Slot | Current Flow Diagram designation | Nominal value | Function/component | Terminal |
F1 | Not assigned | - | | - |
F2 | Fuse 2 on fuse holder B -SB2- | 30 A | Engine control unit -J623- (T94/5), (T94/3), (T94/6)1) (T91/5)27) (T91/6)27) | 87a |
| | 20 A15) | | |
F3 | Fuse 3 on fuse holder B -SB3- | 5 A | Radiator fan control unit -J293- (T4x/2) | 87a |
F4 | Fuse 4 on fuse holder B -SB4- | 15 A | Lambda probe -G39- (T6w/4)2) (T6w/5)3) | 87a |
| | | Lambda probe after catalytic converter -G130- (T6af/4)4) | |
| | | Lambda probe -G39- (T6w/4)5) (T4am/1)6) (T5e/4)27) | |
| | | Lambda probe after catalytic converter -G130- (T4ao/1)28) | |
| | | Lambda probe 2 after catalytic converter -G131- (T4o/1)13) | |
| | | Centre Lambda probe for bank 1 catalytic converter -G465- (T4v/1)11) | |
| | | Electric fuel pump 2 relay -J49- (1B)17) | |
F5 | Fuse 5 on fuse holder B -SB5- | 10 A | Heater element relay -J925- (1B)7) (3B)7) | 87a |
| | | Charge pressure control solenoid valve -N75- (1)8) | |
| | | Heater element for crankcase breather -N79- (1)4) | |
| | | Camshaft control valve 1 -N205- (1)27) | |
| | | Turbocharger air recirculation valve -N249- (1)27) | |
| | | Intake manifold flap valve -N316- (1)27) | |
| | | Exhaust gas recirculation cooler changeover valve -N345- (1)7) | |
| | | Fuel system diagnostic pump -V144- (T4ay/4)10) | |
| | | Fuel pump relay -J17- (F51)15) | |
| | | Secondary air pump relay -J299- (F71)9) (F81)26) | |
| | | Engine component current supply relay -J757- (F51) 27) | |
| | | Charge pressure control solenoid valve -N75- (1)29) | |
| | | Activated charcoal filter solenoid valve 1 -N80- (1)29) | |
F6 | Fuse 6 on fuse holder B -SB6- | 10 A | Secondary air inlet valve -N112- (1)36) | 87a |
| | | Camshaft control valve 1 -N205- (1)13) | |
| | | Turbocharger air recirculation valve -N249- (1)13) | |
| | | Intake manifold flap valve -N316- (1)13) | |
| | | Valve for oil pressure control -N428- (2)14) | |
| | | Coolant circulation pump 2 -V178- (2)27) | |
| | | Throttle valve module -J338- (2)4) | |
| | | Ignition coil 1 with output stage -N70- (T4af/1)25) (3)18) | |
| | | Ignition coil 2 with output stage -N127- (T4ag/1)25) (3)18) | |
| | | Ignition transformer -N152- (T4aa/2)16) | |
F7 | Fuse 7 on fuse holder B -SB7- | 30 A | Fuel pressure regulating valve -N276- (2)8) | 87a |
| | 20 A8) | Fuel metering valve -N290- (2)8) | |
| | | Ignition coil 3 with output stage -N291- (T4ah/1)25) (3)18) | |
| | | Ignition coil 4 with output stage -N292- (T4ai/1)25) (3)18) | |
| | | Ignition coil 5 with output stage -N323- (T4aj/1)15) | |
| | | Air mass meter -G70- (T4j/1) 21) | |
| | | Fuel pump relay -J17- (1A)8) | |
| | | Charge pressure control solenoid valve -N75- (1)18) | |
| | | Activated charcoal filter solenoid valve 1 -N80- (1)19) | |
| | | Camshaft control valve 1 -N205- (1)20) | |
F8 | Fuse 8 on fuse holder B -SB8- | 10 A | Exhaust gas recirculation valve 2 -N213- (1)21) | 87a |
| | | Turbocharger air recirculation valve -N249- (1)18) | |
| | | Magnetic clutch for supercharger -N421- (1)18) | |
| | | Valve for oil pressure control -N428- (2)15) | |
| | | Coolant regulating valve -N515- (1)16) | |
| | | Coolant circulation pump 2 -V178- (2)21) | |
| | | Continued coolant circulation relay -J151- (F41)12) (F43)12) | |
| | | Automatic glow period control unit -J179- (T11b/6)8) | |
| | | Low heat output relay -J359- (F71)23) | |
F9 | Fuse 9 on fuse holder B -SB9- | 10 A | High heat output relay -J360- (F81)23) | 87a |
| | | Additional coolant pump relay -J496- (F41)22) (F43)22) | |
| | | Engine component current supply relay -J757- (F51)12) | |
| | | Fuel pressure regulating valve -N276- (1)22) | |
| | | Coolant circulation pump 2 -V178- (2)7) | |
F10 | Fuse 10 on fuse holder B -SB10- | 5 A | Clutch position sender -G476- (T5m/5) | 87a |
| | | Brake light switch -F- (T4y/4) | |
F11 | Not assigned | - | | - |
F12 | Not assigned | - | | - |
| | | Voltage stabiliser -J532- (T12z/1) | |
F13 | Fuse 13 on fuse holder B -SB13- | 30 A | Control unit with display for radio and navigation -J503- (T16b/15), (T16b/16) | 30a |
| | | Control unit for navigation system -J856- (T10aa/2) | |
| | | Radio -R- (T16b/15), (T16b/16) | |
| | | Motronic current supply relay -J271- (F61)24) | |
F14 | Fuse 14 on fuse holder B -SB14- | 10 A | Terminal 30 voltage supply relay -J317- (F61)8) | 30a |
| | | Engine control unit -J623- (T94/92), (T91/86)27) | |
F15 | Fuse 15 on fuse holder B -SB15- | 10 A | Alarm horn relay -J641- (3A) | 30a |
F16 | Fuse 16 on fuse holder B -SB16- | 40 A | Amplifier -R12- (T38/2) | 30a |
F17 | Fuse 17 on fuse holder B -SB17- | 15 A30) | Mechatronic unit for dual clutch gearbox -J743- (T25/9)30) | 30a |
| | 30 A31) | Mechatronic unit for dual clutch gearbox -J743- (T20/11)31) (T20/18)31) | |
F18 | Fuse 18 on fuse holder B -SB18- | 15 A | Mechatronic unit for dual clutch gearbox -J743- (T25/25)30) | 30a |
F19 | Fuse 19 on fuse holder B -SB19- | 5 A | Onboard supply control unit -J519- (T73b/59) | 30a |
| | | Battery monitoring control unit -J367- (2) | |
F20 | Fuse 20 on fuse holder B -SB20- | 30 A | Onboard supply control unit -J519- (T73a/68) | 30a |
F21 | Fuse 21 on fuse holder B -SB21- | 40 A | Auxiliary air heater element -Z35- (T3am/1)23) | 10 |
| | 50 A26) | Secondary air pump motor -V101- (2)26) | |
F22 | Fuse 22 on fuse holder B -SB22- | 40 A | Auxiliary air heater element -Z35- (T3am/3)23) | 10 |
| | | Fuse 40 on fuse holder C -SC40- | |
F23 | Fuse 23 on fuse holder B -SB23- | 50 A | Fuse 41 on fuse holder C -SC41- | 30a |
| | | Fuse 42 on fuse holder C -SC42- | |
F24 | Fuse 24 on fuse holder B -SB24- | 40 A | Terminal 75 voltage supply relay 1 -J680- (T9m/3) | 30a |
| | 50A33) | | |
F25 | Fuse 25 on fuse holder B -SB25- | 40 A | Terminal 15 voltage supply relay -J329- (T9i/3) | 30a |
| | | Terminal 15 voltage supply relay 2 -J681- (T9k/3) | |
F26 | Fuse 26 on fuse holder B -SB26- | 50 A | Automatic glow period control unit -J179- (T11b/11)8) | 30a |
F27 | Fuse 27 on fuse holder B -SB27- | 50 A | Radiator fan control unit -J293- (T4x/1) | 30a |
F28 | Fuse 28 on fuse holder B -SB28- | 20 A | Fuel pump relay -J17- (F53)15) | 30a |
| | 30 A29) | Engine component current supply relay -J757- (F53)29) | |
F29 | Not assigned | - | | - |
F30 | Fuse 30 on fuse holder B -SB30- | 40 A | ABS control unit -J104- (T47/1) | 30a |
F31 | Fuse 31 on fuse holder B -SB31- | 40 A | ABS control unit -J104- (T47/32) | 30a |
F32 | Fuse 32 on fuse holder B -SB32- | 40 A | Auxiliary air heater element -Z35- (T3am/2)23) | 30a |
| | | Secondary air pump motor -V101- (2)9) | |
Slot | Current Flow Diagram designation | Nominal value | Function/component | Terminal |
F1 | Not assigned | - | | - |
F2 | Fuse 2 on fuse holder B -SB2- | 30 A 20 A1) | Engine control unit -J623- | 87 |
F3 | Fuse 3 on fuse holder B -SB3- | 5 A | Radiator fan control unit -J293- | 87 |
F4 | Fuse 4 on fuse holder B -SB4- | 15 A | Lambda probe -G39- | 87 |
| | | Lambda probe after catalytic converter -G130- | |
F5 | Fuse 5 on fuse holder B -SB5- | 10 A | Lambda probe -G39- | 87 |
| | | Lambda probe after catalytic converter -G130- | |
| | | Centre Lambda probe for bank 1 catalytic converter -G465- | |
| | | Electric fuel pump 2 relay -J49- | |
| | | Heater element relay -J925- | |
| | | Charge pressure control solenoid valve -N75- | |
| | | Heater element for crankcase breather -N79- | |
| | | Camshaft control valve 1 -N205- | |
| | | Turbocharger air recirculation valve -N249- | |
| | | Intake manifold flap valve -N316- | |
| | | Exhaust gas recirculation cooler changeover valve -N345- | |
| | | Fuel system diagnostic pump -V144- | |
F6 | Fuse 6 on fuse holder B -SB6- | 10 A | Fuel pump relay -J17- | 87 |
| | | Secondary air pump relay -J299- | |
| | | Engine component current supply relay -J757- | |
| | | Charge pressure control solenoid valve -N75- | |
| | | Activated charcoal filter solenoid valve 1 -N80- | |
| | | Secondary air inlet valve -N112- | |
| | | Camshaft control valve 1 -N205- | |
| | | Turbocharger air recirculation valve -N249- | |
| | | Intake manifold flap valve -N316- | |
| | | Valve for oil pressure control -N428- | |
| | | Coolant circulation pump 2 -V178- | |
F7 | Fuse 7 on fuse holder B -SB7- | 20 A2) 30 A3) | Throttle valve module -J338- | 87 |
| | | Ignition coil 1 with output stage -N70- | |
| | | Ignition coil 2 with output stage -N127- | |
| | | Ignition transformer -N152- | |
| | | Fuel pressure regulating valve -N276- | |
| | | Fuel metering valve -N290- | |
| | | Ignition coil 3 with output stage -N291- | |
| | | Ignition coil 4 with output stage -N292- | |
| | | Ignition coil 5 with output stage -N323- | |
F8 | Fuse 8 on fuse holder B -SB8- | 10 A | Air mass meter -G70- | 87 |
| | | Fuel pump relay -J17- | |
| | | Charge pressure control solenoid valve -N75- | |
| | | Activated charcoal filter solenoid valve 1 -N80- | |
| | | Camshaft control valve 1 -N205- | |
| | | Exhaust gas recirculation valve 2 -N213- | |
| | | Turbocharger air recirculation valve -N249- | |
| | | Magnetic clutch for supercharger -N421- | |
| | | Valve for oil pressure control -N428- | |
| | | Coolant regulating valve -N515- | |
| | | Coolant circulation pump 2 -V178- | |
F9 | Fuse 9 on fuse holder B -SB9- | 10 A | Continued coolant circulation relay -J151- | 87 |
| | | Automatic glow period control unit -J179- | |
| | | Low heat output relay -J359- | |
| | | High heat output relay -J360- | |
| | | Additional coolant pump relay -J496- | |
| | | Engine component current supply relay -J757- | |
| | | Fuel pressure regulating valve -N276- | |
| | | Coolant circulation pump 2 -V178- | |
F10 | Fuse 10 on fuse holder B -SB10- | 5 A | Clutch position sender -G476- | 87 |
| | | Brake light switch -F- | |
F11 | Not assigned | - | | - |
F12 | Not assigned | - | | - |
F13 | Fuse 13 on fuse holder B -SB13- | 30 A | Voltage stabiliser -J532- | 30 |
| | | Control unit with display for radio and navigation -J503- | |
| | | Control unit for navigation system -J856- | |
| | | Radio -R- | |
F14 | Fuse 14 on fuse holder B -SB14- | 10 A | Motronic current supply relay -J271- | 30 |
| | | Terminal 30 voltage supply relay -J317- | |
| | | Engine control unit -J623- | |
F15 | Fuse 15 on fuse holder B -SB15- | 10 A | Alarm horn relay -J641- | 30 |
F16 | Fuse 16 on fuse holder B -SB16- | 40 A | Amplifier -R12- | 30 |
F17 | Fuse 17 on fuse holder B -SB17- | 15 A4) 30 A5) | Mechatronic unit for dual clutch gearbox -J743- | 30 |
F18 | Fuse 18 on fuse holder B -SB18- | 15 A | Mechatronic unit for dual clutch gearbox -J743-4) | 30 |
F19 | Fuse 19 on fuse holder B -SB19- | 5 A | Onboard supply control unit -J519- | 30 |
F20 | Fuse 20 on fuse holder B -SB20- | 30 A | Onboard supply control unit -J519- | 30 |
F21 | Fuse 21 on fuse holder B -SB21- | 40 A | Auxiliary air heater element -Z35- | 87 |
| | 50 A6) | Secondary air pump motor -V101- | |
F22 | Fuse 22 on fuse holder B -SB22- | 40 A | Auxiliary air heater element -Z35- | 87 |
F23 | Fuse 23 on fuse holder B -SB23- | 50 A | Fuse 40 on fuse holder C -SC40- | 30 |
| | | Fuse 41 on fuse holder C -SC41- | |
| | | Fuse 42 on fuse holder C -SC42- | |
F24 | Fuse 24 on fuse holder B -SB24- | 40 A | Terminal 75 voltage supply relay 1 -J680- | 30 |
| | 50 A7) | | |
F25 | Fuse 25 on fuse holder B -SB25- | 40 A | Terminal 15 voltage supply relay -J329- | 30 |
| | | Terminal 15 voltage supply relay 2 -J681- | |
F26 | Fuse 26 on fuse holder B -SB26- | 50 A | Automatic glow period control unit -J179- | 30 |
F27 | Fuse 27 on fuse holder B -SB27- | 50 A | Radiator fan control unit -J293- | 30 |
F28 | Fuse 28 on fuse holder B -SB28- | 20 A | Fuel pump relay -J17- | 30 |
F29 | Not assigned | - | | - |
F30 | Fuse 30 on fuse holder B -SB30- | 40 A | ABS control unit -J104- | 30 |
F31 | Fuse 31 on fuse holder B -SB31- | 40 A | ABS control unit -J104- | 30 |
F32 | Fuse 32 on fuse holder B -SB32- | 40 A | Secondary air pump motor -V101- | 87 |
| | | Auxiliary air heater element -Z35- | |
Slot | Current Flow Diagram designation | Nominal value | Function/component | Terminal |
F1 | Not assigned | - | | - |
F2 | Fuse 2 on fuse holder B -SB2- | 30 A 20 A1) | Engine control unit -J623- | 87 |
F3 | Fuse 3 on fuse holder B -SB3- | 5 A | Radiator fan control unit -J293- | 87 |
F4 | Fuse 4 on fuse holder B -SB4- | 15 A | Lambda probe -G39- | 87 |
| | | Lambda probe after catalytic converter -G130- | |
F5 | Fuse 5 on fuse holder B -SB5- | 10 A | Lambda probe -G39- | 87 |
| | | Lambda probe after catalytic converter -G130- | |
| | | Centre Lambda probe for bank 1 catalytic converter -G465- | |
| | | Electric fuel pump 2 relay -J49- | |
| | | Heater element relay -J925- | |
| | | Charge pressure control solenoid valve -N75- | |
| | | Heater element for crankcase breather -N79- | |
| | | Camshaft control valve 1 -N205- | |
| | | Turbocharger air recirculation valve -N249- | |
| | | Intake manifold flap valve -N316- | |
| | | Exhaust gas recirculation cooler changeover valve -N345- | |
| | | Fuel system diagnostic pump -V144- | |
F6 | Fuse 6 on fuse holder B -SB6- | 10 A | Fuel pump relay -J17- | 87 |
| | | Secondary air pump relay -J299- | |
| | | Engine component current supply relay -J757- | |
| | | Charge pressure control solenoid valve -N75- | |
| | | Activated charcoal filter solenoid valve 1 -N80- | |
| | | Secondary air inlet valve -N112- | |
| | | Camshaft control valve 1 -N205- | |
| | | Turbocharger air recirculation valve -N249- | |
| | | Intake manifold flap valve -N316- | |
| | | Valve for oil pressure control -N428- | |
| | | Coolant circulation pump 2 -V178- | |
F7 | Fuse 7 on fuse holder B -SB7- | 20 A2) 30 A3) | Throttle valve module -J338- | 87 |
| | | Ignition coil 1 with output stage -N70- | |
| | | Ignition coil 2 with output stage -N127- | |
| | | Ignition transformer -N152- | |
| | | Fuel pressure regulating valve -N276- | |
| | | Fuel metering valve -N290- | |
| | | Ignition coil 3 with output stage -N291- | |
| | | Ignition coil 4 with output stage -N292- | |
| | | Ignition coil 5 with output stage -N323- | |
F8 | Fuse 8 on fuse holder B -SB8- | 10 A | Air mass meter -G70- | 87 |
| | | Fuel pump relay -J17- | |
| | | Charge pressure control solenoid valve -N75- | |
| | | Activated charcoal filter solenoid valve 1 -N80- | |
| | | Camshaft control valve 1 -N205- | |
| | | Exhaust gas recirculation valve 2 -N213- | |
| | | Turbocharger air recirculation valve -N249- | |
| | | Magnetic clutch for supercharger -N421- | |
| | | Valve for oil pressure control -N428- | |
| | | Coolant regulating valve -N515- | |
| | | Coolant circulation pump 2 -V178- | |
F9 | Fuse 9 on fuse holder B -SB9- | 10 A | Continued coolant circulation relay -J151- | 87 |
| | | Automatic glow period control unit -J179- | |
| | | Low heat output relay -J359- | |
| | | High heat output relay -J360- | |
| | | Additional coolant pump relay -J496- | |
| | | Engine component current supply relay -J757- | |
| | | Fuel pressure regulating valve -N276- | |
| | | Coolant circulation pump 2 -V178- | |
F10 | Fuse 10 on fuse holder B -SB10- | 5 A | Clutch position sender -G476- | 87 |
| | | Brake light switch -F- | |
F11 | Not assigned | - | | - |
F12 | Not assigned | - | | - |
F13 | Fuse 13 on fuse holder B -SB13- | 30 A | Voltage stabiliser -J532- | 30 |
| | | Control unit with display for radio and navigation -J503- | |
| | | Control unit for navigation system -J856- | |
| | | Radio -R- | |
F14 | Fuse 14 on fuse holder B -SB14- | 10 A | Motronic current supply relay -J271- | 30 |
| | | Terminal 30 voltage supply relay -J317- | |
| | | Engine control unit -J623- | |
F15 | Fuse 15 on fuse holder B -SB15- | 10 A | Alarm horn relay -J641- | 30 |
F16 | Fuse 16 on fuse holder B -SB16- | 40 A | Amplifier -R12- | 30 |
F17 | Fuse 17 on fuse holder B -SB17- | 15 A4) 30 A5) | Mechatronic unit for dual clutch gearbox -J743- | 30 |
F18 | Fuse 18 on fuse holder B -SB18- | 15 A | Mechatronic unit for dual clutch gearbox -J743-4) | 30 |
F19 | Fuse 19 on fuse holder B -SB19- | 5 A | Onboard supply control unit -J519- | 30 |
F20 | Fuse 20 on fuse holder B -SB20- | 30 A | Onboard supply control unit -J519- | 30 |
F21 | Fuse 21 on fuse holder B -SB21- | 40 A | Auxiliary air heater element -Z35- | 87 |
| | 50 A6) | Secondary air pump motor -V101- | |
F22 | Fuse 22 on fuse holder B -SB22- | 40 A | Auxiliary air heater element -Z35- | 87 |
F23 | Fuse 23 on fuse holder B -SB23- | 50 A | Fuse 40 on fuse holder C -SC40- | 30 |
| | | Fuse 41 on fuse holder C -SC41- | |
| | | Fuse 42 on fuse holder C -SC42- | |
F24 | Fuse 24 on fuse holder B -SB24- | 40 A | Terminal 75 voltage supply relay 1 -J680- | 30 |
| | 50 A7) | | |
F25 | Fuse 25 on fuse holder B -SB25- | 40 A | Terminal 15 voltage supply relay -J329- | 30 |
| | | Terminal 15 voltage supply relay 2 -J681- | |
F26 | Fuse 26 on fuse holder B -SB26- | 50 A | Automatic glow period control unit -J179- | 30 |
F27 | Fuse 27 on fuse holder B -SB27- | 50 A | Radiator fan control unit -J293- | 30 |
F28 | Fuse 28 on fuse holder B -SB28- | 20 A | Fuel pump relay -J17- | 30 |
| | 30 A | | |
F29 | Not assigned | - | | - |
F30 | Fuse 30 on fuse holder B -SB30- | 40 A | ABS control unit -J104- | 30 |
F31 | Fuse 31 on fuse holder B -SB31- | 40 A | ABS control unit -J104- | 30 |
F32 | Fuse 32 on fuse holder B -SB32- | 40 A | Secondary air pump motor -V101- | 87 |
| | | Auxiliary air heater element -Z35- | |
Slot | Current Flow Diagram designation | Nominal value | Function/component | Terminal |
F1 | Not assigned | - | | - |
F2 | Not assigned | - | | - |
F3 | Fuse 3 on fuse holder C -SC3- | 5 A | Control unit in dash panel insert -J285- (T32c/32) | 30a |
F4 | Fuse 4 on fuse holder C -SC4- | 5 A | Telephone transmitter and receiver unit -R36- (T54/1) | 30a |
| | | Control unit in dash panel insert -J285- (T32c/13) | |
F5 | Fuse 5 on fuse holder C -SC5- | 10 A | Onboard supply control unit -J519- (T73a/6) | 55a |
| | | Rear left fog light bulb -L46- (2) | |
F6 | Fuse 6 on fuse holder C -SC6- | 10 A | Rear lid handle release button -E234- (4) | 30a |
| | | Reversing camera -R189- (T4ak/1) | |
| | | Switch and instrument illumination regulator -E20- (T8e/3) | |
F7 | Fuse 7 on fuse holder C -SC7- | 5 A | Left number plate light -X4- (2) | 58 |
| | | Right number plate light -X5- (2) | |
F8 | Fuse 8 on fuse holder C -SC8- | 7.5 A | Washer pump -V5- (1) | 53c |
F9 | Fuse 9 on fuse holder C -SC9- | 10 A | Airbag control unit -J234- (T100/51), (T100/76) | 15a |
| | | Front passenger front airbag deactivated warning lamp -K145- (T4g/3) | |
F10 | Fuse 10 on fuse holder C -SC10- | 10 A | Intermittent wiper switch -E22- (T10m/3) | 15a |
F11 | Not assigned | - | | - |
F12 | Fuse 12 on fuse holder C -SC12- | 5 A | Headlight range control unit -J431- (T26c/23) | 15a |
| | | Main switch for stop/start system -E101- (T6bx/4), (T6bx/2) | |
| | | Fold-in mirror switch -E263- (T10o/5) | |
| | | Tyre Pressure Loss Indicator display button -E492- (T6an/4) | |
| | | Reversing light switch -F4- (1) | |
| | | High-pressure sender -G65- (T3c/3) | |
F13 | Fuse 13 on fuse holder C -SC13- | 5 A | Air quality sensor -G238- (T3an/1) | 15a |
| | | Heater control unit -J162- (T20c/19) | |
| | | Parking aid control unit -J446- (T16m/1) | |
| | | Automatic anti-dazzle interior mirror -Y7- (T6am/1) | |
| | | Left washer jet heater element -Z20- (1) | |
| | | Right washer jet heater element -Z21- (1) | |
| | | Turn signal switch -E2- (T16j/1) | |
| | | Tiptronic switch -F189- (T10s/9) | |
| | | Oil level and oil temperature sender -G266- (1) | |
| | | -GX22- (T10ak/3) | |
| | | ABS control unit -J104- (T47/8) | |
F14 | Fuse 14 on fuse holder C -SC14- | 10 A | Control unit in dash panel insert -J285- (T32c/31) | 15a |
| | | Power steering control unit -J500- (T3ao/3) | |
| | | Steering column electronics control unit -J527- (T16p/14) | |
| | | Voltage stabiliser -J532- (T12z/3) | |
| | | Data bus diagnostic interface -J533- (T20/14) | |
| | | Fuel pump control unit -J538- (T10v/3) | |
| | | Selector lever sensors control unit -J587- (T10s/9) | |
| | | Engine control unit -J623- (T91/50) 27) | |
| | | Heater element for crankcase breather -N79- (1)21) | |
| | | Switch and instrument illumination regulator -E20- (T8e/1) | |
| | | Air mass meter -G70- (T5d/3)13) (T5d/5)4) (T3ar/2)7) | |
F15 | Fuse 15 on fuse holder C -SC15- | 5 A | Engine sound generator control unit -J943- (T12p/1)29) | 15a |
| | | Left headlight range control motor -V48- (T10i/1) | |
| | | Right headlight range control motor -V49- (T10j/1) | |
| | | 16-pin connector -T16- (T16/1), Diagnostic connection | |
F16 | Fuse 16 on fuse holder C -SC16- | 5 A | Engine control unit -J623- (T94/87) | 15a |
F17 | Fuse 17 on fuse holder C -SC17- | 10 A | Interior monitoring sensor -G273- (T4bz/4) | 30a |
| | | Alarm horn -H12- (T3f/3) | |
F18 | Fuse 18 on fuse holder C -SC18- | 15 A | Left headlight dipped beam bulb -M29- (T10i/6) | 56bl |
F19 | Fuse 19 on fuse holder C -SC19- | 15 A | Right headlight dipped beam bulb -M31- (T10j/6) | 56br |
| | | Tiptronic switch -F189- (T10s/10) | |
| | | Heater control unit -J162- (T20c/18) | |
| | | Automatic gearbox control unit -J217- (T52/3) | |
F20 | Fuse 20 on fuse holder C -SC20- | 5 A | Climatronic control unit -J255- (T20c/20) | 30a |
| | | Air conditioning system control unit -J301- (T20c/19) | |
| | | Selector lever sensors control unit -J587- (T10s/10) | |
| | | Ignition key withdrawal lock solenoid -N376- (T10d/10) | |
F21 | Fuse 21 on fuse holder C -SC21- | 15 A | Onboard supply control unit -J519- (T73b/68) | 30a |
F22 | Fuse 22 on fuse holder C -SC22- | 5 A | Ignition/starter switch -D- (T10d/1) | 30a |
| | | Converter box -J935- (T10e/7) | |
| | | Rain and light sensor -G397- (T3ae/1) | |
| | | Onboard supply control unit -J519- (T73b/39), (T73a/66) | |
F23 | Fuse 23 on fuse holder C -SC23- | 20 A | Telephone transmitter and receiver unit -R36- (T54/1) | 30a |
| | | 16-pin connector -T16- (T16/16), Diagnostic connection | |
| | | -GX22- (T10ak/1) | |
| | | Entry and start authorisation control unit -J518- (T32d/3) | |
F24 | Fuse 24 on fuse holder C -SC24- | 10 A | Onboard supply control unit -J519- (T73a/64) | 30a |
| | | Electronic steering column lock control unit -J764- (T16s/2) | |
| | | Data bus diagnostic interface -J533- (T20/1) | |
| | | Multifunction switch -F125- (T10n/10) | |
F25 | Fuse 25 on fuse holder C -SC25- | 25 A32) | Automatic gearbox control unit -J217- (T52/27)32) (T52/28)32) | 15a |
| | 10 A | Mechatronic unit for dual clutch gearbox -J743- (T25/10)30) (T20/13)31) | |
F26 | Not assigned | - | | - |
F27 | Not assigned | - | | - |
F28 | Not assigned | - | | - |
F29 | Fuse 29 on fuse holder C -SC29- | 5 A | Onboard supply control unit -J519- (T73b/51) | 75 |
| | | Blocking diode -J29- (1) | |
F30 | Fuse 30 on fuse holder C -SC30- | 20 A | Cigarette lighter -U1- (T3g/2) | 75a |
| | | 12 V socket -U5- (2) | |
F31 | Fuse 31 on fuse holder C -SC31- | 30 A | Light switch -E1- (T17d/1) | 75 |
F32 | Fuse 32 on fuse holder C -SC32- | 15 A | Fog light switch -E7- (T17d/2) | 75a |
F33 | Fuse 33 on fuse holder C -SC33- | 40 A | Heater control unit -J162- (T5/5) | 75a |
| | | Air conditioning system control unit -J301- (T5/5) | |
| | | Control unit in dash panel insert -J285- (T32c/14) | |
| | | Onboard supply control unit -J519- (T73a/62) | |
F34 | Fuse 34 on fuse holder C -SC34- | 10 A | Left headlight main beam bulb -M30- (T10i/8) | 56al |
| | 15 A35) | Right headlight main beam bulb -M32- (T10j/8) | |
| | | Front left headlight -MX1- (T14c/11) | |
| | | Front right headlight -MX2- (T14c/11) | |
F35 | Fuse 35 on fuse holder C -SC35- | 1 A | Steering column electronics control unit -J527- (T16p/1) | 15a |
F36 | Fuse 36 on fuse holder C -SC36- | 30 A | Onboard supply control unit -J519- (T73a/16) | 30a |
F37 | Fuse 37 on fuse holder C -SC37- | 5 A | Left daytime running light bulb -L174- (T10i/4) | TFL |
F38 | Fuse 38 on fuse holder C -SC38- | 5 A | Right daytime running light bulb -L175- (T10j/4) | TFL |
F39 | Fuse 39 on fuse holder C -SC39- | 30 A | Headlight dipper and flash relay -J- (T9a/3) | 30 |
F40 | Fuse 40 on fuse holder C -SC40- | 25 A | Convertible roof actuation control unit -J256- (T15/6) | 30a |
F41 | Fuse 41 on fuse holder C -SC41- | 25 A | Convertible roof actuation control unit 2 -J1004- (T15a/3) | 30a |
F42 | Fuse 42 on fuse holder C -SC42- | 25 A | Convertible roof actuation control unit 2 -J1004- (T15a/6) | 30a |
F43 | Fuse 43 on fuse holder C -SC43- | 30 A | Front passenger door control unit -J387- (T16d/16) | 30a |
F44 | Fuse 44 on fuse holder C -SC44- | 30 A | Onboard supply control unit -J519- (T73b/67) | 30a |
F45 | Fuse 45 on fuse holder C -SC45- | 30 A | Driver door control unit -J386- (T16c/16) | 30a |
F46 | Fuse 46 on fuse holder C -SC46- | 25 A | Rear left window regulator motor -V26- (T4a/2) | 30a |
| | | Rear right window regulator motor -V27- (T4ab/2) | |
| | | Fuel pump relay -J17- (3A) | |
F47 | Fuse 47 on fuse holder C -SC47- | 20 A | Electric fuel pump 2 relay -J49- (3B)17) | 30a |
| | | Fuel pump control unit -J538- (T10v/1) | |
F48 | Fuse 48 on fuse holder C -SC48- | 30 A | Onboard supply control unit -J519- (T73b/13), (T73b/11) | 30a |
F49 | Fuse 49 on fuse holder C -SC49- | 40 A | Fresh air blower control unit -J126- (T6l/4) | 30a |
F50 | Fuse 50 on fuse holder C -SC50- | 30 A | Heated front seats control unit -J774- (T8v/3), (T8v/6) | 30a |
F51 | Not assigned | - | | - |
F52 | Fuse 52 on fuse holder C -SC52- | 20 A | Onboard supply control unit -J519- (T73a/63) | 30a |
F53 | Fuse 53 on fuse holder C -SC53- | 20 A | Onboard supply control unit -J519- (T73a/73) | 30a |
F54 | Not assigned | - | | - |
F55 | Fuse 55 on fuse holder C -SC55- | 20 A | Light switch -E1- (T17d/15) | 30 |
| | | Headlight dipper and flasher switch -E4- (T16j/10) | |
F56 | Not assigned | - | | - |
F57 | Fuse 57 on fuse holder C -SC57- | 25 A | Control unit with display for radio and navigation -J503- (T16b/15), (T16b/16) | 30a |
| | | Radio -R- (T16b/15), (T16b/16) | |
F58 | Not assigned | - | | - |
F59 | Not assigned | - | | - |
F60 | Not assigned | - | | - |
Slot | Current Flow Diagram designation | Nominal value | Function/component | Terminal |
F1 | Fuse 1 on fuse holder C -SC1- | - | Not assigned | - |
F2 | Fuse 2 on fuse holder C -SC2- | 10 A | Emergency call module control unit and communication unit -J949- | 30 |
F3 | Fuse 3 on fuse holder C -SC3- | 5 A | Control unit in dash panel insert -J285- | 30 |
F4 | Fuse 4 on fuse holder C -SC4- | 5 A | Telephone transmitter and receiver unit -R36- | 30 |
F5 | Fuse 5 on fuse holder C -SC5- | 10 A | Control unit in dash panel insert -J285- | 55 |
| | | Onboard supply control unit -J519- | |
| | | Rear left fog light bulb -L46- | |
F6 | Fuse 6 on fuse holder C -SC6- | 10 A | Rear lid handle release button -E234- | 30 |
| | | Reversing camera -R189- | |
F7 | Fuse 7 on fuse holder C -SC7- | 5 A | Switch and instrument illumination regulator -E20- | 58 |
| | | Left number plate light -X4- | |
| | | Right number plate light -X5- | |
F8 | Fuse 8 on fuse holder C -SC8- | 10 A | Washer pump -V5- | 53 |
F9 | Fuse 9 on fuse holder C -SC9- | 10 A | Airbag control unit -J234- | 15 |
| | | Front passenger front airbag deactivated warning lamp -K145- | |
| | | Seat occupied recognition control unit -J706- | |
F10 | Fuse 10 on fuse holder C -SC10- | 15 A | Intermittent wiper switch -E22- | 15 |
F11 | Not assigned | - | | - |
F12 | Fuse 12 on fuse holder C -SC12- | 5 A | Headlight range control unit -J431- | 15 |
F13 | Fuse 13 on fuse holder C -SC13- | 5 A | Start/Stop operation button -E693- | 15 |
| | | Fold-in mirror switch -E263- | |
| | | Tyre Pressure Loss Indicator display button -E492- | |
| | | Reversing light switch -F4- | |
| | | High-pressure sender -G65- | |
| | | Air quality sensor -G238- | |
| | | Heater control unit -J162- | |
| | | Parking aid control unit -J446- | |
| | | Control module for vehicle location system -J895- | |
| | | Automatic anti-dazzle interior mirror -Y7- | |
| | | Left washer jet heater element -Z20- | |
| | | Right washer jet heater element -Z21- | |
F14 | Fuse 14 on fuse holder C -SC14- | 10 A | CCS switch -E45- | 15 |
| | | Tiptronic switch -F189- | |
| | | Oil level and oil temperature sender -G266- | |
| | | -GX22- | |
| | | ABS control unit -J104- | |
| | | Control unit in dash panel insert -J285- | |
| | | Power steering control unit -J500- | |
| | | Steering column electronics control unit -J527- | |
| | | Voltage stabiliser -J532- | |
| | | Data bus diagnostic interface -J533- | |
| | | Fuel pump control unit -J538- | |
| | | Selector lever sensors control unit -J587- | |
| | | Engine control unit -J623- | |
| | | Heater element for crankcase breather -N79- | |
F15 | Fuse 15 on fuse holder C -SC15- | 5 A | Switch and instrument illumination regulator -E20- | 15 |
| | | Air mass meter -G70- | |
| | | Control unit for structure-borne sound -J869- | |
| | | Left headlight range control motor -V48- | |
| | | Right headlight range control motor -V49- | |
| | | 16-pin connector -T16- , Diagnostic connection | |
F16 | Fuse 16 on fuse holder C -SC16- | 5 A | Engine control unit -J623- | 15 |
F17 | Fuse 17 on fuse holder C -SC17- | 10 A | Interior monitoring sensor -G273- | 30 |
| | | Vehicle inclination sender -G384- | |
| | | Alarm horn -H12- | |
F18 | Fuse 18 on fuse holder C -SC18- | 15 A | Left headlight dipped beam bulb -M29-1) | 56b |
F19 | Fuse 19 on fuse holder C -SC19- | 15 A | Right headlight dipped beam bulb -M31-1) | 56b |
F20 | Fuse 20 on fuse holder C -SC20- | 5 A | Tiptronic switch -F189- | 30 |
| | | Heater control unit -J162- | |
| | | Automatic gearbox control unit -J217- | |
| | | Climatronic control unit -J255- | |
| | | Air conditioning system control unit -J301- | |
| | | Selector lever sensors control unit -J587- | |
| | | Ignition key withdrawal lock solenoid -N376- | |
F21 | Fuse 21 on fuse holder C -SC21- | 15 A | Onboard supply control unit -J519- | 30 |
F22 | Fuse 22 on fuse holder C -SC22- | 5 A | Ignition/starter switch -D- | 30 |
| | | Control module for vehicle location system -J895- | |
| | | Emergency call module control unit and communication unit -J949- | |
| | | Converter box -J935- | |
F23 | Fuse 23 on fuse holder C -SC23- | 20 A | Rain and light sensor -G397- | 30 |
| | | Onboard supply control unit -J519- | |
| | | Telephone transmitter and receiver unit -R36- | |
| | | Emergency call module control unit and communication unit -J949- | |
| | | 16-pin connector -T16- , Diagnostic connection | |
| | | Additional instruments -GX22- | |
F24 | Fuse 24 on fuse holder C -SC24- | 10 A | Onboard supply control unit -J519- | |
| | | Entry and start authorisation control unit -J518- | 30 |
| | | Electronic steering column lock control unit -J764- | |
| | | Data bus diagnostic interface -J533- | |
F25 | Fuse 25 on fuse holder C -SC25- | 25 A2) | Automatic gearbox control unit -J217- | |
| | | Multifunction switch -F125- | 15 |
| | 10 A | Mechatronic unit for dual clutch gearbox -J743- | |
F26 | Fuse 26 on fuse holder C -SC26- | 30 A | Vacuum pump for brakes -V192- | 15 |
F27 | Not assigned | - | | - |
F28 | Not assigned | - | | - |
F29 | Fuse 29 on fuse holder C -SC29- | 5 A | Onboard supply control unit -J519- | 75 |
F30 | Fuse 30 on fuse holder C -SC30- | 20 A | Blocking diode -J29- | 75 |
| | | Cigarette lighter -U1- | |
| | | 12 V socket -U5- | |
F31 | Fuse 31 on fuse holder C -SC31- | 30 A | Light switch -E1- | 75 |
F32 | Fuse 32 on fuse holder C -SC32- | 15 A | Fog light switch -E7- | 75 |
F33 | Fuse 33 on fuse holder C -SC33- | 40 A | Heater control unit -J162- | 75 |
| | | Air conditioning system control unit -J301- | |
F34 | Fuse 34 on fuse holder C -SC34- | 10 A | Control unit in dash panel insert -J285- | |
| | 15 A35) | Onboard supply control unit -J519- | |
| | | Left headlight main beam bulb -M30- | 56a |
| | | Right headlight main beam bulb -M32- | |
| | | Front left headlight -MX1- | |
| | | Front right headlight -MX2- | |
F35 | Fuse 35 on fuse holder C -SC35- | 1 A | Steering column electronics control unit -J527- | 15 |
F36 | Fuse 36 on fuse holder C -SC36- | 30 A | Onboard supply control unit -J519- | 30 |
F37 | Fuse 37 on fuse holder C -SC37- | 5 A | Left daytime running light bulb -L174- | TFL |
F38 | Fuse 38 on fuse holder C -SC38- | 5 A | Right daytime running light bulb -L175- | TFL |
F39 | Fuse 39 on fuse holder C -SC39- | 30 A | Headlight dipper and flash relay -J- | 30 |
F40 | Fuse 40 on fuse holder C -SC40- | 25 A | Convertible roof actuation control unit -J256- | 30 |
F41 | Fuse 41 on fuse holder C -SC41- | 25 A | Convertible roof actuation control unit 2 -J1004- | 30 |
F42 | Fuse 42 on fuse holder C -SC42- | 25 A | Convertible roof actuation control unit 2 -J1004- | 30 |
F43 | Fuse 43 on fuse holder C -SC43- | 30 A | Front passenger door control unit -J387- | 30 |
F44 | Fuse 44 on fuse holder C -SC44- | 30 A | Onboard supply control unit -J519- | 30 |
F45 | Fuse 45 on fuse holder C -SC45- | 30 A | Driver door control unit -J386- | 30 |
F46 | Fuse 46 on fuse holder C -SC46- | 30 A | Rear left window regulator motor -V26- | 30 |
| | | Rear right window regulator motor -V27- | |
F47 | Fuse 47 on fuse holder C -SC47- | 20 A | Fuel pump relay -J17- | 30 |
| | | Electric fuel pump 2 relay -J49- | |
| | | Fuel pump control unit -J538- | |
F48 | Fuse 48 on fuse holder C -SC48- | 30 A | Onboard supply control unit -J519- | 30 |
F49 | Fuse 49 on fuse holder C -SC49- | 40 A | Fresh air blower control unit -J126- | 30 |
F50 | Fuse 50 on fuse holder C -SC50- | 30 A | Heated front seats control unit -J774- | 30 |
F51 | Fuse 51 on fuse holder C -SC51- | 30 A | Sliding sunroof adjustment control unit -J245- | 30 |
F52 | Fuse 52 on fuse holder C -SC52- | 20 A | Onboard supply control unit -J519- | 30 |
F53 | Fuse 53 on fuse holder C -SC53- | 20 A | Onboard supply control unit -J519- | 30 |
F54 | Not assigned | - | | - |
F55 | Fuse 55 on fuse holder C -SC55- | 20 A | Light switch -E1- | 30 |
| | | Headlight dipper and flasher switch -E4- | |
F56 | Not assigned | - | | - |
F57 | Fuse 57 on fuse holder C -SC57- | 25 A | Control unit with display for radio and navigation -J503- | 30 |
| | | Radio -R- | |
F58 | Not assigned | - | | - |
F59 | Not assigned | - | | - |
F60 | Not assigned | - | | - |
Slot | Current Flow Diagram designation | Nominal value | Function/component | Terminal |
F1 | Fuse 1 on fuse holder C -SC1- | 5 A | Blind spot monitor control unit 2 -J1087- | 15 |
F2 | Fuse 2 on fuse holder C -SC2- | 10 A | Emergency call module control unit and communication unit -J949- | 30 |
F3 | Fuse 3 on fuse holder C -SC3- | 5 A | Control unit in dash panel insert -J285- | 30 |
F4 | Fuse 4 on fuse holder C -SC4- | 5 A | Telephone transmitter and receiver unit -R36- | 30 |
F5 | Fuse 5 on fuse holder C -SC5- | 10 A | Control unit in dash panel insert -J285- | 55 |
| | | Onboard supply control unit -J519- | |
| | | Rear left fog light bulb -L46- | |
F6 | Fuse 6 on fuse holder C -SC6- | 10 A | Rear lid handle release button -E234- | 30 |
| | | Reversing camera -R189- | |
F7 | Fuse 7 on fuse holder C -SC7- | 5 A | Switch and instrument illumination regulator -E20- | 58 |
| | | Left number plate light -X4- | |
| | | Right number plate light -X5- | |
F8 | Fuse 8 on fuse holder C -SC8- | 10 A | Washer pump -V5- | 53 |
F9 | Fuse 9 on fuse holder C -SC9- | 10 A | Airbag control unit -J234- | 15 |
| | | Front passenger front airbag deactivated warning lamp -K145- | |
| | | Seat occupied recognition control unit -J706- | |
F10 | Fuse 10 on fuse holder C -SC10- | 15 A | Intermittent wiper switch -E22- | 15 |
F11 | Fuse 11 on fuse holder C -SC11- | 5 A | Light switch -E1- | 15 |
F12 | Not assigned | - | | - |
F13 | Fuse 13 on fuse holder C -SC13- | 5 A | Start/Stop operation button -E693- | 15 |
| | | Fold-in mirror switch -E263- | |
| | | Tyre Pressure Loss Indicator display button -E492- | |
| | | Reversing light switch -F4- | |
| | | High-pressure sender -G65- | |
| | | Air quality sensor -G238- | |
| | | Heater control unit -J162- | |
| | | Parking aid control unit -J446- | |
| | | Control module for vehicle location system -J895- | |
| | | Automatic anti-dazzle interior mirror -Y7- | |
| | | Left washer jet heater element -Z20- | |
| | | Right washer jet heater element -Z21- | |
F14 | Fuse 14 on fuse holder C -SC14- | 10 A | CCS switch -E45- | 15 |
| | | Tiptronic switch -F189- | |
| | | Oil level and oil temperature sender -G266- | |
| | | -GX22- | |
| | | ABS control unit -J104- | |
| | | Control unit in dash panel insert -J285- | |
| | | Power steering control unit -J500- | |
| | | Steering column electronics control unit -J527- | |
| | | Voltage stabiliser -J532- | |
| | | Data bus diagnostic interface -J533- | |
| | | Fuel pump control unit -J538- | |
| | | Selector lever sensors control unit -J587- | |
| | | Engine control unit -J623- | |
| | | Heater element for crankcase breather -N79- | |
F15 | Fuse 15 on fuse holder C -SC15- | 5 A | Switch and instrument illumination regulator -E20- | 15 |
| | | Air mass meter -G70- | |
| | | Control unit for structure-borne sound -J869- | |
| | | Left headlight range control motor -V48- | |
| | | Right headlight range control motor -V49- | |
| | | 16-pin connector -T16- , Diagnostic connection | |
F16 | Fuse 16 on fuse holder C -SC16- | 5 A | Engine control unit -J623- | 15 |
F17 | Fuse 17 on fuse holder C -SC17- | 10 A | Interior monitoring sensor -G273- | 30 |
| | | Vehicle inclination sender -G384- | |
| | | Alarm horn -H12- | |
F18 | Fuse 18 on fuse holder C -SC18- | 15 A | Left headlight dipped beam bulb -M29-1) | 56b |
F19 | Fuse 19 on fuse holder C -SC19- | 15 A | Right headlight dipped beam bulb -M31-1) | 56b |
F20 | Fuse 20 on fuse holder C -SC20- | 10 A | Tiptronic switch -F189- | 30 |
| | | Heater control unit -J162- | |
| | | Automatic gearbox control unit -J217- | |
| | | Climatronic control unit -J255- | |
| | | Air conditioning system control unit -J301- | |
| | | Selector lever sensors control unit -J587- | |
| | | Ignition key withdrawal lock solenoid -N376- | |
F21 | Fuse 21 on fuse holder C -SC21- | 15 A | Onboard supply control unit -J519- | 30 |
F22 | Fuse 22 on fuse holder C -SC22- | 5 A | Ignition/starter switch -D- | 30 |
| | | Control module for vehicle location system -J895- | |
| | | Emergency call module control unit and communication unit -J949- | |
| | | Converter box -J935- | |
F23 | Fuse 23 on fuse holder C -SC23- | 10 A | Rain and light sensor -G397- | 30 |
| | | Onboard supply control unit -J519- | |
| | | Telephone transmitter and receiver unit -R36- | |
| | | Emergency call module control unit and communication unit -J949- | |
| | | 16-pin connector -T16- , Diagnostic connection | |
| | | Additional instruments -GX22- | |
F24 | Fuse 24 on fuse holder C -SC24- | 10 A | Onboard supply control unit -J519- | |
| | | Entry and start authorisation control unit -J518- | 30 |
| | | Electronic steering column lock control unit -J764- | |
| | | Data bus diagnostic interface -J533- | |
F25 | Fuse 25 on fuse holder C -SC25- | 25 A2) | Automatic gearbox control unit -J217- | |
| | | Multifunction switch -F125- | 15 |
| | 10 A | Mechatronic unit for dual clutch gearbox -J743- | |
F26 | Fuse 26 on fuse holder C -SC26- | 30 A | Vacuum pump for brakes -V192- | - |
F27 | Not assigned | - | | - |
F28 | Fuse 28 on fuse holder C -SC28- | 25 A | Terminal 75 voltage supply relay 1 -J680- | 75 |
F29 | Fuse 29 on fuse holder C -SC29- | 5 A | Onboard supply control unit -J519- | 75 |
F30 | Fuse 30 on fuse holder C -SC30- | 20 A | Blocking diode -J29- | 75 |
| | | Cigarette lighter -U1- | |
| | | 12 V socket -U5- | |
F31 | Fuse 31 on fuse holder C -SC31- | 30 A | Light switch -E1- | 75 |
F32 | Fuse 32 on fuse holder C -SC32- | 15 A | Fog light switch -E7- | 75 |
F33 | Fuse 33 on fuse holder C -SC33- | 40 A | Heater control unit -J162- | 75 |
| | | Air conditioning system control unit -J301- | |
F34 | Fuse 34 on fuse holder C -SC34- | 10 A3) | Control unit in dash panel insert -J285- | 30 |
| | 15 A4) | Onboard supply control unit -J519- | |
| | | Left headlight main beam bulb -M30- | 56 |
| | | Right headlight main beam bulb -M32- | |
| | | Front left headlight -MX1- | |
| | | Front right headlight -MX2- | |
F35 | Fuse 35 on fuse holder C -SC35- | 1 A | Steering column electronics control unit -J527- | 15 |
F36 | Fuse 36 on fuse holder C -SC36- | 30 A | Onboard supply control unit -J519- | 30 |
F37 | Fuse 37 on fuse holder C -SC37- | 5 A | Left daytime running light bulb -L174- | TFL |
F38 | Fuse 38 on fuse holder C -SC38- | 5 A | Right daytime running light bulb -L175- | TFL |
F39 | Fuse 39 on fuse holder C -SC39- | 30 A | Headlight dipper and flash relay -J- | 30 |
F40 | Fuse 40 on fuse holder C -SC40- | 25 A | Convertible roof actuation control unit -J256- | 30 |
F41 | Fuse 41 on fuse holder C -SC41- | 25 A | Convertible roof actuation control unit 2 -J1004- | 30 |
F42 | Fuse 42 on fuse holder C -SC42- | 25 A | Convertible roof actuation control unit 2 -J1004- | 30 |
F43 | Fuse 43 on fuse holder C -SC43- | 30 A | Front passenger door control unit -J387- | 30 |
F44 | Fuse 44 on fuse holder C -SC44- | 30 A | Onboard supply control unit -J519- | 30 |
F45 | Fuse 45 on fuse holder C -SC45- | 30 A | Driver door control unit -J386- | 30 |
F46 | Fuse 46 on fuse holder C -SC46- | 30 A | Rear left window regulator motor -V26- | 30 |
| | | Rear right window regulator motor -V27- | |
F47 | Fuse 47 on fuse holder C -SC47- | 20 A | Fuel pump relay -J17- | 30 |
| | | Electric fuel pump 2 relay -J49- | |
| | | Fuel pump control unit -J538- | |
F48 | Fuse 48 on fuse holder C -SC48- | 30 A | Onboard supply control unit -J519- | 30 |
F49 | Fuse 49 on fuse holder C -SC49- | 40 A | Fresh air blower control unit -J126- | 30 |
F50 | Fuse 50 on fuse holder C -SC50- | 30 A | Heated front seats control unit -J774- | 30 |
F51 | Fuse 51 on fuse holder C -SC51- | 30 A | Sliding sunroof adjustment control unit -J245- | 30 |
F52 | Fuse 52 on fuse holder C -SC52- | 20 A | Onboard supply control unit -J519- | 30 |
F53 | Fuse 53 on fuse holder C -SC53- | 20 A | Onboard supply control unit -J519- | 30 |
F54 | Fuse 54 on fuse holder C -SC54- | 25 A | Automatic gearbox control unit -J217- | 30 |
F55 | Fuse 55 on fuse holder C -SC55- | 20 A | Light switch -E1- | 30 |
| | | Headlight dipper and flasher switch -E4- | |
F56 | Fuse 56 on fuse holder C -SC56- | 20 A | Onboard supply control unit -J519- | 30 |
F57 | Fuse 57 on fuse holder C -SC57- | 25 A | Control unit with display for radio and navigation -J503- | 30 |
| | | Radio -R- | |
F58 | Fuse 58 on fuse holder C -SC58- | 10 A | Relay for reducing agent metering system -J963- | 30 |
F59 | Not assigned | - | | - |
F60 | Not assigned | - | | - |
