VW GOLF 2015 – Radio navigation system . Wiring diagrams, Pin Connector, Location

Wiring Diagram VW GOLF 2015 - Multimedia system operating unit - Display unit for front information display and operating unit control unit - Control unit 1 for information electronics

E380	Multimedia system operating unit
J685	Display unit for front information display and operating unit control unit
J794	Control unit 1 for information electronics
SC10	Fuse 10 on fuse holder C
SC12	Fuse 12 on fuse holder C
SC16	Fuse 16 on fuse holder C
T5ad	5-pin connector
T5ah	5-pin connector, grey
T8aq	8-pin connector, black
T12ai	12-pin connector
T12al	12-pin connector, grey
A167	Positive connection 3 (30a) in dash panel wiring harness
*	According to equipment

Wiring Diagram VW GOLF 2015 - Display unit for front information display and operating unit control unit - Control unit 1 for information electronics - Connection for external audio sources

J685	Display unit for front information display and operating unit control unit
J794	Control unit 1 for information electronics
R199	Connection for external audio sources
T4cm	4-pin connector
T5ae	5-pin connector, yellow
T7b	7-pin connector
T8aq	8-pin connector, black
T12ag	12-pin connector, green
T12ai	12-pin connector
T12al	12-pin connector, grey
256	Earth connection 2, in radio wiring harness
B415	Connection 1 (infotainment CAN bus, high), in main wiring harness
B421	Connection 1 (infotainment CAN bus, low), in main wiring harness
V54	Connection 1 (telephone), in main wiring harness
*	According to equipment
*2	gradual introduction

Wiring Diagram VW GOLF 2015 - Data bus diagnostic interface - Control unit 1 for information electronics - Telephone microphone - Connection for external audio sources - Interface for external multimedia unit

J533	Data bus diagnostic interface
J685	Display unit for front information display and operating unit control unit
J794	Control unit 1 for information electronics
R38	Telephone microphone
R199	Connection for external audio sources
R215	Interface for external multimedia unit
T2ei	2-pin connector
T5ae	5-pin connector, yellow
T5d	5-pin connector
T7b	7-pin connector
T12a	12-pin connector, blue
T12ag	12-pin connector, green
T12al	12-pin connector, grey
T20	20-pin connector
A178	Connection (infotainment CAN bus, high), in dash panel wiring harness
A179	Connection (infotainment CAN bus, low), in dash panel wiring harness
B605	Connection 1, in interior wiring harness
B606	Connection 2, in interior wiring harness
V15	Connection, in telephone wiring harness
V16	Connection (screening), in telephone wiring harness
V55	Connection 2 (telephone), in main wiring harness
*	According to equipment
*2	gradual introduction

Wiring Diagram VW GOLF 2015 - Control unit 1 for information electronics - Interface for external multimedia unit

J685	Display unit for front information display and operating unit control unit
J794	Control unit 1 for information electronics
R215	Interface for external multimedia unit
T12ag	12-pin connector, green
T16v	16-pin connector
*	According to equipment

Wiring Diagram VW GOLF 2015 - Control unit 1 for information electronics - Connection for external audio sources - USB hub

J685	Display unit for front information display and operating unit control unit
J794	Control unit 1 for information electronics
R199	Connection for external audio sources
R293	USB hub, under centre console
T4aa	4-pin connector
T4ae	4-pin connector, red
T5af	5-pin connector, green
T5h	5-pin connector, green
T5r	5-pin connector, purple
T5s	5-pin connector
T12ag	12-pin connector, green
270	Earth connection, in telephone wiring harness
B151	Positive connection 3 (30a), in interior wiring harness
*	According to equipment

Wiring Diagram VW GOLF 2015 - Voltage converter for USB charge module - Control unit 1 for information electronics - USB hub - USB charging socket 1

A5	Voltage converter for USB charge module, under centre console
J685	Display unit for front information display and operating unit control unit
J794	Control unit 1 for information electronics
R293	USB hub, under centre console
T4z	4-pin connector
T5af	5-pin connector
T5y	5-pin connector, green
T5z	5-pin connector, blue
T12al	12-pin connector, grey
U37	USB charging socket 1
B219	Positive connection 4 (30a), in interior wiring harness
*	According to equipment

Wiring Diagram VW GOLF 2015 - Control unit 1 for information electronics - Rear left treble loudspeaker - Rear left bass loudspeaker - Front left treble loudspeaker - Front left bass loudspeaker

J685	Display unit for front information display and operating unit control unit
J794	Control unit 1 for information electronics
R14	Rear left treble loudspeaker
R15	Rear left bass loudspeaker
R20	Front left treble loudspeaker
R21	Front left bass loudspeaker
T2m	2-pin connector
T2r	2-pin connector
T4r	4-pin connector
T4s	4-pin connector
T8ar	8-pin connector
T19b	19-pin connector, black
T19c	19-pin connector, black
T27	27-pin connector, black
T27b	27-pin connector, black
TTHL	Coupling point on rear left door
TTVL	Coupling point on front left door
B195	Connection (positive, rear left loudspeaker), in interior wiring harness
B196	Connection (negative, rear left loudspeaker), in interior wiring harness
R71	Connection (positive, loudspeaker)), in rear left door wiring harness
R72	Connection (negative, loudspeaker), in rear left door wiring harness
V8	Connection (negative, front left loudspeaker), in loudspeaker wiring harness
V46	Connection (front left loudspeaker), in loudspeaker wiring harness
*	According to equipment
*2	Only models with 2-doors
*3	Wiring colour depends on equipment
*4	Only models with 4-doors

Wiring Diagram VW GOLF 2015 - Control unit 1 for information electronics - Rear right treble loudspeaker - Rear right bass loudspeaker - Front right treble loudspeaker - Front right bass loudspeaker

J685	Display unit for front information display and operating unit control unit
J794	Control unit 1 for information electronics
R16	Rear right treble loudspeaker
R17	Rear right bass loudspeaker
R22	Front right treble loudspeaker
R23	Front right bass loudspeaker
T2o	2-pin connector
T2t	2-pin connector
T4ac	4-pin connector
T4ad	4-pin connector
T8ar	8-pin connector
T19	19-pin connector, black
T19a	19-pin connector, black
T27a	27-pin connector, black
T27c	27-pin connector, black
TTHR	Coupling point on rear right door
TTVR	Coupling point on front right door
B193	Connection (positive, rear right loudspeaker), in interior wiring harness
B194	Connection (negative, rear right loudspeaker), in interior wiring harness
R73	Connection (positive, loudspeaker)), in rear right door wiring harness
R74	Connection (negative, loudspeaker), in rear right door wiring harness
V9	Connection (positive, front right loudspeaker), in loudspeaker wiring harness
V10	Connection (negative, front right loudspeaker), in loudspeaker wiring harness
*	According to equipment
*2	Only models with 4-doors
*3	From November 2013
*4	Only models with 2-doors
*5	Wiring colour depends on equipment
*6	Up to November 2013

Wiring Diagram VW GOLF 2015 - Control unit 1 for information electronics - TV tuner - Aerial amplifier 1 for TV

J685	Display unit for front information display and operating unit control unit
J794	Control unit 1 for information electronics
RX6	TV tuner
R55	TV aerial 1
R82	Aerial amplifier 1 for TV, Rear window, top right
R248	Radio aerial
T2n	2-pin connector, black
T2p	2-pin connector
T2u	2-pin connector, black
T2v	2-pin connector, green
T12al	12-pin connector, grey
T12l	12-pin connector, black
*	According to equipment
*2	Only models with TV tuner
*3	Rear window aerial

Wiring Diagram VW GOLF 2015 - Control unit 1 for information electronics - TV tuner - Aerial amplifier 2 for TV - Aerial amplifier 3 for TV - Radio aerial 2 - Left aerial module - Right aerial module - Radio aerial

J685	Display unit for front information display and operating unit control unit
J794	Control unit 1 for information electronics
RX6	TV tuner
R56	TV aerial 2
R57	TV aerial 3
R83	Aerial amplifier 2 for TV, Rear window, bottom right
R84	Aerial amplifier 3 for TV, Rear window, bottom left
R93	Radio aerial 2
R108	Left aerial module, Rear window, top left
R109	Right aerial module, Rear window, top right
R248	Radio aerial
*	Only models with no digital radio
*2	Rear window aerial
*3	Only models with no TV receiver
*4	According to equipment

Wiring Diagram VW GOLF 2015 - Heated rear window relay - Control unit 1 for information electronics - Roof aerial - GPS aerial - Left aerial module - Amplitude modulation (AM) frequency filter - Frequency modulation (FM) frequency filter in negative wire - Frequency modulation (FM) frequency filter in positive wire - GSM aerial - Heated rear window

J9	Heated rear window relay
J685	Display unit for front information display and operating unit control unit
J794	Control unit 1 for information electronics
RX5	Roof aerial
R50	GPS aerial
R93	Radio aerial 2
R108	Left aerial module, Rear window, top left
R177	Amplitude modulation (AM) frequency filter
R178	Frequency modulation (FM) frequency filter in negative wire
R179	Frequency modulation (FM) frequency filter in positive wire
R183	Digital radio aerial
R205	GSM aerial
T10d	10-pin connector, black
T10p	10-pin connector, black
THK	Coupling point on rear lid
Z1	Heated rear window
285	Earth connection 7, in interior wiring harness
*	According to equipment
*2	Rear window aerial
*3	Only models with digital radio

VW GOLF 2015 Overview of control units

Overview of control units

5 -	Display unit for front information display and operating unit control unit -J685-

q	Fitting location

q	Fitting location

Control unit for navigation system -J856-

Special vehicle control unit -J608-

q	Fitting locations, models with a diesel engine

q	Fitting location for models with hybrid drive system

q	Connector assignment

q	Connector assignment for models with LED headlights

VW GOLF 2015 Fresh air blower control unit J126 Fresh air blower control unit -J126- Fitting location: On heater and air conditioner unit, front passenger footwell.

1 -	Fresh air blower control unit -J126-

A -	4-pin connector -T4dc-

B -	2-pin connector -T2dq-

Connector assignment of fresh air blower control unit -J126-

-T4dc- (A)	Designation		-T2dq- (B)	Designation
1	Terminal 31		1	Fresh air blower -V2- , +
2			2	Fresh air blower -V2- , -
3	Terminal 30
4	A209 Connection 1 (LIN bus) in dash panel wiring harness

Back to overview VW GOLF 2015 Control unit 1 for information electronics J794 Control unit 1 for information electronics -J794- Fitting location: Equipment " Composition Media, Discover Media/Discover Pro (Standard/High) “ : in glove compartment.

Multiway connector housing J (chambers: 9-18), made up of connectors K, L, M and N.

1 -	Control unit 1 for information electronics -J794-

A -	2-pin connector

q	Digital radio aerial -R183-

B -	2-pin connector

q	GSM aerial -R205-

C -	Not assigned

q

D -	2-pin connector

q	GPS aerial -R50-

E -	4-pin connector

q	Radio aerial -R248-

q	Radio aerial 2 -R93-

F -	4-pin connector

q	TV aerial 1 -R55-

q	Radio aerial -R248-

G -	Not assigned

H -	5-pin connector -T5ae-

q	Interface for external multimedia units -R215-

q	Connection for external audio sources -R199-

q	USB hub -R293-

q	Chip card reader -D8-

I -	5-pin connector -T5ah-

q	Display unit for front information display and operating unit control unit -J685-

J -	8-pin connector -T8aq-

K -	12-pin connector -T12ag-

L -	12-pin connector -T12a-

M -	12-pin connector -T12al-

N -	8-pin connector -T8ar-

O -	2-pin connector -T2n-

Connector assignment of control unit 1 for information electronics -J794-

-T8ar- (N)	Designation		-T8aq- (J)	Designation		-T2n- (O)	Designation
1	Rear right treble loudspeaker -R16- , + rear right bass loudspeaker -R17- , +		9			1	TV tuner -RX6-
2	Front right treble loudspeaker -R22- , + front right bass loudspeaker -R23- , +		10			2	TV tuner -RX6-
3	Front left treble loudspeaker -R20- , + front left bass loudspeaker -R21- ,+		11
4	Rear left treble loudspeaker -R14- , + rear left bass loudspeaker -R15- , +		12
5	Rear right treble loudspeaker -R16- , - rear right bass loudspeaker -R17- , -		13
6	Front right treble loudspeaker -R22- , - front right bass loudspeaker -R23- , -		14
7	Front left treble loudspeaker -R20- , - front left bass loudspeaker -R21- ,-		17(1)	Terminal 31
8	Rear left treble loudspeaker -R14- , - rear left bass loudspeaker -R15- , -		18(2)	Terminal 30

-T12al- (M)	Designation		-T12ag- (K)	Designation		-T12a- (L)	Designation
1	B415 Connection 1 (infotainment CAN bus, high), in main wiring harness		1	Interface for external multimedia units -R215-1 Connection for external audio sources -R199-1		1	Telephone microphone -R38-
2	Display unit for front information display and operating unit control unit -J685-		2	Interface for external multimedia units -R215-1 Connection for external audio sources -R199-1		2
3			3	Interface for external multimedia units -R215-1 Connection for external audio sources -R199-1		3
4			4	Interface for external multimedia units -R215-1 Connection for external audio sources -R199-1		4
5	Terminal 30		5	Interface for external multimedia units -R215-1		5
6	A178 Connection (infotainment CAN bus, high), in dash panel wiring harness		6	Interface for external multimedia units -R215-1		6	Reversing camera -R189-
7	B421 Connection 1 (infotainment CAN bus, low), in main wiring harness		7	Interface for external multimedia units -R215-1 Connection for external audio sources -R199-1		7	Telephone microphone -R38- , shielding connection
8	Display unit for front information display and operating unit control unit -J685-		8	Interface for external multimedia units -R215-1 Connection for external audio sources -R199-1		8
9			9	Interface for external multimedia units -R215-1		9
10			10	Interface for external multimedia units -R215-1		10
11			11	Interface for external multimedia units -R215-1		11
12	A179 Connection (infotainment CAN bus, low), in dash panel wiring harness		12	Interface for external multimedia units -R215-1		12	Reversing camera -R189-

Back to overview VW GOLF 2015 Chip card reader D8 Chip card reader -D8- Fitting location: In glove compartment.

1 -	Chip card reader -D8-

A -	2-pin connector -T2-

q	Toll collection sender -G459-

B -	10-pin connector -T10lh-

q	Traffic data aerial -R173-

C -	5-pin connector -T5as-

q	Control unit 1 for information electronics -J794-

Connector assignment of chip card reader -D8-

-T10lh- (A)	Designation		-T10lh- (A)	Designation
1	Traffic data aerial -R173-		6	Control unit 1 for information electronics -J794-
2	Traffic data aerial -R173-		7	Traffic data aerial -R173-
3	Traffic data aerial -R173-		8	Traffic data aerial -R173-
4	Traffic data aerial -R173-		9	Terminal 30
5			10	Terminal 31

Back to overview VW GOLF 2015 Front passenger door control unit J387 Front passenger door control unit -J387- Fitting location: In front passenger door.

1 -	Front passenger door control unit -J387-

A -	6-pin connector -T6ct-

B -	20-pin connector -T20b-

C -	16-pin connector -T16g-

D -	32-pin connector -T32c-

Connector assignment of front passenger door control unit -J387-

-T6ct- (A)	Designation		-T20b- (B)	Designation		-T16g- (C)	Designation		-T32c- (D)	Designation
1			1			1	Front passenger side entry light in exterior mirror -W53-		1
2			2			2			2
3	Right window regulator motor -V15-		3			3	Front passenger side exterior mirror -VX5-		3	Light for passenger side interior door handle illumination -L220- Light for passenger door ambient lighting -W87-
4			4			4	Front passenger side exterior mirror -VX5-		4	Terminal 58
5			5	Front passenger door contact switch -F3-		5	Front passenger side exterior mirror -VX5-		5	Terminal 31
6	Right window regulator motor -V15-		6	Front passenger door central locking actuator for SAFELOCK function -F244-		6			6
			7			7	Front passenger side mirror adjustment motor -V25-		7
			8			8	Front passenger side mirror adjustment motor -V150-		8	Light for passenger door ambient lighting -W87-
			9			9	Front passenger side fold-in mirror motor -V122-		9
			10	LIN bus		10	Front passenger side fold-in mirror motor -V122-		10
			11	Front passenger door lock unit -VX22-		11	Front passenger side turn signal repeater bulb -L132-		11
			12	Central locking SAFE function motor, in front passenger door -V162-		12			12
			13	Front passenger door central locking motor -V57-		13	Front passenger side exterior mirror -VX5-		13
			14	B407 Connection 2 (convenience CAN bus, low), in main wiring harness		14	Front passenger side exterior mirror -VX5-		14
			15	B398 Connection 2 (convenience CAN bus, high), in main wiring harness		15	Heated exterior mirror on front passenger side -Z5-		15
			16			16	Front passenger side exterior mirror -VX5-		16	Light conductor for front right sill panel moulding ambient lighting -W68-
			17						17
			18						18
			19	Terminal 30					19
			20	Terminal 31					20
									21
									22
									23
									24
									25
									26
									27
									28
									29
									30
									31
									32	Front passenger side window regulator button -E716-

Back to overview VW GOLF 2015 Display unit for front information display and operating unit control unit J685 1 -  Display unit for front information display and operating unit control unit -J685- A -  4-pin connector q   Radio aerial -R248- q   Radio aerial 2 -R93- B -  8-pin connector -T8aq- C -  12-pin connector -T12ag- D -  12-pin connector -T12a- E -  8-pin connector -T8ar- F -  12-pin connector -T12al- Connector assignment of display unit for front information display and operating unit control unit -J685-     -T8ar- (E) Designation -T8aq- (B) Designation 1 Rear right treble loudspeaker -R16- , + rear right bass loudspeaker -R17- , +   9   2 Front right treble loudspeaker -R22- , + front right bass loudspeaker -R23- , +   10   3 Front left treble loudspeaker -R20- , + front left bass loudspeaker -R21- ,+   11   4 Rear left treble loudspeaker -R14- , + rear left bass loudspeaker -R15- , +   12   5 Rear right treble loudspeaker -R16- , - rear right bass loudspeaker -R17- , -   13   6 Front right treble loudspeaker -R22- , - front right bass loudspeaker -R23- , -   14   7 Front left treble loudspeaker -R20- , - front left bass loudspeaker -R21- ,-   17(1) Terminal 31 8 Rear left treble loudspeaker -R14- , - rear left bass loudspeaker -R15- , -   18(2) Terminal 30 -T12al- (F) Designation   -T12ag- (C) Designation   -T12a- (D) Designation 1     1   1   2     2     2   3     3   3   4     4   4   5     5     5   6 A178 Connection (infotainment CAN bus, high), in dash panel wiring harness 6   6   7     7   7   8     8   8   9     9     9   10     10     10   11     11     11   12 A179 Connection (infotainment CAN bus, low), in dash panel wiring harness 12   12   Back to overview 1 -  Display unit for front information display and operating unit control unit -J685- A -  12-pin connector -T12ai- B -  5-pin connector -T5ad- q   Control unit 1 for information electronics -J794- Connector assignment of display unit for front information display and operating unit control unit -J685-     -T12ai- (A) Designation 1 Terminal 30 2   3 B415 Connection 1 (infotainment CAN bus, high), in main wiring harness 4   5   6   7 Terminal 31 8   9 B421 Connection 1 (infotainment CAN bus, low), in main wiring harness 10   11   12   Back to overview VW GOLF 2015 Air conditioning system control unit -J301- / heater control unit -J65- Fitting location: In centre of dash panel.     Get access to all wiring diagrams of the car 1 -  Air conditioning system control unit -J301- / heater control unit -J65- A -  16-pin connector -T16c- B -  20-pin connector -T20c- Connector assignment of air conditioning system control unit -J301- / heater control unit -J65-     -T16c- (A) Designation   -T20c- (B) Designation 1 Potentiometer for air distribution flap control motor -G645- Potentiometer for temperature flap control motor -G92-   1   2 Potentiometer for temperature flap control motor -G92-   2 3 Potentiometer for air distribution flap control motor -G645-   3 4     4 5 Temperature flap control motor -V68- 5 B506 Connection (convenience CAN bus, high), in interior wiring harness 6 Temperature flap control motor -V68- 6 B507 Connection (convenience CAN bus, low), in interior wiring harness 7 Air distribution flap control motor -V428-   7 8 Air distribution flap control motor -V428-   8 9 Air recirculation flap control motor -V113- 9 10 Air recirculation flap control motor -V113- 10 11 Evaporator temperature sensor -G308- l  Only models with air conditioning system   11   12     12   13     13   14 Potentiometer for air distribution flap control motor -G645- Potentiometer for temperature flap control motor -G92-   14 15     15   16     16 A209 Connection 1 (LIN bus) in dash panel wiring harness       17         18 Air conditioner compressor regulating valve -N280- l  Only models with air conditioning system       19 Terminal 31       20 Terminal 30 Back to overview VW GOLF 2015 Climatronic control unit J255 Climatronic control unit -J255- Fitting location: In centre of dash panel.     Get access to all wiring diagrams of the car 1 -  Climatronic control unit -J255- A -  16-pin connector -T16d- B -  16-pin connector -T16c- C -  20-pin connector -T20c- Connector assignment of Climatronic control unit -J255-     -T16d- (A) Designation   -T16c- (B) Designation   -T20c- (C) Designation 1 Left temperature flap control motor -V158-   1 Potentiometer for front air distribution flap control motor -G642- Potentiometer for fresh air/recirculated air, air flow flap control motor -G644- , 5V Potentiometer for defroster flap control motor -G135- Potentiometer for left temperature flap control motor -G220- Potentiometer for right temperature flap control motor -G221-   1 Sunlight penetration photosensor -G107- 2 Left temperature flap control motor -V158-   2 Potentiometer for left temperature flap control motor -G220-   2   3 Defroster flap control motor -V107- 3 Potentiometer for right temperature flap control motor -G221- ,   3 Sunlight penetration photosensor -G107- 4 Defroster flap control motor -V107- 4 Potentiometer for defroster flap control motor -G135-   4   5 Front air distribution flap control motor -V426-   5 Potentiometer for front air distribution flap control motor -G642-   5 B506 Connection (convenience CAN bus, high), in interior wiring harness 6 Front air distribution flap control motor -V426-   6     6 B507 Connection (convenience CAN bus, low), in interior wiring harness 7     7 Potentiometer for fresh air/recirculated air, air flow flap control motor -G644-   7 Refrigerant shut-off valve for heater and air conditioner unit -N541-1) 8     8 Footwell vent temperature sender -G192-   8   9 Fresh air/recirculated air, air flow flap control motor -V425-   9     9 Sunlight penetration photosensor -G107- 10 Fresh air/recirculated air, air flow flap control motor -V425-   10     10 Refrigerant shut-off valve for high-voltage battery heat exchanger -N542-1) 11 Right temperature flap control motor -V159-   11 Evaporator temperature sensor -G308-   11   12 Right temperature flap control motor -V159-   12   12   13     13   13 Left vent temperature sender -G150- 14     14 Potentiometer for front air distribution flap control motor -G642- , - Potentiometer for fresh air/recirculated air, air flow flap control motor -G644- , - Potentiometer for defroster flap control motor -G135- , - Potentiometer for left temperature flap control motor -G220- , - Potentiometer for right temperature flap control motor -G221- , - Footwell vent temperature sender -G192- , - Evaporator temperature sensor -G308- , -   14 Right vent temperature sender -G151- 15     15   15   16     16   16 A209 Connection 1 (LIN bus) in dash panel wiring harness         17 Sunlight penetration photosensor -G107- , - right vent temperature sender -G151- , - left vent temperature sender -G150- , -         18 Air conditioner compressor regulating valve -N280- Air conditioning system relay -J32-1)         19 Terminal 31         20 Terminal 30 1) Only models with hybrid drive system Back to overview VW GOLF 2015 Front camera for driver assist systems R242 Front camera for driver assist systems -R242- Fitting location: Near interior mirror.     Get access to all wiring diagrams of the car 1 -  Front camera for driver assist systems -R242- A -  12-pin connector -T12ar- Connector assignment of front camera for driver assist systems -R242-     -T12ar- (A) Designation 1 Adaptive cruise control unit -J428- 2 B109 Connection 1 (CAN bus extended low), in main wiring harness 3   4 Windscreen heater for front sensors -Z113- 5 Terminal 31 6 Terminal 15 7 Adaptive cruise control unit -J428- 8 B108 Connection 1 (CAN bus extended high), in main wiring harness 9   10   11   12   Back to overview VW GOLF 2015 Main beam assist control unit J844 Main beam assist control unit -J844- Fitting location: On interior mirror.     Get access to all wiring diagrams of the car 1 -  Main beam assist control unit -J844- A -  8-pin connector -T8bg- Connector assignment of main beam assist control unit -J844-     -T8bg- (A) Designation 1 Terminal 15 2 Terminal 31 3 B108 Connection 1 (CAN bus extended high), in main wiring harness 4   5   6 Front interior light -WX1- , - 7   8 B109 Connection 1 (CAN bus extended low), in main wiring harness Back to overview VW GOLF 2015 Selector lever E313 Selector lever -E313- Fitting location: In centre console, on selector lever bracket.     Get access to all wiring diagrams of the car 1 -  Selector lever -E313- A -  10-pin connector -T10s- Connector assignment of selector lever -E313-     -T10s- (A) Designation 1 Terminal 31 2 Control unit for electronic steering column lock -J764- 1)   Steering column electronics control unit -J527- 1) 3 Terminal 581) 4   5 Terminal 58 6   7 B383 Connection 1 (powertrain CAN bus, high), in main wiring harness   B776 Connection 1 (hybrid CAN bus, high), in main wiring harness2) 8 B390 Connection 1 (powertrain CAN bus, low), in main wiring harness   B777 Connection 1 (hybrid CAN bus, low), in main wiring harness2) 9 Terminal 15 10 Terminal 30 1) Depending on equipment 2) Only models with hybrid drive system Back to overview VW GOLF 2015 TV tuner RX6 TV tuner -RX6- Fitting location: under seat on front right     Get access to all wiring diagrams of the car 1 -  TV tuner -RX6- A -  2-pin connector -T2- q   TV aerial 1 -R55- B -  4-pin connector -T4- q   TV aerial 2 -R56- q   TV aerial 3 -R57- C -  Not assigned D -  2-pin connector -T2u- E -  12-pin connector -T12l- Connector assignment of TV tuner -RX6-     -T12l- (E) Designation   -T2u- (D) Designation 1 Terminal 30 1 Digital sound package control unit -J525- / control unit 1 for information electronics -J794- 2 Terminal 31 2 Digital sound package control unit -J525- / control unit 1 for information electronics -J794- 3 Control unit 1 for information electronics -J794-     4         5         6         7       8         9         10         11         12         Back to overview VW GOLF 2015 Special vehicle control unit J608 Special vehicle control unit -J608- Fitting location: under seat on front right     Get access to all wiring diagrams of the car 1 -  Special vehicle control unit -J608- A -  12-pin connector -T12c- B -  16-pin connector -T16e- C -  20-pin connector -T20m- D -  16-pin connector -T16b- Back to overview VW GOLF 2015 Fuel pump control unit -J538- , for models with petrol engine Fitting location: Under rear bench seat.     Get access to all wiring diagrams of the car 1 -  Fuel pump control unit -J538- A -  5-pin connector -T5ai- Connector assignment of fuel pump control unit -J538-     -T5ai- (A) Designation 1 Fuel system pressurisation pump -G6- , + 2 Fuel system pressurisation pump -G6- , - 3 Terminal 87 4 Terminal 31 5   Back to overview VW GOLF 2015 Fuel pump control unit -J538- , for models with diesel engine Fitting location: Under rear bench seat.     Get access to all wiring diagrams of the car 1 -  Fuel pump control unit -J538- A -  6-pin connector -T6cg- Connector assignment of fuel pump control unit -J538-     -T6cg- (A) Designation 1 Fuel system pressurisation pump -G6- , W-phase 2 Fuel system pressurisation pump -G6- , V-phase 3 Fuel system pressurisation pump -G6- , U-phase 4 Terminal 31 5 Terminal 87 6   Back to overview VW GOLF 2015 Fuel pump control unit -J538- , only models with hybrid drive system Fitting location: under load floor in luggage compartment.     Get access to all wiring diagrams of the car 1 -  Fuel pump control unit -J538- A -  5-pin connector -T5ai- Connector assignment of fuel pump control unit -J538-     -T5ai- (A) Designation 1 Fuel system pressurisation pump -G6- , + 2 Fuel system pressurisation pump -G6- , - 3 Terminal 87 4 Terminal 31 5 Engine control unit -J623- Back to overview VW GOLF 2015 Sliding sunroof adjustment control unit J245 Sliding sunroof adjustment control unit -J245- Fitting location: On rear sunroof motor.     Get access to all wiring diagrams of the car 1 -  Sliding sunroof adjustment control unit -J245- A -  10-pin connector -T10le- Connector assignment of sliding sunroof adjustment control unit -J245-     -T10le- (A) Designation 1 LIN bus 2   3   4 Sunroof button -E325- 5 Diagnosis 6 Sunroof button -E325- 7 Sunroof button -E325- 8   9 Terminal 31 10 Terminal 30 Back to overview VW GOLF 2015 Control unit for navigation system J856 Control unit for navigation system -J856- Fitting location: under seat on front right     Get access to all wiring diagrams of the car 1 -  Control unit for navigation system -J856- A -  10-pin connector -T10y- B -  5-pin connector -T5- q   Control unit 1 for information electronics -J794- C -  5-pin connector -T5- q   Multimedia system operating unit -E380- D -  2-pin connector q   Radio aerial -R248- E -  20-pin connector -T20p- F -  2-pin connector q   Digital radio aerial -R183- Connector assignment of control unit for navigation system -J856-     -T10y- (A) Designation   -T20p- (E) Designation 1 Terminal 31 1   2 Terminal 30 2   3     3   4     4 Telephone microphone -R38- 5 B421 Connection 1 (infotainment CAN bus, low), in main wiring harness 5   6     6 Control unit 1 for information electronics -J794- 7   7 Control unit 1 for information electronics -J794- 8 B415 Connection 1 (infotainment CAN bus, high), in main wiring harness 8 Control unit 1 for information electronics -J794- 9     9 Connection for external audio sources -R199- Interface for external multimedia unit -R215- 10     10 Connection for external audio sources -R199- Interface for external multimedia unit -R215-       11         12         13         14 Telephone microphone -R38-       15         16 Control unit 1 for information electronics -J794-     17 Control unit 1 for information electronics -J794-       18         19 Connection for external audio sources -R199- Interface for external multimedia unit -R215-       20 Connection for external audio sources -R199- Interface for external multimedia unit -R215- Back to overview VW GOLF 2015 Steering column electronics control unit J527 Steering column electronics control unit -J527- Fitting location: On A-pillar.     Get access to all wiring diagrams of the car 1 -  Steering column electronics control unit -J527- A -  16-pin connector -T16r- , for models with no steering wheel heating A -  14-pin connector -T14a- , for models with steering wheel heating B -  4-pin connector -T4k- Connector assignment of steering column electronics control unit -J527- , for models with no steering wheel heating     -T16r- (A) Designation   -T16r- (A) Designation   -T4k- (B) Designation 1 Terminal 30   9   1 Airbag control unit -J234- 2 Terminal 31   10   2 Airbag control unit -J234- 3 B507 Connection (convenience CAN bus, low), in interior wiring harness   11 Selector lever -E313-   3 4 B506 Connection (convenience CAN bus, high), in interior wiring harness   12   4   5 Cruise control system   13     6 Engine control unit -J623- , terminal 50   14 Onboard supply control unit -J519- , terminal 15       7 Onboard supply control unit -J519- , terminal S 15     8 B549 Connection 2 (LIN bus) in main wiring harness 16 Onboard supply control unit -J519- , terminal 15     Connector assignment of steering column electronics control unit -J527- , for models with steering wheel heating     -T14a- (A) Designation   -T14a- (B) Designation   -T4k- (B) Designation 1 Terminal 30 for steering wheel heating   8 Terminal 31 for steering wheel heating 1 Airbag control unit -J234- 2 Terminal 30   9 Selector lever -E313-   2 Airbag control unit -J234- 3     10 Onboard supply control unit -J519- , terminal 15   3   4 Terminal 31   11 Onboard supply control unit -J519- , terminal 15   4   5 B507 Connection (convenience CAN bus, low), in interior wiring harness   12 Onboard supply control unit -J519- , terminal S       6 B506 Connection (convenience CAN bus, high), in interior wiring harness   13 Engine control unit -J623- , terminal 50       7 Cruise control system off   14 B549 Connection 2 (LIN bus) in main wiring harness     Back to overview VW GOLF 2015 Storage compartment with interface for mobile telephone R265 Storage compartment with interface for mobile telephone -R265- Fitting location: Under centre armrest, front.     Get access to all wiring diagrams of the car 1 -  Storage compartment with interface for mobile telephone -R265- A -  4-pin connector -T4h- B -  2-pin connector q   Two-way signal amplifier for mobile telephone/data services -J984- q   GSM aerial Connector assignment for storage compartment with interface for mobile telephone -R265-     -T4h- (A) Designation 1 Terminal 30 2 Terminal 30 3 Control unit 1 for information electronics -J794- 4 Terminal 31 Back to overview VW GOLF 2015 Multifunction steering wheel control unit J453 Multifunction steering wheel control unit -J453- Fitting location: Inside the operating unit of the multifunction buttons on left of steering wheel -E440- .     Get access to all wiring diagrams of the car 1 -  Multifunction steering wheel control unit -J453- A -  5-pin connector -T5k- B -  12-pin connector -T12k- Connector assignment of multifunction steering wheel control unit -J453-     -T5k- (A) Designation   -T12k- (B) Designation 1 Terminal 31   1   2 Terminal 30   2   3 LIN bus   3 Driver side airbag igniter -N95- , + 4   4 Driver side airbag igniter -N95- , - 5 Steering column electronics control unit -J527-   5       6       7 Terminal 31     8 Horn plate -H-       9 LIN bus       10 Terminal 30       11 Multifunction steering wheel control unit -J453-       12   Back to overview VW GOLF 2015 Driver door control unit J386 Driver door control unit -J386- Fitting location: In driver door.     Get access to all wiring diagrams of the car 1 -  Driver door control unit -J386- A -  6-pin connector -T6o- B -  20-pin connector -T20a- C -  16-pin connector -T16a- D -  32-pin connector -T32a- Connector assignment of driver door control unit -J386-     -T6o- (A) Designation   -T20a- (B) Designation   -T16a- (C) Designation   -T32a- (D) Designation 1     1 Driver side contact switch in lock cylinder -F241- 1 Driver side entry light in exterior mirror -W52- 1 Central locking SAFE function warning lamp -K133- 2     2     2 2 3 Left window regulator motor -V14-   3   3 Heated exterior mirror on driver side -Z4- Driver side turn signal repeater bulb in exterior mirror -L131- 3 Light for driver door ambient lighting -W86- Light for driver side interior door handle illumination -L219- 4     4     4 Driver side exterior mirror -VX4-   4 Terminal 58 5     5 Driver door contact switch -F2- 5 Driver side mirror adjustment motor -V17- Driver side mirror adjustment motor -V149-   5 Terminal 31 6 Left window regulator motor -V14-   6 Driver door central locking actuator for SAFELOCK function -F243-   6   6       7     7 Driver side mirror adjustment motor -V17- 7       8   8 Driver side mirror adjustment motor -V149-   8 Light for driver door ambient lighting -W86-       9     9 Driver side fold-in mirror motor -V121-   9         10 LIN bus   10 Driver side fold-in mirror motor -V121- 10       11 Driver door lock unit -VX21- 11 Driver side turn signal repeater bulb in exterior mirror -L131-   11         12 Driver door central locking SAFELOCK function motor -V161-   12   12       13 Driver door central locking motor -V56-   13 Driver side exterior mirror -VX4-   13 Driver side interior locking button for central locking system -E308-       14 B507 Connection (convenience CAN bus, low), in interior wiring harness   14 Driver side exterior mirror -VX4-   14         15 B506 Connection (convenience CAN bus, high), in interior wiring harness   15 Heated exterior mirror on driver side -Z4- 15       16     16 Driver side exterior mirror -VX4- 16 Light conductor for front left sill panel moulding ambient lighting -W67-       17       17         18           18         19 Terminal 30       19         20 Terminal 31       20                     21                     22                     23                     24 Exterior mirror adjuster -EX11-                   25 Exterior mirror adjuster -EX11-                   26                     27 Childproof lock button -E318-                   28 Driver side interior locking button for central locking system -E308-                   29 Rear passenger side window regulator button -E713-                   30 Rear driver side window regulator button -E711-                   31 Front passenger side window regulator button -E716-                   32 Front driver side window regulator button -E710- Back to overview VW GOLF 2015 Massage control unit J740 Massage control unit -J740- Fitting location: On driver seat.     Get access to all wiring diagrams of the car 1 -  Massage control unit -J740- A -  16-pin connector -T16w- B -  12-pin connector -T12an- Connector assignment of massage control unit -J740-     -T16w- (A) Designation   -T12an- (B) Designation 1     1 2     2 3     3 4 Lumbar support longitudinal adjustment sender -G375-   4   5     5 6 Lumbar support height adjustment sender -G374-   6   7 Driver seat lumbar support adjustment switch -E176-   7   8 Driver seat lumbar support adjustment switch -E176-   8   9 Driver seat lumbar support adjustment switch -E176- , Massage function button -E337-   9   10     10 11 Driver seat lumbar support longitudinal adjustment motor -V125-   11 Terminal 30 12 Lumbar support longitudinal adjustment sender -G375- , Lumbar support height adjustment sender -G374- 12 Terminal 31 13 Driver seat lumbar support longitudinal adjustment motor -V125-       14 Massage function button -E337-     15 Driver seat lumbar support height adjustment motor -V129-       16 Driver seat lumbar support height adjustment motor -V129-       Back to overview VW GOLF 2015 Digital sound package control unit J525 Digital sound package control unit -J525- Fitting location: Under driver seat.     Get access to all wiring diagrams of the car A -  Digital sound package control unit -J525- A -  38-pin connector -T38- B -  2-pin connector -T2ed- Connector assignment of digital sound package control unit -J525-     -T38- (A) Designation   -T38- (A) Designation 1 Terminal 30   20 Rear right bass loudspeaker -R17- , - 2 Terminal 31   21 Front right bass loudspeaker -R23- , + 3 Front left bass loudspeaker -R21- , -   22   4 Subwoofer -R211- , -   23 5 Subwoofer -R211- , -   24 6 Front right treble loudspeaker -R22- ,-   25   7 Rear left bass loudspeaker -R15- , +   26   8 Rear right bass loudspeaker -R17- , + 27   9 Front right bass loudspeaker -R23- , - 28   10     29 11 Front left treble loudspeaker -R20- , +   30 12 Front left treble loudspeaker -R20- , -   31 Rear left treble loudspeaker -R14- , + 13   32 Rear left treble loudspeaker -R14- , - 14     33 Rear right treble loudspeaker -R16- , + 15 Front left bass loudspeaker -R21- , + 34 Rear right treble loudspeaker -R16- , - 16 Subwoofer -R211- , + 35 17 Subwoofer -R211- , +   36   18 Front right treble loudspeaker -R22- ,+ 37 19 Rear left bass loudspeaker -R15- , - 38 Control unit 1 for information electronics -J794- Back to overview VW GOLF 2015 Control unit for electronic steering column lock J764 Control unit for electronic steering column lock -J764- Fitting location: On A-pillar.     Get access to all wiring diagrams of the car 1 -  Control unit for electronic steering column lock -J764- A -  16-pin connector -T16s- Connector assignment of control unit for electronic steering column lock -J764-     -T16s- (A) Designation   -T16s- (A) Designation 1     9   2 Terminal 30   10 Terminal 31 3     11   4 Starter button -E378- 12 Engine control unit -J623- , terminal 50 5     13 Starter button -E378- 6 Onboard supply control unit -J519- , terminal 15 14 Selector lever -E313- 7 Onboard supply control unit -J519- , terminal S 15 B507 Connection (convenience CAN bus, low), in interior wiring harness 8 Onboard supply control unit -J519- , terminal 15 16 B506 Connection (convenience CAN bus, high), in interior wiring harness Back to overview VW GOLF 2015 Control unit in dash panel insert J285 Control unit in dash panel insert -J285- Fitting location: In dash panel.     Get access to all wiring diagrams of the car 1 -  Control unit in dash panel insert -J285- A -  18-pin connector -T18- Connector assignment of control unit in dash panel insert -J285-     -T18- (A) Designation   -T18- (A) Designation 1 Terminal 30   10 Terminal 31 2     11 Fuel gauge sender -G- , terminal 31 3     12 Fuel gauge sender for auxiliary fuel tank -G292- 4     13 Fuel gauge sender for auxiliary fuel tank -G292- 5     14 Fuel gauge sender -G- 6     15 Fuel gauge sender -G- l 7 Parking brake pressure switch -F234-   16 8 Immobiliser reader coil -D2- 17 B507 Connection (convenience CAN bus, low), in interior wiring harness 9 Immobiliser reader coil -D2- 18 B506 Connection (convenience CAN bus, high), in interior wiring harness Back to overview VW GOLF 2015 Onboard supply control unit J519 Onboard supply control unit -J519- Fitting location: Behind dash panel, left     Get access to all wiring diagrams of the car 1 -  Onboard supply control unit -J519- A -  73-pin connector -T73a- B -  46-pin connector -T46b- C -  73-pin connector -T73c- Connector assignment of onboard supply control unit -J519-     -T73a- (A) Designation   -T46b- (B) Designation   -T73c- (C) Designation 1 Terminal 30 t  seat heating   1 Right headlight dipped beam bulb -M31-   1 Terminal 30 t  left light supply 2 Heated seat cushion for driver seat -Z6- 2 Right headlight main beam bulb -M32- Right static cornering light -M52-   2   3 Fuel tank filler flap central locking actuator -F219- - 3   3 Bulb 2 for rear right turn signal -M81- 4 Fuel tank filler flap central locking actuator -F219- + 4 Left daytime running light bulb -L174-   4 Terminal 30 t  anti-theft alarm system 5 Heated seat cushion for front passenger seat -Z8- 5 Right fog light bulb -L23- Right static cornering light -M52-   5 Left headlight dipped beam bulb -M29- 6 Rear right door central locking motor, lock -V215-   6   6 Left tail light bulb -M4- Right tail light bulb -M2- 7 Rear right door central locking motor, lock -V215-   7 Washer pump -V5- 7 8     8 Washer pump -V5-   8 Right brake and tail light bulb -M22- 9 Rear lid central locking motor -V53-   9 Left washer jet heater element -Z20- Right washer jet heater element -Z21-   9 Bulb 2 for rear left turn signal -M80- 10     10 Front left side marker bulb -M33-   10 Left brake and tail light bulb 2 -M58- 11     11 Reversing light switch -F4-   11 Left reversing light bulb -M16- 12 Term. 31   12 Front right brake pad wear sender -G35- 12 Terminal 30 t  interior light 13 Terminal 15 voltage supply relay -J329-   13 Brake fluid level warning contact -F34-   13   14 Terminal 15   14 Bonnet contact switch -F387-   14 Interface for entry and start system -J965- 15 Sliding sunroof adjustment control unit -J245- , LIN bus   15   15 Light switch -E1- t  Dipped beam position 16 B506 Connection (convenience CAN bus, high), in interior wiring harness   16 Coolant shortage indicator sender -G32-   16 Light switch -E1- t  Automatic headlight control position 17 B507 Connection (convenience CAN bus, low), in interior wiring harness   17   17   18     18   18   19     19 Ambient temperature sensor -G17- , - coolant shortage indicator sender -G32- , - windscreen washer fluid level sender -G33- , -   19 20     20 Front right turn signal bulb -M7-   20   21     21 Right side light bulb -M3- Front right side marker bulb -M34-   21 Driving mode selection button -E735- 22     22 Front right headlight -MX2- t  Xenon shutter   22   23     23 Front left headlight -MX1- t  Xenon shutter   23   24     24 Horn relay -J413-   24 Heated rear window relay -J9- 25     25     25   26     26 Heated rear window relay -J9-   26   27     27 Ambient temperature sensor -G17-   27   28     28 Windscreen washer fluid level sender -G33-   28 Rain and light sensor -G397- 29 Rotary light switch -EX1- t  Fog light t  Rear fog light   29     29 30   30 Wiper motor control unit -J400-   30   31 Tank flap release -EX13-   31 Alarm horn -H12-   31 Rear right turn signal bulb -M8- 32 Rear lid handle release button -E234-   32 Right daytime running light bulb -L175-   32 Button for deactivating interior monitoring and vehicle inclination sensor -E616- 33 Rear right door central locking actuator for SAFELOCK function -F246-   33     33 34 34   34 Driving mode selection button -E735- 35 Rear left door central locking actuator for SAFELOCK function -F245-   35     35 36 Rear left door central locking motor, lock -V214- , safe +   36 Front left turn signal bulb -M5- 36   37 Rear right door central locking motor, lock -V215- , safe +   37   37   38     38     38   39     39 Left headlight main beam bulb -M30- Left static cornering light -M51-   39   40     40   40 Front right seat temperature sender -G345- 41     41     41   42     42     42 Indicator lamp for hazard warning light -K6- 43 Light switch -E1-   43   43 Front left seat temperature sender -G344- 44 Ignition/starter switch -D- , terminal 15   44     44   45     45 Left fog light bulb -L22- Left static cornering light -M51-   45   46 Rotary light switch -EX1- , zero position   46 Headlight washer system pump -V11-   46   47 Ignition/starter switch -D- , terminal 15       47   48 Rear right door contact switch -F11-       48 Indicator lamp for hazard warning light -K6- 49       49 50 Rear left door contact switch -F10-       50 51 Button for deactivating interior monitoring and vehicle inclination sensor -E616-         51 Start/Stop operation button -E693- 52 Rear lid lock unit -F256-   52   53 Rear lid lock unit -F256-     53 54 Steering column electronics control unit -J527-         54 55 Headlight range control and instrument illumination regulator -EX14-     55 56           56 Front left seat temperature sender -G344- Front right seat temperature sender -G345- 57 High-level brake light bulb -M25-         57 58           58 Brake light switch -F- 59 Left number plate light -X4- Right number plate light -X5-       59 60 Rear left turn signal bulb -M6-         60 Start/Stop operation button -E693- 61 Rear window wiper motor -V12-         61 62 Rear window wiper motor -V12-         62 Terminal 58d 63 Terminal 31         63 Terminal 31 64 Right reversing light bulb -M17-         64 65 Right tail light bulb -M2-         65 66 Terminal 30 t  right light supply     66   67         67 Front interior light -WX1- 68 Rear left door central locking motor, lock -V214-     68   69 Rear left door central locking motor, lock -V214-     69   70           70   71 Left brake and tail light bulb -M21-         71   72 Rear left fog light bulb -L46- Rear right fog light bulb -L47-         72 Front left footwell light -K268- Front right footwell light -K269- 73 Terminal 30 t  central locking supply     73 Terminal 30 Back to overview VW GOLF 2015 Parking aid control unit -J446- / park assist steering control unit -J791- Fitting location: Behind dash panel on driver side.     Get access to all wiring diagrams of the car 1 -  Parking aid control unit -J446- / park assist steering control unit -J791- A -  18-pin connector -T18k- B -  26-pin connector -T26i- Connector assignment of parking aid control unit -J446- / park assist steering control unit -J791-       -T18k- (A) Designation -T26i- (B) Designation   1 1     2 Front left sender for park assist steering on left side of vehicle -G568- , signal 2) 2 Front parking aid warning buzzer -H22-1) 3 Front centre left parking aid sender -G254- , signal 3 Park assist steering button -E581-   4 Front right parking aid sender -G252- , signal 4 Warning light for park​ assist steering​ -K241-   5 5     6 6 Rear left parking aid sender -G203- , signal   7   7 Rear centre right parking aid sender -G205- , signal   8   8 Rear right park assist steering sender -G717- , signal   9 9 Rear parking aid warning buzzer -H15-1)   10 Front right parking aid sender -G252- , terminal 31 front centre right parking aid sender -G253- , terminal 31 front centre left parking aid sender -G254- , terminal 31 front left parking aid sender -G255- , terminal 31 front left sender for park assist steering on left side of vehicle -G568- , terminal 31 2) front right sender for park assist steering on right side of vehicle -G569- , terminal 31 2) 10 Front parking aid warning buzzer -H22-1)   11 Front left parking aid sender -G255- , signal 11   12 Front centre right parking aid sender -G253- , signal 12   13 Front right sender for park assist steering on right side of vehicle -G569- , signal 2) 13 Terminal 31   14 Front right parking aid sender -G252- , terminal 15 front centre right parking aid sender -G253- , terminal 15 front centre left parking aid sender -G254- , terminal 15 front left parking aid sender -G255- , terminal 15 front left sender for park assist steering on left side of vehicle -G568- , terminal 15 2) front right sender for park assist steering on right side of vehicle -G569- , terminal 15 2) 14 Terminal 15   15 15 Rear parking aid warning buzzer -H15-1) 16 16 Parking aid button -E266-   17 17 Parking aid warning lamp -K136- 18 18 Rear left parking aid sender -G203- , terminal 15 rear centre left parking aid sender -G204- , terminal 15 rear centre right parking aid sender -G205- , terminal 15 rear right parking aid sender -G206- , terminal 15 rear left parking aid sender -G716- , terminal 15 2) rear right park assist steering sender -G717- , terminal 15 2)     19 Rear left park assist steering sender -G716- , signal 2)     20 Rear centre left parking aid sender -G204- , signal     21 Rear right parking aid sender -G206- , signal     22 Rear left parking aid sender -G203- , terminal 31 rear centre left parking aid sender -G204- , terminal 31 rear centre right parking aid sender -G205- , terminal 31 rear right parking aid sender -G206- , terminal 31 rear left parking aid sender -G716- , terminal 31 2) rear right park assist steering sender -G717- , terminal 31 2)     23 B664 Connection (running gear sensors CAN bus, low), in main wiring harness     24 B663 Connection (running gear sensors CAN bus, high), in main wiring harness     25       26   1) Only models with park assist steering 2) Depending on equipment Back to overview VW GOLF 2015 Emergency call module control unit and communication unit J949 Emergency call module control unit and communication unit -J949- Fitting location: behind dash panel insert -KX2-     Get access to all wiring diagrams of the car 1 -  Emergency call module control unit and communication unit -J949- A -  26-pin connector -T26a- B -  1) Emergency call module aerial -R263- B -  2) GSM aerial -R205- Back to overview Connector assignment of emergency call module control unit and communication unit -J949-     -T26a- (A) Designation   -T26a- (A) Designation 1 Terminal 30   14 B506 Connection (convenience CAN bus, high), in interior wiring harness 2 B507 Connection (convenience CAN bus, low), in interior wiring harness   15 3     16 4 Telephone microphone -R38- 17 Telephone microphone -R38- 5 Telephone microphone -R38- 18 Telephone microphone -R38- 6 Telematics button module -E734- 19 Telematics button module -E734- 7 Telematics button module -E734- 20 Telematics button module -E734- 8     21 9     22 10 Control unit 1 for information electronics -J794-   23   11 Control unit 1 for information electronics -J794-   24   12     25   13     26 Terminal 31 Back to overview VW GOLF 2015 Data bus diagnostic interface J533 Data bus diagnostic interface -J533- Fitting location: Below the dash panel.     Get access to all wiring diagrams of the car 1 -  Data bus diagnostic interface -J533- A -  20-pin connector -T20- Connector assignment of data bus diagnostic interface -J533-     -T20- (A) Designation   -T20- (A) Designation 1 Terminal 30   11 Terminal 31 2 Terminal 30   12 Terminal 31 3 A227 Connection 2 (LIN bus) in dash panel wiring harness 13 B549 Connection 2 (LIN bus) in main wiring harness 4     14 Terminal 15 5 B407 Connection 2 (convenience CAN bus, low), in main wiring harness   15 B398 Connection 2 (convenience CAN bus, high), in main wiring harness 6 B390 Connection 1 (powertrain CAN bus, low), in main wiring harness   16 B383 Connection 1 (powertrain CAN bus, high), in main wiring harness 7 B109 Connection 1 (CAN bus extended low), in main wiring harness   17 B108 Connection 1 (CAN bus extended high), in main wiring harness 8 B664 Connection (running gear sensors CAN bus, low), in main wiring harness   18 B663 Connection (running gear sensors CAN bus, high), in main wiring harness 9 B714 Connection 1 (CAN bus diagnosis, low), in main wiring harness   19 B713 Connection 1 (diagnosis CAN bus, high), in main wiring harness 10 A179 Connection (infotainment CAN bus, low), in dash panel wiring harness   20 A178 Connection (infotainment CAN bus, high), in dash panel wiring harness Back to overview VW GOLF 2015 Airbag control unit J234 Airbag control unit -J234- Fitting location: Behind centre console.     Get access to all wiring diagrams of the car 1 -  Airbag control unit -J234- A -  90-pin connector -T90- Back to overview VW GOLF 2015 Control unit for cornering light and headlight range control J745 Control unit for cornering light and headlight range control -J745- Fitting location: Behind dash panel on driver side.     Get access to all wiring diagrams of the car 1 -  Control unit for cornering light and headlight range control -J745- A -  26-pin connector -T26h- VW GOLF 2015 Connector assignment Connector assignment Connector assignment of control unit for cornering light and headlight range control -J745- -T26h- (A) Designation   -T26h- (A) Designation 1     14 2 B668 Connection 2 (CAN bus extended high) in main wiring harness1) B108 Connection 1 (CAN bus extended high) in main wiring harness1)   15   3 B669 Connection 2 (CAN bus extended low) in main wiring harness 1) B109 Connection 1 (CAN bus extended low) in main wiring harness 1)   16   4 E135 Connection (CAN bus extended high), in engine compartment wiring harness   17 5 E136 Connection (CAN bus extended low), in engine compartment wiring harness   18 6     19 7 Rear left vehicle level sender -G76- , PWM   20 8     21 9     22 10 Rear left vehicle level sender -G76- , 5V   23 Terminal 15 11 Rear left vehicle level sender -G76- , -   24 Terminal 31 12     25 13     26 1) Depending on equipment Back to overview     Connector assignment of control unit for cornering light and headlight range control -J745- , for models with LED headlights -T26h- (A) Designation   -T26h- (A) Designation 1     14 2 B668 Connection 2 (CAN bus extended, high), in main wiring harness   15 Right headlight range control motor -V49- 3 B669 Connection 2 (CAN bus extended, low), in main wiring harness   16 Left headlight range control motor -V48- 4     17 Left headlight range control motor -V48- 5     18 Left headlight range control motor -V48- 6     19 Left headlight range control motor -V48- 7     20 Right headlight range control motor -V49- 8     21 Right headlight range control motor -V49- 9     22 Right headlight range control motor -V49- 10     23 Terminal 15 11     24 Terminal 31 12     25 13     26 Back to overview Interface for entry and start system -J965- Fitting location: Below the dash panel.     Get access to all wiring diagrams of the car 1 -  Interface for entry and start system -J965- A -  32-pin connector -T32b- Connector assignment of interface for entry and start system -J965-     -T32b- (A) Designation   -T32b– (A) Designation 1     17 Terminal 31 2     18 3 Terminal 30   19 Interior aerial 1 for entry and start system -R138- 4     20 Rear bumper aerial for entry and start system -R136- 5 Front passenger door exterior handle contact sensor -G416-   21 Passenger side aerial for entry and start system -R135- 6     22 Luggage compartment aerial for entry and start system -R137- 7     23 Driver side aerial for entry and start system -R134- 8     24 Driver side aerial for entry and start system -R134- 9 Driver door exterior handle contact sensor -G415-   25 Luggage compartment aerial for entry and start system -R137- 10 Onboard supply control unit -J519- 26 Passenger side aerial for entry and start system -R135- 11     27 Rear bumper aerial for entry and start system -R136- 12     28 Interior aerial 1 for entry and start system -R138- 13     29   14     30 Ignition and starter button illumination bulb -L190- 15     31   16 B407 Connection 2 (convenience CAN bus, low), in main wiring harness 32 B398 Connection 2 (convenience CAN bus, high), in main wiring harness Back to overview     VW GOLF 2015 Overview of fuse holders Overview of fuse holders   Note: The fitting locations are identical on LHD and RHD models. Get access to all wiring diagrams of the car q   Fuse assignment, only for vehicles with no special vehicle interface, from August 2013 q   Fitting location q   Fuse assignment, only for vehicles with special vehicle interface, from November 2013 q   Fuse assignment from July 2014 3 -  Fuse carrier 1 -ST1- q   Fuse assignment, only for special vehicles, from August 2013 q   Fitting location right-hand drive q   Fuse assignment, from August 2012 q   Fuse assignment, from April 2013 q   Fuse assignment, from November 2013 q   Fuse assignment from May 2014 q   Fuse assignment, from November 2014 q   Fuse assignment, from May 2015 q   Fuse assignment, from July 2014, only models with hybrid drive system q   Fuse assignment, from May 2015, only models with hybrid drive system 4 -  Relay and fuse carrier 3 -SR3-   Note: Only for special vehicles q   Fitting location q   Fuse assignment, only for special vehicles, from April 2013 q   Fuse assignment, from August 2012 q   Fuse assignment, from April 2013 q   Fuse assignment, from November 2013 q   Fuse assignment from May 2014 q   Fuse assignment, from July 2014, only models with hybrid drive system q   Fitting location, only models with hybrid drive system q   Fuse assignment, from August 2012 q   Fuse assignment, from July 2014, only models with hybrid drive system 7 -  High-voltage system fuse 3 -S353- q   Fuse assignment, from July 2014 q   Fuse assignment, only for special vehicles, from August 2013 VW GOLF 2015 Fitting location of fuse holder F -SF- , only models with no special vehicle interface Get access to all wiring diagrams of the car 1 -  Fuse holder F -SF- Fuse colours for J-Case fuse: t  50 A - red t  40 A - green t  30 A - pink Fuse colours for ATO flat fuse: t  40 A - orange t  30 A - light green t  25 A - natural (white) t  20 A - yellow t  15 A - light blue t  10 A - red t  7.5 A - brown t  5 A - light brown t  1A - black Fuse colours, for mini fuses: t  20 A - yellow t  15 A - light blue t  10 A - red t  7.5 A - brown t  5 A - light brown t  1A - black Back to overview     VW GOLF 2015 Fuse assignment of fuse holder F -SF- , only models with no special vehicle interface, from August 2013 Slot Current flow diagram designation Nominal value Function/component Terminal SF1 Fuse 1 on fuse holder F -SF1- 2) only Special vehicle fuse 1) 30 SF2 Fuse 2 on fuse holder F -SF2- 2) only Special vehicle fuse 1) 30 SF3 Fuse 3 on fuse holder F -SF3- 2) only Special vehicle fuse 1) 30 SF4 Fuse 4 on fuse holder F -SF4- 2) only Special vehicle fuse 1) 30 SF5 Fuse 5 on fuse holder F -SF5- 2) only Special vehicle fuse 1) 30 SF6 Fuse 6 on fuse holder F -SF6- 2) only Special vehicle fuse 1) 30 SF7 Fuse 7 on fuse holder F -SF7- 2) only Special vehicle fuse 1) 30 SF8 Fuse 8 on fuse holder F -SF8- 2) only Special vehicle fuse 1) 30 SF9 Fuse 9 on fuse holder F -SF9- 2) only Special vehicle fuse 1) 30 SF10 Fuse 10 on fuse holder F -SF10- 2) only Special vehicle fuse 1) 30 SF11 Fuse 11 on fuse holder F -SF11- 2) only Special vehicle fuse 1) 30 SF12 Fuse 12 on fuse holder F -SF12- 2) only Special vehicle fuse 1) 30 SF13 Fuse 13 on fuse holder F -SF13- 2) only Special vehicle fuse 1) 30 1) According to equipment 2) Fuse rating, see installation description for special installations Back to overview VW GOLF 2015 Fitting location of fuse holder F -SF- , only models with special vehicle interface Get access to all wiring diagrams of the car 1 -  Fuse holder F -SF- Fuse colours for J-Case fuse: t  50 A - red t  40 A - green t  30 A - pink Fuse colours for ATO flat fuse: t  40 A - orange t  30 A - light green t  25 A - natural (white) t  20 A - yellow t  15 A - light blue t  10 A - red t  7.5 A - brown t  5 A - light brown t  1A - black Fuse colours, for mini fuses: t  20 A - yellow t  15 A - light blue t  10 A - red t  7.5 A - brown t  5 A - light brown t  1A - black Back to overview     VW GOLF 2015 Fuse assignment of fuse holder F -SF- , only models with special vehicle interface, from November 2013 Slot Current flow diagram designation Nominal value Function/component Terminal SF1 Fuse 1 on fuse holder F -SF1- 2) only Special vehicle fuse 1) 30 SF2 Fuse 2 on fuse holder F -SF2- 2) only Special vehicle fuse 1) 30 SF3 Fuse 3 on fuse holder F -SF3- 2) only Special vehicle fuse 1) 30 SF4 Fuse 4 on fuse holder F -SF4- 2) only Special vehicle fuse 1) 30 SF5 Fuse 5 on fuse holder F -SF5- 2) only Special vehicle fuse 1) 30 SF6 Fuse 6 on fuse holder F -SF6- 2) only Special vehicle fuse 1) 30 SF7 Fuse 7 on fuse holder F -SF7- 2) only Special vehicle fuse 1) 30 SF8 Fuse 8 on fuse holder F -SF8- 2) only Special vehicle fuse 1) 30 SF9 Fuse 9 on fuse holder F -SF9- 2) only Special vehicle fuse 1) 30 SF10 Fuse 10 on fuse holder F -SF10- 2) only Special vehicle fuse 1) 30 SF11 Fuse 11 on fuse holder F -SF11- 2) only Special vehicle fuse 1) 30 SF12 Fuse 12 on fuse holder F -SF12- 2) only Special vehicle fuse 1) 30 SF13 Fuse 13 on fuse holder F -SF13- 2) only Special vehicle fuse 1) 30 SF14 Fuse 14 on fuse holder F -SF14- 2) only Special vehicle fuse 1) 30 SF15 Fuse 15 on fuse holder F -SF15- 2) only Special vehicle fuse 1) 30 1) According to equipment 2) Fuse rating, see installation description for special installations Back to overview VW GOLF 2015 Fitting location of fuse holder D -SD- , only models with hybrid drive system Get access to all wiring diagrams of the car 1 -  Fuse 1 on fuse holder D -SD1- 2 -  Fuse 2 on fuse holder D -SD2- Back to overview     VW GOLF 2015 Fuse assignment of fuse holder D -SD- , from July 2014, only models with hybrid drive system Slot Current flow diagram designation Nominal value Function/component Terminal 1 Fuse 1 on fuse holder D -SD1- 200 A 508 Threaded connection (30), on E-box t  Supply for fuse holder A -SA- 30 2 Not assigned -   - Back to overview VW GOLF 2015 Fitting location of fuse holder C SC Fitting location of fuse holder C -SC- Fitting location, fuse holder C -SC- , left-hand drive Get access to all wiring diagrams of the car 1 -  Fuse holder C -SC- Fuse colours for J-Case fuse: t  50 A - red t  40 A - green t  30 A - pink Fuse colours for ATO flat fuse: t  40 A - orange t  30 A - light green t  25 A - natural (white) t  20 A - yellow t  15 A - light blue t  10 A - red t  7.5 A - brown t  5 A - light brown t  1A - black Fuse colours, for mini fuses: t  20 A - yellow t  15 A - light blue t  10 A - red t  7.5 A - brown t  5 A - light brown t  1A - black Back to overview     Fitting location, fuse holder C -SC- , right-hand drive Get access to all wiring diagrams of the car 1 -  Fuse holder C -SC- Fuse colours for J-Case fuse: t  50 A - red t  40 A - green t  30 A - pink Fuse colours for ATO flat fuse: t  40 A - orange t  30 A - light green t  25 A - natural (white) t  20 A - yellow t  15 A - light blue t  10 A - red t  7.5 A - brown t  5 A - light brown t  1A - black Fuse colours, for mini fuses: t  20 A - yellow t  15 A - light blue t  10 A - red t  7.5 A - brown t  5 A - light brown t  1A - black Back to overview     Fuse assignment of fuse holder C -SC- , from August 2012 Slot Current flow diagram designation Nominal value Function/component Terminal F1 not assigned - - F2 not assigned - - F3 not assigned - - F4 Fuse 4 on fuse holder C -SC4- 10 A Onboard supply control unit -J519- t  Anti-theft alarm system 30 F5 Fuse 5 on fuse holder C -SC5- 5 A Data bus diagnostic interface -J533- 30 F6 Fuse 6 on fuse holder C -SC6- 5 A Anti-theft alarm sensor -G578- 30 F7 Fuse 7 on fuse holder C -SC7- 10 A Heater and air conditioning controls -EX21- 30     Heater control unit -J65-       Climatronic control unit -J255-       Air conditioning system control unit -J301-       Selector lever -E313-     Remote control receiver for auxiliary coolant heater -R149-       Heated rear window relay -J9- F8 Fuse 8 on fuse holder C -SC8- 10 A Rotary light switch -EX1- 30     Electromechanical parking brake button -E538-       Rain and light sensor -G397-       Diagnostic connection -U31- F9 not assigned - - F10 Fuse 10 on fuse holder C -SC10- 10 A Display unit for front information display and operating unit control unit -J685- 30     Control unit for navigation system -J856-   F11 Fuse 11 on fuse holder C -SC11- 15 A All-wheel drive control unit -J492- 30 F12 Fuse 12 on fuse holder C -SC12- 20 A Control unit 1 for information electronics -J794- 30 F13 Fuse 13 on fuse holder C -SC13- 15 A Electronically controlled damping control unit -J250- 30 F14 Fuse 14 on fuse holder C -SC14- 30 A Fresh air blower control unit -J126- 30 F15 Fuse 15 on fuse holder C -SC15- 10 A Control unit for electronic steering column lock -J764- 30 F16 Fuse 16 on fuse holder C -SC16- 7.5 A Two-way signal amplifier for mobile telephone/data services -J984- 30     Aerial amplifier 3 -R112-         Voltage converter for USB charge module -A5-   F17 Fuse 17 on fuse holder C -SC17- 5 A Control unit in dash panel insert -J285- Dash panel insert -KX2- 30 F18 Fuse 18 on fuse holder C -SC18- 7.5 A Reversing camera -R189- 30       Rear lid handle release button -E234-   F19 Fuse 19 on fuse holder C -SC19- 7.5 A Interface for entry and start system -J965- 30 F20 not assigned -   - F21 not assigned - - F22 not assigned - - F23 Fuse 23 on fuse holder C -SC23- 40 A Onboard supply control unit -J519- t  Front right headlight -MX2- 30 F24 Fuse 24 on fuse holder C -SC24- 30 A Sliding sunroof adjustment control unit -J245- 30 F25 Fuse 25 on fuse holder C -SC25- 30 A Driver door control unit -J386- 1) 30     Rear left window regulator motor -V26- 1) 30     Front passenger door control unit -J387-2)         Rear right window regulator motor -V27- 2)   F26 Fuse 26 on fuse holder C -SC26- 30 A Onboard supply control unit -J519- t  Front seat heating 30 F27 Fuse 27 on fuse holder C -SC27- 30 A Digital sound package control unit -J525- 30 F28 Fuse 28 on fuse holder C -SC28- 20 A Trailer detector control unit -J345- 30 F29 not assigned - 15 F30 Fuse 30 on fuse holder C -SC30- 25 A Control unit for front left belt tensioner -J854- 30 F31 Fuse 31 on fuse holder C -SC31- 40 A Onboard supply control unit -J519- t  Front left headlight -MX1- 30 F32 Fuse 32 on fuse holder C -SC32- 7.5 A Front camera for driver assist systems -R242- 15     Adaptive cruise control unit -J428-     Parking aid control unit -J446-     Park assist steering control unit -J791- F33 Fuse 33 on fuse holder C -SC33- 5 A Airbag control unit -J234- 15       Front passenger airbag deactivated warning lamp -K145-   F34 Fuse 34 on fuse holder C -SC34- 7.5 A Rotary light switch -EX1- 15     Interior mirror -EX5-       Relay for power sockets -J807-       Terminal 15 relief relay -J404-       Reversing light switch -F4-     Pressure sender for refrigerant circuit -G805-     Air quality sensor -G238-     TCS and ESP button -E256-         Electromechanical parking brake button -E538- F35 Fuse 35 on fuse holder C -SC35- 10 A Diagnostic connection -U31- 15     Headlight range control and instrument illumination regulator -EX14-       Control unit for cornering light and headlight range control -J745-     Left headlight range control motor -V48-       Right headlight range control motor -V49-   F36 Fuse 36 on fuse holder C -SC36- 10 A Control unit for right daytime running light and side light -J861- 15 F37 Fuse 37 on fuse holder C -SC37- 10 A Control unit for left daytime running light and side light -J860- 15 F38 Fuse 38 on fuse holder C -SC38- 20 A Trailer detector control unit -J345- 30 F39 Fuse 39 on fuse holder C -SC39- 30 A Front passenger door control unit -J387-1) 30     Rear right window regulator motor -V27- 1)     Driver door control unit -J386- 2) 30       Rear left window regulator motor -V26- 2)   F40 4) , 5) Fuse 40 on fuse holder C -SC40- 20 A Cigarette lighter -U1- 3) 15 4) / 30 5)     12 V socket -U5-       12 V socket 2 -U18-         12 V socket 3 -U19-   F41 Fuse 41 on fuse holder C -SC41- 1 A Steering column electronics control unit -J527- 30 F42 Fuse 42 on fuse holder C -SC42- 40 A Onboard supply control unit -J519- t  Central locking 30 F43 Fuse 43 on fuse holder C -SC43- 30 A Onboard supply control unit -J519- 30 F44 Fuse 44 on fuse holder C -SC44- 15 A Trailer detector control unit -J345- 30 F45 Fuse 45 on fuse holder C -SC45- 15 A Driver seat lumbar support adjustment switch -E176- 30     Driver seat adjustment operating unit -E470- F46 not assigned - - F47 Fuse 47 on fuse holder C -SC47- 15 A Rear window wiper motor -V12- 15 F48 not assigned - - F49 Fuse 49 on fuse holder C -SC49- 5 A Clutch position sender -G476- 15     Starter relay 1 -J906-         Starter relay 2 -J907-   F50 not assigned - - F51 Fuse 51 on fuse holder C -SC51- 25 A Control unit for front right belt tensioner -J855- 15 F52 not assigned - - F53 Fuse 53 on fuse holder C -SC53- 30 A Heated rear window relay -J9- 15 1) Only left-hand drive models 2) Only right-hand drive models 3) Smokers version 4) Factory fitted with power supply from terminal 15 5) Power supply via terminal 30 possible   Note: The fuse SC40 is supplied via terminal 15 from the factory and can be supplied via terminal 30 by reconnecting. If a consumer is connected to the electric socket or to the cigarette lighter, ensure that the consumer is disconnected from the voltage supply when the engine is switched off to prevent the drive battery being discharged. Back to overview     VW GOLF 2015 Fuse assignment of fuse holder C -SC- , from April 2013 Slot Current flow diagram designation Nominal value Function/component Terminal F1 not assigned - - F2 not assigned - - F3 not assigned - - F4 Fuse 4 on fuse holder C -SC4- 10 A Onboard supply control unit -J519- t  Anti-theft alarm system 30 F5 Fuse 5 on fuse holder C -SC5- 5 A Data bus diagnostic interface -J533- 30 F6 Fuse 6 on fuse holder C -SC6- 5 A Anti-theft alarm sensor -G578- 30 F7 Fuse 7 on fuse holder C -SC7- 10 A Heater and air conditioning controls -EX21- 30     Heater control unit -J65-       Climatronic control unit -J255-       Air conditioning system control unit -J301-       Selector lever -E313-     Remote control receiver for auxiliary coolant heater -R149-       Heated rear window relay -J9- F8 Fuse 8 on fuse holder C -SC8- 10 A Rotary light switch -EX1- 30     Electromechanical parking brake button -E538-       Rain and light sensor -G397-       Diagnostic connection -U31- F9 not assigned - - F10 Fuse 10 on fuse holder C -SC10- 10 A Display unit for front information display and operating unit control unit -J685- 30     Control unit for navigation system -J856-       TV tuner -RX6-   F11 Fuse 11 on fuse holder C -SC11- 15 A All-wheel drive control unit -J492- 30 F12 Fuse 12 on fuse holder C -SC12- 20 A Control unit 1 for information electronics -J794- 30 F13 Fuse 13 on fuse holder C -SC13- 15 A Electronically controlled damping control unit -J250- 30 F14 Fuse 14 on fuse holder C -SC14- 30 A Fresh air blower control unit -J126- 30 F15 Fuse 15 on fuse holder C -SC15- 10 A Control unit for electronic steering column lock -J764- 30 F16 Fuse 16 on fuse holder C -SC16- 7.5 A Two-way signal amplifier for mobile telephone/data services -J984- 30     Aerial amplifier 3 -R112-       Voltage converter for USB charge module -A5-       USB hub -R293-         Chip card reader -D8-   F17 Fuse 17 on fuse holder C -SC17- 5 A Control unit in dash panel insert -J285- Dash panel insert -KX2- 30 F18 Fuse 18 on fuse holder C -SC18- 7.5 A Reversing camera -R189- 30       Rear lid handle release button -E234-   F19 Fuse 19 on fuse holder C -SC19- 7.5 A Interface for entry and start system -J965- 30 F20 not assigned - - F21 not assigned - - F22 not assigned - - F23 Fuse 23 on fuse holder C -SC23- 40 A Onboard supply control unit -J519- t  Front right headlight -MX2- 30 F24 Fuse 24 on fuse holder C -SC24- 30 A Sliding sunroof adjustment control unit -J245- 30 F25 Fuse 25 on fuse holder C -SC25- 30 A Driver door control unit -J386- 1) 30     Rear left window regulator motor -V26- 1) 30     Front passenger door control unit -J387-2)         Rear right window regulator motor -V27- 2)   F26 Fuse 26 on fuse holder C -SC26- 30 A Onboard supply control unit -J519- t  Front seat heating 30 F27 Fuse 27 on fuse holder C -SC27- 30 A Digital sound package control unit -J525- 30 F28 Fuse 28 on fuse holder C -SC28- 20 A Trailer detector control unit -J345- 30 F29 Fuse 29 on fuse holder C -SC29-   Special vehicle fuse/according to equipment   F30 Fuse 30 on fuse holder C -SC30- 25 A Control unit for front left belt tensioner -J854- 30 F31 Fuse 31 on fuse holder C -SC31- 40 A Onboard supply control unit -J519- t  Front left headlight -MX1- 30 F32 Fuse 32 on fuse holder C -SC32- 7.5 A Front camera for driver assist systems -R242- 15     Adaptive cruise control unit -J428-     Parking aid control unit -J446-     Park assist steering control unit -J791- F33 Fuse 33 on fuse holder C -SC33- 5 A Airbag control unit -J234- 15       Front passenger airbag deactivated warning lamp -K145-   F34 Fuse 34 on fuse holder C -SC34- 7.5 A Rotary light switch -EX1- 15     Interior mirror -EX5-       Relay for power sockets -J807-       Reversing light switch -F4-     Pressure sender for refrigerant circuit -G805-     Air quality sensor -G238-     Electromechanical parking brake button -E538-       TCS and ESP button -E256-       Terminal 15 relief relay -J404-         Control unit for structure-borne sound -J869-6) F35 Fuse 35 on fuse holder C -SC35- 10 A Diagnostic connection -U31- 15     Headlight range control and instrument illumination regulator -EX14-       Control unit for cornering light and headlight range control -J745-     Left headlight range control motor -V48-       Right headlight range control motor -V49-   F36 Fuse 36 on fuse holder C -SC36- 10 A Control unit for right daytime running light and side light -J861- 15 F37 Fuse 37 on fuse holder C -SC37- 10 A Control unit for left daytime running light and side light -J860- 15 F38 Fuse 38 on fuse holder C -SC38- 20 A Trailer detector control unit -J345- 30 F39 Fuse 39 on fuse holder C -SC39- 30 A Front passenger door control unit -J387-1) 30     Rear right window regulator motor -V27- 1)     Driver door control unit -J386- 2) 30       Rear left window regulator motor -V26- 2)   F40 4) , 5) Fuse 40 on fuse holder C -SC40- 20 A Cigarette lighter -U1- 3) 15 4) / 30 5)     12 V socket -U5-         12 V socket 2 -U18-   F41 Fuse 41 on fuse holder C -SC41- 1 A Steering column electronics control unit -J527- 30 F42 Fuse 42 on fuse holder C -SC42- 40 A Onboard supply control unit -J519- t  Central locking 30 F43 Fuse 43 on fuse holder C -SC43- 30 A Onboard supply control unit -J519- 30 F44 Fuse 44 on fuse holder C -SC44- 15 A Trailer detector control unit -J345- 30 F45 Fuse 45 on fuse holder C -SC45- 15 A Driver seat lumbar support adjustment switch -E176- 30     Driver seat adjustment operating unit -E470- F46 not assigned - - F47 Fuse 47 on fuse holder C -SC47- 15 A Rear window wiper motor -V12- 15 F48 not assigned - - F49 Fuse 49 on fuse holder C -SC49- 5 A Clutch position sender -G476- 15     Starter relay 1 -J906-         Starter relay 2 -J907-   F50 not assigned - - F51 Fuse 51 on fuse holder C -SC51- 25 A Control unit for front right belt tensioner -J855- 15 F52 Fuse 52 on fuse holder C -SC52- 10 A Engine sound generator control unit -J943- 15 F53 Fuse 53 on fuse holder C -SC53- 30 A Heated rear window relay -J9- 15 1) Only left-hand drive models 2) Only right-hand drive models 3) Smokers version 4) Factory fitted with power supply from terminal 15 5) Power supply via terminal 30 possible 6) Only models with GTI equipment   Note: The fuse SC40 is supplied via terminal 15 from the factory and can be supplied via terminal 30 by reconnecting. If a consumer is connected to the electric socket or to the cigarette lighter, ensure that the consumer is disconnected from the voltage supply when the engine is switched off to prevent the drive battery being discharged. Back to overview     VW GOLF 2015 Fuse assignment of fuse holder C -SC- , from November 2013 Slot Current flow diagram designation Nominal value Function/component Terminal F1 not assigned - - F2 Fuse 2 on fuse holder C -SC2- 15 A Steering column electronics control unit -J527-7) 30 F3 Fuse 3 on fuse holder C -SC3- - Special vehicle fuse/according to equipment - F4 Fuse 4 on fuse holder C -SC4- 10 A Onboard supply control unit -J519- t  Anti-theft alarm system 30 F5 Fuse 5 on fuse holder C -SC5- 5 A Data bus diagnostic interface -J533- 30 F6 Fuse 6 on fuse holder C -SC6- 5 A Anti-theft alarm sensor -G578- 30 F7 Fuse 7 on fuse holder C -SC7- 10 A Heater and air conditioning controls -EX21- 30     Heater control unit -J65-       Climatronic control unit -J255-       Air conditioning system control unit -J301-       Selector lever -E313-     Remote control receiver for auxiliary coolant heater -R149-       Heated rear window relay -J9- F8 Fuse 8 on fuse holder C -SC8- 10 A Rotary light switch -EX1- 30     Electromechanical parking brake button -E538-       Rain and light sensor -G397-       Diagnostic connection -U31- F9 Fuse 9 on fuse holder C -SC9- 1 A Steering column electronics control unit -J527- 30 F10 Fuse 10 on fuse holder C -SC10- 10 A Display unit for front information display and operating unit control unit -J685- 30     Control unit for navigation system -J856-       TV tuner -RX6-   F11 Fuse 11 on fuse holder C -SC11- 25 A Control unit for front left belt tensioner -J854- 30 F12 Fuse 12 on fuse holder C -SC12- 20 A Control unit 1 for information electronics -J794- 30 F13 Fuse 13 on fuse holder C -SC13- 15 A Electronically controlled damping control unit -J250- 30 F14 Fuse 14 on fuse holder C -SC14- 30 A Fresh air blower control unit -J126- 30 F15 Fuse 15 on fuse holder C -SC15- 10 A Control unit for electronic steering column lock -J764- 30 F16 Fuse 16 on fuse holder C -SC16- 7.5 A Two-way signal amplifier for mobile telephone/data services -J984- 30     Aerial amplifier 3 -R112-       Voltage converter for USB charge module -A5-       USB hub -R293-         Chip card reader -D8-   F17 Fuse 17 on fuse holder C -SC17- 5 A Control unit in dash panel insert -J285- Dash panel insert -KX2- 30 F18 Fuse 18 on fuse holder C -SC18- 7.5 A Reversing camera -R189- 30       Rear lid handle release button -E234-   F19 Fuse 19 on fuse holder C -SC19- 7.5 A Interface for entry and start system -J965- 30 F20 not assigned - - F21 Fuse 21 on fuse holder C -SC21- 15 A All-wheel drive control unit -J492- 30 F22 not assigned - - F23 Fuse 23 on fuse holder C -SC23- 40 A Onboard supply control unit -J519- t  Front right headlight -MX2- 30 F24 Fuse 24 on fuse holder C -SC24- 30 A Sliding sunroof adjustment control unit -J245- 30 F25 Fuse 25 on fuse holder C -SC25- 30 A Driver door control unit -J386- 1) 30     Rear left window regulator motor -V26- 1) 30     Front passenger door control unit -J387-2)         Rear right window regulator motor -V27- 2)   F26 Fuse 26 on fuse holder C -SC26- 30 A Onboard supply control unit -J519- t  Front seat heating 30 F27 Fuse 27 on fuse holder C -SC27- 30 A Digital sound package control unit -J525- 30 F28 Fuse 28 on fuse holder C -SC28- 20 A Trailer detector control unit -J345- 30 F29 Fuse 29 on fuse holder C -SC29- - Special vehicle fuse/according to equipment - F30 not assigned - - F31 Fuse 31 on fuse holder C -SC31- 40 A Onboard supply control unit -J519- t  Front left headlight -MX1- 30 F32 Fuse 32 on fuse holder C -SC32- 7.5 A Front camera for driver assist systems -R242- 15     Adaptive cruise control unit -J428-     Parking aid control unit -J446-     Park assist steering control unit -J791- F33 Fuse 33 on fuse holder C -SC33- 5 A Airbag control unit -J234- 15       Front passenger airbag deactivated warning lamp -K145-   F34 Fuse 34 on fuse holder C -SC34- 7.5 A Rotary light switch -EX1- 15     Interior mirror -EX5-       Relay for power sockets -J807-       Reversing light switch -F4-     Pressure sender for refrigerant circuit -G805-     Air quality sensor -G238-     Electromechanical parking brake button -E538-       Control unit for structure-borne sound -J869-6)     TCS and ESP button -E256-   F35 Fuse 35 on fuse holder C -SC35- 10 A Diagnostic connection -U31- 15     Headlight range control and instrument illumination regulator -EX14-       Control unit for cornering light and headlight range control -J745-     Left headlight range control motor -V48-       Right headlight range control motor -V49-   F36 Fuse 36 on fuse holder C -SC36- 10 A Control unit for right daytime running light and side light -J861- 15 F37 Fuse 37 on fuse holder C -SC37- 10 A Control unit for left daytime running light and side light -J860- 15 F38 Fuse 38 on fuse holder C -SC38- 20 A Trailer detector control unit -J345- 30 F39 Fuse 39 on fuse holder C -SC39- 30 A Front passenger door control unit -J387-1) 30     Rear right window regulator motor -V27- 1)     Driver door control unit -J386- 2) 30       Rear left window regulator motor -V26- 2)   F40 4) , 5) Fuse 40 on fuse holder C -SC40- 20 A Cigarette lighter -U1- 3) 15 4) / 30 5)     12 V socket -U5-         12 V socket 2 -U18-   F41 Fuse 41 on fuse holder C -SC41- 25 A Control unit for front right belt tensioner -J855- 30 F42 Fuse 42 on fuse holder C -SC42- 40 A Onboard supply control unit -J519- t  Central locking 30 F43 Fuse 43 on fuse holder C -SC43- 30 A Onboard supply control unit -J519- 30 F44 Fuse 44 on fuse holder C -SC44- 15 A Trailer detector control unit -J345- 30 F45 Fuse 45 on fuse holder C -SC45- 15 A Driver seat lumbar support adjustment switch -E176- 30     Driver seat adjustment operating unit -E470- F46 not assigned - - F47 Fuse 47 on fuse holder C -SC47- 15 A Rear window wiper motor -V12- 15 F48 Fuse 48 on fuse holder C -SC48- 10A Engine sound generator control unit -J943- 15 F49 Fuse 49 on fuse holder C -SC49- 5 A Clutch position sender -G476- 15     Starter relay 1 -J906-         Starter relay 2 -J907-   F50 not assigned - - F51 not assigned - - F52 not assigned - - F53 Fuse 53 on fuse holder C -SC53- 30 A Heated rear window relay -J9- 15 1) Only left-hand drive models 2) Only right-hand drive models 3) Smokers version 4) Factory fitted with power supply from terminal 15 5) Power supply via terminal 30 possible 6) Only models with GTI equipment 7) Only models with heated steering wheel   Note: The fuse SC40 is supplied via terminal 15 from the factory and can be supplied via terminal 30 by reconnecting. If a consumer is connected to the electric socket or to the cigarette lighter, ensure that the consumer is disconnected from the voltage supply when the engine is switched off to prevent the drive battery being discharged. Back to overview     VW GOLF 2015 Fuse assignment of fuse holder C -SC- , from May 2014 Slot Current flow diagram designation Nominal value Function/component Terminal F1 not assigned - - F2 Fuse 2 on fuse holder C -SC2- 10 A Steering column electronics control unit -J527-7) 30 F3 Fuse 3 on fuse holder C -SC3- - Special vehicle fuse/according to equipment - F4 Fuse 4 on fuse holder C -SC4- 10 A Onboard supply control unit -J519- t  Anti-theft alarm system 30 F5 Fuse 5 on fuse holder C -SC5- 5 A Data bus diagnostic interface -J533- 30 F6 Fuse 6 on fuse holder C -SC6- 5 A Anti-theft alarm sensor -G578- 30 F7 Fuse 7 on fuse holder C -SC7- 10 A Heater and air conditioning controls -EX21- 30     Heater control unit -J65-       Climatronic control unit -J255-       Air conditioning system control unit -J301-       Selector lever -E313-     Remote control receiver for auxiliary coolant heater -R149-       Heated rear window relay -J9- F8 Fuse 8 on fuse holder C -SC8- 10 A Rotary light switch -EX1- 30     Electromechanical parking brake button -E538-       Rain and light sensor -G397-       Diagnostic connection -U31- F9 Fuse 9 on fuse holder C -SC9- 1 A Steering column electronics control unit -J527- 30 F10 Fuse 10 on fuse holder C -SC10- 10 A Display unit for front information display and operating unit control unit -J685- 30     Control unit for navigation system -J856-       TV tuner -RX6-   F11 Fuse 11 on fuse holder C -SC11- 25 A Control unit for front left belt tensioner -J854- 30 F12 Fuse 12 on fuse holder C -SC12- 20 A Control unit 1 for information electronics -J794- 30 F13 Fuse 13 on fuse holder C -SC13- 15 A Electronically controlled damping control unit -J250- 30 F14 Fuse 14 on fuse holder C -SC14- 30 A Fresh air blower control unit -J126- 30 F15 Fuse 15 on fuse holder C -SC15- 10 A Control unit for electronic steering column lock -J764- 30 F16 Fuse 16 on fuse holder C -SC16- 7.5 A Two-way signal amplifier for mobile telephone/data services -J984- 30     Storage compartment with interface for mobile telephone -R265-     Voltage converter for USB charge module -A5-       USB hub -R293-         Chip card reader -D8-   F17 Fuse 17 on fuse holder C -SC17- 5 A Control unit in dash panel insert -J285- Dash panel insert -KX2- 30 F18 Fuse 18 on fuse holder C -SC18- 7.5 A Reversing camera -R189- 30       Rear lid handle release button -E234-   F19 Fuse 19 on fuse holder C -SC19- 7.5 A Interface for entry and start system -J965- 30 F20 not assigned -   - F21 Fuse 21 on fuse holder C -SC21- 15 A All-wheel drive control unit -J492- 30 F22 Fuse 22 on fuse holder C -SC22- 15 A Trailer detector control unit -J345- 30 F23 Fuse 23 on fuse holder C -SC23- 40 A Onboard supply control unit -J519- t  Front right headlight -MX2- 30 F24 Fuse 24 on fuse holder C -SC24- 30 A Sliding sunroof adjustment control unit -J245- 30 F25 Fuse 25 on fuse holder C -SC25- 30 A Driver door control unit -J386- 1) 30     Rear left window regulator motor -V26- 1) 30     Front passenger door control unit -J387-2)         Rear right window regulator motor -V27- 2)   F26 Fuse 26 on fuse holder C -SC26- 30 A Onboard supply control unit -J519- t  Front seat heating 30 F27 Fuse 27 on fuse holder C -SC27- 30 A Digital sound package control unit -J525- 30 F28 Fuse 28 on fuse holder C -SC28- 25 A Trailer detector control unit -J345- 30 F29 Fuse 29 on fuse holder C -SC29- - Special vehicle fuse/according to equipment - F30 not assigned - - F31 Fuse 31 on fuse holder C -SC31- 40 A Onboard supply control unit -J519- t  Front left headlight -MX1- 30 F32 Fuse 32 on fuse holder C -SC32- 7.5 A Front camera for driver assist systems -R242- 15   10 A 8) Adaptive cruise control unit -J428-     Parking aid control unit -J446-     Park assist steering control unit -J791-     Blind Spot Monitor control unit -J1086-       Blind Spot Monitor control unit 2 -J1087-   F33 Fuse 33 on fuse holder C -SC33- 5 A Airbag control unit -J234- 15       Front passenger airbag deactivated warning lamp -K145-   F34 Fuse 34 on fuse holder C -SC34- 7.5 A Rotary light switch -EX1- 15     Interior mirror -EX5-       Relay for power sockets -J807-       Reversing light switch -F4-     Pressure sender for refrigerant circuit -G805-     Air quality sensor -G238-     Electromechanical parking brake button -E538-       Control unit for structure-borne sound -J869-6)     TCS and ESP button -E256-   F35 Fuse 35 on fuse holder C -SC35- 10 A Diagnostic connection -U31- 15     Headlight range control and instrument illumination regulator -EX14-       Control unit for cornering light and headlight range control -J745-     Left headlight range control motor -V48-       Right headlight range control motor -V49-   F36 Fuse 36 on fuse holder C -SC36- 10 A Control unit for right daytime running light and side light -J861- 15 F37 Fuse 37 on fuse holder C -SC37- 10 A Control unit for left daytime running light and side light -J860- 15 F38 Fuse 38 on fuse holder C -SC38- 25 A Trailer detector control unit -J345- 30 F39 Fuse 39 on fuse holder C -SC39- 30 A Front passenger door control unit -J387-1) 30     Rear right window regulator motor -V27- 1)     Driver door control unit -J386- 2) 30       Rear left window regulator motor -V26- 2)   F40 4) , 5) Fuse 40 on fuse holder C -SC40- 20 A Cigarette lighter -U1- 3) 15 4) / 30 5)     12 V socket -U5-         12 V socket 2 -U18-   F41 Fuse 41 on fuse holder C -SC41- 25 A Control unit for front right belt tensioner -J855- 30 F42 Fuse 42 on fuse holder C -SC42- 40 A Onboard supply control unit -J519- t  Central locking 30 F43 Fuse 43 on fuse holder C -SC43- 30 A Onboard supply control unit -J519- 30 F44 Fuse 44 on fuse holder C -SC44- 15 A Trailer detector control unit -J345- 30 F45 Fuse 45 on fuse holder C -SC45- 15 A Driver seat lumbar support adjustment switch -E176- 30     Driver seat adjustment operating unit -E470- F46 not assigned - - F47 Fuse 47 on fuse holder C -SC47- 15 A Rear window wiper motor -V12- 15 F48 Fuse 48 on fuse holder C -SC48- 10A Engine sound generator control unit -J943- 15 F49 Fuse 49 on fuse holder C -SC49- 5 A Clutch position sender -G476- 15     Starter relay 1 -J906-         Starter relay 2 -J907-   F50 not assigned - - F51 not assigned - - F52 not assigned - - F53 Fuse 53 on fuse holder C -SC53- 30 A Heated rear window relay -J9- 15 1) Only left-hand drive models 2) Only right-hand drive models 3) Smokers version 4) Factory fitted with power supply from terminal 15 5) Power supply via terminal 30 possible 6) Only models with GTI equipment 7) Only models with heated steering wheel 8) Only models with blind spot monitor   Note: The fuse SC40 is supplied via terminal 15 from the factory and can be supplied via terminal 30 by reconnecting. If a consumer is connected to the electric socket or to the cigarette lighter, ensure that the consumer is disconnected from the voltage supply when the engine is switched off to prevent the drive battery being discharged. Back to overview     VW GOLF 2015 Fuse assignment of fuse holder C -SC- , from November 2014 Slot Current flow diagram designation Nominal value Function/component Terminal F1 not assigned - - F2 Fuse 2 on fuse holder C -SC2- 10 A Steering column electronics control unit -J527-7) 30 F3 Fuse 3 on fuse holder C -SC3- - Special vehicle fuse/according to equipment - F4 Fuse 4 on fuse holder C -SC4- 10 A Onboard supply control unit -J519- t  Anti-theft alarm system 30 F5 Fuse 5 on fuse holder C -SC5- 5 A Data bus diagnostic interface -J533- 30 F6 Fuse 6 on fuse holder C -SC6- 5 A Anti-theft alarm sensor -G578- 30 F7 Fuse 7 on fuse holder C -SC7- 10 A Heater and air conditioning controls -EX21- 30     Heater control unit -J65-       Climatronic control unit -J255-       Air conditioning system control unit -J301-       Selector lever -E313-     Remote control receiver for auxiliary coolant heater -R149-       Heated rear window relay -J9- F8 Fuse 8 on fuse holder C -SC8- 10 A Rotary light switch -EX1- 30     Electromechanical parking brake button -E538-       Rain and light sensor -G397-       Diagnostic connection -U31- F9 Fuse 9 on fuse holder C -SC9- 5A Steering column electronics control unit -J527- 30 F10 Fuse 10 on fuse holder C -SC10- 10 A Display unit for front information display and operating unit control unit -J685- 30     Control unit for navigation system -J856-       TV tuner -RX6-   F11 Fuse 11 on fuse holder C -SC11- 25 A Control unit for front left belt tensioner -J854- 30 F12 Fuse 12 on fuse holder C -SC12- 20 A Control unit 1 for information electronics -J794- 30 F13 Fuse 13 on fuse holder C -SC13- 15 A Electronically controlled damping control unit -J250- 30 F14 Fuse 14 on fuse holder C -SC14- 30 A Fresh air blower control unit -J126- 30 F15 Fuse 15 on fuse holder C -SC15- 10 A Control unit for electronic steering column lock -J764- 30 F16 Fuse 16 on fuse holder C -SC16- 7.5 A Two-way signal amplifier for mobile telephone/data services -J984- 30     Storage compartment with interface for mobile telephone -R265-     Voltage converter for USB charge module -A5-       USB hub -R293-         Chip card reader -D8-   F17 Fuse 17 on fuse holder C -SC17- 5 A Control unit in dash panel insert -J285- Dash panel insert -KX2- 30 F18 Fuse 18 on fuse holder C -SC18- 7.5 A Reversing camera -R189- 30       Rear lid handle release button -E234-   F19 Fuse 19 on fuse holder C -SC19- 7.5 A Interface for entry and start system -J965- 30 F20 Fuse 20 on fuse holder C -SC20- 7.5 A 9) Control unit for fuel tank leak detection -J909-9) 30 F21 Fuse 21 on fuse holder C -SC21- 15 A All-wheel drive control unit -J492- 30 F22 Fuse 22 on fuse holder C -SC22- 15 A Trailer detector control unit -J345- 30 F23 Fuse 23 on fuse holder C -SC23- 40 A Onboard supply control unit -J519- t  Front right headlight -MX2- 30 F24 Fuse 24 on fuse holder C -SC24- 30 A Sliding sunroof adjustment control unit -J245- 30 F25 Fuse 25 on fuse holder C -SC25- 30 A Driver door control unit -J386- 1) 30     Rear left window regulator motor -V26- 1) 30     Front passenger door control unit -J387-2)         Rear right window regulator motor -V27- 2)   F26 Fuse 26 on fuse holder C -SC26- 30 A Onboard supply control unit -J519- t  Front seat heating 30 F27 Fuse 27 on fuse holder C -SC27- 30 A Digital sound package control unit -J525- 30 F28 Fuse 28 on fuse holder C -SC28- 25 A Trailer detector control unit -J345- 30 F29 Fuse 29 on fuse holder C -SC29- - Special vehicle fuse/according to equipment - F30 not assigned - - F31 Fuse 31 on fuse holder C -SC31- 40 A Onboard supply control unit -J519- t  Front left headlight -MX1- 30 F32 Fuse 32 on fuse holder C -SC32- 7.5 A Front camera for driver assist systems -R242- 15   10 A 8) Adaptive cruise control unit -J428-     Parking aid control unit -J446-     Park assist steering control unit -J791-     Blind Spot Monitor control unit -J1086-       Blind Spot Monitor control unit 2 -J1087-   F33 Fuse 33 on fuse holder C -SC33- 5 A Airbag control unit -J234- 15       Front passenger airbag deactivated warning lamp -K145-   F34 Fuse 34 on fuse holder C -SC34- 7.5 A Rotary light switch -EX1- 15     Interior mirror -EX5-       Relay for power sockets -J807-       Reversing light switch -F4-     Pressure sender for refrigerant circuit -G805-     Air quality sensor -G238-     Electromechanical parking brake button -E538-       Control unit for structure-borne sound -J869-6)     TCS and ESP button -E256-   F35 Fuse 35 on fuse holder C -SC35- 10 A Diagnostic connection -U31- 15     Headlight range control and instrument illumination regulator -EX14-       Control unit for cornering light and headlight range control -J745-     Left headlight range control motor -V48-       Right headlight range control motor -V49-   F36 Fuse 36 on fuse holder C -SC36- 10 A Control unit for right daytime running light and side light -J861- 15 F37 Fuse 37 on fuse holder C -SC37- 10 A Control unit for left daytime running light and side light -J860- 15 F38 Fuse 38 on fuse holder C -SC38- 25 A Trailer detector control unit -J345- 30 F39 Fuse 39 on fuse holder C -SC39- 30 A Front passenger door control unit -J387-1) 30     Rear right window regulator motor -V27- 1)     Driver door control unit -J386- 2) 30       Rear left window regulator motor -V26- 2)   F40 4) , 5) Fuse 40 on fuse holder C -SC40- 20 A Cigarette lighter -U1- 3) 15 4) / 30 5)     12 V socket -U5-         12 V socket 2 -U18-   F41 Fuse 41 on fuse holder C -SC41- 25 A Control unit for front right belt tensioner -J855- 30 F42 Fuse 42 on fuse holder C -SC42- 40 A Onboard supply control unit -J519- t  Central locking 30 F43 Fuse 43 on fuse holder C -SC43- 30 A Onboard supply control unit -J519- 30 F44 Fuse 44 on fuse holder C -SC44- 15 A Trailer detector control unit -J345- 30 F45 Fuse 45 on fuse holder C -SC45- 15 A Driver seat lumbar support adjustment switch -E176- 30     Driver seat adjustment operating unit -E470- F46 not assigned - - F47 Fuse 47 on fuse holder C -SC47- 15 A Rear window wiper motor -V12- 15 F48 Fuse 48 on fuse holder C -SC48- 10A Engine sound generator control unit -J943- 15 F49 Fuse 49 on fuse holder C -SC49- 5 A Clutch position sender -G476- 15     Starter relay 1 -J906-         Starter relay 2 -J907-   F50 not assigned - - F51 not assigned - - F52 not assigned - - F53 Fuse 53 on fuse holder C -SC53- 30 A Heated rear window relay -J9- 15 1) Only left-hand drive models 2) Only right-hand drive models 3) Smokers version 4) Factory fitted with power supply from terminal 15 5) Power supply via terminal 30 possible 6) Only models with GTI equipment 7) Only models with heated steering wheel 8) Only models with blind spot monitor 9) Only for American markets   Note: The fuse SC40 is supplied via terminal 15 from the factory and can be supplied via terminal 30 by reconnecting. If a consumer is connected to the electric socket or to the cigarette lighter, ensure that the consumer is disconnected from the voltage supply when the engine is switched off to prevent the drive battery being discharged. Back to overview     VW GOLF 2015 Fuse assignment of fuse holder C -SC- , from May 2015 Slot Current flow diagram designation Nominal value Function/component Terminal F1 not assigned - - F2 Fuse 2 on fuse holder C -SC2- 10 A Steering column electronics control unit -J527-7) 30 F3 Fuse 3 on fuse holder C -SC3- - Special vehicle fuse/according to equipment - F4 Fuse 4 on fuse holder C -SC4- 10 A Onboard supply control unit -J519- t  Anti-theft alarm system 30 F5 Fuse 5 on fuse holder C -SC5- 5 A Data bus diagnostic interface -J533- 30 F6 Fuse 6 on fuse holder C -SC6- 5 A Anti-theft alarm sensor -G578- 30 F7 Fuse 7 on fuse holder C -SC7- 10 A Heater and air conditioning controls -EX21- 30     Heater control unit -J65-       Climatronic control unit -J255-       Air conditioning system control unit -J301-       Selector lever -E313-     Remote control receiver for auxiliary coolant heater -R149-       Heated rear window relay -J9- F8 Fuse 8 on fuse holder C -SC8- 10 A Rotary light switch -EX1- 30     Electromechanical parking brake button -E538-       Rain and light sensor -G397-       Diagnostic connection -U31- F9 Fuse 9 on fuse holder C -SC9- 5A Steering column electronics control unit -J527- 30 F10 Fuse 10 on fuse holder C -SC10- 7.5 A Display unit for front information display and operating unit control unit -J685- 30 F11 Fuse 11 on fuse holder C -SC11- 25 A Control unit for front left belt tensioner -J854- 30 F12 Fuse 12 on fuse holder C -SC12- 20 A Control unit 1 for information electronics -J794- 30       Control unit for navigation system -J856-   F13 Fuse 13 on fuse holder C -SC13- 15 A Electronically controlled damping control unit -J250- 30 F14 Fuse 14 on fuse holder C -SC14- 30 A Fresh air blower control unit -J126- 30 F15 Fuse 15 on fuse holder C -SC15- 10 A Control unit for electronic steering column lock -J764- 30 F16 Fuse 16 on fuse holder C -SC16- 7.5 A Two-way signal amplifier for mobile telephone/data services -J984- 30     Storage compartment with interface for mobile telephone -R265-     Voltage converter for USB charge module -A5-       Chip card reader -D8-       USB hub -R293-         TV tuner -RX6-   F17 Fuse 17 on fuse holder C -SC17- 5 A 10) Control unit in dash panel insert -J285- 30     7.5 A 10) Dash panel insert -KX2-   F18 Fuse 18 on fuse holder C -SC18- 7.5 A Reversing camera -R189- 30       Rear lid handle release button -E234-   F19 Fuse 19 on fuse holder C -SC19- 7.5 A Interface for entry and start system -J965- 30 F20 Fuse 20 on fuse holder C -SC20- 7.5 A 9) Control unit for fuel tank leak detection -J909-9) 30 F21 Fuse 21 on fuse holder C -SC21- 15 A All-wheel drive control unit -J492- 30 F22 Fuse 22 on fuse holder C -SC22- 15 A Trailer detector control unit -J345- 30 F23 Fuse 23 on fuse holder C -SC23- 40 A Onboard supply control unit -J519- t  Front right headlight -MX2- 30 F24 Fuse 24 on fuse holder C -SC24- 30 A Sliding sunroof adjustment control unit -J245- 30 F25 Fuse 25 on fuse holder C -SC25- 30 A Driver door control unit -J386- 1) 30     Rear left window regulator motor -V26- 1) 30     Front passenger door control unit -J387-2)         Rear right window regulator motor -V27- 2)   F26 Fuse 26 on fuse holder C -SC26- 30 A Onboard supply control unit -J519- t  Front seat heating 30 F27 Fuse 27 on fuse holder C -SC27- 30 A Digital sound package control unit -J525- 30 F28 Fuse 28 on fuse holder C -SC28- 25 A Trailer detector control unit -J345- 30 F29 not assigned -   - F30 not assigned - - F31 Fuse 31 on fuse holder C -SC31- 40 A Onboard supply control unit -J519- t  Front left headlight -MX1- 30 F32 Fuse 32 on fuse holder C -SC32- 7.5 A Front camera for driver assist systems -R242- 15   10 A 8) Adaptive cruise control unit -J428-     Parking aid control unit -J446-     Park assist steering control unit -J791-     Blind Spot Monitor control unit -J1086-       Blind Spot Monitor control unit 2 -J1087-   F33 Fuse 33 on fuse holder C -SC33- 5 A Airbag control unit -J234- 15       Front passenger airbag deactivated warning lamp -K145-   F34 Fuse 34 on fuse holder C -SC34- 7.5 A Rotary light switch -EX1- 15     Interior mirror -EX5-       Relay for power sockets -J807-       Reversing light switch -F4-     Pressure sender for refrigerant circuit -G805-     Air quality sensor -G238-     Electromechanical parking brake button -E538-       Control unit for structure-borne sound -J869-6)     TCS and ESP button -E256-   F35 Fuse 35 on fuse holder C -SC35- 10 A Diagnostic connection -U31- 15     Headlight range control and instrument illumination regulator -EX14-       Control unit for cornering light and headlight range control -J745-     Left headlight range control motor -V48-       Right headlight range control motor -V49-   F36 Fuse 36 on fuse holder C -SC36- 10 A Control unit for right daytime running light and side light -J861- 15 F37 Fuse 37 on fuse holder C -SC37- 10 A Control unit for left daytime running light and side light -J860- 15 F38 Fuse 38 on fuse holder C -SC38- 25 A Trailer detector control unit -J345- 30 F39 Fuse 39 on fuse holder C -SC39- 30 A Front passenger door control unit -J387-1) 30     Rear right window regulator motor -V27- 1)     Driver door control unit -J386- 2) 30       Rear left window regulator motor -V26- 2)   F40 4) , 5) Fuse 40 on fuse holder C -SC40- 20 A Cigarette lighter -U1- 3) 15 4) / 30 5)     12 V socket -U5-         12 V socket 2 -U18-   F41 Fuse 41 on fuse holder C -SC41- 25 A Control unit for front right belt tensioner -J855- 30 F42 Fuse 42 on fuse holder C -SC42- 40 A Onboard supply control unit -J519- t  Central locking 30 F43 Fuse 43 on fuse holder C -SC43- 30 A Onboard supply control unit -J519- 30 F44 Fuse 44 on fuse holder C -SC44- 15 A Trailer detector control unit -J345- 30 F45 Fuse 45 on fuse holder C -SC45- 15 A Driver seat lumbar support adjustment switch -E176- 30     Driver seat adjustment operating unit -E470- F46 not assigned - - F47 Fuse 47 on fuse holder C -SC47- 15 A Rear window wiper motor -V12- 15 F48 Fuse 48 on fuse holder C -SC48- 10A Engine sound generator control unit -J943- 15 F49 Fuse 49 on fuse holder C -SC49- 5 A Clutch position sender -G476- 15     Starter relay 1 -J906-         Starter relay 2 -J907-   F50 not assigned - - F51 not assigned - - F52 not assigned - - F53 Fuse 53 on fuse holder C -SC53- 30 A Heated rear window relay -J9- 15 1) Only left-hand drive models 2) Only right-hand drive models 3) Smokers version 4) Factory fitted with power supply from terminal 15 5) Power supply via terminal 30 possible 6) Only models with GTI equipment 7) Only models with heated steering wheel 8) Only models with blind spot monitor 9) Only for American markets 10) According to equipment   Note: The fuse SC40 is supplied via terminal 15 from the factory and can be supplied via terminal 30 by reconnecting. If a consumer is connected to the electric socket or to the cigarette lighter, ensure that the consumer is disconnected from the voltage supply when the engine is switched off to prevent the drive battery being discharged. Back to overview     VW GOLF 2015 Fuse assignment of fuse holder C -SC- , from July 2014, only models with hybrid drive system Slot Current flow diagram designation Nominal value Function/component Terminal F1 not assigned - - F2 Fuse 2 on fuse holder C -SC2- 10 A Steering column electronics control unit -J527-6) 30 F3 not assigned - - F4 Fuse 4 on fuse holder C -SC4- 10 A Onboard supply control unit -J519- t  Anti-theft alarm system 30 F5 Fuse 5 on fuse holder C -SC5- 5 A Data bus diagnostic interface -J533- 30 F6 Fuse 6 on fuse holder C -SC6- 5 A Anti-theft alarm sensor -G578- 30 F7 Fuse 7 on fuse holder C -SC7- 10 A Heater and air conditioning controls -EX21- 30     Climatronic control unit -J255-       Selector lever -E313-     Remote control receiver for auxiliary coolant heater -R149-       Heated rear window relay -J9- F8 Fuse 8 on fuse holder C -SC8- 10 A Rotary light switch -EX1- 30     Electromechanical parking brake button -E538-       Rain and light sensor -G397-       Diagnostic connection -U31- F9 Fuse 9 on fuse holder C -SC9- 1 A Steering column electronics control unit -J527- 30 F10 Fuse 10 on fuse holder C -SC10- 10 A Display unit for front information display and operating unit control unit -J685- 30     Control unit for navigation system -J856-       TV tuner -RX6-   F11 Fuse 11 on fuse holder C -SC11- 25 A Control unit for front left belt tensioner -J854- 30 F12 Fuse 12 on fuse holder C -SC12- 20 A Control unit 1 for information electronics -J794- 30 F13 not assigned - - F14 Fuse 14 on fuse holder C -SC14- 30 A Fresh air blower control unit -J126- 30 F15 Fuse 15 on fuse holder C -SC15- 10 A Control unit for electronic steering column lock -J764- 30 F16 Fuse 16 on fuse holder C -SC16- 7.5 A Two-way signal amplifier for mobile telephone/data services -J984- 30     Storage compartment with interface for mobile telephone -R265-     Voltage converter for USB charge module -A5-       USB hub -R293-         Chip card reader -D8-   F17 Fuse 17 on fuse holder C -SC17- 5 A Dash panel insert -KX2- 30       Emergency call module control unit and communication unit -J949-   F18 Fuse 18 on fuse holder C -SC18- 7.5 A Reversing camera -R189- 30       Rear lid handle release button -E234-   F19 Fuse 19 on fuse holder C -SC19- 7.5 A Interface for entry and start system -J965- 30 F20 not assigned -   - F21 not assigned - - F22 Fuse 22 on fuse holder C -SC22- 15 A Trailer detector control unit -J345- 30 F23 Fuse 23 on fuse holder C -SC23- 40 A Onboard supply control unit -J519- t  Front right headlight -MX2- 30 F24 Fuse 24 on fuse holder C -SC24- 30 A Sliding sunroof adjustment control unit -J245- 30 F25 Fuse 25 on fuse holder C -SC25- 30 A Driver door control unit -J386- 1) 30     Rear left window regulator motor -V26- 1) 30     Front passenger door control unit -J387-2)         Rear right window regulator motor -V27- 2)   F26 Fuse 26 on fuse holder C -SC26- 30 A Onboard supply control unit -J519- t  Front seat heating 30 F27 Fuse 27 on fuse holder C -SC27- 30 A Digital sound package control unit -J525- 30 F28 Fuse 28 on fuse holder C -SC28- 25 A Trailer detector control unit -J345- 30 F29 not assigned - - F30 Fuse 30 on fuse holder C -SC30- 10 A High-voltage battery 1 -AX2- 30       Maintenance connector for high-voltage system -TW-   F31 Fuse 31 on fuse holder C -SC31- 40 A Onboard supply control unit -J519- t  Front left headlight -MX1- 30 F32 Fuse 32 on fuse holder C -SC32- 7.5 A Front camera for driver assist systems -R242- 15   10 A 7) Adaptive cruise control unit -J428-     Parking aid control unit -J446-     Park assist steering control unit -J791-     Blind Spot Monitor control unit -J1086-       Blind Spot Monitor control unit 2 -J1087-   F33 Fuse 33 on fuse holder C -SC33- 5 A Airbag control unit -J234- 15       Front passenger airbag deactivated warning lamp -K145-   F34 Fuse 34 on fuse holder C -SC34- 7.5 A Rotary light switch -EX1- 15     Interior mirror -EX5-       Relay for power sockets -J807-       Reversing light switch -F4-     Air quality sensor -G238-     Electromechanical parking brake button -E538-       Control unit for structure-borne sound -J869- F35 Fuse 35 on fuse holder C -SC35- 10 A Diagnostic connection -U31- 15     Control unit for cornering light and headlight range control -J745- F36 Fuse 36 on fuse holder C -SC36- 5 A Output module 1 for right LED headlight -A27- 15 F37 Fuse 37 on fuse holder C -SC37- 5 A Output module 1 for left LED headlight -A31- 15 F38 Fuse 38 on fuse holder C -SC38- 25 A Trailer detector control unit -J345- 30 F39 Fuse 39 on fuse holder C -SC39- 30 A Front passenger door control unit -J387-1) 30     Rear right window regulator motor -V27- 1)     Driver door control unit -J386- 2) 30       Rear left window regulator motor -V26- 2)   F40 4) , 5) Fuse 40 on fuse holder C -SC40- 20 A Cigarette lighter -U1- 3) 15 4) / 30 5)     12 V socket -U5-         12 V socket 2 -U18-   F41 Fuse 41 on fuse holder C -SC41- 25 A Control unit for front right belt tensioner -J855- 30 F42 Fuse 42 on fuse holder C -SC42- 40 A Onboard supply control unit -J519- t  Central locking 30 F43 Fuse 43 on fuse holder C -SC43- 30 A Onboard supply control unit -J519- 30 F44 Fuse 44 on fuse holder C -SC44- 15 A Trailer detector control unit -J345- 30 F45 Fuse 45 on fuse holder C -SC45- 15 A Driver seat lumbar support adjustment switch -E176- 30     Driver seat adjustment operating unit -E470- F46 not assigned - - F47 Fuse 47 on fuse holder C -SC47- 15 A Rear window wiper motor -V12- 15 F48 not assigned - - F49 Fuse 49 on fuse holder C -SC49- 5 A High-voltage battery 1 -AX2- 15     Power and control electronics for electric drive -JX1-   F50 not assigned - - F51 not assigned - - F52 not assigned - - F53 Fuse 53 on fuse holder C -SC53- 30 A Heated rear window relay -J9- 15 1) Only left-hand drive models 2) Only right-hand drive models 3) Smokers version 4) Factory fitted with power supply from terminal 15 5) Power supply via terminal 30 possible 6) Only models with heated steering wheel 7) Only models with blind spot monitor   Note: The fuse SC40 is supplied via terminal 15 from the factory and can be supplied via terminal 30 by reconnecting. If a consumer is connected to the electric socket or to the cigarette lighter, ensure that the consumer is disconnected from the voltage supply when the engine is switched off to prevent the drive battery being discharged. Back to overview     VW GOLF 2015 Fuse assignment of fuse holder C -SC- , from May 2015, only models with hybrid drive system Slot Current flow diagram designation Nominal value Function/component Terminal F1 not assigned - - F2 Fuse 2 on fuse holder C -SC2- 10 A Steering column electronics control unit -J527-6) 30 F3 not assigned - - F4 Fuse 4 on fuse holder C -SC4- 10 A Onboard supply control unit -J519- t  Anti-theft alarm system 30 F5 Fuse 5 on fuse holder C -SC5- 5 A Data bus diagnostic interface -J533- 30 F6 Fuse 6 on fuse holder C -SC6- 5 A Anti-theft alarm sensor -G578- 30 F7 Fuse 7 on fuse holder C -SC7- 10 A Heater and air conditioning controls -EX21- 30     Climatronic control unit -J255-       Selector lever -E313-     Remote control receiver for auxiliary coolant heater -R149-       Heated rear window relay -J9- F8 Fuse 8 on fuse holder C -SC8- 10 A Rotary light switch -EX1- 30     Electromechanical parking brake button -E538-       Rain and light sensor -G397-       Diagnostic connection -U31- F9 Fuse 9 on fuse holder C -SC9- 5 A Steering column electronics control unit -J527- 30 F10 Fuse 10 on fuse holder C -SC10- 7.5 A Display unit for front information display and operating unit control unit -J685- 30 F11 Fuse 11 on fuse holder C -SC11- 25 A Control unit for front left belt tensioner -J854- 30 F12 Fuse 12 on fuse holder C -SC12- 20 A Control unit 1 for information electronics -J794- 30     Control unit for navigation system -J856- F13 not assigned - - F14 Fuse 14 on fuse holder C -SC14- 30 A Fresh air blower control unit -J126- 30 F15 Fuse 15 on fuse holder C -SC15- 10 A Control unit for electronic steering column lock -J764- 30 F16 Fuse 16 on fuse holder C -SC16- 7.5 A Two-way signal amplifier for mobile telephone/data services -J984- 30     Storage compartment with interface for mobile telephone -R265-     Voltage converter for USB charge module -A5-       USB hub -R293-         Chip card reader -D8-         TV tuner -RX6-   F17 Fuse 17 on fuse holder C -SC17- 5 A 8) Dash panel insert -KX2- 30     7.5 A 8) Emergency call module control unit and communication unit -J949-   F18 Fuse 18 on fuse holder C -SC18- 7.5 A Reversing camera -R189- 30       Rear lid handle release button -E234-   F19 Fuse 19 on fuse holder C -SC19- 7.5 A Interface for entry and start system -J965- 30 F20 not assigned -   - F21 not assigned - - F22 Fuse 22 on fuse holder C -SC22- 15 A Trailer detector control unit -J345- 30 F23 Fuse 23 on fuse holder C -SC23- 40 A Onboard supply control unit -J519- t  Front right headlight -MX2- 30 F24 Fuse 24 on fuse holder C -SC24- 30 A Sliding sunroof adjustment control unit -J245- 30 F25 Fuse 25 on fuse holder C -SC25- 30 A Driver door control unit -J386- 1) 30     Rear left window regulator motor -V26- 1) 30     Front passenger door control unit -J387-2)         Rear right window regulator motor -V27- 2)   F26 Fuse 26 on fuse holder C -SC26- 30 A Onboard supply control unit -J519- t  Front seat heating 30 F27 Fuse 27 on fuse holder C -SC27- 30 A Digital sound package control unit -J525- 30 F28 Fuse 28 on fuse holder C -SC28- 25 A Trailer detector control unit -J345- 30 F29 not assigned - - F30 Fuse 30 on fuse holder C -SC30- 10 A High-voltage battery 1 -AX2- 30       Maintenance connector for high-voltage system -TW-   F31 Fuse 31 on fuse holder C -SC31- 40 A Onboard supply control unit -J519- t  Front left headlight -MX1- 30 F32 Fuse 32 on fuse holder C -SC32- 7.5 A Front camera for driver assist systems -R242- 15   10 A 7) Adaptive cruise control unit -J428-     Parking aid control unit -J446-     Park assist steering control unit -J791-     Blind Spot Monitor control unit -J1086-       Blind Spot Monitor control unit 2 -J1087-   F33 Fuse 33 on fuse holder C -SC33- 5 A Airbag control unit -J234- 15       Front passenger airbag deactivated warning lamp -K145-   F34 Fuse 34 on fuse holder C -SC34- 7.5 A Rotary light switch -EX1- 15     Interior mirror -EX5-       Relay for power sockets -J807-       Reversing light switch -F4-     Air quality sensor -G238-     Electromechanical parking brake button -E538-       Control unit for structure-borne sound -J869- F35 Fuse 35 on fuse holder C -SC35- 10 A Diagnostic connection -U31- 15     Control unit for cornering light and headlight range control -J745- F36 Fuse 36 on fuse holder C -SC36- 5 A Output module 1 for right LED headlight -A27- 15 F37 Fuse 37 on fuse holder C -SC37- 5 A Output module 1 for left LED headlight -A31- 15 F38 Fuse 38 on fuse holder C -SC38- 25 A Trailer detector control unit -J345- 30 F39 Fuse 39 on fuse holder C -SC39- 30 A Front passenger door control unit -J387-1) 30     Rear right window regulator motor -V27- 1)     Driver door control unit -J386- 2) 30       Rear left window regulator motor -V26- 2)   F40 4) , 5) Fuse 40 on fuse holder C -SC40- 20 A Cigarette lighter -U1- 3) 15 4) / 30 5)     12 V socket -U5-         12 V socket 2 -U18-   F41 Fuse 41 on fuse holder C -SC41- 25 A Control unit for front right belt tensioner -J855- 30 F42 Fuse 42 on fuse holder C -SC42- 40 A Onboard supply control unit -J519- t  Central locking 30 F43 Fuse 43 on fuse holder C -SC43- 30 A Onboard supply control unit -J519- 30 F44 Fuse 44 on fuse holder C -SC44- 15 A Trailer detector control unit -J345- 30 F45 Fuse 45 on fuse holder C -SC45- 15 A Driver seat lumbar support adjustment switch -E176- 30     Driver seat adjustment operating unit -E470- F46 not assigned - - F47 Fuse 47 on fuse holder C -SC47- 15 A Rear window wiper motor -V12- 15 F48 not assigned - - F49 Fuse 49 on fuse holder C -SC49- 5 A High-voltage battery 1 -AX2- 15     Power and control electronics for electric drive -JX1-   F50 not assigned - - F51 not assigned - - F52 not assigned - - F53 Fuse 53 on fuse holder C -SC53- 30 A Heated rear window relay -J9- 15 1) Only left-hand drive models 2) Only right-hand drive models 3) Smokers version 4) Factory fitted with power supply from terminal 15 5) Power supply via terminal 30 possible 6) Only models with heated steering wheel 7) Only models with blind spot monitor 8) According to equipment   Note: The fuse SC40 is supplied via terminal 15 from the factory and can be supplied via terminal 30 by reconnecting. If a consumer is connected to the electric socket or to the cigarette lighter, ensure that the consumer is disconnected from the voltage supply when the engine is switched off to prevent the drive battery being discharged. Back to overview     VW GOLF 2015 Fitting location of relay and fuse carrier 3 -SR3- , only for special vehicles Get access to all wiring diagrams of the car 1 -  Relay and fuse carrier 3 -SR3- Fuse colours for J-Case fuse: t  50 A - red t  40 A - green t  30 A - pink Fuse colours for ATO flat fuse: t  40 A - orange t  30 A - light green t  25 A - natural (white) t  20 A - yellow t  15 A - light blue t  10 A - red t  7.5 A - brown t  5 A - light brown t  1A - black Fuse colours, for mini fuses: t  20 A - yellow t  15 A - light blue t  10 A - red t  7.5 A - brown t  5 A - light brown t  1A - black Back to overview     VW GOLF 2015 Fuse assignment of relay and fuse carrier 3 -SR3- , only for special vehicles, from April 2013 Slot Current flow diagram designation Nominal value Function/component Terminal A Special vehicle fuse 4 -S294- 2) only Special vehicle fuse 1) 30   Special vehicle fuse 5 -S295- 2) only Special vehicle fuse 1) 30 B Special vehicle fuse 6 -S296- 2) only Special vehicle fuse 1) 30 C Special vehicle fuse 7 -S297- 2) only Special vehicle fuse 1) 30 1) According to equipment 2) Fuse rating, see installation description for special installations Back to overview VW GOLF 2015 Fitting location of fuse holder B SB Fitting location of fuse holder B -SB-   Note: The fitting locations are identical on LHD and RHD models.     Get access to all wiring diagrams of the car 1 -  Fuse holder B -SB- Fuse colours for J-Case fuse: t  50 A - red t  40 A - green t  30 A - pink Fuse colours for ATO flat fuse: t  40 A - orange t  30 A - light green t  25 A - natural (white) t  20 A - yellow t  15 A - light blue t  10 A - red t  7.5 A - brown t  5 A - light brown t  1A - black Back to overview     VW GOLF 2015 Fuse assignment of fuse holder B -SB- , from August 2012 Slot Current flow diagram designation Nominal value Function/component Terminal F1 Fuse 1 on fuse holder B -SB1- 40 A ABS control unit -J104- 30 F2 Fuse 2 on fuse holder B -SB2- 40 A ABS control unit -J104- 30       ABS hydraulic pump -V64- F3 Fuse 3 on fuse holder B -SB3- 15 A 1) 30 A 2) Engine control unit -J623- 87 F4 Fuse 4 on fuse holder B -SB4- 5 A 2) 10 A 1) Oil level and oil temperature sender -G266- 87     Radiator fan control unit -J293-       Activated charcoal filter solenoid valve 1 -N80-1)     Camshaft control valve 1 -N205-1)     Exhaust camshaft control valve 1 -N318-1)       Valve for oil pressure control -N428-1)       High heat output relay -J360-2)       Exhaust gas recirculation cooler changeover valve -N345-2)       Low heat output relay -J359-2)       Charge pressure control solenoid valve -N75-2)       Inlet cam actuator for cylinder 2 -N583-1)     Exhaust cam actuator for cylinder 2 -N587-1)     Inlet cam actuator for cylinder 3 -N591-1)     Exhaust cam actuator for cylinder 3 -N595-1)       Ethanol concentration sender -G708-1) F5 Fuse 5 on fuse holder B -SB5- 10 A 2) Fuel pressure regulating valve -N276- 87     Fuel metering valve -N290- F6 Fuse 6 on fuse holder B -SB6- 5 A Brake light switch -F- 87 F7 Fuse 7 on fuse holder B -SB7- 7.5 A 1) 10 A 2) Fuel pressure regulating valve -N276-1) 87     Charge air cooling pump -V188-1)       Valve for oil pressure control -N428-2)       Solenoid valve for coolant circuit -N492-2)       Charge air cooling pump -V188-2)       Auxiliary pump for heating -V488-2)   F8 Fuse 8 on fuse holder B -SB8- 10 A 1) 15 A 2) Lambda probe 1 before catalytic converter -GX10- t  Lambda probe heater -Z19- 87       Lambda probe 1 after catalytic converter -GX7- t  Lambda probe 1 heater after catalytic converter -Z29- F9 Fuse 9 on fuse holder B -SB9- 5 A 2) 20 A 1) Ignition coil 1 with output stage -N70-1) 87     Ignition coil 2 with output stage -N127-1)       Ignition coil 3 with output stage -N291-1)     Ignition coil 4 with output stage -N292-1)       Air mass meter -G70-       Automatic glow period control unit -J179-2)       Heater element for crankcase breather -N79- 2)   F10 Fuse 10 on fuse holder B -SB10- 15 A 1) 20 A 2) Fuel pump control unit -J538- 87 F11 Fuse 11 on fuse holder B -SB11- 40 A Auxiliary air heater element -Z35- 87 F12 Fuse 12 on fuse holder B -SB12- 40 A Auxiliary air heater element -Z35- 87 F13 Fuse 13 on fuse holder B -SB13- 30 A Mechatronic unit for dual clutch gearbox -J743- 30 F14 not assigned - - F15 Fuse 15 on fuse holder B -SB15- 15 A Horn relay -J413- 30 F16 not assigned -   - F17 Fuse 17 on fuse holder B -SB17- 7.5 A Main relay -J271- 1) 30     Terminal 30 voltage supply relay -J317- 2)     Engine control unit -J623-         ABS control unit -J104- F18 Fuse 18 on fuse holder B -SB18- 5 A Battery monitor control unit -J367- 30       Data bus diagnostic interface -J533- 3) F19 Fuse 19 on fuse holder B -SB19- 30 A Wiper motor control unit -J400- 30 F20 Fuse 20 on fuse holder B -SB20- 20 A Alarm horn -H12- 30 F21 not assigned - - F22 Fuse 22 on fuse holder B -SB22- 5 A Engine control unit -J623- 50 F23 Fuse 23 on fuse holder B -SB23- 30 A Starter -B- 50 F24 Fuse 24 on fuse holder B -SB24- 40 A Auxiliary air heater element -Z35- 87 F25 not assigned - - F26 not assigned - - F27 not assigned - - F28 not assigned - - F29 not assigned - - F30 not assigned - - F31 not assigned - - F32 not assigned - - F33 not assigned - - F34 not assigned - - F35 not assigned - - F36 not assigned - - F37 Fuse 37 on fuse holder B -SB37- 20 A Auxiliary heater control unit -J364- 30 F38 not assigned - - 1) Only models with petrol engine 2) for models with diesel engine only 3) Only models with no start/stop system Back to overview     VW GOLF 2015 Fuse assignment of fuse holder B -SB- , from April 2013 Slot Current flow diagram designation Nominal value Function/component Terminal F1 Fuse 1 on fuse holder B -SB1- 40 A ABS control unit -J104- 30 F2 Fuse 2 on fuse holder B -SB2- 40 A ABS control unit -J104- 30       ABS hydraulic pump -V64- F3 Fuse 3 on fuse holder B -SB3- 15 A 1) 30 A 2) Engine control unit -J623- 87 F4 Fuse 4 on fuse holder B -SB4- 5 A 2), 6) Oil level and oil temperature sender -G266- 87   10 A 1) Radiator fan control unit -J293-       Activated charcoal filter solenoid valve 1 -N80-1)     Camshaft control valve 1 -N205-1)     Exhaust camshaft control valve 1 -N318-1)       Valve for oil pressure control -N428-1)       High heat output relay -J360-2)       Exhaust gas recirculation cooler changeover valve -N345-2)       Low heat output relay -J359-2)       Charge pressure control solenoid valve -N75-2)       Inlet cam actuator for cylinder 2 -N583-1)     Exhaust cam actuator for cylinder 2 -N587-1)     Inlet cam actuator for cylinder 3 -N591-1)     Exhaust cam actuator for cylinder 3 -N595-1)     Ethanol concentration sender -G708-1)       High-pressure valve for gas mode -N372-5)     Turbocharger air recirculation valve -N249-4)     Intake manifold flap valve -N316-4)       Piston cooling jet control valve -N522-4) F5 Fuse 5 on fuse holder B -SB5- 10 A 2), 6) Fuel pressure regulating valve -N276- 87   7.5 A 5) Injector, cylinder 1 -N30-6)     Injector, cylinder 2 -N31-6)     Injector, cylinder 3 -N32-6)     Injector, cylinder 4 -N33-6)     Fuel metering valve -N290-     Engine component current supply relay -J757-4)     Relay for gas shut-off valves -J908-5)       Gas injection valve 1 -N366-5)       Gas injection valve 2 -N367-5)       Gas injection valve 3 -N368-5)         Gas injection valve 4 -N369-5)   F6 Fuse 6 on fuse holder B -SB6- 5 A Brake light switch -F- 87 F7 Fuse 7 on fuse holder B -SB7- 7.5 A 1) Fuel pressure regulating valve -N276-1) 87   10 A 2) Charge air cooling pump -V188-1)       Valve for oil pressure control -N428-2)       Solenoid valve for coolant circuit -N492-2)       Charge air cooling pump -V188-2)       Gearbox oil cooling pump -V478-4)       Coolant shut-off valve -N82-4)     Auxiliary pump for heating -V488-2)   F8 Fuse 8 on fuse holder B -SB8- 10 A 1) 15 A 2) Lambda probe 1 before catalytic converter -GX10- t  Lambda probe heater -Z19- 87       Lambda probe 1 after catalytic converter -GX7- t  Lambda probe 1 heater after catalytic converter -Z29- F9 Fuse 9 on fuse holder B -SB9- 5 A 2) 20 A 1) Ignition coil 1 with output stage -N70-1) 87     Ignition coil 2 with output stage -N127-1)       Ignition coil 3 with output stage -N291-1)     Ignition coil 4 with output stage -N292-1)       Automatic glow period control unit -J179-2)       Air mass meter -G70-       Heater element for crankcase breather -N79- 2)     10A 1) Exhaust flap control unit -J883-1)       Sender 1 for secondary air pressure -G609-1)       Charge air cooling pump -V188-1)       Activated charcoal filter solenoid valve 1 -N80-1)       Camshaft control valve 1 -N205-1)       Exhaust camshaft control valve 1 -N318-1)   F10 Fuse 10 on fuse holder B -SB10- 10 A 1) 20 A 2) Fuel pump control unit -J538- 87 F11 Fuse 11 on fuse holder B -SB11- 40 A Auxiliary air heater element -Z35- 87 F12 Fuse 12 on fuse holder B -SB12- 40 A Auxiliary air heater element -Z35- 87 F13 Fuse 13 on fuse holder B -SB13- 30 A Mechatronic unit for dual clutch gearbox -J743- t  Dual clutch gearbox 0CW 30     15 A Mechatronic unit for dual clutch gearbox -J743- t  Dual clutch gearbox 0D9   F14 Fuse 14 on fuse holder B -SB14- 40 A Heated windscreen relay -J47- 30 F15 Fuse 15 on fuse holder B -SB15- 15 A Horn relay -J413- 30 F16 Fuse 16 on fuse holder B -SB16- 20 A Engine component current supply relay -J757-4) 30     7.5 A Relay for gas shut-off valves -J908-5)   F17 Fuse 17 on fuse holder B -SB17- 7.5 A Main relay -J271- 1) 30     Terminal 30 voltage supply relay -J317- 2)     Engine control unit -J623-       ABS control unit -J104-         Heated windscreen relay -J47- F18 Fuse 18 on fuse holder B -SB18- 5 A Battery monitor control unit -J367- 30       Data bus diagnostic interface -J533- 3) F19 Fuse 19 on fuse holder B -SB19- 30 A Wiper motor control unit -J400- 30 F20 Fuse 20 on fuse holder B -SB20- 10 A Alarm horn -H12- 30 F21 not assigned - - F22 Fuse 22 on fuse holder B -SB22- 5 A Engine control unit -J623- 50 F23 Fuse 23 on fuse holder B -SB23- 30 A Starter -B- 50 F24 Fuse 24 on fuse holder B -SB24- 40 A Auxiliary air heater element -Z35- 87 F25 not assigned - - F26 not assigned - - F27 not assigned - - F28 not assigned - - F29 not assigned - - F30 not assigned - - F31 Fuse 31 on fuse holder B -SB31- 15 A Vacuum pump for brakes -V192- 87 F32 not assigned - - F33 not assigned - - F34 Fuse 34 on fuse holder B -SB34- 15 A Axle differential lock control unit -J647-4) 30 F35 not assigned - - F36 not assigned - - F37 Fuse 37 on fuse holder B -SB37- 20 A Auxiliary heater control unit -J364- 30 F38 not assigned - - 1) Only models with petrol engine 2) for models with diesel engine only 3) Only models with no start/stop system 4) Only models with GTI equipment 5) Only models with natural gas engine (CNG) 6) Only models with MPI petrol engine Back to overview     VW GOLF 2015 Fuse assignment of fuse holder B -SB- , from November 2013 Slot Current flow diagram designation Nominal value Function/component Terminal F1 Fuse 1 on fuse holder B -SB1- 40 A 8) 20 A 9) ABS control unit -J104- 30 F2 Fuse 2 on fuse holder B -SB2- 40 A ABS control unit -J104- 30       ABS hydraulic pump -V64- F3 Fuse 3 on fuse holder B -SB3- 15 A 1) 30 A 2) Engine control unit -J623- 87 F4 Fuse 4 on fuse holder B -SB4- 5 A 2), 7) Oil level and oil temperature sender -G266- 87   10 A 1) Radiator fan control unit -J293-       Activated charcoal filter solenoid valve 1 -N80-1)     Camshaft control valve 1 -N205-1)     Exhaust camshaft control valve 1 -N318-1)       Valve for oil pressure control -N428-1)       High heat output relay -J360-2)       Exhaust gas recirculation cooler changeover valve -N345-2)       Low heat output relay -J359-2)       Charge pressure control solenoid valve -N75-2)       Inlet cam actuator for cylinder 2 -N583-1)     Exhaust cam actuator for cylinder 2 -N587-1)     Inlet cam actuator for cylinder 3 -N591-1)     Exhaust cam actuator for cylinder 3 -N595-1)     Ethanol concentration sender -G708-1)       High-pressure valve for gas mode -N372-5)     Turbocharger air recirculation valve -N249-4)     Intake manifold flap valve -N316-4)       Piston cooling jet control valve -N522-4) F5 Fuse 5 on fuse holder B -SB5- 10 A 2), 7) Fuel pressure regulating valve -N276- 87   7.5 A 5) Injector, cylinder 1 -N30-7)     Injector, cylinder 2 -N31-7)     Injector, cylinder 3 -N32-7)     Injector, cylinder 4 -N33-7)     Fuel metering valve -N290-     Engine component current supply relay -J757-4)     Relay for gas shut-off valves -J908-5)       Gas injection valve 1 -N366-5)       Gas injection valve 2 -N367-5)       Gas injection valve 3 -N368-5)         Gas injection valve 4 -N369-5)   F6 Fuse 6 on fuse holder B -SB6- 5 A Brake light switch -F- 87 F7 Fuse 7 on fuse holder B -SB7- 7.5 A 1) 10 A 2) Fuel pressure regulating valve -N276-1) 87     Charge air cooling pump -V188-1)       Valve for oil pressure control -N428-2)       Solenoid valve for coolant circuit -N492-2)       Charge air cooling pump -V188-2)       Gearbox oil cooling pump -V478-4)       Coolant shut-off valve -N82-4)     Auxiliary pump for heating -V488-2)         Radiator blind control motor -V544-2)   F8 Fuse 8 on fuse holder B -SB8- 10 A 1) 15 A 2), 6) Lambda probe 1 before catalytic converter -GX10- t  Lambda probe heater -Z19- 87       Lambda probe 1 after catalytic converter -GX7- t  Lambda probe 1 heater after catalytic converter -Z29- F9 Fuse 9 on fuse holder B -SB9- 5 A 2) 20 A 1) Ignition coil 1 with output stage -N70-1) 87     Ignition coil 2 with output stage -N127-1)       Ignition coil 3 with output stage -N291-1)     Ignition coil 4 with output stage -N292-1)       Automatic glow period control unit -J179-2)       Air mass meter -G70-       Heater element for crankcase breather -N79- 2)     10A 1) Exhaust flap control unit -J883-1)       Sender 1 for secondary air pressure -G609-1)       Charge air cooling pump -V188-1)       Activated charcoal filter solenoid valve 1 -N80-1)       Camshaft control valve 1 -N205-1)       Exhaust camshaft control valve 1 -N318-1)   F10 Fuse 10 on fuse holder B -SB10- 10 A 1) 20 A 2) Fuel pump control unit -J538- 87 F11 Fuse 11 on fuse holder B -SB11- 40 A Auxiliary air heater element -Z35- 87 F12 Fuse 12 on fuse holder B -SB12- 40 A Auxiliary air heater element -Z35- 87 F13 Fuse 13 on fuse holder B -SB13- 30 A Mechatronic unit for dual clutch gearbox -J743- t  Dual clutch gearbox 0CW 30     15 A Mechatronic unit for dual clutch gearbox -J743- t  Dual clutch gearbox 0D9   F14 Fuse 14 on fuse holder B -SB14- 40 A Heated windscreen relay -J47- 30 F15 Fuse 15 on fuse holder B -SB15- 15 A Horn relay -J413- 30 F16 Fuse 16 on fuse holder B -SB16- 20 A Engine component current supply relay -J757-4) 30     7.5 A Relay for gas shut-off valves -J908-5)   F17 Fuse 17 on fuse holder B -SB17- 7.5 A Main relay -J271- 1) 30     Terminal 30 voltage supply relay -J317- 2)     Engine control unit -J623-       ABS control unit -J104-         Heated windscreen relay -J47- F18 Fuse 18 on fuse holder B -SB18- 5 A Battery monitor control unit -J367- 30       Data bus diagnostic interface -J533- 3) F19 Fuse 19 on fuse holder B -SB19- 30 A Wiper motor control unit -J400- 30 F20 Fuse 20 on fuse holder B -SB20- 10 A Alarm horn -H12- 30 F21 not assigned - - F22 Fuse 22 on fuse holder B -SB22- 5 A Engine control unit -J623- 50 F23 Fuse 23 on fuse holder B -SB23- 30 A Starter -B- 50 F24 Fuse 24 on fuse holder B -SB24- 40 A Auxiliary air heater element -Z35- 87 F25 not assigned - - F26 not assigned - - F27 not assigned - - F28 not assigned - - F29 not assigned - - F30 not assigned - - F31 Fuse 31 on fuse holder B -SB31- 15 A Vacuum pump for brakes -V192- 87 F32 not assigned - - F33 not assigned - - F34 Fuse 34 on fuse holder B -SB34- 15 A Axle differential lock control unit -J647-4) 30 F35 not assigned - - F36 not assigned - - F37 Fuse 37 on fuse holder B -SB37- 20 A Auxiliary heater control unit -J364- 30 F38 not assigned - - 1) Only models with petrol engine 2) for models with diesel engine only 3) Only models with no start/stop system 4) Only models with GTI equipment 5) Only models with natural gas engine (CNG) 6) Only models with E85 petrol engine 7) Only models with MPI petrol engine 8) Only models with no electric parking brake 9) Only models with electric parking brake Back to overview     VW GOLF 2015 Fuse assignment of fuse holder B -SB- , from May 2014 Slot Current flow diagram designation Nominal value Function/component Terminal F1 Fuse 1 on fuse holder B -SB1- 40 A 9) 20 A 10) ABS control unit -J104- 30 F2 Fuse 2 on fuse holder B -SB2- 40 A ABS control unit -J104- 30       ABS hydraulic pump -V64- F3 Fuse 3 on fuse holder B -SB3- 15 A 1) 30 A 2) Engine control unit -J623- 87 F4 Fuse 4 on fuse holder B -SB4- 5 A 2), 6) Oil level and oil temperature sender -G266- 87   10 A 1) Radiator fan control unit -J293-       Activated charcoal filter solenoid valve 1 -N80-1)     Camshaft control valve 1 -N205-1)     Exhaust camshaft control valve 1 -N318-1)       Valve for oil pressure control -N428-1)       High heat output relay -J360-2)       Exhaust gas recirculation cooler changeover valve -N345-2)       Low heat output relay -J359-2)       Charge pressure control solenoid valve -N75-2)       Inlet cam actuator for cylinder 2 -N583-1)     Exhaust cam actuator for cylinder 2 -N587-1)     Inlet cam actuator for cylinder 3 -N591-1)     Exhaust cam actuator for cylinder 3 -N595-1)     Ethanol concentration sender -G708-1)       High-pressure valve for gas mode -N372-5)     Turbocharger air recirculation valve -N249-4)     Intake manifold flap valve -N316-4)       Piston cooling jet control valve -N522-4) F5 Fuse 5 on fuse holder B -SB5- 10 A 2), 6) Fuel pressure regulating valve -N276- 87   7.5 A 5) Injector, cylinder 1 -N30-6)     Injector, cylinder 2 -N31-6)     Injector, cylinder 3 -N32-6)     Injector, cylinder 4 -N33-6)     Fuel metering valve -N290-     Engine component current supply relay -J757-4)     Relay for gas shut-off valves -J908-5)       Gas injection valve 1 -N366-5)       Gas injection valve 2 -N367-5)       Gas injection valve 3 -N368-5)         Gas injection valve 4 -N369-5)   F6 Fuse 6 on fuse holder B -SB6- 5 A Brake light switch -F- 87 F7 Fuse 7 on fuse holder B -SB7- 7.5 A 1) 10 A 2) Fuel pressure regulating valve -N276-1) 87     Charge air cooling pump -V188-1)       Valve for oil pressure control -N428-2)       Solenoid valve for coolant circuit -N492-2)       Charge air cooling pump -V188-2)       Gearbox oil cooling pump -V478-4)       Coolant shut-off valve -N82-4)     Auxiliary pump for heating -V488-2)         Radiator blind control motor -V544-2)   F8 Fuse 8 on fuse holder B -SB8- 10 A 1) 15 A 2), 5), 7) Lambda probe 1 before catalytic converter -GX10- t  Lambda probe heater -Z19- 87     Lambda probe 1 after catalytic converter -GX7- t  Lambda probe 1 heater after catalytic converter -Z29-   F9 Fuse 9 on fuse holder B -SB9- 5 A 2) 20 A 1) Ignition coil 1 with output stage -N70-1) 87     Ignition coil 2 with output stage -N127-1)       Ignition coil 3 with output stage -N291-1)     Ignition coil 4 with output stage -N292-1)       Automatic glow period control unit -J179-2)       Air mass meter -G70-       Heater element for crankcase breather -N79- 2)     10A 1) Exhaust flap control unit -J883-1)       Sender 1 for secondary air pressure -G609-1)       Charge air cooling pump -V188-1)       Activated charcoal filter solenoid valve 1 -N80-1)       Camshaft control valve 1 -N205-1)       Exhaust camshaft control valve 1 -N318-1)   F10 Fuse 10 on fuse holder B -SB10- 15 A 1) 20 A 2) Fuel pump control unit -J538- 87     10 A 6) Fuel pump relay -J17-6)   F11 Fuse 11 on fuse holder B -SB11- 40 A 50 A 8) Auxiliary air heater element -Z35- Secondary air pump motor -V101-8) 87 F12 Fuse 12 on fuse holder B -SB12- 40 A Auxiliary air heater element -Z35- 87 F13 Fuse 13 on fuse holder B -SB13- 30 A Mechatronic unit for dual clutch gearbox -J743- t  Dual clutch gearbox 0CW 30     Automatic gearbox control unit -J217-   15 A Mechatronic unit for dual clutch gearbox -J743- t  Dual clutch gearbox 0D9 F14 Fuse 14 on fuse holder B -SB14- 40 A Heated windscreen relay -J47- 30 F15 Fuse 15 on fuse holder B -SB15- 15 A Horn relay -J413- 30 F16 Fuse 16 on fuse holder B -SB16- 20 A Engine component current supply relay -J757-4) 30   5 A Relay for gas shut-off valves -J908-5)       15 A Fuel pump relay -J17-6)   F17 Fuse 17 on fuse holder B -SB17- 7.5 A Main relay -J271- 1) 30     Terminal 30 voltage supply relay -J317- 2)     Engine control unit -J623-       ABS control unit -J104-         Heated windscreen relay -J47- F18 Fuse 18 on fuse holder B -SB18- 5 A Battery monitor control unit -J367- 30       Data bus diagnostic interface -J533- 3) F19 Fuse 19 on fuse holder B -SB19- 30 A Wiper motor control unit -J400- 30 F20 Fuse 20 on fuse holder B -SB20- 10 A Alarm horn -H12- 30 F21 not assigned - - F22 Fuse 22 on fuse holder B -SB22- 5 A Engine control unit -J623- 50 F23 Fuse 23 on fuse holder B -SB23- 30 A Starter -B- 50 F24 Fuse 24 on fuse holder B -SB24- 40 A Auxiliary air heater element -Z35- 87 F25 not assigned - - F26 not assigned - - F27 not assigned - - F28 not assigned - - F29 not assigned - - F30 not assigned - - F31 Fuse 31 on fuse holder B -SB31- 15 A Vacuum pump for brakes -V192- 87 F32 not assigned - - F33 not assigned - - F34 Fuse 34 on fuse holder B -SB34- 15 A Axle differential lock control unit -J647-4) 30 F35 not assigned - - F36 not assigned - - F37 Fuse 37 on fuse holder B -SB37- 20 A Auxiliary heater control unit -J364- 30 F38 not assigned - - 1) Only models with petrol engine 2) for models with diesel engine only 3) Only models with no start/stop system 4) Only models with GTI equipment 5) Only models with natural gas engine (CNG) 6) Only models with MPI petrol engine 7) Only models with E85 petrol engine 8) Only for American markets 9) Only models with no electric parking brake 10) Only models with electric parking brake Back to overview     VW GOLF 2015 Fuse assignment of fuse holder B -SB- , only models with hybrid drive system, from July 2014 Slot Current flow diagram designation Nominal value Function/component Terminal F1 Fuse 1 on fuse holder B -SB1- 40 A ABS control unit -J104- 30 F2 Fuse 2 on fuse holder B -SB2- 40 A ABS control unit -J104- 30       ABS hydraulic pump -V64- F3 Fuse 3 on fuse holder B -SB3- 15 A Engine control unit -J623- 87 F4 Fuse 4 on fuse holder B -SB4- 10 A Oil level and oil temperature sender -G266- 87     Activated charcoal filter solenoid valve 1 -N80-     Camshaft control valve 1 -N205-     Exhaust camshaft control valve 1 -N318-       Valve for oil pressure control -N428-       Coolant shortage indicator control unit -J120- F5 Fuse 5 on fuse holder B -SB5- 10 A Coolant valve for gearbox -N488- 87     Coolant pump for high-voltage battery -V590-       Coolant pump for high-temperature circuit -V467-   F6 not assigned - - F7 Fuse 7 on fuse holder B -SB7- 15 A Fuel pressure regulating valve -N276- 87     Low-temperature circuit coolant pump -V468-     Coolant changeover valve 1 -N632-         Coolant changeover valve 2 -N633-   F8 Fuse 8 on fuse holder B -SB8- 15 A Lambda probe 1 before catalytic converter -GX10- t  Lambda probe heater -Z19- 87     Lambda probe 1 after catalytic converter -GX7- t  Lambda probe 1 heater after catalytic converter -Z29-   F9 Fuse 9 on fuse holder B -SB9- 20 A Ignition coil 1 with output stage -N70- 87     Ignition coil 2 with output stage -N127-     Ignition coil 3 with output stage -N291-     Ignition coil 4 with output stage -N292- F10 Fuse 10 on fuse holder B -SB10- 15 A Fuel pump control unit -J538- 87 F11 not assigned -   - F12 not assigned - - F13 not assigned - - F14 Fuse 14 on fuse holder B -SB14- 40 A Heated windscreen relay -J47- 30 F15 Fuse 15 on fuse holder B -SB15- 15 A Horn relay -J413- 30 F16 Fuse 16 on fuse holder B -SB16- 10 A Power and control electronics for electric drive -JX1- 30     Charging unit 1 for high-voltage battery -AX4- F17 Fuse 17 on fuse holder B -SB17- 7.5 A Main relay -J271- 30     Engine control unit -J623-       ABS control unit -J104-         Heated windscreen relay -J47- F18 not assigned - - F19 Fuse 19 on fuse holder B -SB19- 30 A Wiper motor control unit -J400- 30 F20 Fuse 20 on fuse holder B -SB20- 10 A Alarm horn -H12- 30 F21 not assigned - - F22 not assigned - - F23 not assigned - - F24 Fuse 24 on fuse holder B -SB24- 40 A Brake servo -NX6- 87 F25 not assigned - - F26 not assigned - - F27 not assigned - - F28 not assigned - - F29 not assigned - - F30 not assigned - - F31 Fuse 31 on fuse holder B -SB31- 7.5 A Coolant circulation pump before power and control electronics for electric drive -V508- 87       Fuel tank shut-off valve -N288- F32 not assigned - - F33 Fuse 33 on fuse holder B -SB33- 30 A Brake system pressure accumulator -VX70- 30 F34 Fuse 34 on fuse holder B -SB34- 5 A Brake servo -NX6- 30 F35 Fuse 35 on fuse holder B -SB35- 7.5 A Air conditioning system relay -J32- 30 F36 not assigned - - F37 Fuse 37 on fuse holder B -SB37- 20 A Auxiliary heater control unit -J364- 30 F38 not assigned - - Back to overview     VW GOLF 2015 Fitting location, fuse holder A SA Fitting location, fuse holder A -SA- Fitting location, fuse holder A -SA- Get access to all wiring diagrams of the car 1 -  Fuse holder A -SA- 508 -  Threaded connection (30) on E-box Multifuse strip fuse → Repair Group  97   Note: The fuse strip (multifuse) must be replaced as a complete unit. Back to overview     Fitting location of fuse holder A -SA- , only models with hybrid drive system Get access to all wiring diagrams of the car 1 -  Fuse holder A -SA- 508 -  Threaded connection (30) on E-box Multifuse strip fuse → Repair Group  97   Note: The fuse strip (multifuse) must be replaced as a complete unit. Back to overview     Fuse assignment of fuse holder A -SA- , from August 2012 Screw location Current flow diagram designation Nominal value Function/component Terminal J1 Fuse 1 on fuse holder A -SA1- 125 A Supply for the fuses: 30       -SC2-         -SC4- …-SC14-         -SC30- …-SC42-         -SC47- …-SC49-         -SC53-         Terminal 15 voltage supply relay -J329-         Relay for power sockets -J807-     Starter relay 2 -J907- G1 Fuse 2 on fuse holder A -SA2- 400 A Alternator -C- 30 E1 Fuse 3 on fuse holder A -SA3- 80 A Power steering control unit -J500- 30 K1 Fuse 4 on fuse holder A -SA4- 80 A Supply for the fuses: 30       -SC15- …-SC20-         -SC23- …-SC28-       -SB43- …-SB45-   L1 Fuse 5 on fuse holder A -SA5- 50 A Radiator fan -VX57- 30 Back to overview VW GOLF 2015 Fuse assignment of fuse holder A -SA- , from July 2014, only models with hybrid drive system Screw location Current flow diagram designation Nominal value Function/component Terminal J1 Fuse 1 on fuse holder A -SA1- 125 A Fuse holder C -SC- t  Terminal 30 supply_1 30   Terminal 15 voltage supply relay -J329-       Relay for power sockets -J807-   G1 Fuse 2 on fuse holder A -SA2- 400 A Power and control electronics for electric drive -JX1- 30 E1 Fuse 3 on fuse holder A -SA3- 80 A Power steering control unit -J500- 30 K1 Fuse 4 on fuse holder A -SA4- 80 A Fuse holder C -SC- t  Terminal 30 supply_2 30 L1 Fuse 5 on fuse holder A -SA5- 80 A Radiator fan -VX57- 30 P1 Fuse 6 on fuse holder A -SA6- 50 A Mechatronic unit for dual clutch gearbox -J743- t  Dual clutch gearbox 0DD 30 Back to overview VW GOLF 2015 Fitting location of fuse holder G -SG- , only for special vehicles Get access to all wiring diagrams of the car 1 -  Fuse holder G -SG- Back to overview     VW GOLF 2015 Fuse assignment of fuse holder G -SG- , only for special vehicles, from August 2013 Slot Current flow diagram designation Nominal value Function/component Terminal F1 Main fuse 1 for special equipment -SG1- 50A Battery isolation relay -J7- 30 F2 Not assigned -   - Back to overview VW GOLF 2015 Fitting location of fuse holder 1 -ST1- , only for special vehicles Get access to all wiring diagrams of the car 1 -  Fuse carrier 1 -ST1- Fuse colours for J-Case fuse: t  50 A - red t  40 A - green t  30 A - pink Fuse colours for ATO flat fuse: t  40 A - orange t  30 A - light green t  25 A - natural (white) t  20 A - yellow t  15 A - light blue t  10 A - red t  7.5 A - brown t  5 A - light brown t  1A - black Fuse colours, for mini fuses: t  20 A - yellow t  15 A - light blue t  10 A - red t  7.5 A - brown t  5 A - light brown t  1A - black Back to overview     VW GOLF 2015 Fuse assignment of fuse holder 1 -ST1- , only for special vehicles, from August 2013 Slot Current flow diagram designation Nominal value Function/component Terminal A Special vehicle fuse 1 -S291- 2) only Special vehicle fuse 1) 30 B Special vehicle fuse 2 -S292- 2) only Special vehicle fuse 1) 30 C Special vehicle fuse 3 -S293- 2) only Special vehicle fuse 1) 30 1) According to equipment 2) Fuse rating, see installation description for special installations Back to overview VW GOLF 2015 Fitting location of high-voltage system fuse 3 S353 Fitting location of high-voltage system fuse 3 -S353- in the power and control electronics for electric drive -JX1-     Get access to all wiring diagrams of the car 1 -  High-voltage system fuse 3 -S353- q   in the power and control electronics for electric drive -JX1- Back to overview     VW GOLF 2015 Fuse assignment of high-voltage system fuse 3 -S353- , from July 2014 Screw location Current flow diagram designation Nominal value Function/component Terminal 1 High-voltage system fuse 3 -S353- 80 A Power and control electronics for electric drive -JX1-   Back to overview VW GOLF 2015 Earth points in front part of vehicle Earth points in front part of vehicle Earth points in front part of vehicle Get access to all wiring diagrams of the car    12 Earth point on left in engine compartment q   Specified torque 20 Nm    15 Earth point on cylinder head q   Specified torque 9 Nm    652 Earth point, engine and gearbox earth q   Specified torque 20 Nm    656 Earth point on right headlight q   Specified torque 9 Nm    671 Earth point 1 on front of left longitudinal member q   Specified torque 9 Nm    673 Earth point 3 on front of left longitudinal member q   Specified torque 9 Nm Get access to all wiring diagrams of the car    672 Earth point 2 on front of left longitudinal member q   Specified torque 20 Nm    685 Earth point 1 on front of right longitudinal member q   Specified torque 9 Nm Additional earth points in front part of vehicle, for models with hybrid drive system Get access to all wiring diagrams of the car VW GOLF 2015 Coupling point on left in engine compartment TML    81 Earth point in centre of engine compartment q   near high-voltage battery charging socket 1 -UX4- q   Specified torque 9 Nm    640 Earth point 2 on left in engine compartment q   on charging unit 1 for high-voltage battery -AX4- q   Specified torque 8 Nm    686 Earth point 2 on front of right longitudinal member q   Specified torque 9 Nm    777 Earth point for air conditioner compressor q   Specified torque 9 Nm    778 Earth point for high-voltage heater (PTC) q   Specified torque 9 Nm    779 Earth point 1 for power and control electronics for electric drive q   Specified torque 9 Nm Earth points in middle part of vehicle Get access to all wiring diagrams of the car    43 Earth point, lower part of right A-pillar q   Specified torque 9 Nm    44 Earth point on lower part of left A-pillar q   Specified torque 9 Nm    638 Earth point on right A-pillar q   Specified torque 9 Nm    684 Earth point on front of left side member q   Specified torque 9 Nm    689 Earth point, at front, central in roof q   Specified torque 9 Nm    810 Earth point on central tube for dash panel, centre left q   Specified torque 9 Nm Get access to all wiring diagrams of the car    811 Earth point on central tube for dash panel, centre right q   Specified torque 9 Nm Earth points in rear part of vehicle Get access to all wiring diagrams of the car    62 Earth point, right C-pillar q   Specified torque 2 Nm    612 Earth point, at centre on rear lid q   Specified torque 2 Nm    730 Earth point 1, on right rear wheel housing q   Specified torque 9 Nm Get access to all wiring diagrams of the car    729 Earth point, on left rear wheel housing q   Specified torque 9 Nm    50 Earth point, on left in luggage compartment q   Only models with hybrid drive system q   Specified torque 9 Nm Earth points from below, for models with hybrid drive system Get access to all wiring diagrams of the car    782 Earth point 1, on high-voltage battery q   Specified torque 9 Nm    791 Earth point on rear right of underbody q   Specified torque 9 Nm    794 Earth point 1 in high-voltage battery q   Specified torque 9 Nm VW GOLF 2015 10-pin connector -T10kv- , black/10-pin connector -T10kw- , black Coupling point on left in engine compartment -TML- Coupling point on left in engine compartment -TML- Get access to all wiring diagrams of the car 10-pin connector -T10kv- , black/10-pin connector -T10kw- , black q   for models with diesel engine only 6-pin connector -T6cj- , black/6-pin connector -T6cq- , black q   for models with petrol engine only 10-pin connector -T10ky- , black/10-pin connector -T10kx- , black q   Only models with diesel engine 14-pin connector -T14i- , grey/14-pin connector -T14h- , grey 14-pin connector -T14l- , grey/14-pin connector -T14m- , grey q   Only models with 2.0 l petrol engine 4-pin connector -T4dd- , black/4-pin connector -T4de- , black q   Only models with 1.2/1.4 l petrol engine 8-pin connector -T8at- , black/8-pin connector -T8as- , black q   Only models with 1.6/2.0 l diesel engine q   Only models with 2.0l petrol engine without gearbox oil cooling pump -V478- 10-pin connector -T10ag- , black/10-pin connector -T10af- , black q   Only models with 2.0l petrol engine with gearbox oil cooling pump -V478- 8-pin connector -T8au- , black/8-pin connector -T8az- , black 4-pin connector -T4x- , black/4-pin connector -T4f- , black 6-pin connector -T6as- , black/6-pin connector -T6at- , black q   Only models with axle differential lock control unit -J647- Coupling point on left in engine compartment -TML- , only models with hybrid drive system Get access to all wiring diagrams of the car 14-pin connector -T14q- , black/14-pin connector -T14t- , black 14-pin connector -T14z- , grey/14-pin connector -T14v- , grey C -  8-pin connector -T8au- , black/8-pin connector -T8az- , black 14-pin connector -T14aa- , grey/14-pin connector -T14ab- , grey 14-pin connector -T14ac- , black/14-pin connector -T14ad- , black Coupling point on engine, top centre -TMOM- Get access to all wiring diagrams of the car 8-pin connector -T8h- /8-pin connector -T8i- Coupling point on engine, top right -TMOR- Get access to all wiring diagrams of the car 8-pin connector -T8f- /8-pin connector -T8g- 14-pin connector -T14e- /14-pin connector -T14f- Diagnostic connection -U31- Diagnostic connection -U31- , left-hand drive models Get access to all wiring diagrams of the car A -  16-pin connector -T16- , black Diagnostic connection -U31- , right-hand drive models Get access to all wiring diagrams of the car A -  16-pin connector -T16- , black Coupling point on front left door -TTVL- Get access to all wiring diagrams of the car 27-pin connector -T27- , black/27-pin connector -T27b- , black Coupling point in front left door -TTIVL- Get access to all wiring diagrams of the car 4-pin connector -T4ac- , black/4-pin connector -T4ad- , black Coupling point on rear left door -TTHL- Get access to all wiring diagrams of the car 19-pin connector -T19b- , black/19-pin connector -T19c- , black Coupling point for all-wheel drive -TSAA- Get access to all wiring diagrams of the car B -  6-pin connector -T6i- , black Coupling point for rear left seat -TSHL- Get access to all wiring diagrams of the car B -  3-pin connector -T3cx- , yellow Coupling point in interior, below left -TIUL- Coupling point in interior, below left -TIUL- Get access to all wiring diagrams of the car 17-pin connector -T17j- , white/17-pin connector -T17p- , white 17-pin connector -T17h- , green/17-pin connector -T17q- , green 1-pin connector -T1aj- , black/1-pin connector -T1ai- , black q   Only models with hybrid drive system 17-pin connector -T17e- , brown/17-pin connector -T17m- , brown 17-pin connector -T17g- , blue/17-pin connector -T17o- , blue 17-pin connector -T17f- , red/17-pin connector -T17n- , red 17-pin connector -T17d- , black/17-pin connector -T17l- , black Coupling point in interior, below left -TIUL- , only models with special equipment Get access to all wiring diagrams of the car 2-pin connector -T2iy- , black/2-pin connector -T2iz- , black q   According to equipment 4-pin connector -T4cn- , black/4-pin connector -T4co- , black q   According to equipment 6-pin connector -T6ae- , black/6-pin connector -T6ad- , black q   According to equipment 6-pin connector -T6au- , black/6-pin connector -T6av- , black q   According to equipment Coupling point for front left seat -TSVL- Coupling point for front left seat -TSVL- , LHD models Get access to all wiring diagrams of the car 2-pin connector -T2fw- , black/2-pin connector -T2fx- , black 3-pin connector -T3cy- , yellow/3-pin connector -T3cz- , yellow 10-pin connector -T10a- , black/10-pin connector -T10w- , black Coupling point for front left seat -TSVL- , RHD models Get access to all wiring diagrams of the car A -  Not assigned B -  3-pin connector -T3cy- , yellow/3-pin connector -T3cz- , yellow C -  10-pin connector -T10a- , black/10-pin connector -T10w- , black D -  4-pin connector -T4ee- , black/4-pin connector -T4ef- , black Coupling point for roof -TH- Get access to all wiring diagrams of the car 16-pin connector -T16j- /16-pin connector -T16k- Coupling point for roof, centre -THM- Get access to all wiring diagrams of the car 6-pin connector -T6cr- /6-pin connector -T6cp- Coupling point in interior, centre -TIM- Get access to all wiring diagrams of the car 2-pin connector -T2iw- , black/2-pin connector -T2ix- , black Coupling point on front right door -TTVR- Get access to all wiring diagrams of the car 27-pin connector -T27a- , black/27-pin connector -T27c- , black Coupling point in front right door -TTIVR- Get access to all wiring diagrams of the car 4-pin connector -T4ae- , black/4-pin connector -T4af- , black Coupling point on rear right door -TTHR- Get access to all wiring diagrams of the car 19-pin connector -T19- , black/19-pin connector -T19a- , black Coupling point for rear right seat -TSHR- Get access to all wiring diagrams of the car B -  3-pin connector -T3cv- , yellow Coupling point in interior, below right -TIUR- Get access to all wiring diagrams of the car 17-pin connector -T17k- , brown/17-pin connector -T17s- , brown 17-pin connector -T17i- , black/17-pin connector -T17r- , black Get access to all wiring diagrams of the car B -  2-pin connector -T2es- , black Coupling point for front right seat -TSVR- Coupling point for front right seat -TSVR- , LHD models Get access to all wiring diagrams of the car B -  10-pin connector -T10b- , black/10-pin connector -T10x- , black C -  3-pin connector -T3db- , yellow/3-pin connector -T3dc- , yellow D -  A -  10-pin connector -T10x- , black/10-pin connector -T10b- , black B -  3-pin connector -T3db- , yellow/3-pin connector -T3dc- , yellow C -  2-pin connector -T2fw- , black/2-pin connector -T2fx- , black q   According to equipment Coupling point on rear lid -THK- Get access to all wiring diagrams of the car 10-pin connector -T10l- , brown/10-pin connector -T10n- , brown 10-pin connector -T10d- , black/10-pin connector -T10p- , black Coupling point in luggage compartment, left -THRL- Get access to all wiring diagrams of the car 8-pin connector -T8aw- , black/8-pin connector -T8ba- , black Coupling point in luggage compartment, centre -THRM- , only models with hybrid drive system Get access to all wiring diagrams of the car 4-pin connector -T4cv- , black/4-pin connector -T4cw- , black 14-pin connector -T14x- , black/14-pin connector -T14y- , black Coupling point in luggage compartment, right -THRR- Coupling point in luggage compartment, right -THRR- Get access to all wiring diagrams of the car 2-pin connector -T2ca- , black/2-pin connector -T2cb- , black q   According to equipment 10-pin connector -T10la- , black/10-pin connector -T10lf- , black q   According to equipment Coupling point in luggage compartment, right -THRR- , only models with special vehicle interface Get access to all wiring diagrams of the car 8-pin connector -T8u- , black/8-pin connector -T8t- , black Coupling point on rear cross member, left -TAQL- Get access to all wiring diagrams of the car A -  5-pin connector -T5ab- , brown/5-pin connector -T5ao- , brown VW GOLF 2015 Overview of relay carriers Overview of relay carriers   Note The fitting locations are identical on LHD and RHD models. Get access to all wiring diagrams of the car 1 -  Relay and fuse carrier 4 -SR4- , in luggage compartment   Note Only for special vehicles t  Battery isolator relay -J7- q   Fitting location and relay assignment, only for vehicles with no special vehicle interface, from August 2013 q   Fitting location and relay assignment, only for vehicles with special vehicle interface, from November 2013 2 -  Relay and fuse carrier 2 -SR2- , on left under dash panel t  Heated rear window relay -J9- t  Terminal 15 voltage supply relay -J329- t  Terminal 15 relief relay -J404- t  Relay for power sockets -J807- q   Fitting locations and relay assignment, LHD, from August 2012 q   Fitting locations and relay assignment, RHD, from August 2012 Relay and fuse carrier 3 -SR3- , on left under dash panel   Note Only for special vehicles t  Driving school mode relay -J746- q   Fitting location and relay assignment, from January 2013 3 -  Relay and fuse carrier 1 -SR1- , on E-box in engine compartment t  Fuel pump relay -J17- t  Air conditioning system relay -J32- t  Heated windscreen relay -J47- t  Coolant shortage indicator control unit -J120- t  Automatic glow period control unit -J179- t  Main relay -J271- t  Secondary air pump relay -J299- t  Terminal 30 voltage supply relay -J317- t  Low heat output relay -J359- t  High heat output relay -J360- t  Horn relay -J413- t  Engine component current supply relay -J757- t  Starter relay 1 -J906- t  Starter relay 2 -J907- t  Relay for gas shut-off valves -J908- q   Fitting location and relay assignment, equipment version 1, from August 2012 q   Fitting location and relay assignment, equipment version 2, from April 2013 VW GOLF 2015 Relay and fuse carrier 4 -SR4- , in luggage compartment Fitting location and relay assignment of relay and fuse carrier 4 -SR4- , only models with no special vehicle interface, from May 2013 Get access to all wiring diagrams of the car 1 -  Relay and fuse carrier 4 -SR4- , in luggage compartment R1 -  Battery isolator relay -J7- q   Only for special vehicles R2 -  Relay for special vehicles q   According to equipment Back to overview     Fitting location and relay assignment of relay and fuse carrier 4 -SR4- , only models with special vehicle interface, from November 2013 Get access to all wiring diagrams of the car 1 -  Relay and fuse carrier 4 -SR4- , in luggage compartment R1 -  Battery isolator relay -J7- q   Only for special vehicles R2 -  Relay for special vehicles q   According to equipment R3 -  Relay for special vehicles q   According to equipment Back to overview     Relay and fuse carrier 2 -SR2- , on left under dash panel Fitting location and relay assignment of relay and fuse carrier 2 -SR2- , left-hand drive models, from August 2012 Get access to all wiring diagrams of the car 1 -  Relay and fuse carrier 2 -SR2- , on left under dash panel R1 -  Not assigned R2 -  Terminal 15 relief relay -J404- q   According to equipment, up to November 2013 R3 -  Not assigned R4 -  Terminal 15 voltage supply relay -J329- R5 -  Heated rear window relay -J9- R6 -  Relay for power sockets -J807- Back to overview     Fitting location and relay assignment of relay and fuse carrier 2 -SR2- , right-hand drive models, from August 2012 Get access to all wiring diagrams of the car 1 -  Relay and fuse carrier 2 -SR2- , on left under dash panel R1 -  Not assigned R2 -  Terminal 15 relief relay -J404- q   According to equipment, up to November 2013 R3 -  Not assigned R4 -  Terminal 15 voltage supply relay -J329- R5 -  Heated rear window relay -J9- R6 -  Relay for power sockets -J807- Back to overview     Relay and fuse carrier 3 -SR3- , on left under dash panel Fitting location and fuse assignment of relay and fuse carrier 3 -SR3- , only for special vehicles, from May 2013 Get access to all wiring diagrams of the car 1 -  Relay and fuse carrier 3 -SR3- R1 -  Driving school mode relay -J746- q   Only for special vehicles Back to overview     Relay and fuse carrier 1 -SR1- , on E-box in engine compartment Fitting location and relay assignment of relay and fuse carrier 1 -SR1- , on E-box, equipment version 1, from August 2012 Get access to all wiring diagrams of the car 1 -  Relay and fuse carrier 1 -SR1- , on E-box in engine compartment R1 -  Starter relay 1 -J906- R2 -  Starter relay 2 -J907- R3 -  Horn relay -J413- R4 -  High heat output relay -J360- q   Only models with auxiliary air heater R5 -  Main relay -J271- q   Only models with petrol engine R5 -  Terminal 30 voltage supply relay -J317- q   Only models with a diesel engine R6 -  Automatic glow period control unit -J179- q   Only models with a diesel engine R7 -  Low heat output relay -J359- q   Only models with auxiliary air heater R8 -  Fuel pump relay -J17- q   Only models with MPI petrol engine R9 -  Not assigned R10 -  Not assigned Back to overview     Fitting location and relay assignment of relay and fuse carrier 1 -SR1- , on E-box, equipment version 2, from April 2013 Get access to all wiring diagrams of the car 1 -  Relay and fuse carrier 1 -SR1- , on E-box in engine compartment R1 -  Starter relay 1 -J906- R2 -  Starter relay 2 -J907- R3 -  Horn relay -J413- R4 -  Secondary air pump relay -J299- q   Only for American markets R4 -  High heat output relay -J360- q   Only models with auxiliary air heater R5 -  Main relay -J271- q   Only models with petrol engine R5 -  Terminal 30 voltage supply relay -J317- q   Only models with a diesel engine R6 -  Automatic glow period control unit -J179- q   Only models with a diesel engine R6 -  Coolant shortage indicator control unit -J120- q   Only models with hybrid drive system R7 -  Low heat output relay -J359- q   Only models with auxiliary air heater R8 -  Engine component current supply relay -J757- q   According to equipment R8 -  Relay for gas shut-off valves -J908- q   Only models with CNG engine R8 -  Air conditioning system relay -J32- q   Only models with hybrid drive system R11 -  Heated windscreen relay -J47- q   Only models with heated windscreen Back to overview     VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015VW GOLF 2015 Didn't find a car made after 2014? Look here -> DiagnostData.com! Login Email or Login Password Remember me Sign up Get a new password Sign up Email Password Confirm password * A password will be generated automatically and sent to your Email Login Get a new password Get a new password Email Login Sign up
