Positive connection 8 (15a) in dash panel wiring harness
B315
Positive connection 1 (30a) in main wiring harness
*
Up to April 2013
*2
Only models with auxiliary coolant heater
*3
Only models with no auxiliary coolant heater
*4
From May 2013
Wiring Diagram VW GOLF CABRIOLET 2014 - High-pressure sender - Evaporator output temperature sender - Air conditioning system control unit - Air recirculation flap control motor
Potentiometer for air distribution flap control motor
J301
Air conditioning system control unit, on right in engine compartment
T6aj
6-pin connector
T6m
6-pin connector
T16e
16-pin connector
V68
Temperature flap control motor
V428
Air distribution flap control motor
L2
Connection in air conditioning system wiring harness
L10
Connection 2, in air conditioning system wiring harness
Wiring Diagram VW GOLF CABRIOLET 2014 - Fresh air blower switch - Air conditioning system control unit - Fresh air blower series resistor with overheating fuse - Fresh air blower
Connector assignment of parking aid control unit -J446-
-T18i- (A)
Designation
-T26k- (B)
Designation
1
1
2
2
Front parking aid warning buzzer -H22- (+)
3
Front centre left parking aid sender -G254- , signal
3
Park assist steering button -E581-
4
Front right parking aid sender -G252- , signal
4
Warning light for park assist steering -K241-
5
5
6
6
Rear left parking aid sender -G203- , signal
7
7
Rear centre right parking aid sender -G205- , signal
8
8
Rear right park assist steering sender -G717- , signal
9
9
Rear parking aid warning buzzer -H15- (-)
10
Front right parking aid sender -G252- (GND) Front centre right parking aid sender -G253- (GND) Front centre left parking aid sender -G254- (GND) Front left parking aid sender -G255- (GND)
10
Front parking aid warning buzzer -H22- (-)
11
Front left parking aid sender -G255- , signal
11
12
Front centre right parking aid sender -G253- , signal
12
13
13
Terminal 31
14
Front right parking aid sender -G252- (U+) Front centre right parking aid sender -G253- (U+) Front centre left parking aid sender -G254- (U+) Front left parking aid sender -G255- (U+)
14
Terminal 15
15
15
Rear parking aid warning buzzer -H15- (+)
16
16
Parking aid button -E266-
17
17
Parking aid warning lamp -K136-
18
18
Rear left parking aid sender -G203- (U+) Rear centre left parking aid sender -G204- (U+) Rear centre right parking aid sender -G205- (U+)
Rear right parking aid sender -G206- (U+)
19
20
Rear centre left parking aid sender -G204- , signal
21
Rear right parking aid sender -G206- , signal
22
Rear left parking aid sender -G203- (GND) Rear centre left parking aid sender -G204- (GND) Rear centre right parking aid sender -G205- (GND)
Rear right parking aid sender -G206- (GND)
23
B390 Connection 1 (powertrain CAN bus, low), in main wiring harness
24
B383 Connection 1 (powertrain CAN bus, high), in main wiring harness
25
26
Back to overview
VW GOLF CABRIOLET 2014 Park assist steering control unit J791
Park assist steering control unit -J791-
Fitting location:
Left-hand drive models: on left under dash panel, behind relay carrier above onboard supply control unit
Right-hand drive models: on right under dash panel, behind relay carrier above onboard supply control unit
1 -
Connectors on park assist steering control unit -J791-
Connector assignment of park assist steering control unit -J791-
-T18i- (A)
Designation
-T26k- (B)
Designation
1
1
2
Front left sender for park assist steering on left side of vehicle -G568- , signal
2
Front parking aid warning buzzer -H22- (+)
3
Front centre left parking aid sender -G254- , signal
3
Park assist steering button -E581-
4
Front right parking aid sender -G252- , signal
4
Warning light for park assist steering -K241-
5
5
6
6
Rear left parking aid sender -G203- , signal
7
7
Rear centre right parking aid sender -G205- , signal
8
8
Rear right park assist steering sender -G717- , signal
9
9
Rear parking aid warning buzzer -H15- (-)
10
Front right parking aid sender -G252- (GND) Front centre right parking aid sender -G253- (GND) Front centre left parking aid sender -G254- (GND) Front left parking aid sender -G255- (GND) Front left sender for park assist steering on left side of vehicle -G568- (GND) Front right sender for park assist steering on right side of vehicle -G569- (GND)
10
Front parking aid warning buzzer -H22- (-)
11
Front left parking aid sender -G255- , signal
11
12
Front centre right parking aid sender -G253- , signal
12
13
Front right sender for park assist steering on right side of vehicle -G569- , signal
13
Terminal 31
14
Front right parking aid sender -G252- (U+) Front centre right parking aid sender -G253- (U+) Front centre left parking aid sender -G254- (U+) Front left parking aid sender -G255- (U+) Front left sender for park assist steering on left side of vehicle -G568- (U+) Front right sender for park assist steering on right side of vehicle -G569- (U+)
14
Terminal 15
15
15
Rear parking aid warning buzzer -H15- (+)
16
16
Parking aid button -E266-
17
17
Parking aid warning lamp -K136-
18
18
Rear left parking aid sender -G203- (U+) Rear centre left parking aid sender -G204- (U+) Rear centre right parking aid sender -G205- (U+)
Rear right parking aid sender -G206- (U+) Rear left park assist steering sender -G716- (U+) Rear right park assist steering sender -G717- (U+)
19
Rear left park assist steering sender -G716- , signal
20
Rear centre left parking aid sender -G204- , signal
21
Rear right parking aid sender -G206- , signal
22
Rear left parking aid sender -G203- (GND) Rear centre left parking aid sender -G204- (GND) Rear centre right parking aid sender -G205- (GND)
Rear right parking aid sender -G206- (GND) Rear left park assist steering sender -G716- (GND) Rear right park assist steering sender -G717- (GND)
23
B390 Connection 1 (powertrain CAN bus, low), in main wiring harness
24
B383 Connection 1 (powertrain CAN bus, high), in main wiring harness
25
26
Back to overview
