VW THE BEETLE CABRIOLET 2013 – Front and rear parking aid (PDC), (7X2) . Wiring diagrams, Pin Connector, Location

Wiring Diagram VW THE BEETLE CABRIOLET 2013 - Terminal 15 voltage supply relay - Onboard supply control unit - Terminal 15 voltage supply relay 2

A	Battery
C	Alternator
G65	High-pressure sender
J329	Terminal 15 voltage supply relay
J519	Onboard supply control unit
J680	Terminal 75 voltage supply relay 1
J681	Terminal 15 voltage supply relay 2
J935	Converter box
SA1	Fuse 1 in fuse holder A
SC13	Fuse 13 on fuse holder C
SB20	Fuse 20 on fuse holder B
SB28	Fuse 28 on fuse holder B
SB29	Fuse 29 on fuse holder B
T3c	3-pin connector
T9i	9-pin connector
T9k	9-pin connector
T9m	9-pin connector
T10e	10-pin connector
T73a	73-pin connector
367	Earth connection 2, in main wiring harness
A2	Positive connection (15), in dash panel wiring harness
A12	Positive connection (75a), in dash panel wiring harness
A20	Positive connection (15a), in dash panel wiring harness
A32	Positive connection (30), in dash panel wiring harness
*	According to equipment

Wiring Diagram VW THE BEETLE CABRIOLET 2013 - Parking aid button - Rear parking aid warning buzzer - Front parking aid warning buzzer - Parking aid control unit

E1	Light switch
E20	Switch and instrument illumination regulator
E229	Hazard warning lights button
E266	Parking aid button
H15	Rear parking aid warning buzzer
H22	Front parking aid warning buzzer
J104	ABS control unit
J285	Control unit in dash panel insert
J446	Parking aid control unit
T2hc	2-pin connector
T2hd	2-pin connector
T6aw	6-pin connector
T6bq	6-pin connector
T8e	8-pin connector
T12q	12-pin connector
T16m	16-pin connector
T17d	17-pin connector
T32c	32-pin connector
T47	47-pin connector
372	Earth connection 7, in main wiring harness
375	Earth connection 10, in main wiring harness
382	Earth connection 17, in main wiring harness
387	Earth connection 22, in main wiring harness
B238	Positive connection 2 (58b), in interior wiring harness
B383	Connection 1 (powertrain CAN bus, high), in main wiring harness
B390	Connection 1 (powertrain CAN bus, low), in main wiring harness
*	From December 2011

Wiring Diagram VW THE BEETLE CABRIOLET 2013 - Rear left parking aid sender - Rear right parking aid sender - Front right parking aid sender - Front left parking aid sender - Front left inner parking aid sensor - Front right inner parking aid sensor - Rear left inner parking aid sender - Rear right inner parking aid sender - Parking aid control unit

G203	Rear left parking aid sender
G206	Rear right parking aid sender
G252	Front right parking aid sender
G255	Front left parking aid sender
G332	Front left inner parking aid sensor
G333	Front right inner parking aid sensor
G334	Rear left inner parking aid sender
G335	Rear right inner parking aid sender
J446	Parking aid control unit
T3ge	3-pin connector
T3gf	3-pin connector
T3gg	3-pin connector
T3gh	3-pin connector
T3gi	3-pin connector
T3gj	3-pin connector
T3gk	3-pin connector
T3ra	3-pin connector
T8n	8-pin connector
T8p	8-pin connector
T12n	12-pin connector
T12q	12-pin connector
349	Earth connection (horn), in front bumper wiring harness
352	Earth connection (parking aid), in rear bumper wiring harness
X65	Connection (parking aid), in front bumper wiring harness
X68	Positive connection (parking aid), in rear bumper wiring harness

VW THE BEETLE CABRIOLET 2013 Overview of relay carriers

Overview of relay carriers

1 -	Relay and fuse carrier 1 -SR1- , on E-box in engine compartment

t	Continued coolant circulation relay -J151-

t	Additional coolant pump relay -J496-

t	Fuel pump relay -J17-

t	Engine component current supply relay -J757-

t	Motronic current supply relay -J271-

t	Terminal 30 voltage supply relay -J317-

t	Low heat output relay -J359-

t	High heat output relay -J360-

t	Secondary air pump relay -J299-

q	Fitting location and relay assignment, from December 2011

2 -	Relay and fuse carrier 2 -SR2- , under dash panel on driver's side

t	Alarm horn relay -J641-

t	Starter relay 2 -J907-

t	Fuel pump relay -J17-

t	Electric fuel pump 2 relay -J49-

t	Heater element relay -J925-

t	Terminal 75 voltage supply relay 1 -J680-

t	Terminal 50 voltage supply relay -J682-

t	Starter relay 1 -J906-

t	Terminal 15 voltage supply relay 2 -J681-

t	Headlight dipper and flash relay -J-

t	Terminal 15 voltage supply relay -J329-

t	Converter box -J935-

t	Relay for reducing agent metering system -J963-

q	Fitting location and relay assignment, from December 2011

q	Fitting location and relay assignment, from July 2014

VW THE BEETLE CABRIOLET 2013

Relay and fuse carrier 1 -SR1- , on E-box in engine compartment

Fitting location and relay assignment on E-box, from December 2011

1 -	Relay and fuse carrier 1 -SR1- , on E-box in engine compartment

R1 -	Continued coolant circulation relay -J151- (643, 646)

R1 -	Additional coolant pump relay -J496- (643, 646)

R2 -	Fuel pump relay -J17- (643, 646)

R2 -	Engine component current supply relay -J757- (643, 646)

R3 -	Motronic current supply relay -J271- (644)

q	Only models with petrol engine

R3 -	Terminal 30 voltage supply relay -J317- (644)

q	Only models with a diesel engine

R4 -	Secondary air pump relay -J299- (644, 645)

q	Only models with 147 kW

R4 -	Low heat output relay -J359- (644, 645)

q	Only models with auxiliary air heater

R5 -	High heat output relay -J360- (644, 645)

q	Only models with auxiliary air heater

R5 -	Secondary air pump relay -J299- (644, 645)

q	Only models with 155 kW

R6 -	Automatic glow period control unit -J179- (457, 508)

q	Only models with a diesel engine

Note The​ number​ in​ brackets​ after​ the​ part​ designation​ denotes​ the​ control​ number​ on​ the​ housing.​ Back to overview

Relay and fuse carrier 2 -SR2- , under dash panel on driver's side

Fitting location and relay assignment of relay and fuse carrier 2 -SR2- , from December 2011

1 -	Relay and fuse carrier 2 -SR2- , under dash panel on driver's side

1 -	Alarm horn relay -J641- (646)

2 -	Starter relay 2 -J907- (507)

3 -	Fuel pump relay -J17- (646)

3 -	Electric fuel pump 2 relay -J49- (646)

3 -	Heater element relay -J925- (646)

4 -	Not assigned

5 -	Not assigned

6 -	Terminal 50 voltage supply relay -J682- (645)

6 -	Starter relay 1 -J906- (645)

7 -	Terminal 15 voltage supply relay 2 -J681- (645)

8 -	Headlight dipper and flash relay -J- (645)

9 -	Terminal 15 voltage supply relay -J329- (645)

10 -	Terminal 75 voltage supply relay 1 -J680- (645, 644)

11 -	Not assigned

12 -	Converter box -J935- (499, 501)

Note The​ number​ in​ brackets​ after​ the​ part​ designation​ denotes​ the​ control​ number​ on​ the​ housing.​ Back to overview

Fitting location and relay assignment of relay and fuse carrier 2 -SR2- , from July 2014

1 -	Relay and fuse carrier 2 -SR2- , under dash panel on driver's side

1 -	Alarm horn relay -J641- (646)

2 -	Starter relay 2 -J907- (507)

3 -	Fuel pump relay -J17- (646)

3 -	Electric fuel pump 2 relay -J49- (646)

3 -	Heater element relay -J925- (646)

4 -	Not assigned

5 -	Isolation relay for powertrain CAN bus -J788-

6 -	Terminal 50 voltage supply relay -J682- (645)

6 -	Starter relay 1 -J906- (645)

7 -	Converter box -J935-

8 -	Headlight dipper and flash relay -J- (645, 646)

9 -	Terminal 15 voltage supply relay -J329- (645)

10 -	Terminal 75 voltage supply relay 1 -J680- (645, 644)

11 -	Relay for reducing agent metering system -J963-

12 -	Not assigned

Note The​ number​ in​ brackets​ after​ the​ part​ designation​ denotes​ the​ control​ number​ on​ the​ housing.​ Back to overview

VW THE BEETLE CABRIOLET 2013 Overview of control units

Overview of control units

Multimedia system control unit -J650- / mobile telephone operating electronics control unit -J412-

q	Fitting location

Control unit with display for radio and navigation -J503- / radio -R-

q	Connector assignment

6 -	Control unit for reducing-agent heater -J891-

q	Fitting location

7 -	Headlight range control unit -J431-

q	Fitting location

q	Fitting location with 75-pin connector -T75-

VW THE BEETLE CABRIOLET 2013 Voltage stabiliser J532 Voltage stabiliser -J532- Fitting location: Behind glove compartment

1 -	Voltage stabiliser -J532-

A -	12-pin connector -T12z-

Connector assignment of voltage stabiliser -J532-

-T12z- (A)	Designation		-T12z- (A)	Designation
1	Terminal 30		7	Connection 2 (radio), in interior wiring harness
2	Terminal 31		8
3	Terminal 15		9
4	Positive connection (50), in dash panel wiring harness		10
5			11
6			12

Back to overview VW THE BEETLE CABRIOLET 2013 Multimedia system control unit -J650- / mobile telephone operating electronics control unit -J412- Fitting location: Behind glove compartment Equipped without emergency call module control unit and communication unit -J949- : Equipped with emergency call module control unit and communication unit -J949- :

Multimedia system control unit -J650-

1 -	Multimedia system control unit -J650-

A -	12-pin connector -T12m-

Connector assignment of multimedia system control unit -J650-

-T12m- (A)	Designation
1	Terminal 31
2	Connection 1 (convenience CAN bus, low), in main wiring harness
3
4	Control unit with display for radio and navigation -J503-
5	Additional connections unit for audio and video -R176-
6	Additional connections unit for audio and video -R176-
7	Terminal 30
8	Connection 1 (convenience CAN bus, high), in main wiring harness
9	Control unit with display for radio and navigation -J503-
10	Control unit with display for radio and navigation -J503-
11	Additional connections unit for audio and video -R176-
12	Additional connections unit for audio and video -R176-

Back to overview

Mobile telephone operating electronics control unit -J412-

1 -	Mobile telephone operating electronics control unit -J412-

A -	54-pin connector -T54b-

Connector assignment of mobile telephone operating electronics control unit -J412-

-T54b- (A)	Designation		-T54b- (A)	Designation
1	Terminal 30		28
2	Terminal 31		29
3			30
4	Control unit with display for radio and navigation -J503- , Radio -R-1)		31
5	Control unit with display for radio and navigation -J503- , Radio -R-1)		32
6	Emergency call module control unit and communication unit -J949-		33
7	Emergency call module control unit and communication unit -J949-		34
8	Control unit with display for radio and navigation -J503- , Radio -R-1)		35
9	Control unit with display for radio and navigation -J503- , Radio -R-1)		36
10			37
11	Emergency call module control unit and communication unit -J949- , Control unit with display for radio and navigation -J503- , Radio -R-1)		38
12	Emergency call module control unit and communication unit -J949- , Control unit with display for radio and navigation -J503- , Radio -R-1)		39
13			40
14			41
15			42
16			43
17	Convenience CAN bus high		44
18	Convenience CAN bus low		45
19			46
20			47
21			48
22	Control unit with display for radio and navigation -J503- , Radio -R-1)		49
23	Control unit with display for radio and navigation -J503- , Radio -R-1)		50
24	Control unit with display for radio and navigation -J503- , Radio -R-1)		51
25			52
26			53
27			54

1) Depending on equipment

Back to overview VW THE BEETLE CABRIOLET 2013 Front passenger door control unit J387 Front passenger door control unit -J387- Fitting location: In front passenger door.

1 -	Front passenger door control unit -J387-

A -	16-pin connector -T16d-

Connector assignment of front passenger door control unit -J387-

-T16d- (A)	Designation
1
2
3
4
5	Connection 1 (LIN bus) in main wiring harness
6	Window regulator switch in front passenger door -E107-
7	Window regulator switch in front passenger door -E107-
8	Terminal 31
9
10
11
12
13	Microswitch for lowering front passenger window -E622-
14
15
16	Terminal 30

Back to overview VW THE BEETLE CABRIOLET 2013 Equipped with " RNS 315 " : Equipped with " RNS 510 " :

1 -  Radio -R- A -  2-pin connector q   GSM aerial -R205- q   Satellite aerial -R170- q   GPS aerial -R50- B -  4-pin connector q   Aerial -R11- q   Radio aerial 2 -R93- C -  26-pin connector -T26d- q   TV tuner -R78- D -  16-pin connector -T16b- E -  12-pin connector -T12c- F -  12-pin connector -T12o- G -  16-pin connector -T16b- H -  16-pin connector -T16b- Connector assignment of radio -R-     -T16b- (H) Designation -T16b- (G) Designation 1 Rear right treble loudspeaker -R16- , + rear right bass loudspeaker -R17- , + Amplifier -R12-1)   9 Connection 1 (convenience CAN bus, high), in main wiring harness 2 Front right treble loudspeaker -R22- , + front right bass loudspeaker -R23- , + Amplifier -R12-1)   10 Connection 1 (convenience CAN bus, low), in main wiring harness 3 Front left treble loudspeaker -R20- , + front left bass loudspeaker -R21- , + Amplifier -R12-1)   11   4 Rear left treble loudspeaker -R14- , + rear left bass loudspeaker -R15- , + Amplifier -R12-1)   12 Terminal 31 5 Rear right treble loudspeaker -R16- , - rear right bass loudspeaker -R17- , - amplifier -R12-1)   13   6 Front right treble loudspeaker -R22- , - front right bass loudspeaker -R23- , - amplifier -R12-1)   14   7 Front left treble loudspeaker -R20- , - front left bass loudspeaker -R21- , - amplifier -R12-1)   15 Terminal 30 8 Rear left treble loudspeaker -R14- , - rear left bass loudspeaker -R15- , - amplifier -R12-1)   16 Terminal 30 1) Depending on equipment -T12c- (E) Designation -T12o- (F) Designation 1 Telephone microphone -R38- , -   1 Connection for external audio sources -R199- , Multimedia system control unit -J650-1) 2     2 Connection for external audio sources -R199- , Multimedia system control unit -J650-1) 3     3 Terminal 30 4 Telephone transmitter and receiver unit -R36-   4   5 Telephone transmitter and receiver unit -R36-   5   6 Telephone transmitter and receiver unit -R36-   6   7 Telephone microphone -R38- , +   7 Connection for external audio sources -R199- , Multimedia system control unit -J650-1) 8     8   9 Telephone transmitter and receiver unit -R36-   9   10     10   11 Telephone transmitter and receiver unit -R36-   11   12 Telephone transmitter and receiver unit -R36-   12   1) Depending on equipment Back to overview     1 -  Control unit with display for radio and navigation -J503- A -  Not assigned B -  4-pin connector q   Aerial -R11- q   Radio aerial 2 -R93- C -  2-pin connector q   GPS aerial -R50- D -  16-pin connector -T16b- E -  12-pin connector -T12c- F -  12-pin connector -T12o- G -  16-pin connector -T16b- H -  16-pin connector -T16b- Connector assignment of control unit with display for radio and navigation -J503-     -T16b- (H) Designation -T16b- (G) Designation 1 Rear right treble loudspeaker -R16- , + rear right bass loudspeaker -R17- , + Amplifier -R12-1)   9 Connection 1 (convenience CAN bus, high), in main wiring harness 2 Front right treble loudspeaker -R22- , + front right bass loudspeaker -R23- , + Amplifier -R12-1)   10 Connection 1 (convenience CAN bus, low), in main wiring harness 3 Front left treble loudspeaker -R20- , + front left bass loudspeaker -R21- , + Amplifier -R12-1)   11   4 Rear left treble loudspeaker -R14- , + rear left bass loudspeaker -R15- , + Amplifier -R12-1)   12 Terminal 31 5 Rear right treble loudspeaker -R16- , - rear right bass loudspeaker -R17- , - amplifier -R12-1)   13   6 Front right treble loudspeaker -R22- , - front right bass loudspeaker -R23- , - amplifier -R12-1)   14   7 Front left treble loudspeaker -R20- , - front left bass loudspeaker -R21- , - amplifier -R12-1)   15 Terminal 30 8 Rear left treble loudspeaker -R14- , - rear left bass loudspeaker -R15- , - amplifier -R12-1)   16 Terminal 30 1) Depending on equipment -T12c- (E) Designation -T12o- (F) Designation 1 Telephone microphone -R38- , -   1 Connection for external audio sources -R199- , Multimedia system control unit -J650-1) 2     2 Connection for external audio sources -R199- , multimedia system control unit -J650-1) 3     3 Terminal 30 4 Telephone transmitter and receiver unit -R36-   4   5 Telephone transmitter and receiver unit -R36-   5   6 Telephone transmitter and receiver unit -R36-   6   7 Telephone microphone -R38- , +   7 Connection for external audio sources -R199- , Multimedia system control unit -J650-1) 8     8   9 Telephone transmitter and receiver unit -R36-   9   10     10   11 Telephone transmitter and receiver unit -R36-   11   12 Telephone transmitter and receiver unit -R36-   12   1) Depending on equipment Back to overview     1 -  Control unit with display for radio and navigation -J503- A -  2-pin connector q   Satellite aerial -R170- B -  Not assigned C -  4-pin connector q   Aerial -R11- q   Radio aerial 2 -R93- D -  26-pin connector -T26d- q   TV tuner -R78- E -  2-pin connector q   GPS aerial -R50- F -  16-pin connector -T16b- F -  12-pin connector -T12o- G -  16-pin connector -T16b- H -  16-pin connector -T16b- Connector assignment of control unit with display for radio and navigation -J503-     -T16b- (H) Designation -T16b- (G) Designation 1 Rear right treble loudspeaker -R16- , + rear right bass loudspeaker -R17- , + Amplifier -R12-1)   9 Connection 1 (convenience CAN bus, high), in main wiring harness 2 Front right treble loudspeaker -R22- , + front right bass loudspeaker -R23- , + Amplifier -R12-1)   10 Connection 1 (convenience CAN bus, low), in main wiring harness 3 Front left treble loudspeaker -R20- , + front left bass loudspeaker -R21- , + Amplifier -R12-1)   11   4 Rear left treble loudspeaker -R14- , + rear left bass loudspeaker -R15- , + Amplifier -R12-1)   12 Terminal 31 5 Rear right treble loudspeaker -R16- , - rear right bass loudspeaker -R17- , - amplifier -R12-1)   13   6 Front right treble loudspeaker -R22- , - front right bass loudspeaker -R23- , - amplifier -R12-1)   14   7 Front left treble loudspeaker -R20- , - front left bass loudspeaker -R21- , - amplifier -R12-1)   15 Terminal 30 8 Rear left treble loudspeaker -R14- , - rear left bass loudspeaker -R15- , - amplifier -R12-1)   16 Terminal 30 1) Depending on equipment -T12c- (E) Designation -T12o- (F) Designation 1 Telephone microphone -R38- , -   1 Connection for external audio sources -R199- , Multimedia system control unit -J650-1) 2     2 Connection for external audio sources -R199- , Multimedia system control unit -J650-1) 3     3 Terminal 30 4 Telephone transmitter and receiver unit -R36-   4   5 Telephone transmitter and receiver unit -R36-   5   6 Telephone transmitter and receiver unit -R36-   6   7 Telephone microphone -R38- , +   7 Connection for external audio sources -R199- , Multimedia system control unit -J650-1) 8     8   9 Telephone transmitter and receiver unit -R36-   9   10     10   11 Telephone transmitter and receiver unit -R36-   11   12 Telephone transmitter and receiver unit -R36-   12   1) Depending on equipment Back to overview VW THE BEETLE CABRIOLET 2013 Seat occupied recognition control unit J706 Seat occupied recognition control unit -J706- Fitting location: Under seat.     Get access to all wiring diagrams of the car 1 -  Seat occupied recognition control unit -J706- A -  2-pin connector -T2ap- q   Pressure sensor for seat occupied recognition -G452- B -  3-pin connector -T3h- Connector assignment of seat occupied recognition control unit -J706-     -T3h- (A) Designation 1 Terminal 15 2 Airbag control unit -J234- 3 Terminal 31 Back to overview VW THE BEETLE CABRIOLET 2013 Control unit for reducing-agent heater J891 Control unit for reducing-agent heater -J891- Fitting location: under seat on front right     Get access to all wiring diagrams of the car 1 -  Control unit for reducing-agent heater -J891- A -  5-pin connector -T5h- B -  4-pin connector -T4as- Connector assignment of control unit for reducing-agent heater -J891-     -T5h- (A) Designation -T4as- (B) Designation 1 Heater for reducing-agent line (heater circuit 2) -Z104-   1 Engine control unit -J623- 2     2 Engine control unit -J623- 3 Connection 2 (87a), in engine compartment wiring harness   3 Engine control unit -J623- 4 Heater for reducing-agent tank (heater circuit 1) -Z102-   4 Engine control unit -J623- 5 Connection 2 (87a), in engine compartment wiring harness       Back to overview VW THE BEETLE CABRIOLET 2013 Headlight range control unit J431 Headlight range control unit -J431- Fitting location: under seat on front right     Get access to all wiring diagrams of the car 1 -  Headlight range control unit -J431- A -  26-pin connector -T26c- Connector assignment of headlight range control unit -J431-     -T26c- (A) Designation   -T26c- (A) Designation 1     14 2 Connection 1 (powertrain CAN bus, high), in main wiring harness 15 Front right headlight -MX2- 3 Connection 1 (powertrain CAN bus, low), in main wiring harness 16 Front left headlight -MX1- 4     17 Front left headlight -MX1- 5     18 Front left headlight -MX1- 6     19 Front left headlight -MX1- 7 Rear left vehicle level sender -G76- , PWM   20 Front right headlight -MX2- 8     21 Front right headlight -MX2- 9     22 Front right headlight -MX2- 10 Rear left vehicle level sender -G76- , 5V   23 Terminal 15 11 Rear left vehicle level sender -G76- , -   24 Terminal 31 12     25 13     26   Back to overview VW THE BEETLE CABRIOLET 2013 Control unit in dash panel insert J285 Control unit in dash panel insert -J285- Fitting location: In dash panel.     Get access to all wiring diagrams of the car 1 -  Control unit in dash panel insert -J285- A -  32-pin connector -T32c- Connector assignment of control unit in dash panel insert -J285-     -T32c- (A) Designation   -T32c- (A) Designation 1 Fuel system pressurisation pump -G6- , Fuel pump control unit -J538-   17 Windscreen washer fluid level sender -G33- 2 Fuel system pressurisation pump -G6- , Fuel pump control unit -J538-   18 Coolant shortage indicator sender -G32- 3     19 Ambient temperature sensor -G17- 4     20 Earth connection 1 (sender earth) in main wiring harness 5     21 Intermittent wiper switch -E22- 6     22 Intermittent wiper switch -E22- 7 Immobiliser reader coil -D2- 23 Intermittent wiper switch -E22- 8 Immobiliser reader coil -D2- 24 9   25 Handbrake warning switch -F9- 10     26 Brake fluid level warning contact -F34- 11 Oil level and oil temperature sender -G266-   27 Oil pressure switch -F1- 12     28 Connection 1 (powertrain CAN bus, high), in main wiring harness 13 Connection (rear fog light), in main wiring harness   29 Connection 1 (powertrain CAN bus, low), in main wiring harness 14 Positive connection 1 (56a), in interior wiring harness   30 15 Front left brake pad wear sender -G34-   31 Terminal 15 16 Terminal 31   32 Terminal 30 Back to overview VW THE BEETLE CABRIOLET 2013 Steering column electronics control unit J527 Steering column electronics control unit -J527- Fitting location: On A-pillar.     Get access to all wiring diagrams of the car 1 -  Steering column electronics control unit -J527- A -  16-pin connector -T16p- B -  4-pin connector -T4k- Connector assignment of steering column electronics control unit -J527-     -T16p- (A) Designation   -T16p- (A) Designation   -T4k- (B) Designation 1 Terminal 30   9   1 Airbag control unit -J234- 2 Terminal 31   10   2 Airbag control unit -J234- 3 Convenience CAN bus low   11     3   4 Convenience CAN bus high   12 Connection 1 (powertrain CAN bus, low), in main wiring harness   4   5 Cruise control system   13 Connection 1 (powertrain CAN bus, high), in main wiring harness   6     14 Terminal 15     7   15 Onboard supply control unit -J519-     8 LIN bus   16     Back to overview VW THE BEETLE CABRIOLET 2013 Convertible roof actuation control unit J256 Convertible roof actuation control unit -J256- Fitting location: In rear left side panel     Get access to all wiring diagrams of the car 1 -  Convertible roof actuation control unit -J256- A -  11-pin connector -T11c- Connector assignment of steering column electronics control unit -J527-     -T11c- (A) Designation   -T11c- (A) Designation 1 Connection 1 (convenience CAN bus, high), in main wiring harness 7 Convertible roof actuation button -E137- 2 Connection 1 (convenience CAN bus, low), in main wiring harness 8 Terminal 30 3     9 4     10 5 Left convertible roof latch release motor -V98-   11 6 Convertible roof actuation button -E137-   Back to overview VW THE BEETLE CABRIOLET 2013 Fuel pump control unit J538 Fuel pump control unit -J538- Fitting location: Under rear bench seat.     Get access to all wiring diagrams of the car 1 -  Fuel pump control unit -J538- A -  10-pin connector -T10v- Connector assignment of fuel pump control unit -J538-     -T10v- (A) Designation 1 Terminal 30 2 Engine control unit -J623- 3 Terminal 15 4 Control unit in dash panel insert -J285- 5 Earth connection 1 (sender earth) in main wiring harness 6 Terminal 31 7 Onboard supply control unit -J519- 8 Control unit in dash panel insert -J285- 9   10   Back to overview VW THE BEETLE CABRIOLET 2013 Control unit for electronic steering column lock J764 Control unit for electronic steering column lock -J764- Fitting location: On A-pillar.     Get access to all wiring diagrams of the car 1 -  Control unit for electronic steering column lock -J764- A -  16-pin connector -T16s- Connector assignment of control unit for electronic steering column lock -J764-     -T16s- (A) Designation   -T16s- (A) Designation 1     9   2 Terminal 30   10 Terminal 31 3 Starter relay 2 -J907-   11 4 Starter button -E378- 12 Engine control unit -J623- , Converter box -J935-1) 5     13 Starter button -E378- 6 Converter box -J935- 14 Selector lever sensors control unit -J587- 7 Onboard supply control unit -J519- 15 Connection 1 (convenience CAN bus, low), in main wiring harness 8 Converter box -J935- 16 Connection 1 (convenience CAN bus, high), in main wiring harness 1) Depending on equipment Back to overview VW THE BEETLE CABRIOLET 2013 Convertible roof actuation control unit 2 J1004 Convertible roof actuation control unit 2 -J1004- Fitting location: In rear right side panel     Get access to all wiring diagrams of the car 1 -  Convertible roof actuation control unit 2 -J1004- A -  11-pin connector -T11d- Connector assignment of convertible roof actuation control unit 2 -J1004-     -T11d- (A) Designation   -T11d- (A) Designation 1 Connection 1 (convenience CAN bus, high), in main wiring harness 7 2 Connection 1 (convenience CAN bus, low), in main wiring harness 8 Terminal 30 3     9 4     10 5 Right convertible roof latch release motor -V99-   11 Onboard supply control unit -J519- 6       Back to overview VW THE BEETLE CABRIOLET 2013 Heated front seats control unit J774 Heated front seats control unit -J774- Fitting location: On front of seat frame.     Get access to all wiring diagrams of the car 1 -  Heated front seats control unit -J774- A -  8-pin connector -T8v- Connector assignment of heated front seats control unit -J774-     -T8v- (A) Designation 1 Heated seat cushion for front passenger seat -Z8- 2 Onboard supply control unit -J519- 3 Terminal 30 4 Connection (seat heating), in main wiring harness 5 Heated seat cushion for driver seat -Z6- 6 Terminal 30 7 Terminal 31 8 Connection 5, in driver seat wiring harness Back to overview VW THE BEETLE CABRIOLET 2013 Driver door control unit J386 Driver door control unit -J386- Fitting location: In driver door.     Get access to all wiring diagrams of the car 1 -  Driver door control unit -J386- A -  16-pin connector -T16c- Connector assignment of driver door control unit -J386-     -T16c- (A) Designation 1   2   3   4 Front right window regulator switch in driver door -E81- 5 Connection 1 (LIN bus) in main wiring harness 6 Front left window regulator switch -E40- 7 Front right window regulator switch in driver door -E81- 8 Terminal 31 9   10   11   12 Fold-in mirror switch -E263- 13 Microswitch for lowering driver window -E621- 14 Driver side fold-in mirror motor -V121- 15 Driver side fold-in mirror motor -V121- 16 Terminal 30 Back to overview VW THE BEETLE CABRIOLET 2013 Amplifier R12 Amplifier -R12- Fitting location: Under driver seat.     Get access to all wiring diagrams of the car 1 -  Amplifier -R12- A -  38-pin connector -T38- Connector assignment of amplifier -R12-     -T38- (A) Designation   -T38- (A) Designation 1 Terminal 31   20 Front left treble loudspeaker -R20- 2 Terminal 30   21 Rear left bass loudspeaker -R15- 3 Front right bass loudspeaker -R23-   22 Rear right bass loudspeaker -R17- 4 Subwoofer -R211-   23 Connection 1 (convenience CAN bus, low), in main wiring harness 5 Subwoofer -R211-   24 6 Front left bass loudspeaker -R21-   25   7 Front right treble loudspeaker -R22-   26   8 Front left treble loudspeaker -R20-   27 Radio -R- , Control unit with display for radio and navigation -J503-1) 9 Rear left bass loudspeaker -R15-   28 Radio -R- , Control unit with display for radio and navigation -J503-1) 10 Rear right bass loudspeaker -R17-   29 Radio -R- , Control unit with display for radio and navigation -J503-1) 11 Front right mid-range and treble loudspeaker -R27-   30 Radio -R- , Control unit with display for radio and navigation -J503-1) 12 Front right mid-range and treble loudspeaker -R27-   31 Connection 1 (convenience CAN bus, high), in main wiring harness 13 Front left mid-range and treble loudspeaker -R26-   32 14 Front left mid-range and treble loudspeaker -R26-   33   15 Front right bass loudspeaker -R23-   34   16 Subwoofer -R211-   35 Radio -R- , Control unit with display for radio and navigation -J503-1) 17 Subwoofer -R211-   36 Radio -R- , Control unit with display for radio and navigation -J503-1) 18 Front left bass loudspeaker -R21- 37 Radio -R- , Control unit with display for radio and navigation -J503-1) 19 Front right treble loudspeaker -R22- 38 Radio -R- , Control unit with display for radio and navigation -J503-1) 1) Depending on equipment Back to overview VW THE BEETLE CABRIOLET 2013 Parking aid control unit J446 Parking aid control unit -J446- Fitting location: Behind dash panel on driver side.     Get access to all wiring diagrams of the car 1 -  Parking aid control unit -J446- A -  16-pin connector -T16m- B -  12-pin connector -T12- C -  12-pin connector -T12n- Connector assignment of parking aid control unit -J446-     -T16m- (A) Designation   -T12- (B) Designation   -T12n- (C) Designation 1 Terminal 15   1 Connection (parking aid), in front bumper wiring harness   1   2 Rear parking aid warning buzzer -H15-   2 Earth connection (horn), in front bumper wiring harness   2 Rear right inner parking aid sender -G335- 3     3 Front parking aid warning buzzer -H22-   3 Rear left inner parking aid sender -G334- 4 Parking aid button -E266- 4 Front parking aid warning buzzer -H22-   4 Rear right parking aid sender -G206- 5     5 Front left parking aid sender -G255- , signal   5 Rear left parking aid sender -G203- 6 Connection 1 (powertrain CAN bus, high), in main wiring harness 6 Front left inner parking aid sensor -G332- , signal   6   7   7 Front right inner parking aid sensor -G333- , signal   7   8 Terminal 30   8 Front right parking aid sender -G252- , signal   8 Parking aid earth connection, in rear bumper wiring harness 9     9     9   10 Rear parking aid warning buzzer -H15-   10     10   11     11     11 Positive connection (parking aid), in rear bumper wiring harness 12     12     12   13 Parking aid button -E266-         14             15 Connection 1 (powertrain CAN bus, low), in main wiring harness           16             Back to overview VW THE BEETLE CABRIOLET 2013 Onboard supply control unit J519 Onboard supply control unit -J519- Fitting location: Behind dash panel, left     Get access to all wiring diagrams of the car 1 -  Onboard supply control unit -J519- A -  73-pin connector -T73a- B -  73-pin connector -T73b- Connector assignment of onboard supply control unit -J519-     -T73a- (A) Designation   -T73b- (B) Designation 1     1 Switch and instrument illumination regulator -E20- 2 Left headlight dipped beam bulb -M29- , Front left headlight -MX1-   2 Right headlight dipped beam bulb -M31- , Front right headlight -MX2- 3     3 Left LED module for daytime running light and side light -L176- , Front left headlight -MX1- 4 Connection 1 (DCt), in interior wiring harness   4   5 Right LED module for daytime running light and side light -L177- , Front right headlight -MX2-   5 Front left headlight -MX1- 6 Connection (rear fog light), in main wiring harness 6 Front right headlight -MX2- 7 Rear fog light switch -E18- 7 Positive connection 2 (58), in dash panel wiring harness, Positive connection (58), in number plate lights wiring harness2) 8     8 9     9 Left fog light bulb -L22- 10 Rear lid lock unit -F256- 10 Right fog light bulb -L23- 11 Connection 1 (central locking), in interior wiring harness, Front passenger seat central locking motor -V57-   11 Terminal 30 12 Connection 2 (central locking), in interior wiring harness 12 Connection (RL), in dash panel wiring harness 13 Connection (SAFE1) in central locking wiring harness,Tank filler flap locking motor -V155- 13 Terminal 30 14 Terminal 31   14 Positive connection (left turn signal), in dash panel wiring harness 15 Connection 3 (central locking), in interior wiring harness, Driver door central locking motor -V56-   15 Positive connection (right turn signal), in dash panel wiring harness 16 Terminal 30   16 Connection 2 (54) in dash panel wiring harness 17     17 Connection 1 (LIN bus) in main wiring harness 18     18 Connection 1 (powertrain CAN bus, low), in main wiring harness 19 Driver side central locking lock unit -F220-   19 Connection 1 (powertrain CAN bus, high), in main wiring harness 20 Front passenger side central locking lock unit -F221-   20 Connection 1 (convenience CAN bus, high), in main wiring harness 21 Front passenger side central locking lock unit -F221-   21 Connection 1 (convenience CAN bus, low), in main wiring harness 22 Driver door central locking motor -V56-   22 16-pin connector -T16- 23 Rear lid handle release button -E234-   23 16-pin connector -T16- 24 Driver side central locking lock unit -F220-   24 Connection 2 (LIN bus) in main wiring harness 25 Connection 1 (central locking), in main wiring harness, Driver side interior locking button for central locking system -E308-   25   26     26   27 Bonnet contact switch -F266-   27 Intermittent wiper switch -E22- 28 Hazard warning lights button -E229-   28   29 Steering column electronics control unit -J527-   29 Light switch -E1- 30 Earth connection, in rear door switch wiring harness   30 Deactivation button for vehicle inclination sender -E360- 31 Rear lid electric opener motor -V254-   31 Air conditioning system control unit -J301-3) , Heater control unit -J162-4) 32 Turn signal switch -E2-   32 Wiper motor control unit -J400- 33 Turn signal switch -E2-   33   34   34 Positive connection 2 (58b), in interior wiring harness 35     35   36 Heated front seats control unit -J774- 36 Alarm horn -H12- 37   37 Connection 1 (LIN bus) in dash panel wiring harness2) 38 Connection (mirror adjustment/heating), in dash panel wiring harness   38 Terminal 31 39     39 Terminal 30 40 Connection (58R), in dash panel wiring harness   40   41 Connection (58L), in dash panel wiring harness   41   42 Electronic ignition lock -D9- , Control unit for electronic steering column lock -J764- 42   43 Connection (54), in interior light wiring harness   43 Fog light switch -E7- 44 Terminal 15   44 Turn signal switch -E2- 45 Light switch -E1-   45 Connection (CCS), in dash panel wiring harness 46     46 Turn signal switch -E2- 47 Entry and start authorisation control unit -J518-   47 Turn signal switch -E2- 48     48 Connection (RL), in interior wiring harness 49     49 Connection (61), in dash panel wiring harness 50     50 Positive connection (50), in dash panel wiring harness 51     51 Connection (75a), in dash panel wiring harness 52 Fuel pump control unit -J538- 52 Light switch -E1- 53 Alarm horn relay -J641- 53 Intermittent wiper switch -E22- 54 Terminal 75 voltage supply relay 1 -J680-1) , Positive connection (75a) in dash panel wiring harness2) 54   55 Converter box -J935-   55 Clutch position sender -G476- , Mechatronic unit for dual clutch gearbox -J743- 56 Hazard warning lights button -E229-   56   57 Deactivation button for vehicle inclination sender -E360- 57   58 Central locking SAFE function warning lamp -K133- 58 Exterior mirror heater button -E231- 59 Connection 2 (central locking), in main wiring harness   59 Terminal 30 60 Air conditioning system control unit -J301-3) , Heater control unit -J162-4) 60 Terminal 31 61     61 Connection (53c), in dash panel wiring harness 62 Positive connection 1 (56a), in interior wiring harness   62 Intermittent wiper switch -E22- 63 Terminal 30   63 Frequency modulation (FM) frequency filter in positive wire -R179- 64 Positive connection (30a), in dash panel wiring harness   64   65 Positive connection 2 (30a), in interior wiring harness   65 66 Positive connection 3 (30a) in dash panel wiring harness 66   67     67 Terminal 30 68 Terminal 30 68 Terminal 30 69 Wiper motor control unit -J400- 69   70 Terminal 31   70   71 Wiper motor control unit -J400-   71   72 Connection (dual tone horn), in dash panel wiring harness   72   73 Terminal 30 73   1) To December 2012 2) From December 2012 3) To June 2012 4) From June 2012 Back to overview VW THE BEETLE CABRIOLET 2013 Telephone transmitter and receiver unit R36 Telephone transmitter and receiver unit -R36- Fitting location: under seat on front right     Get access to all wiring diagrams of the car 1 -  Telephone transmitter and receiver unit -R36- A -  54-pin connector -T54- Connector assignment of telephone transmitter and receiver unit -R36-     -T54- (A) Designation   -T54- (A) Designation 1 Terminal 30   28 2 Terminal 31   29 3     30 Operating unit for preparation for mobile telephone -E508- 4 Control unit with display for radio and navigation -J503-   31 Operating unit for preparation for mobile telephone -E508- 5 Control unit with display for radio and navigation -J503-   32   6     33 7     34 8 Control unit with display for radio and navigation -J503-   35   9 Control unit with display for radio and navigation -J503-   36   10     37 11 Telephone microphone -R38- , Control unit with display for radio and navigation -J503-1)   38   12 Telephone microphone -R38- , Control unit with display for radio and navigation -J503-1)   39 Terminal 31 13     40 14     41 15     42 16     43 17 Connection 1 (convenience CAN bus, high), in main wiring harness 44 18 Connection 1 (convenience CAN bus, low), in main wiring harness 45 19     46   20     47   21     48   22     49   23     50   24     51   25     52   26     53   27     54   1) Depending on equipment Back to overview VW THE BEETLE CABRIOLET 2013 Entry and start authorisation control unit J518 Entry and start authorisation control unit -J518- Fitting location: Below the dash panel.     Get access to all wiring diagrams of the car 1 -  Entry and start authorisation control unit -J518- A -  32-pin connector -T32d- Connector assignment of entry and start authorisation control unit -J518-     -T32d- (A) Designation   -T32d- (A) Designation 1     17 Terminal 31 2     18 Interior aerial 2 for entry and start system -R139- 3 Terminal 30   19 Interior aerial 1 for entry and start system -R138- 4     20 Rear bumper aerial for entry and start system -R136- 5 Front passenger door exterior handle contact sensor -G416-   21 Front passenger door exterior handle contact sensor -G416-1) , Passenger side aerial for entry and start system -R135-2) 6     22 Luggage compartment aerial for entry and start system -R137-2) 7     23 Driver door exterior handle contact sensor -G415-1) , Driver side aerial for entry and start system -R134-2) 8     24 Driver side aerial for entry and start system -R134- 9 Driver door exterior handle contact sensor -G415-   25 Luggage compartment aerial for entry and start system -R137-2) 10 Onboard supply control unit -J519- 26 Passenger side aerial for entry and start system -R135- 11     27 Rear bumper aerial for entry and start system -R136- 12     28 Interior aerial 1 for entry and start system -R138- 13     29 Interior aerial 2 for entry and start system -R139- 14     30 Starter button -E378- 15     31   16 Connection 1 (convenience CAN bus, low), in main wiring harness 32 Connection 1 (convenience CAN bus, high), in main wiring harness 1) To December 2012 2) From December 2012 Back to overview VW THE BEETLE CABRIOLET 2013 Airbag control unit J234 Airbag control unit -J234- 1 -  Airbag control unit -J234- A -  50-pin connector -T50- Back to overview 1 -  Airbag control unit -J234- A -  75-pin connector -T75- Back to overview Data bus diagnostic interface -J533- Fitting location: Below the dash panel.     Get access to all wiring diagrams of the car 1 -  Data bus diagnostic interface -J533- A -  20-pin connector -T20- Connector assignment of data bus diagnostic interface -J533-     -T20- (A) Designation   -T20- (A) Designation 1 Terminal 30   11 Terminal 31 2     12 Connection 1 (LIN bus) in dash panel wiring harness 3     13 4     14 Terminal 15 5 Connection 1 (convenience CAN bus, low), in main wiring harness 15 Connection 1 (convenience CAN bus, high), in main wiring harness 6 Connection 1 (powertrain CAN bus, low), in main wiring harness 16 Connection 1 (powertrain CAN bus, high), in main wiring harness 7     17 8 Connection (dash panel insert CAN bus, low) in dash panel wiring harness   18 Connection (dash panel insert CAN bus, high) in dash panel wiring harness 9 16-pin connector -T16- 19 16-pin connector -T16- 10     20 Back to overview VW THE BEETLE CABRIOLET 2013 Equipped with air conditioning system control unit -J301- : Equipped with Climatronic control unit -J255- :     Heater control unit -J162- Get access to all wiring diagrams of the car 1 -  Heater control unit -J162- A -  20-pin connector -T20c- B -  5-pin connector -T5- Connector assignment of heater control unit -J162-     -T20c- (A) Designation   -T5- (B) Designation 1 Engine control unit -J623-   1 Fresh air blower series resistor with overheating fuse -N24- 2 Engine control unit -J623-   2 Fresh air blower series resistor with overheating fuse -N24- 3 Potentiometer for air recirculation flap control motor -G143-   3 Fresh air blower series resistor with overheating fuse -N24- 4     4 Fresh air blower -V2- 5     5 Terminal 75 voltage supply relay 1 -J680- 6 Potentiometer for air recirculation flap control motor -G143-       7         8 Onboard supply control unit -J519-       9         10 Terminal 31   11 Driver seat temperature sensor -G59- , Heated front seats control unit -J774-       12 Onboard supply control unit -J519-   13       14         15 Front passenger seat temperature sensor -G60- , Heated front seats control unit -J774-       16       17 Terminal 58d       18 Terminal 30       19 Terminal 15       20 Terminal 31       Back to overview     Air conditioning system control unit -J301- Get access to all wiring diagrams of the car 1 -  Air conditioning system control unit -J301- A -  16-pin connector -T16e- B -  20-pin connector -T20c- C -  5-pin connector -T5- Connector assignment of air conditioning system control unit -J301-     -T16e- (A) Designation   -T20c- (B) Designation -T5- (C) Designation 1     1   1 Fresh air blower series resistor with overheating fuse -N24- 2 Footwell vent temperature sender -G192-   2   2 Fresh air blower series resistor with overheating fuse -N24- 3     3     3 Fresh air blower series resistor with overheating fuse -N24- 4     4     4 Fresh air blower -V2- 5     5 High-pressure sender -G65-   5 Terminal 75 voltage supply relay 1 -J680- 6     6         7     7 Convenience CAN bus low       8 Footwell vent temperature sender -G192-   8 Convenience CAN bus high     9 Air recirculation flap control motor -V113-   9         10 Air recirculation flap control motor -V113- 10     11     11       12     12 Front passenger seat temperature sensor -G60- , Heated front seats control unit -J774-     13     13 Driver seat temperature sensor -G59- , Heated front seats control unit -J774-     14     14         15     15         16   16 Air conditioner compressor regulating valve -N280-           17               18               19 Terminal 30             20 Terminal 31       Back to overview     Climatronic control unit -J255- Get access to all wiring diagrams of the car 1 -  Climatronic control unit -J255- A -  20-pin connector -T20c- B -  16-pin connector -T16g- C -  16-pin connector -T16f- Connector assignment of Climatronic control unit -J255-     -T20c- (A) Designation   -T16g- (B) Designation   -T16f- (C) Designation 1 Sunlight penetration photosensor -G107- 1 Potentiometer for left temperature flap control motor -G220- , Potentiometer for right temperature flap control motor -G221- , Potentiometer for fresh air/recirculated air, air flow flap control motor -G644- , Potentiometer for centre flap servomotor -G112- , Potentiometer for defroster flap control motor -G135-   1 Left temperature flap control motor -V158- 2 High-pressure sender -G65-   2 Potentiometer for left temperature flap control motor -G220-   2 Left temperature flap control motor -V158- 3 Sunlight penetration photosensor -G107- 3 Potentiometer for right temperature flap control motor -G221- 3 Defroster flap control motor -V107- 4 Air quality sensor -G238-   4 Potentiometer for defroster flap control motor -G135-   4 Defroster flap control motor -V107- 5 Convenience CAN bus high   5 Potentiometer for centre flap servomotor -G112-   5 Centre flap control motor -V70- 6 Convenience CAN bus low   6   6 Centre flap control motor -V70- 7     7 Potentiometer for fresh air/recirculated air, air flow flap control motor -G644-   7 8     8 Left footwell vent temperature sender -G261-   8   9 Sunlight penetration photosensor -G107- 9 Right footwell vent temperature sender -G262- 9 Fresh air/recirculated air, air flow flap control motor -V425- 10 Driver seat temperature sensor -G59- , Heated front seats control unit -J774- 10 10 Fresh air/recirculated air, air flow flap control motor -V425- 11 Front passenger seat temperature sensor -G60- , Heated front seats control unit -J774- 11 Evaporator temperature sensor -G308-   11 Right temperature flap control motor -V159- 12     12     12 Right temperature flap control motor -V159- 13 Left vent temperature sender -G150-   13   13   14 Right vent temperature sender -G151-   14 Evaporator temperature sensor -G308- , Left footwell vent temperature sender -G261- , Right footwell vent temperature sender -G262- , Potentiometer for left temperature flap control motor -G220- , Potentiometer for defroster flap control motor -G135- , Potentiometer for right temperature flap control motor -G221- , Potentiometer for fresh air/recirculated air, air flow flap control motor -G644- , Potentiometer for centre flap servomotor -G112- , 14   15     15     15 Fresh air blower -V2- 16 Air conditioner compressor regulating valve -N280- 16   16 Fresh air blower -V2- 17 Left vent temperature sender -G150- , Right vent temperature sender -G151-           18               19 Terminal 31         20 Terminal 30         Back to overview VW THE BEETLE CABRIOLET 2013 Emergency call module control unit and communication unit J949 Emergency call module control unit and communication unit -J949- Fitting location: under seat on front right     Get access to all wiring diagrams of the car 1 -  Emergency call module control unit and communication unit -J949- A -  4-pin connector -T4m- q   GSM aerial -R205- q   GPS aerial -R50- B -  26-pin connector -T26e- Connector assignment of emergency call module control unit and communication unit -J949-     -T26e- (B) Designation   -T26e- (B) Designation 1 Terminal 30   14 Convenience CAN bus high 2 Convenience CAN bus low 15   3   16 4 Telephone microphone -R38- , + 17 Telephone microphone -R38- , - 5     18 6 Operating unit for preparation for mobile telephone -E508- , Mobile telephone operating electronics control unit -J412-1)   19 Operating unit for preparation for mobile telephone -E508-1) 7 Operating unit for preparation for mobile telephone -E508- , Mobile telephone operating electronics control unit -J412-1)   20 Operating unit for preparation for mobile telephone -E508-1) 8     21 9     22 10     23   11     24   12     25 13     26 Terminal 31 1) Depending on equipment Back to overview     VW THE BEETLE CABRIOLET 2013 Overview of fuse holder Overview of fuse holder Get access to all wiring diagrams of the car q   Fuse assignment, from December 2011 q   Fuse assignment, from December 2011 q   Fuse assignment from July 2013 q   Fuse assignment from July 2014 q   Fuse assignment, from December 2011 q   Fuse assignment from July 2013 q   Fuse assignment from July 2014 VW THE BEETLE CABRIOLET 2013 Fitting location fuse holder A SA Fitting location fuse holder A -SA- Get access to all wiring diagrams of the car 1 -  Fuse holder A -SA- 507 -  Threaded connection (30), on battery fuse holder Multifuse strip fuse → Repair Group 97   Note The strip fuse (Multifuse) must be replaced as a complete unit. Back to overview     VW THE BEETLE CABRIOLET 2013 Fuse assignment fuse holder A -SA- , from December 2011 Screw location Current Flow Diagram designation Nominal value Function/component Terminal B Fuse 1 on fuse holder A -SA1- 200 A Alternator -C- 30 C Fuse 2 on fuse holder A -SA2-   Not assigned D Fuse 3 on fuse holder A -SA3- 80 A Power steering control unit -J500- 30       Electromechanical power steering motor -V187-   E Fuse 4 on fuse holder A -SA4- 80 A Supply for fuses: 30       -SC3-         -SC6-         -SC17-         -SC20- …-SC24-         -SC36-         -SC39-         -SC43- …-SC53-         -SC55-       -SC57-   Back to overview     VW THE BEETLE CABRIOLET 2013 Fitting location fuse holder B SB Fitting location fuse holder B -SB- Get access to all wiring diagrams of the car 1 -  Fuse holder B -SB- Fuse colours for J-Case fuse: t  50 A - red t  40 A - green t  30 A - pink Fuse colours for ATO flat fuse: t  40 A - orange t  30 A - light green t  25 A - natural (white) t  20 A - yellow t  15 A - light blue t  10 A - red t  7.5 A - brown t  5 A - light brown t  1 A - black Back to overview     VW THE BEETLE CABRIOLET 2013 Fuse assignment fuse holder B -SB- , from December 2011 Slot Current Flow Diagram designation Nominal value Function/component Terminal F1 Not assigned -   - F2 Fuse 2 on fuse holder B -SB2- 30 A Engine control unit -J623- (T94/5), (T94/3), (T94/6)1) (T91/5)27) (T91/6)27) 87a   20 A15)     F3 Fuse 3 on fuse holder B -SB3- 5 A Radiator fan control unit -J293- (T4x/2) 87a F4 Fuse 4 on fuse holder B -SB4- 15 A Lambda probe -G39- (T6w/4)2) (T6w/5)3) 87a     Lambda probe after catalytic converter -G130- (T6af/4)4)     Lambda probe -G39- (T6w/4)5) (T4am/1)6) (T5e/4)27)         Lambda probe after catalytic converter -G130- (T4ao/1)28)         Lambda probe 2 after catalytic converter -G131- (T4o/1)13)         Centre Lambda probe for bank 1 catalytic converter -G465- (T4v/1)11)         Electric fuel pump 2 relay -J49- (1B)17)   F5 Fuse 5 on fuse holder B -SB5- 10 A Heater element relay -J925- (1B)7) (3B)7) 87a       Charge pressure control solenoid valve -N75- (1)8)         Heater element for crankcase breather -N79- (1)4)         Camshaft control valve 1 -N205- (1)27)         Turbocharger air recirculation valve -N249- (1)27)         Intake manifold flap valve -N316- (1)27)         Exhaust gas recirculation cooler changeover valve -N345- (1)7)       Fuel system diagnostic pump -V144- (T4ay/4)10)     Fuel pump relay -J17- (F51)15)         Secondary air pump relay -J299- (F71)9) (F81)26)         Engine component current supply relay -J757- (F51) 27)       Charge pressure control solenoid valve -N75- (1)29)         Activated charcoal filter solenoid valve 1 -N80- (1)29)   F6 Fuse 6 on fuse holder B -SB6- 10 A Secondary air inlet valve -N112- (1)36) 87a       Camshaft control valve 1 -N205- (1)13)         Turbocharger air recirculation valve -N249- (1)13)         Intake manifold flap valve -N316- (1)13)         Valve for oil pressure control -N428- (2)14)       Coolant circulation pump 2 -V178- (2)27)         Throttle valve module -J338- (2)4)         Ignition coil 1 with output stage -N70- (T4af/1)25) (3)18)         Ignition coil 2 with output stage -N127- (T4ag/1)25) (3)18)         Ignition transformer -N152- (T4aa/2)16) F7 Fuse 7 on fuse holder B -SB7- 30 A Fuel pressure regulating valve -N276- (2)8) 87a     20 A8) Fuel metering valve -N290- (2)8)         Ignition coil 3 with output stage -N291- (T4ah/1)25) (3)18)         Ignition coil 4 with output stage -N292- (T4ai/1)25) (3)18)       Ignition coil 5 with output stage -N323- (T4aj/1)15)     Air mass meter -G70- (T4j/1) 21)     Fuel pump relay -J17- (1A)8)     Charge pressure control solenoid valve -N75- (1)18)     Activated charcoal filter solenoid valve 1 -N80- (1)19)       Camshaft control valve 1 -N205- (1)20)   F8 Fuse 8 on fuse holder B -SB8- 10 A Exhaust gas recirculation valve 2 -N213- (1)21) 87a     Turbocharger air recirculation valve -N249- (1)18)       Magnetic clutch for supercharger -N421- (1)18)     Valve for oil pressure control -N428- (2)15)       Coolant regulating valve -N515- (1)16)         Coolant circulation pump 2 -V178- (2)21)       Continued coolant circulation relay -J151- (F41)12) (F43)12)       Automatic glow period control unit -J179- (T11b/6)8)     Low heat output relay -J359- (F71)23)   F9 Fuse 9 on fuse holder B -SB9- 10 A High heat output relay -J360- (F81)23) 87a     Additional coolant pump relay -J496- (F41)22) (F43)22)     Engine component current supply relay -J757- (F51)12)       Fuel pressure regulating valve -N276- (1)22)       Coolant circulation pump 2 -V178- (2)7)   F10 Fuse 10 on fuse holder B -SB10- 5 A Clutch position sender -G476- (T5m/5) 87a       Brake light switch -F- (T4y/4)   F11 Not assigned -   - F12 Not assigned -   -     Voltage stabiliser -J532- (T12z/1)   F13 Fuse 13 on fuse holder B -SB13- 30 A Control unit with display for radio and navigation -J503- (T16b/15), (T16b/16) 30a     Control unit for navigation system -J856- (T10aa/2)       Radio -R- (T16b/15), (T16b/16)     Motronic current supply relay -J271- (F61)24) F14 Fuse 14 on fuse holder B -SB14- 10 A Terminal 30 voltage supply relay -J317- (F61)8) 30a       Engine control unit -J623- (T94/92), (T91/86)27) F15 Fuse 15 on fuse holder B -SB15- 10 A Alarm horn relay -J641- (3A) 30a F16 Fuse 16 on fuse holder B -SB16- 40 A Amplifier -R12- (T38/2) 30a F17 Fuse 17 on fuse holder B -SB17- 15 A30) Mechatronic unit for dual clutch gearbox -J743- (T25/9)30) 30a     30 A31) Mechatronic unit for dual clutch gearbox -J743- (T20/11)31) (T20/18)31) F18 Fuse 18 on fuse holder B -SB18- 15 A Mechatronic unit for dual clutch gearbox -J743- (T25/25)30) 30a F19 Fuse 19 on fuse holder B -SB19- 5 A Onboard supply control unit -J519- (T73b/59) 30a       Battery monitoring control unit -J367- (2) F20 Fuse 20 on fuse holder B -SB20- 30 A Onboard supply control unit -J519- (T73a/68) 30a F21 Fuse 21 on fuse holder B -SB21- 40 A Auxiliary air heater element -Z35- (T3am/1)23) 10     50 A26) Secondary air pump motor -V101- (2)26)   F22 Fuse 22 on fuse holder B -SB22- 40 A Auxiliary air heater element -Z35- (T3am/3)23) 10     Fuse 40 on fuse holder C -SC40- F23 Fuse 23 on fuse holder B -SB23- 50 A Fuse 41 on fuse holder C -SC41- 30a     Fuse 42 on fuse holder C -SC42- F24 Fuse 24 on fuse holder B -SB24- 40 A Terminal 75 voltage supply relay 1 -J680- (T9m/3) 30a   50A33)   F25 Fuse 25 on fuse holder B -SB25- 40 A Terminal 15 voltage supply relay -J329- (T9i/3) 30a       Terminal 15 voltage supply relay 2 -J681- (T9k/3)   F26 Fuse 26 on fuse holder B -SB26- 50 A Automatic glow period control unit -J179- (T11b/11)8) 30a F27 Fuse 27 on fuse holder B -SB27- 50 A Radiator fan control unit -J293- (T4x/1) 30a F28 Fuse 28 on fuse holder B -SB28- 20 A Fuel pump relay -J17- (F53)15) 30a   30 A29) Engine component current supply relay -J757- (F53)29)   F29 Not assigned - - F30 Fuse 30 on fuse holder B -SB30- 40 A ABS control unit -J104- (T47/1) 30a F31 Fuse 31 on fuse holder B -SB31- 40 A ABS control unit -J104- (T47/32) 30a F32 Fuse 32 on fuse holder B -SB32- 40 A Auxiliary air heater element -Z35- (T3am/2)23) 30a     Secondary air pump motor -V101- (2)9)   1) Engine codes CAYC, CBFA, CCTA, CCZA, CFFB, CJAA 2) Engine codes CBTA, CBUA, CFFB, CJAA 3) Engine codes CAYC, CBZB 4) Engine code CJAA 5) Engine codes CAVD, CBFA, CCTA, CCZA, CNWA, CTHD 6) Engine code CCCA 7) Engine codes CAYC 8) Engine codes CAYC, CFFB, CJAA 9) Engine codes CBFA, CBUA 10) Engine codes CBFA, CBTA, CBUA, CPLA, CPPA 11) Engine code CBUA 12) Engine codes CCZA, CBFA, CCTA, 13) Engine codes CBFA, CCTA, CCZA 14) Engine code CCZA 15) Engine codes CBTA, CBUA, CCCA 16) Engine codes CBZB 17) Engine codes CFFB, CJAA 18) Engine codes CAVD, CNWA, CTHD 19) Engine codes CAVD, CBTA, CBUA, CBZB, CCCA, CNWA, CTHD 20) Engine codes CAVD, CBTA, CBUA, CCCA, CNWA, CTHD 21) Engine code CFFB 22) Engine codes CAVD, CBZB, CNWA, CTHD 23) Engine codes CAYC, CFFB, CJAA, CBZB 24) Engine codes CAVD, CBFA, CCTA, CCZA, CNWA, CTHD, CBTA, CBUA, CCCA 25) Engine codes CBFA, CCTA, CCZA, CBTA, CBUA, CCCA 26) Engine code CPPA 27) Engine codes CPLA, CPLB, CPPA 28) Engine codes CAVD, CNWA, CTHD, CPLA, CPLB, CPPA, CBZB, CBFA, CBTA, CBUA, CCCA 29) Engine codes CBFA, CCTA, CCZA, CPLA, CPLB, CPPA 30) For models with dual clutch gearbox 02E only 31) For models with dual clutch gearbox 0AM only 33) Only models with Climatronic 34) To December 2012 36) Engine codes CBUA, CPPA Back to overview     VW THE BEETLE CABRIOLET 2013 Fuse assignment fuse holder B -SB- , from July 2013 Slot Current Flow Diagram designation Nominal value Function/component Terminal F1 Not assigned - - F2 Fuse 2 on fuse holder B -SB2- 30 A 20 A1) Engine control unit -J623- 87 F3 Fuse 3 on fuse holder B -SB3- 5 A Radiator fan control unit -J293- 87 F4 Fuse 4 on fuse holder B -SB4- 15 A Lambda probe -G39- 87     Lambda probe after catalytic converter -G130-   F5 Fuse 5 on fuse holder B -SB5- 10 A Lambda probe -G39- 87     Lambda probe after catalytic converter -G130-     Centre Lambda probe for bank 1 catalytic converter -G465-       Electric fuel pump 2 relay -J49-     Heater element relay -J925-       Charge pressure control solenoid valve -N75-     Heater element for crankcase breather -N79-     Camshaft control valve 1 -N205-     Turbocharger air recirculation valve -N249-     Intake manifold flap valve -N316-     Exhaust gas recirculation cooler changeover valve -N345-     Fuel system diagnostic pump -V144- F6 Fuse 6 on fuse holder B -SB6- 10 A Fuel pump relay -J17- 87     Secondary air pump relay -J299-       Engine component current supply relay -J757-     Charge pressure control solenoid valve -N75-       Activated charcoal filter solenoid valve 1 -N80-       Secondary air inlet valve -N112-       Camshaft control valve 1 -N205-       Turbocharger air recirculation valve -N249-       Intake manifold flap valve -N316-       Valve for oil pressure control -N428-         Coolant circulation pump 2 -V178- F7 Fuse 7 on fuse holder B -SB7- 20 A2) 30 A3) Throttle valve module -J338- 87     Ignition coil 1 with output stage -N70-     Ignition coil 2 with output stage -N127-     Ignition transformer -N152-       Fuel pressure regulating valve -N276-       Fuel metering valve -N290-       Ignition coil 3 with output stage -N291-       Ignition coil 4 with output stage -N292-     Ignition coil 5 with output stage -N323-   F8 Fuse 8 on fuse holder B -SB8- 10 A Air mass meter -G70- 87     Fuel pump relay -J17-       Charge pressure control solenoid valve -N75-     Activated charcoal filter solenoid valve 1 -N80-       Camshaft control valve 1 -N205-       Exhaust gas recirculation valve 2 -N213-       Turbocharger air recirculation valve -N249-       Magnetic clutch for supercharger -N421-       Valve for oil pressure control -N428-       Coolant regulating valve -N515-         Coolant circulation pump 2 -V178- F9 Fuse 9 on fuse holder B -SB9- 10 A Continued coolant circulation relay -J151- 87     Automatic glow period control unit -J179-       Low heat output relay -J359-       High heat output relay -J360-       Additional coolant pump relay -J496-       Engine component current supply relay -J757-     Fuel pressure regulating valve -N276-         Coolant circulation pump 2 -V178- F10 Fuse 10 on fuse holder B -SB10- 5 A Clutch position sender -G476- 87       Brake light switch -F-   F11 Not assigned - - F12 Not assigned - - F13 Fuse 13 on fuse holder B -SB13- 30 A Voltage stabiliser -J532- 30     Control unit with display for radio and navigation -J503-     Control unit for navigation system -J856-         Radio -R-   F14 Fuse 14 on fuse holder B -SB14- 10 A Motronic current supply relay -J271- 30     Terminal 30 voltage supply relay -J317-         Engine control unit -J623-   F15 Fuse 15 on fuse holder B -SB15- 10 A Alarm horn relay -J641- 30 F16 Fuse 16 on fuse holder B -SB16- 40 A Amplifier -R12- 30 F17 Fuse 17 on fuse holder B -SB17- 15 A4) 30 A5) Mechatronic unit for dual clutch gearbox -J743- 30 F18 Fuse 18 on fuse holder B -SB18- 15 A Mechatronic unit for dual clutch gearbox -J743-4) 30 F19 Fuse 19 on fuse holder B -SB19- 5 A Onboard supply control unit -J519- 30 F20 Fuse 20 on fuse holder B -SB20- 30 A Onboard supply control unit -J519- 30 F21 Fuse 21 on fuse holder B -SB21- 40 A Auxiliary air heater element -Z35- 87     50 A6) Secondary air pump motor -V101-   F22 Fuse 22 on fuse holder B -SB22- 40 A Auxiliary air heater element -Z35- 87 F23 Fuse 23 on fuse holder B -SB23- 50 A Fuse 40 on fuse holder C -SC40- 30   Fuse 41 on fuse holder C -SC41-       Fuse 42 on fuse holder C -SC42- F24 Fuse 24 on fuse holder B -SB24- 40 A Terminal 75 voltage supply relay 1 -J680- 30     50 A7)   F25 Fuse 25 on fuse holder B -SB25- 40 A Terminal 15 voltage supply relay -J329- 30       Terminal 15 voltage supply relay 2 -J681-   F26 Fuse 26 on fuse holder B -SB26- 50 A Automatic glow period control unit -J179- 30 F27 Fuse 27 on fuse holder B -SB27- 50 A Radiator fan control unit -J293- 30 F28 Fuse 28 on fuse holder B -SB28- 20 A Fuel pump relay -J17- 30 F29 Not assigned - - F30 Fuse 30 on fuse holder B -SB30- 40 A ABS control unit -J104- 30 F31 Fuse 31 on fuse holder B -SB31- 40 A ABS control unit -J104- 30 F32 Fuse 32 on fuse holder B -SB32- 40 A Secondary air pump motor -V101- 87       Auxiliary air heater element -Z35-   1) Only models with 2.5l petrol engine 2) Only models with diesel engine 3) Only models with petrol engine 4) For models with dual clutch gearbox 02E only 5) For models with dual clutch gearbox 0AM only 6) Only models with 2.0l petrol engine 7) Only models with Climatronic Back to overview     VW THE BEETLE CABRIOLET 2013 Fuse assignment fuse holder B -SB- , from July 2014 Slot Current Flow Diagram designation Nominal value Function/component Terminal F1 Not assigned - - F2 Fuse 2 on fuse holder B -SB2- 30 A 20 A1) Engine control unit -J623- 87 F3 Fuse 3 on fuse holder B -SB3- 5 A Radiator fan control unit -J293- 87 F4 Fuse 4 on fuse holder B -SB4- 15 A Lambda probe -G39- 87     Lambda probe after catalytic converter -G130-   F5 Fuse 5 on fuse holder B -SB5- 10 A Lambda probe -G39- 87     Lambda probe after catalytic converter -G130-     Centre Lambda probe for bank 1 catalytic converter -G465-       Electric fuel pump 2 relay -J49-     Heater element relay -J925-       Charge pressure control solenoid valve -N75-     Heater element for crankcase breather -N79-     Camshaft control valve 1 -N205-     Turbocharger air recirculation valve -N249-     Intake manifold flap valve -N316-     Exhaust gas recirculation cooler changeover valve -N345-     Fuel system diagnostic pump -V144- F6 Fuse 6 on fuse holder B -SB6- 10 A Fuel pump relay -J17- 87     Secondary air pump relay -J299-       Engine component current supply relay -J757-     Charge pressure control solenoid valve -N75-       Activated charcoal filter solenoid valve 1 -N80-       Secondary air inlet valve -N112-       Camshaft control valve 1 -N205-       Turbocharger air recirculation valve -N249-       Intake manifold flap valve -N316-       Valve for oil pressure control -N428-         Coolant circulation pump 2 -V178- F7 Fuse 7 on fuse holder B -SB7- 20 A2) 30 A3) Throttle valve module -J338- 87     Ignition coil 1 with output stage -N70-     Ignition coil 2 with output stage -N127-     Ignition transformer -N152-       Fuel pressure regulating valve -N276-       Fuel metering valve -N290-       Ignition coil 3 with output stage -N291-       Ignition coil 4 with output stage -N292-     Ignition coil 5 with output stage -N323-   F8 Fuse 8 on fuse holder B -SB8- 10 A Air mass meter -G70- 87     Fuel pump relay -J17-       Charge pressure control solenoid valve -N75-     Activated charcoal filter solenoid valve 1 -N80-       Camshaft control valve 1 -N205-       Exhaust gas recirculation valve 2 -N213-       Turbocharger air recirculation valve -N249-       Magnetic clutch for supercharger -N421-       Valve for oil pressure control -N428-       Coolant regulating valve -N515-         Coolant circulation pump 2 -V178- F9 Fuse 9 on fuse holder B -SB9- 10 A Continued coolant circulation relay -J151- 87     Automatic glow period control unit -J179-       Low heat output relay -J359-       High heat output relay -J360-       Additional coolant pump relay -J496-       Engine component current supply relay -J757-     Fuel pressure regulating valve -N276-         Coolant circulation pump 2 -V178- F10 Fuse 10 on fuse holder B -SB10- 5 A Clutch position sender -G476- 87       Brake light switch -F-   F11 Not assigned - - F12 Not assigned - - F13 Fuse 13 on fuse holder B -SB13- 30 A Voltage stabiliser -J532- 30     Control unit with display for radio and navigation -J503-     Control unit for navigation system -J856-         Radio -R-   F14 Fuse 14 on fuse holder B -SB14- 10 A Motronic current supply relay -J271- 30     Terminal 30 voltage supply relay -J317-         Engine control unit -J623-   F15 Fuse 15 on fuse holder B -SB15- 10 A Alarm horn relay -J641- 30 F16 Fuse 16 on fuse holder B -SB16- 40 A Amplifier -R12- 30 F17 Fuse 17 on fuse holder B -SB17- 15 A4) 30 A5) Mechatronic unit for dual clutch gearbox -J743- 30 F18 Fuse 18 on fuse holder B -SB18- 15 A Mechatronic unit for dual clutch gearbox -J743-4) 30 F19 Fuse 19 on fuse holder B -SB19- 5 A Onboard supply control unit -J519- 30 F20 Fuse 20 on fuse holder B -SB20- 30 A Onboard supply control unit -J519- 30 F21 Fuse 21 on fuse holder B -SB21- 40 A Auxiliary air heater element -Z35- 87     50 A6) Secondary air pump motor -V101-   F22 Fuse 22 on fuse holder B -SB22- 40 A Auxiliary air heater element -Z35- 87 F23 Fuse 23 on fuse holder B -SB23- 50 A Fuse 40 on fuse holder C -SC40- 30   Fuse 41 on fuse holder C -SC41-       Fuse 42 on fuse holder C -SC42- F24 Fuse 24 on fuse holder B -SB24- 40 A Terminal 75 voltage supply relay 1 -J680- 30     50 A7)   F25 Fuse 25 on fuse holder B -SB25- 40 A Terminal 15 voltage supply relay -J329- 30       Terminal 15 voltage supply relay 2 -J681-   F26 Fuse 26 on fuse holder B -SB26- 50 A Automatic glow period control unit -J179- 30 F27 Fuse 27 on fuse holder B -SB27- 50 A Radiator fan control unit -J293- 30 F28 Fuse 28 on fuse holder B -SB28- 20 A Fuel pump relay -J17- 30     30 A     F29 Not assigned - - F30 Fuse 30 on fuse holder B -SB30- 40 A ABS control unit -J104- 30 F31 Fuse 31 on fuse holder B -SB31- 40 A ABS control unit -J104- 30 F32 Fuse 32 on fuse holder B -SB32- 40 A Secondary air pump motor -V101- 87       Auxiliary air heater element -Z35-   1) Only models with 2.5l petrol engine 2) Only models with diesel engine 3) Only models with petrol engine 4) For models with dual clutch gearbox 02E only 5) For models with dual clutch gearbox 0AM only 6) Only models with 2.0l petrol engine 7) Only models with Climatronic Back to overview     VW THE BEETLE CABRIOLET 2013 Fitting locationfuse holder C SC Fitting locationfuse holder C -SC- Fitting location fuse holder C -SC- Get access to all wiring diagrams of the car 1 -  Fuse holder C -SC- Fuse colours for ATO flat fuse: t  40 A - orange t  30 A - light green t  25 A - natural (white) t  20 A - yellow t  15 A - light blue t  10 A - red t  7.5 A - brown t  5 A - light brown t  1 A - black Fuse colours for mini fuse: t  20 A - yellow t  15 A - light blue t  10 A - red t  7.5 A - brown t  5 A - light brown t  1 A - black Back to overview     Fuse assignment fuse holder C -SC- , from December 2011 Slot Current Flow Diagram designation Nominal value Function/component Terminal F1 Not assigned - - F2 Not assigned - - F3 Fuse 3 on fuse holder C -SC3- 5 A Control unit in dash panel insert -J285- (T32c/32) 30a F4 Fuse 4 on fuse holder C -SC4- 5 A Telephone transmitter and receiver unit -R36- (T54/1) 30a       Control unit in dash panel insert -J285- (T32c/13)   F5 Fuse 5 on fuse holder C -SC5- 10 A Onboard supply control unit -J519- (T73a/6) 55a       Rear left fog light bulb -L46- (2)   F6 Fuse 6 on fuse holder C -SC6- 10 A Rear lid handle release button -E234- (4) 30a     Reversing camera -R189- (T4ak/1)         Switch and instrument illumination regulator -E20- (T8e/3) F7 Fuse 7 on fuse holder C -SC7- 5 A Left number plate light -X4- (2) 58     Right number plate light -X5- (2)   F8 Fuse 8 on fuse holder C -SC8- 7.5 A Washer pump -V5- (1) 53c F9 Fuse 9 on fuse holder C -SC9- 10 A Airbag control unit -J234- (T100/51), (T100/76) 15a       Front passenger front airbag deactivated warning lamp -K145- (T4g/3) F10 Fuse 10 on fuse holder C -SC10- 10 A Intermittent wiper switch -E22- (T10m/3) 15a F11 Not assigned - - F12 Fuse 12 on fuse holder C -SC12- 5 A Headlight range control unit -J431- (T26c/23) 15a   Main switch for stop/start system -E101- (T6bx/4), (T6bx/2)         Fold-in mirror switch -E263- (T10o/5)       Tyre Pressure Loss Indicator display button -E492- (T6an/4)         Reversing light switch -F4- (1)         High-pressure sender -G65- (T3c/3) F13 Fuse 13 on fuse holder C -SC13- 5 A Air quality sensor -G238- (T3an/1) 15a       Heater control unit -J162- (T20c/19)       Parking aid control unit -J446- (T16m/1)         Automatic anti-dazzle interior mirror -Y7- (T6am/1)     Left washer jet heater element -Z20- (1)     Right washer jet heater element -Z21- (1)         Turn signal switch -E2- (T16j/1)       Tiptronic switch -F189- (T10s/9)         Oil level and oil temperature sender -G266- (1)         -GX22- (T10ak/3)       ABS control unit -J104- (T47/8) F14 Fuse 14 on fuse holder C -SC14- 10 A Control unit in dash panel insert -J285- (T32c/31) 15a       Power steering control unit -J500- (T3ao/3)       Steering column electronics control unit -J527- (T16p/14)         Voltage stabiliser -J532- (T12z/3)       Data bus diagnostic interface -J533- (T20/14)         Fuel pump control unit -J538- (T10v/3)         Selector lever sensors control unit -J587- (T10s/9)         Engine control unit -J623- (T91/50) 27)     Heater element for crankcase breather -N79- (1)21)       Switch and instrument illumination regulator -E20- (T8e/1)       Air mass meter -G70- (T5d/3)13) (T5d/5)4) (T3ar/2)7) F15 Fuse 15 on fuse holder C -SC15- 5 A Engine sound generator control unit -J943- (T12p/1)29) 15a     Left headlight range control motor -V48- (T10i/1)       Right headlight range control motor -V49- (T10j/1)       16-pin connector -T16- (T16/1), Diagnostic connection   F16 Fuse 16 on fuse holder C -SC16- 5 A Engine control unit -J623- (T94/87) 15a F17 Fuse 17 on fuse holder C -SC17- 10 A Interior monitoring sensor -G273- (T4bz/4) 30a     Alarm horn -H12- (T3f/3)   F18 Fuse 18 on fuse holder C -SC18- 15 A Left headlight dipped beam bulb -M29- (T10i/6) 56bl F19 Fuse 19 on fuse holder C -SC19- 15 A Right headlight dipped beam bulb -M31- (T10j/6) 56br     Tiptronic switch -F189- (T10s/10)     Heater control unit -J162- (T20c/18)     Automatic gearbox control unit -J217- (T52/3) F20 Fuse 20 on fuse holder C -SC20- 5 A Climatronic control unit -J255- (T20c/20) 30a   Air conditioning system control unit -J301- (T20c/19)     Selector lever sensors control unit -J587- (T10s/10)       Ignition key withdrawal lock solenoid -N376- (T10d/10) F21 Fuse 21 on fuse holder C -SC21- 15 A Onboard supply control unit -J519- (T73b/68) 30a F22 Fuse 22 on fuse holder C -SC22- 5 A Ignition/starter switch -D- (T10d/1) 30a     Converter box -J935- (T10e/7)   Rain and light sensor -G397- (T3ae/1)       Onboard supply control unit -J519- (T73b/39), (T73a/66)   F23 Fuse 23 on fuse holder C -SC23- 20 A Telephone transmitter and receiver unit -R36- (T54/1) 30a       16-pin connector -T16- (T16/16), Diagnostic connection         -GX22- (T10ak/1)   Entry and start authorisation control unit -J518- (T32d/3)   F24 Fuse 24 on fuse holder C -SC24- 10 A Onboard supply control unit -J519- (T73a/64) 30a     Electronic steering column lock control unit -J764- (T16s/2)       Data bus diagnostic interface -J533- (T20/1)       Multifunction switch -F125- (T10n/10)   F25 Fuse 25 on fuse holder C -SC25- 25 A32) Automatic gearbox control unit -J217- (T52/27)32) (T52/28)32) 15a   10 A Mechatronic unit for dual clutch gearbox -J743- (T25/10)30) (T20/13)31)   F26 Not assigned -   - F27 Not assigned -   - F28 Not assigned -   - F29 Fuse 29 on fuse holder C -SC29- 5 A Onboard supply control unit -J519- (T73b/51) 75     Blocking diode -J29- (1) F30 Fuse 30 on fuse holder C -SC30- 20 A Cigarette lighter -U1- (T3g/2) 75a     12 V socket -U5- (2) F31 Fuse 31 on fuse holder C -SC31- 30 A Light switch -E1- (T17d/1) 75 F32 Fuse 32 on fuse holder C -SC32- 15 A Fog light switch -E7- (T17d/2) 75a F33 Fuse 33 on fuse holder C -SC33- 40 A Heater control unit -J162- (T5/5) 75a     Air conditioning system control unit -J301- (T5/5)     Control unit in dash panel insert -J285- (T32c/14)       Onboard supply control unit -J519- (T73a/62)   F34 Fuse 34 on fuse holder C -SC34- 10 A Left headlight main beam bulb -M30- (T10i/8) 56al     15 A35) Right headlight main beam bulb -M32- (T10j/8)         Front left headlight -MX1- (T14c/11)         Front right headlight -MX2- (T14c/11)   F35 Fuse 35 on fuse holder C -SC35- 1 A Steering column electronics control unit -J527- (T16p/1) 15a F36 Fuse 36 on fuse holder C -SC36- 30 A Onboard supply control unit -J519- (T73a/16) 30a F37 Fuse 37 on fuse holder C -SC37- 5 A Left daytime running light bulb -L174- (T10i/4) TFL F38 Fuse 38 on fuse holder C -SC38- 5 A Right daytime running light bulb -L175- (T10j/4) TFL F39 Fuse 39 on fuse holder C -SC39- 30 A Headlight dipper and flash relay -J- (T9a/3) 30 F40 Fuse 40 on fuse holder C -SC40- 25 A Convertible roof actuation control unit -J256- (T15/6) 30a F41 Fuse 41 on fuse holder C -SC41- 25 A Convertible roof actuation control unit 2 -J1004- (T15a/3) 30a F42 Fuse 42 on fuse holder C -SC42- 25 A Convertible roof actuation control unit 2 -J1004- (T15a/6) 30a F43 Fuse 43 on fuse holder C -SC43- 30 A Front passenger door control unit -J387- (T16d/16) 30a F44 Fuse 44 on fuse holder C -SC44- 30 A Onboard supply control unit -J519- (T73b/67) 30a F45 Fuse 45 on fuse holder C -SC45- 30 A Driver door control unit -J386- (T16c/16) 30a F46 Fuse 46 on fuse holder C -SC46- 25 A Rear left window regulator motor -V26- (T4a/2) 30a     Rear right window regulator motor -V27- (T4ab/2)         Fuel pump relay -J17- (3A) F47 Fuse 47 on fuse holder C -SC47- 20 A Electric fuel pump 2 relay -J49- (3B)17) 30a       Fuel pump control unit -J538- (T10v/1)   F48 Fuse 48 on fuse holder C -SC48- 30 A Onboard supply control unit -J519- (T73b/13), (T73b/11) 30a F49 Fuse 49 on fuse holder C -SC49- 40 A Fresh air blower control unit -J126- (T6l/4) 30a F50 Fuse 50 on fuse holder C -SC50- 30 A Heated front seats control unit -J774- (T8v/3), (T8v/6) 30a F51 Not assigned -   - F52 Fuse 52 on fuse holder C -SC52- 20 A Onboard supply control unit -J519- (T73a/63) 30a F53 Fuse 53 on fuse holder C -SC53- 20 A Onboard supply control unit -J519- (T73a/73) 30a F54 Not assigned -   - F55 Fuse 55 on fuse holder C -SC55- 20 A Light switch -E1- (T17d/15) 30     Headlight dipper and flasher switch -E4- (T16j/10)   F56 Not assigned -   - F57 Fuse 57 on fuse holder C -SC57- 25 A Control unit with display for radio and navigation -J503- (T16b/15), (T16b/16) 30a     Radio -R- (T16b/15), (T16b/16)   F58 Not assigned -   - F59 Not assigned -   - F60 Not assigned -   - 4) Engine code CJAA 7) Engine codes CAYC 13) Engine codes CBFA, CCTA, CCZA 17) Engine codes CFFB, CJAA 21) Engine code CFFB 27) Engine codes CPLA, CPLB, CPPA 30) For models with dual clutch gearbox 02E only 31) For models with dual clutch gearbox 0AM only 32) For models with Tiptronic only 35) Only models with automatic headlight range control Back to overview     VW THE BEETLE CABRIOLET 2013 Fuse assignment fuse holder C -SC- , from July 2013 Slot Current Flow Diagram designation Nominal value Function/component Terminal F1 Fuse 1 on fuse holder C -SC1- - Not assigned - F2 Fuse 2 on fuse holder C -SC2- 10 A Emergency call module control unit and communication unit -J949- 30 F3 Fuse 3 on fuse holder C -SC3- 5 A Control unit in dash panel insert -J285- 30 F4 Fuse 4 on fuse holder C -SC4- 5 A Telephone transmitter and receiver unit -R36- 30 F5 Fuse 5 on fuse holder C -SC5- 10 A Control unit in dash panel insert -J285- 55       Onboard supply control unit -J519-       Rear left fog light bulb -L46-   F6 Fuse 6 on fuse holder C -SC6- 10 A Rear lid handle release button -E234- 30     Reversing camera -R189-   F7 Fuse 7 on fuse holder C -SC7- 5 A Switch and instrument illumination regulator -E20- 58     Left number plate light -X4-     Right number plate light -X5-   F8 Fuse 8 on fuse holder C -SC8- 10 A Washer pump -V5- 53 F9 Fuse 9 on fuse holder C -SC9- 10 A Airbag control unit -J234- 15       Front passenger front airbag deactivated warning lamp -K145-       Seat occupied recognition control unit -J706-   F10 Fuse 10 on fuse holder C -SC10- 15 A Intermittent wiper switch -E22- 15 F11 Not assigned - - F12 Fuse 12 on fuse holder C -SC12- 5 A Headlight range control unit -J431- 15 F13 Fuse 13 on fuse holder C -SC13- 5 A Start/Stop operation button -E693- 15       Fold-in mirror switch -E263-       Tyre Pressure Loss Indicator display button -E492-         Reversing light switch -F4-       High-pressure sender -G65-     Air quality sensor -G238-       Heater control unit -J162-       Parking aid control unit -J446-       Control module for vehicle location system -J895-         Automatic anti-dazzle interior mirror -Y7-     Left washer jet heater element -Z20-     Right washer jet heater element -Z21-   F14 Fuse 14 on fuse holder C -SC14- 10 A CCS switch -E45- 15       Tiptronic switch -F189-       Oil level and oil temperature sender -G266-         -GX22-       ABS control unit -J104-     Control unit in dash panel insert -J285-         Power steering control unit -J500-     Steering column electronics control unit -J527-         Voltage stabiliser -J532-       Data bus diagnostic interface -J533-         Fuel pump control unit -J538-         Selector lever sensors control unit -J587-         Engine control unit -J623-     Heater element for crankcase breather -N79- F15 Fuse 15 on fuse holder C -SC15- 5 A Switch and instrument illumination regulator -E20- 15     Air mass meter -G70-     Control unit for structure-borne sound -J869-       Left headlight range control motor -V48-       Right headlight range control motor -V49-       16-pin connector -T16- , Diagnostic connection   F16 Fuse 16 on fuse holder C -SC16- 5 A Engine control unit -J623- 15 F17 Fuse 17 on fuse holder C -SC17- 10 A Interior monitoring sensor -G273- 30     Vehicle inclination sender -G384-       Alarm horn -H12-   F18 Fuse 18 on fuse holder C -SC18- 15 A Left headlight dipped beam bulb -M29-1) 56b F19 Fuse 19 on fuse holder C -SC19- 15 A Right headlight dipped beam bulb -M31-1) 56b F20 Fuse 20 on fuse holder C -SC20- 5 A Tiptronic switch -F189- 30     Heater control unit -J162-     Automatic gearbox control unit -J217-     Climatronic control unit -J255-       Air conditioning system control unit -J301-       Selector lever sensors control unit -J587-       Ignition key withdrawal lock solenoid -N376- F21 Fuse 21 on fuse holder C -SC21- 15 A Onboard supply control unit -J519- 30 F22 Fuse 22 on fuse holder C -SC22- 5 A Ignition/starter switch -D- 30     Control module for vehicle location system -J895-     Emergency call module control unit and communication unit -J949-         Converter box -J935- F23 Fuse 23 on fuse holder C -SC23- 20 A Rain and light sensor -G397- 30       Onboard supply control unit -J519-     Telephone transmitter and receiver unit -R36-         Emergency call module control unit and communication unit -J949-         16-pin connector -T16- , Diagnostic connection         Additional instruments -GX22- F24 Fuse 24 on fuse holder C -SC24- 10 A Onboard supply control unit -J519-       Entry and start authorisation control unit -J518- 30     Electronic steering column lock control unit -J764-       Data bus diagnostic interface -J533-   F25 Fuse 25 on fuse holder C -SC25- 25 A2) Automatic gearbox control unit -J217-     Multifunction switch -F125- 15   10 A Mechatronic unit for dual clutch gearbox -J743-   F26 Fuse 26 on fuse holder C -SC26- 30 A Vacuum pump for brakes -V192- 15 F27 Not assigned - - F28 Not assigned -   - F29 Fuse 29 on fuse holder C -SC29- 5 A Onboard supply control unit -J519- 75 F30 Fuse 30 on fuse holder C -SC30- 20 A Blocking diode -J29- 75     Cigarette lighter -U1-       12 V socket -U5- F31 Fuse 31 on fuse holder C -SC31- 30 A Light switch -E1- 75 F32 Fuse 32 on fuse holder C -SC32- 15 A Fog light switch -E7- 75 F33 Fuse 33 on fuse holder C -SC33- 40 A Heater control unit -J162- 75     Air conditioning system control unit -J301- F34 Fuse 34 on fuse holder C -SC34- 10 A Control unit in dash panel insert -J285-     15 A35) Onboard supply control unit -J519-       Left headlight main beam bulb -M30- 56a     Right headlight main beam bulb -M32-         Front left headlight -MX1-       Front right headlight -MX2- F35 Fuse 35 on fuse holder C -SC35- 1 A Steering column electronics control unit -J527- 15 F36 Fuse 36 on fuse holder C -SC36- 30 A Onboard supply control unit -J519- 30 F37 Fuse 37 on fuse holder C -SC37- 5 A Left daytime running light bulb -L174- TFL F38 Fuse 38 on fuse holder C -SC38- 5 A Right daytime running light bulb -L175- TFL F39 Fuse 39 on fuse holder C -SC39- 30 A Headlight dipper and flash relay -J- 30 F40 Fuse 40 on fuse holder C -SC40- 25 A Convertible roof actuation control unit -J256- 30 F41 Fuse 41 on fuse holder C -SC41- 25 A Convertible roof actuation control unit 2 -J1004- 30 F42 Fuse 42 on fuse holder C -SC42- 25 A Convertible roof actuation control unit 2 -J1004- 30 F43 Fuse 43 on fuse holder C -SC43- 30 A Front passenger door control unit -J387- 30 F44 Fuse 44 on fuse holder C -SC44- 30 A Onboard supply control unit -J519- 30 F45 Fuse 45 on fuse holder C -SC45- 30 A Driver door control unit -J386- 30 F46 Fuse 46 on fuse holder C -SC46- 30 A Rear left window regulator motor -V26- 30       Rear right window regulator motor -V27-   F47 Fuse 47 on fuse holder C -SC47- 20 A Fuel pump relay -J17- 30     Electric fuel pump 2 relay -J49-         Fuel pump control unit -J538-   F48 Fuse 48 on fuse holder C -SC48- 30 A Onboard supply control unit -J519- 30 F49 Fuse 49 on fuse holder C -SC49- 40 A Fresh air blower control unit -J126- 30 F50 Fuse 50 on fuse holder C -SC50- 30 A Heated front seats control unit -J774- 30 F51 Fuse 51 on fuse holder C -SC51- 30 A Sliding sunroof adjustment control unit -J245- 30 F52 Fuse 52 on fuse holder C -SC52- 20 A Onboard supply control unit -J519- 30 F53 Fuse 53 on fuse holder C -SC53- 20 A Onboard supply control unit -J519- 30 F54 Not assigned -   - F55 Fuse 55 on fuse holder C -SC55- 20 A Light switch -E1- 30     Headlight dipper and flasher switch -E4-   F56 Not assigned -   - F57 Fuse 57 on fuse holder C -SC57- 25 A Control unit with display for radio and navigation -J503- 30     Radio -R- F58 Not assigned -   - F59 Not assigned -   - F60 Not assigned -   - 1) Not for models with dual clutch gearbox 2) For models with Tiptronic only Back to overview     VW THE BEETLE CABRIOLET 2013 Fuse assignment fuse holder C -SC- , from July 2014 Slot Current Flow Diagram designation Nominal value Function/component Terminal F1 Fuse 1 on fuse holder C -SC1- 5 A Blind spot monitor control unit 2 -J1087- 15 F2 Fuse 2 on fuse holder C -SC2- 10 A Emergency call module control unit and communication unit -J949- 30 F3 Fuse 3 on fuse holder C -SC3- 5 A Control unit in dash panel insert -J285- 30 F4 Fuse 4 on fuse holder C -SC4- 5 A Telephone transmitter and receiver unit -R36- 30 F5 Fuse 5 on fuse holder C -SC5- 10 A Control unit in dash panel insert -J285- 55       Onboard supply control unit -J519-       Rear left fog light bulb -L46-   F6 Fuse 6 on fuse holder C -SC6- 10 A Rear lid handle release button -E234- 30     Reversing camera -R189-   F7 Fuse 7 on fuse holder C -SC7- 5 A Switch and instrument illumination regulator -E20- 58     Left number plate light -X4-     Right number plate light -X5-   F8 Fuse 8 on fuse holder C -SC8- 10 A Washer pump -V5- 53 F9 Fuse 9 on fuse holder C -SC9- 10 A Airbag control unit -J234- 15       Front passenger front airbag deactivated warning lamp -K145-       Seat occupied recognition control unit -J706-   F10 Fuse 10 on fuse holder C -SC10- 15 A Intermittent wiper switch -E22- 15 F11 Fuse 11 on fuse holder C -SC11- 5 A Light switch -E1- 15 F12 Not assigned - - F13 Fuse 13 on fuse holder C -SC13- 5 A Start/Stop operation button -E693- 15       Fold-in mirror switch -E263-       Tyre Pressure Loss Indicator display button -E492-         Reversing light switch -F4-       High-pressure sender -G65-     Air quality sensor -G238-       Heater control unit -J162-       Parking aid control unit -J446-       Control module for vehicle location system -J895-         Automatic anti-dazzle interior mirror -Y7-     Left washer jet heater element -Z20-     Right washer jet heater element -Z21-   F14 Fuse 14 on fuse holder C -SC14- 10 A CCS switch -E45- 15       Tiptronic switch -F189-       Oil level and oil temperature sender -G266-         -GX22-       ABS control unit -J104-     Control unit in dash panel insert -J285-         Power steering control unit -J500-     Steering column electronics control unit -J527-         Voltage stabiliser -J532-       Data bus diagnostic interface -J533-         Fuel pump control unit -J538-         Selector lever sensors control unit -J587-         Engine control unit -J623-     Heater element for crankcase breather -N79- F15 Fuse 15 on fuse holder C -SC15- 5 A Switch and instrument illumination regulator -E20- 15     Air mass meter -G70-     Control unit for structure-borne sound -J869-       Left headlight range control motor -V48-       Right headlight range control motor -V49-       16-pin connector -T16- , Diagnostic connection   F16 Fuse 16 on fuse holder C -SC16- 5 A Engine control unit -J623- 15 F17 Fuse 17 on fuse holder C -SC17- 10 A Interior monitoring sensor -G273- 30     Vehicle inclination sender -G384-       Alarm horn -H12-   F18 Fuse 18 on fuse holder C -SC18- 15 A Left headlight dipped beam bulb -M29-1) 56b F19 Fuse 19 on fuse holder C -SC19- 15 A Right headlight dipped beam bulb -M31-1) 56b F20 Fuse 20 on fuse holder C -SC20- 10 A Tiptronic switch -F189- 30     Heater control unit -J162-     Automatic gearbox control unit -J217-     Climatronic control unit -J255-       Air conditioning system control unit -J301-       Selector lever sensors control unit -J587-       Ignition key withdrawal lock solenoid -N376- F21 Fuse 21 on fuse holder C -SC21- 15 A Onboard supply control unit -J519- 30 F22 Fuse 22 on fuse holder C -SC22- 5 A Ignition/starter switch -D- 30     Control module for vehicle location system -J895-     Emergency call module control unit and communication unit -J949-         Converter box -J935- F23 Fuse 23 on fuse holder C -SC23- 10 A Rain and light sensor -G397- 30       Onboard supply control unit -J519-     Telephone transmitter and receiver unit -R36-         Emergency call module control unit and communication unit -J949-         16-pin connector -T16- , Diagnostic connection         Additional instruments -GX22- F24 Fuse 24 on fuse holder C -SC24- 10 A Onboard supply control unit -J519-       Entry and start authorisation control unit -J518- 30     Electronic steering column lock control unit -J764-       Data bus diagnostic interface -J533-   F25 Fuse 25 on fuse holder C -SC25- 25 A2) Automatic gearbox control unit -J217-     Multifunction switch -F125- 15   10 A Mechatronic unit for dual clutch gearbox -J743-   F26 Fuse 26 on fuse holder C -SC26- 30 A Vacuum pump for brakes -V192- - F27 Not assigned - - F28 Fuse 28 on fuse holder C -SC28- 25 A Terminal 75 voltage supply relay 1 -J680- 75 F29 Fuse 29 on fuse holder C -SC29- 5 A Onboard supply control unit -J519- 75 F30 Fuse 30 on fuse holder C -SC30- 20 A Blocking diode -J29- 75     Cigarette lighter -U1-       12 V socket -U5- F31 Fuse 31 on fuse holder C -SC31- 30 A Light switch -E1- 75 F32 Fuse 32 on fuse holder C -SC32- 15 A Fog light switch -E7- 75 F33 Fuse 33 on fuse holder C -SC33- 40 A Heater control unit -J162- 75     Air conditioning system control unit -J301- F34 Fuse 34 on fuse holder C -SC34- 10 A3) Control unit in dash panel insert -J285- 30   15 A4) Onboard supply control unit -J519-       Left headlight main beam bulb -M30- 56     Right headlight main beam bulb -M32-         Front left headlight -MX1-       Front right headlight -MX2- F35 Fuse 35 on fuse holder C -SC35- 1 A Steering column electronics control unit -J527- 15 F36 Fuse 36 on fuse holder C -SC36- 30 A Onboard supply control unit -J519- 30 F37 Fuse 37 on fuse holder C -SC37- 5 A Left daytime running light bulb -L174- TFL F38 Fuse 38 on fuse holder C -SC38- 5 A Right daytime running light bulb -L175- TFL F39 Fuse 39 on fuse holder C -SC39- 30 A Headlight dipper and flash relay -J- 30 F40 Fuse 40 on fuse holder C -SC40- 25 A Convertible roof actuation control unit -J256- 30 F41 Fuse 41 on fuse holder C -SC41- 25 A Convertible roof actuation control unit 2 -J1004- 30 F42 Fuse 42 on fuse holder C -SC42- 25 A Convertible roof actuation control unit 2 -J1004- 30 F43 Fuse 43 on fuse holder C -SC43- 30 A Front passenger door control unit -J387- 30 F44 Fuse 44 on fuse holder C -SC44- 30 A Onboard supply control unit -J519- 30 F45 Fuse 45 on fuse holder C -SC45- 30 A Driver door control unit -J386- 30 F46 Fuse 46 on fuse holder C -SC46- 30 A Rear left window regulator motor -V26- 30       Rear right window regulator motor -V27-   F47 Fuse 47 on fuse holder C -SC47- 20 A Fuel pump relay -J17- 30     Electric fuel pump 2 relay -J49-         Fuel pump control unit -J538-   F48 Fuse 48 on fuse holder C -SC48- 30 A Onboard supply control unit -J519- 30 F49 Fuse 49 on fuse holder C -SC49- 40 A Fresh air blower control unit -J126- 30 F50 Fuse 50 on fuse holder C -SC50- 30 A Heated front seats control unit -J774- 30 F51 Fuse 51 on fuse holder C -SC51- 30 A Sliding sunroof adjustment control unit -J245- 30 F52 Fuse 52 on fuse holder C -SC52- 20 A Onboard supply control unit -J519- 30 F53 Fuse 53 on fuse holder C -SC53- 20 A Onboard supply control unit -J519- 30 F54 Fuse 54 on fuse holder C -SC54- 25 A Automatic gearbox control unit -J217- 30 F55 Fuse 55 on fuse holder C -SC55- 20 A Light switch -E1- 30     Headlight dipper and flasher switch -E4-   F56 Fuse 56 on fuse holder C -SC56- 20 A Onboard supply control unit -J519- 30 F57 Fuse 57 on fuse holder C -SC57- 25 A Control unit with display for radio and navigation -J503- 30     Radio -R- F58 Fuse 58 on fuse holder C -SC58- 10 A Relay for reducing agent metering system -J963- 30 F59 Not assigned -   - F60 Not assigned -   - 1) Not for models with dual clutch gearbox 2) For models with Tiptronic only 3) Only models with xenon headlights 4) Only models with halogen headlights Back to overview     VW THE BEETLE CABRIOLET 2013 Overview of earth points Overview of earth points Get access to all wiring diagrams of the car    1 Earth strap, battery - body q   Specified torque 20 Nm    12 Earth point on left in engine compartment q   Specified torque 20 Nm    642 Earth point for electronically controlled fan q   Specified torque 9 Nm    652 Earth point, engine and gearbox earth q   Specified torque 20 Nm    655 Earth​ point​ on​ left​ headlight​ q   Specified torque 9 Nm    656 Earth point on right headlight q   Specified torque 9 Nm Get access to all wiring diagrams of the car    44 Earth point on lower part of left A-pillar q   Specified torque 9 Nm    45 Earth​ point,​ behind​ centre​ of​ dash​ panel​ q   Specified torque 9 Nm    47 Earth point, in front right footwell q   Specified torque 9 Nm    602 Earth point in front left footwell q   Specified torque 9 Nm    605 Earth point on top end of steering column q   Specified torque 9 Nm    638 Earth point on right A-pillar q   Specified torque 9 Nm Get access to all wiring diagrams of the car    662 Earth point in rear left side panel q   Specified torque 9 Nm Get access to all wiring diagrams of the car    663 Earth point, in rear right side panel q   Specified torque 9 Nm VW THE BEETLE CABRIOLET 2013 Overview of control units Overview of control units Get access to all wiring diagrams of the car q   Fitting location with 105-pin connector -T105- / 91-pin connector -T91- 8 -  Mechatronic unit for dual clutch gearbox -J743- , 02E q   Fitting location with 20-pin connector -T20e- 10 -  Control unit for NOx sender -J583- q   Fitting location with 5-pin connector -T5x- VW THE BEETLE CABRIOLET 2013 Radiator fan control unit J293 Radiator fan control unit -J293- Fitting location: On radiator.     Get access to all wiring diagrams of the car 1 -  Radiator fan control unit -J293- A -  4-pin connector -T4x- Connector assignment of radiator fan control unit -J293-     -T4x- (A) Designation 1 Terminal 30 2 Terminal 87 3 Fan speed, engine control unit -J623- 4 Terminal 31 Back to overview VW THE BEETLE CABRIOLET 2013 ABS control unit J104 ABS control unit -J104- Fitting location: In engine compartment.     Get access to all wiring diagrams of the car 1 -  ABS control unit -J104- A -  47-pin connector -T47a- Connector assignment of ABS control unit -J104-     -T47a- (A) Designation   -T47a- (A) Designation 1 Terminal 30   25 2 26 3 27 4 28 5 Brake servo vacuum sender -G483- 29 6 30 7 31 8 Terminal 15 32 Terminal 30 9 33 Front right speed sensor -G45- 10 34 Front right speed sensor -G45- 11 35 Tyre Pressure Loss Indicator display button -E492- 12 Connection 1 (powertrain CAN bus, high), in main wiring harness 36 Rear left speed sensor -G46- 13 Connection 1 (powertrain CAN bus, low), in main wiring harness 37 Rear left speed sensor -G46- 14     38 Connection (54), in interior light wiring harness -B131- 15     39 16     40 Brake servo vacuum sender -G483- 17   41 Brake servo vacuum sender -G483- 18   42 Rear right speed sensor -G44- 19   43 Rear right speed sensor -G44- 20     44 21     45 Front left speed sensor -G47- 22     46 Front left speed sensor -G47- 23   47 Terminal 31 24         Back to overview VW THE BEETLE CABRIOLET 2013 Control unit for structure-borne sound J869 Control unit for structure-borne sound -J869- Fitting location: in plenum chamber     Get access to all wiring diagrams of the car 1 -  Control unit for structure-borne sound -J869- A -  12-pin connector -T12p- Connector assignment of control unit for structure-borne sound -J869-     -T12p- (A) Designation   -T12p- (A) Designation 1 Terminal 15 7 Actuator for structure-borne sound -R214- 2 Terminal 31 8 Actuator for structure-borne sound -R214- 3     9 4     10   5     11   6 Connection 1 (powertrain CAN bus, low), in main wiring harness 12 Connection 1 (powertrain CAN bus, high), in main wiring harness Back to overview VW THE BEETLE CABRIOLET 2013 Battery monitoring control unit J367 Battery monitoring control unit -J367- Fitting location: On battery.     Get access to all wiring diagrams of the car 1 -  Battery monitoring control unit -J367- A -  2-pin connector -T2- Connector assignment of battery monitor control unit -J367-     -T2- (A) Designation 1 LIN bus 2 Terminal 30 Back to overview VW THE BEETLE CABRIOLET 2013 Power steering control unit J500 Power steering control unit -J500- Fitting location: Near steering box.     Get access to all wiring diagrams of the car 1 -  Power steering control unit -J500- A -  3-pin connector -T3ao- B -  2-pin connector -T2l- C -  5-pin connector -T5g- Connector assignment of power steering control unit -J500-     -T2l- (B) Designation   -T3ao- (A) Designation 1 Terminal 31   1 Connection 1 (powertrain CAN bus, low), in main wiring harness 2 Terminal 30   2 Connection 1 (powertrain CAN bus, high), in main wiring harness     3 Terminal 15 Back to overview VW THE BEETLE CABRIOLET 2013 Engine control unit J623 Engine control unit -J623- 1 -  Engine control unit -J623- A -  60-pin connector -T60- B -  94-pin connector -T94- Back to overview 1 -  Engine control unit -J623- A -  105-pin connector -T105- B -  91-pin connector -T91- Back to overview Automatic gearbox control unit -J217- Fitting location: In engine compartment.     Get access to all wiring diagrams of the car 1 -  Automatic gearbox control unit -J217- A -  52-pin connector -T52- Connector assignment of automatic gearbox control unit -J217-     -T52- (A) Designation   -T52- (A) Designation 1 Terminal 31   27 Terminal 15 2 Terminal 31 28 Terminal 15 3 Terminal 30 29 Tiptronic switch -F189- 4 Solenoid valve 10 -N283- 30 Solenoid valve 3 -N90- 5 Solenoid valve 4 -N91- 31 Solenoid valve 6 -N93- 6 Solenoid valve 5 -N92- 32 Solenoid valve 9 -N282- 7   33 8 Gearbox oil temperature sender -G93- 34 Connection 1 (powertrain CAN bus, low), in main wiring harness 9 Connection (K-diagnosis wire), in dash panel wiring harness 35 10 Multifunction switch -F125- 36 Multifunction switch -F125- 11   37 12   38 Gearbox output speed sender -G195- 13   39 Front vent temperature sender -G152- 14     40 Tiptronic switch -F189- 15 Solenoid valve 2 -N89-   41 Solenoid valve 1 -N88- 16 Solenoid valve 9 -N282-   42   17 Solenoid valve 6 -N93-   43 Solenoid valve 4 -N91- 18 Solenoid valve 3 -N90-   44 Solenoid valve 10 -N283- 19     45 Gearbox oil temperature sender -G93- 20     46 Connection 1 (powertrain CAN bus, high), in main wiring harness 21 Multifunction switch -F125-   47 Multifunction switch -F125- 22 Multifunction switch -F125-   48 Tiptronic switch -F189- 23   49   24     50 Gearbox output speed sender -G195- 25     51 Front vent temperature sender -G152- 26     52   Back to overview VW THE BEETLE CABRIOLET 2013 Mechatronic unit for dual clutch gearbox J743 Mechatronic unit for dual clutch gearbox -J743- Mechatronic unit for dual clutch gearbox -J743- , 20-pin connector -T20e- Fitting location: On dual clutch gearbox 02E.     Get access to all wiring diagrams of the car 1 -  Mechatronic unit for dual clutch gearbox -J743- A -  20-pin connector -T20e- Connector assignment of mechatronic unit for dual clutch gearbox -J743-     -T20e- (A) Designation   -T20e- (A) Designation 1 Connection (K-diagnosis wire), in dash panel wiring harness   11 Terminal 30 2     12   3     13 Terminal 15 4     14   5     15 Connection 1 (powertrain CAN bus, low), in main wiring harness 6     16 Terminal 31 7     17 Onboard supply control unit -J519- , Starter inhibitor 8     18 Terminal 30 9     19 Terminal 31 10 Connection 1 (powertrain CAN bus, high), in main wiring harness   20   Back to overview 1 -  Mechatronic unit for dual clutch gearbox -J743- A -  25-pin connector -T25- Connector assignment of mechatronic unit for dual clutch gearbox -J743-     -T25- (A) Designation   -T25- (A) Designation 1     14   2     15   3     16 Multifunction switch -F125- , Starter inhibitor 4     17   5     18   6     19   7     20   8 Terminal 31   21   9 Terminal 30   22   10 Terminal 15   23   11     24 Terminal 31 12 Connection 1 (powertrain CAN bus, low), in main wiring harness   25 Terminal 30 13 Connection 1 (powertrain CAN bus, high), in main wiring harness       Back to overview VW THE BEETLE CABRIOLET 2013 Coupling point in engine compartment, left TML 1 -  Control unit for NOx sender -J583- A -  5-pin connector -T5x- Connector assignment of control unit for NOx sender -J583-     -T5x- (A) Designation 1 Connection (87a), in engine wiring harness 2 Earth connection 16, in main wiring harness 3 Engine control unit -J623- 4 Engine control unit -J623- 5   Back to overview     VW THE BEETLE CABRIOLET 2013 2-pin connector -T2j- , 2-pin connector -T2l- black Coupling point in engine compartment, left -TML- Get access to all wiring diagrams of the car B -  14-pin connector -T14a- , black D -  4-pin connector -T4t- , black q   Only models with air conditioning system E -  8-pin connector -T8o- , black Diagnostic connection -U31- Diagnostic connection -U31- , left-hand drive models Get access to all wiring diagrams of the car A -  16-pin connector -T16- , black Diagnostic connection -U31- , right-hand drive models Get access to all wiring diagrams of the car A -  16-pin connector -T16- , black Coupling point in interior -TI- , on heater and air conditioner unit -VX1- Get access to all wiring diagrams of the car A -  10-pin connector -T10k- , on heater and air conditioner unit, front passenger footwell Coupling point on front left door -TTVL- Get access to all wiring diagrams of the car B -  17-pin connector -T17- , black Coupling point for front left seat -TSVL- Get access to all wiring diagrams of the car B -  3-pin connector -T3m- , yellow D -  Coupling point on front right door -TTVR- Get access to all wiring diagrams of the car B -  17-pin connector -T17c- , brown Coupling point for front right seat -TSVR- Get access to all wiring diagrams of the car B -  3-pin connector -T3n- , yellow D -  Coupling point in luggage compartment, right -THRR- Get access to all wiring diagrams of the car B -  3-pin connector -T3a- , black VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013VW THE BEETLE CABRIOLET 2013 Can't find your car? Check -> DiagnostData.com! Login Email or Login Password Remember me Sign up Get a new password Sign up Email Password Confirm password * A password will be generated automatically and sent to your Email Login Get a new password Get a new password Email Login Sign up
