right parking aid sender -G205- (GND) Rear right parking aid sender -G206- (GND) Rear left park assist steering sender -G716- (GND) Rear right park assist steering sender -G717- (GND)
		23	B390 Connection 1 (powertrain CAN bus, low), in main wiring harness
		24	B383 Connection 1 (powertrain CAN bus, high), in main wiring harness
		25
		26

Back to overview

VW GOLF CABRIOLET 2014 Battery monitoring control unit J367

Battery monitoring control unit -J367-

Fitting location:

on negative battery terminal

Note

Only models with start/stop system

VW GOLF CABRIOLET 2014 Battery monitoring control unit J367

Get access to all wiring diagrams of the car

1 -	Battery monitoring control unit -J367-

A -	2-pin connector -T2bn-

Back to overview

VW GOLF CABRIOLET 2014 Mechatronic unit for dual clutch gearbox J743

Mechatronic unit for dual clutch gearbox -J743-

Fitting location:

in gearbox

Note

Figure shows model with dual clutch gearbox 02E.

VW GOLF CABRIOLET 2014 Mechatronic unit for dual clutch gearbox J743

Get access to all wiring diagrams of the car

1 -	Mechatronic unit for dual clutch gearbox -J743-

A -	20-pin connector -T20e-

-	25-pin connector -T25- , model with dual clutch gearbox 0AM

Back to overview

VW GOLF CABRIOLET 2014 Radiator fan control unit J293

Radiator fan control unit -J293-

Get access to all wiring diagrams of the car

1 -	Radiator fan control unit -J293-

Connector:

q	-A-4-pin connector -T4x- on wiring harness

q	-B-4-pin connector -T4x- on radiator fan

Back to overview

VW GOLF CABRIOLET 2014 Power steering control unit J500

Power steering control unit -J500-

Fitting location:

on front axle carrier -arrow-

VW GOLF CABRIOLET 2014 Power steering control unit J500

Get access to all wiring diagrams of the car

Connector assignment:

Get access to all wiring diagrams of the car

A -	Power steering control unit -J500-

Connectors:

B -	2-pin connector -T2a- on wiring harness

C -	3-pin connector -T3bq- on wiring harness

D -	5-pin connector -T5g- on wiring harness

Back to overview

VW GOLF CABRIOLET 2014 Engine control unit J623

Engine control unit -J623-

Fitting location:

central in plenum chamber

VW GOLF CABRIOLET 2014 Engine control unit J623

Get access to all wiring diagrams of the car

-	Engine control unit -J623--Arrow-

A -	94-pin connector -T94-

B -	60-pin connector -T60-

Back to overview

VW GOLF CABRIOLET 2014 ABS control unit J104

ABS control unit -J104-

Fitting location:

Left-hand drive models: on plenum chamber bulkhead on right in engine compartment

Right-hand drive models: on plenum chamber bulkhead on left in engine compartment

Note

Figure shows left-hand drive model. The view for a RHD model is basically a mirror image.

VW GOLF CABRIOLET 2014 ABS control unit J104

Get access to all wiring diagrams of the car

1 -	ABS control unit -J104-

A -	47-pin connector -T47c-

Back to overview

VW GOLF CABRIOLET 2014 Overview of coupling points

Overview of coupling points

Get access to all wiring diagrams of the car

Coupling point for reversing camera in rear lid

q	4-pin connector -T4cu- , blue

q	4-pin connector -T4bt- , black

q	Fitting location

Diagnostic connection -U31-

q	16-pin connector -T16-

q	Fitting location

Coupling point near starter

q	2-pin connector -T2c-

q	4-pin connector -T4t-

q	Fitting location

VW GOLF CABRIOLET 2014 Coupling point under dash panel in left footwell

Coupling point under dash panel in left footwell

Fitting location:

Left-hand drive models: on left under dash panel

Right-hand drive models: on right under dash panel

Note

Figure shows left-hand drive model. The view for a RHD model is basically a mirror image.

VW GOLF CABRIOLET 2014 Coupling point under dash panel in left footwell

Get access to all wiring diagrams of the car

-	10-pin connector -T10k- , black, -arrow-

Back to overview

VW GOLF CABRIOLET 2014 Coupling point on right A-pillar

Coupling point on right A-pillar

Note

Figure shows left-hand drive model. The view for a RHD model is basically a mirror image.

VW GOLF CABRIOLET 2014 Coupling point on right A-pillar

Get access to all wiring diagrams of the car

A -	28-pin connector -T28a-

Back to overview

VW GOLF CABRIOLET 2014 Coupling point under seat on front right

Coupling point under seat on front right

Get access to all wiring diagrams of the car

A -	10-pin connector -T10b-

B -	2-pin connector -T2y- , black

C -	3-pin connector -T3l- , yellow

Back to overview

VW GOLF CABRIOLET 2014 Coupling point in rear right side panel

Coupling point in rear right side panel

Get access to all wiring diagrams of the car

A -	2-pin connector -T2aj- , black

-	8-pin connector -T8l- , black

-	10-pin connector -T10kn- , black

B -	10-pin connector -T10am- , red

Back to overview

VW GOLF CABRIOLET 2014 Coupling point on left in luggage compartment

Coupling point on left in luggage compartment

Get access to all wiring diagrams of the car

1 -	Convertible roof actuation control unit -J256-

2 -	Convertible roof actuation hydraulic pump -V118-

3 -	10-pin connector -T10ak- , black

Back to overview

VW GOLF CABRIOLET 2014 Coupling point under seat on front left

Coupling point under seat on front left

Get access to all wiring diagrams of the car

A -	10-pin connector -T10a-

B -	2-pin connector -T2q- , black

C -	3-pin connector -T3k- , yellow

Back to overview

VW GOLF CABRIOLET 2014 Coupling point on left A-pillar

Coupling point on left A-pillar

Note

Figure shows left-hand drive model. The view for a RHD model is basically a mirror image.

VW GOLF CABRIOLET 2014 Coupling point on left A-pillar

Get access to all wiring diagrams of the car

A -	28-pin connector -T28-

Back to overview

VW GOLF CABRIOLET 2014 Engine coupling point near battery

Engine coupling point near battery

Get access to all wiring diagrams of the car

A -	14-pin connector -T14a- , black

Back to overview

VW GOLF CABRIOLET 2014 Coupling point near starter

Coupling point near starter

Get access to all wiring diagrams of the car

A -	2-pin connector -T2c-

-	4-pin connector -T4t-

Back to overview

VW GOLF CABRIOLET 2014 Coupling point near left headlight

Coupling point near left headlight

Get access to all wiring diagrams of the car

A -	6-pin connector -T6z- , black

Back to overview

VW GOLF CABRIOLET 2014 Front bumper coupling point

Front bumper coupling point

Get access to all wiring diagrams of the car

B -	8-pin connector -T8w- , black

Back to overview

VW GOLF CABRIOLET 2014 Coupling point on radiator fan, bottom left

Coupling point on radiator fan, bottom left

Get access to all wiring diagrams of the car

A -	4-pin connector -T4x- , black

Back to overview

VW GOLF CABRIOLET 2014 Diagnostic connection U31

Diagnostic connection -U31-

Fitting location:

Left-hand drive models: on left under dash panel

Right-hand drive models: on right under dash panel

Note

Figure shows left-hand drive model. The view for a RHD model is basically a mirror image.

VW GOLF CABRIOLET 2014 Diagnostic connection U31

Get access to all wiring diagrams of the car

A -	16-pin connector -T16-

Back to overview

VW GOLF CABRIOLET 2014 Coupling point behind glove compartment

Coupling point behind glove compartment

Fitting location:

Left-hand drive models: on left behind glove compartment

Right-hand drive models: on right behind glove compartment

Note

Figure shows left-hand drive model. The view for a RHD model is basically a mirror image.

VW GOLF CABRIOLET 2014 Coupling point behind glove compartment

Get access to all wiring diagrams of the car

A -	10-pin connector -T10f- , black

Back to overview

VW GOLF CABRIOLET 2014 Coupling point under selector lever cover

Coupling point under selector lever cover

Get access to all wiring diagrams of the car

A -	10-pin connector -T10s-

Back to overview

VW GOLF CABRIOLET 2014 Coupling point near left headlight

Coupling point near left headlight

Get access to all wiring diagrams of the car

A -	2-pin connector -T2n- , black

Back to overview

VW GOLF CABRIOLET 2014 Coupling point for reversing camera in rear lid

Coupling point for reversing camera in rear lid

Get access to all wiring diagrams of the car

1 -	4-pin connector -T4bt- , black

2 -	4-pin connector -T4cu- , blue

Back to overview

VW GOLF CABRIOLET 2014

VW GOLF CABRIOLET 2014 Overview of earth points in engine compartment

Overview of earth points in engine compartment

Get access to all wiring diagrams of the car

656	Earth point, on right headlight

q	Specified torque: 9 Nm

q	Fitting location:

607	Earth point, on left in plenum chamber

q	Specified torque: 9 Nm

q	Fitting location:

1	Earth strap, battery - body

q	Specified torque: 9 Nm

q	Fitting location:

615	Earth point, on left suspension strut

q	Specified torque: 9 Nm

q	Fitting location:

642	Earth point for electronically controlled fan

q	Specified torque: 9 Nm

q	Fitting location:

q	From November 2011

655	Earth point on left headlight

q	Specified torque: 9 Nm

q	Fitting location:

q	Up to November 2011

652	Earth point, engine and gearbox earth

q	Specified torque: 9 Nm

q	Fitting location:

14	Earth point on gearbox

q	Specified torque: 15 Nm

q	Fitting location:

656	Earth point on right headlight -arrow-

Get access to all wiring diagrams of the car

607	Earth point on left in plenum chamber -arrow-

Get access to all wiring diagrams of the car

1	Earth strap, battery - body -arrow B-

Get access to all wiring diagrams of the car

615	Earth point on left suspension strut -arrow A- , only RHD models

Get access to all wiring diagrams of the car

655	Earth point on left headlight -arrow A-

Get access to all wiring diagrams of the car

642	Earth point for electronically controlled fan -arrow B-

l	Up to November 2011

Get access to all wiring diagrams of the car

642	Earth point for electronically controlled fan -arrow-

l	From November 2011

Get access to all wiring diagrams of the car

652	Earth point for engine and gearbox earth -arrow C-

Get access to all wiring diagrams of the car

18	Earth point on engine block -arrow-

Get access to all wiring diagrams of the car

Overview of earth points in vehicle interior

Get access to all wiring diagrams of the car

43	Earth point, lower part of right A-pillar

q	Specified torque: 9 Nm

q	Fitting location:

47	Earth point, in front right footwell

q	Specified torque: 9 Nm

q	Fitting location

45	Earth point, behind centre of dash panel

q	Specified torque: 9 Nm

q	Fitting location

602	Earth point in front left footwell

q	Specified torque: 9 Nm

q	Fitting location

44	Earth point on lower part of left A-pillar

q	Specified torque: 9 Nm

q	Fitting location

605	Earth point on top end of steering column

q	Specified torque: 9 Nm

q	Fitting location

43	Earth point on lower part of right A-pillar -arrow A-

Get access to all wiring diagrams of the car

47	Earth point in front right footwell -arrow B-

Get access to all wiring diagrams of the car

45	Earth point, behind centre of dash panel -arrow-

Get access to all wiring diagrams of the car

602	Earth point in front left footwell -arrow B-

Get access to all wiring diagrams of the car

44	Earth point on lower part of left A-pillar -arrow A-

Get access to all wiring diagrams of the car

605	Earth point on top end of steering column

Get access to all wiring diagrams of the car

Overview of earth points in luggage compartment

Get access to all wiring diagrams of the car

682	Earth point 2 in rear right side panel

q	Fitting location

50	Earth point, on left in luggage compartment

q	Fitting location

662	Earth point in rear left side panel

q	Fitting location

682	Earth point 2 in rear right side panel -arrow-

Get access to all wiring diagrams of the car

50	Earth point on left in luggage compartment -arrow A-

Get access to all wiring diagrams of the car

662	Earth point in rear left side panel -arrow A-

Get access to all wiring diagrams of the car

VW GOLF CABRIOLET 2014 – Power operated convertible roof . Wiring diagrams, Pin Connector, Location

Wiring Diagram VW GOLF CABRIOLET 2014 - Convertible roof actuation button - Central switch for window regulators - Convertible roof actuation control unit - Convertible roof actuation hydraulic pump

Wiring Diagram VW GOLF CABRIOLET 2014 - Left latch switch for convertible roof - Right latch switch for convertible roof - Convertible roof latch open switch - Convertible roof latch closed switch - Convertible roof actuation control unit

Wiring Diagram VW GOLF CABRIOLET 2014 - Convertible roof stowed switch - Convertible roof front switch - Convertible roof actuation control unit - Data bus diagnostic interface - Convertible roof lock motor

VW GOLF CABRIOLET 2014 Overview of control units

VW GOLF CABRIOLET 2014 Emergency call module control unit and communication unit J949

VW GOLF CABRIOLET 2014 Remote control receiver for auxiliary coolant heater R149

VW GOLF CABRIOLET 2014 Aerial filter R87

VW GOLF CABRIOLET 2014 Mobile telephone operating electronics control unit J412

VW GOLF CABRIOLET 2014 Multimedia system control unit J650

VW GOLF CABRIOLET 2014 Mobile telephone operating electronics control unit J412

VW GOLF CABRIOLET 2014 Heated front seats control unit J774

VW GOLF CABRIOLET 2014 Rear right window regulator motor V27

VW GOLF CABRIOLET 2014 Fuel pump control unit J538

VW GOLF CABRIOLET 2014 Electronically controlled damping control unit J250

VW GOLF CABRIOLET 2014 Trailer detector control unit J345

VW GOLF CABRIOLET 2014 Blind spot monitor control unit J1086

VW GOLF CABRIOLET 2014 Blind spot monitor control unit 2 J1087

VW GOLF CABRIOLET 2014 Convertible roof actuation control unit J256

VW GOLF CABRIOLET 2014 Rear left window regulator motor V26

VW GOLF CABRIOLET 2014 Amplifier R12

VW GOLF CABRIOLET 2014 Overview of control units

VW GOLF CABRIOLET 2014 Auxiliary heater control unit J364

VW GOLF CABRIOLET 2014 Airbag control unit J234

VW GOLF CABRIOLET 2014 Control unit for cornering light and headlight range control J745

VW GOLF CABRIOLET 2014 Voltage stabiliser J532

VW GOLF CABRIOLET 2014 Fresh air blower control unit J126

VW GOLF CABRIOLET 2014 Front passenger door control unit J387

VW GOLF CABRIOLET 2014

VW GOLF CABRIOLET 2014 Data bus diagnostic interface J533

VW GOLF CABRIOLET 2014 Driver door control unit J386

VW GOLF CABRIOLET 2014 Steering column electronics control unit J527

VW GOLF CABRIOLET 2014

VW GOLF CABRIOLET 2014 Onboard supply control unit J519

VW GOLF CABRIOLET 2014 Parking aid control unit J446

VW GOLF CABRIOLET 2014 Park assist steering control unit J791

VW GOLF CABRIOLET 2014 Battery monitoring control unit J367

VW GOLF CABRIOLET 2014 Mechatronic unit for dual clutch gearbox J743

VW GOLF CABRIOLET 2014 Radiator fan control unit J293

VW GOLF CABRIOLET 2014 Power steering control unit J500

VW GOLF CABRIOLET 2014 Engine control unit J623

VW GOLF CABRIOLET 2014 ABS control unit J104

VW GOLF CABRIOLET 2014 Overview of coupling points

VW GOLF CABRIOLET 2014 Coupling point under dash panel in left footwell

VW GOLF CABRIOLET 2014 Coupling point on right A-pillar

VW GOLF CABRIOLET 2014 Coupling point under seat on front right

VW GOLF CABRIOLET 2014 Coupling point in rear right side panel

VW GOLF CABRIOLET 2014 Coupling point on left in luggage compartment

VW GOLF CABRIOLET 2014 Coupling point under seat on front left

VW GOLF CABRIOLET 2014 Coupling point on left A-pillar

VW GOLF CABRIOLET 2014 Engine coupling point near battery

VW GOLF CABRIOLET 2014 Coupling point near starter

VW GOLF CABRIOLET 2014 Coupling point near left headlight

VW GOLF CABRIOLET 2014 Front bumper coupling point

VW GOLF CABRIOLET 2014 Coupling point on radiator fan, bottom left

VW GOLF CABRIOLET 2014 Diagnostic connection U31

VW GOLF CABRIOLET 2014 Coupling point behind glove compartment

VW GOLF CABRIOLET 2014 Coupling point under selector lever cover

VW GOLF CABRIOLET 2014 Coupling point near left headlight

VW GOLF CABRIOLET 2014 Coupling point for reversing camera in rear lid

VW GOLF CABRIOLET 2014

VW GOLF CABRIOLET 2014 Overview of earth points in engine compartment

Login

Sign up

Get a new password
