VW GOL 2007 – Fog light (Gol/Saveiro 4) . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW GOL
  4. >VW GOL 2007
  5. >VW GOL 2007 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW GOL 2007 - Battery - starter - alternator - voltage regulator



Wiring Diagram VW GOL 2007 - Battery - starter - alternator - voltage regulator https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
ABattery
BStarter
CAlternator
C1Voltage regulator
KDash panel insert
T2bo2-pin connector, on alternator
T2v2-pin connector, near battery
T16c16-pin connector, brown, next to relay plate
T32a32-pin connector, on dash panel insert
  1 Earth strap, battery - body
  49 Earth point, near battery
  D26 Positive connection (B+), in alternator wiring harness
  P1 Positive connection (30), in fuse holder on battery

Wiring Diagram VW GOL 2007 - Ignition/starter switch - X-contact relief relay - terminal 30 wiring junction



Wiring Diagram VW GOL 2007 - Ignition/starter switch - X-contact relief relay - terminal 30 wiring junction https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
DIgnition/starter switch
F4Reversing light switch
J59X-contact relief relay
RRadio
SA14Fuse 14 on fuse holder A
SA21Fuse 21 on fuse holder A
SA32Fuse 32 on fuse holder A
T2ax2-pin connector, on reversing light switch
T6a6-pin connector, on X-contact relief relay
T7c7-pin connector, on ignition/starter switch
T8h8-connector, on radio
T16f16-pin connector, black, behind the glove compartment
TV2Terminal 30 wiring junction
  135 Earth connection 2, in dash panel wiring harness
  A2 Positive connection (15), in dash panel wiring harness
  A40 Positive connection (30), in dash panel wiring harness
  A49 Connection 1, in dash panel wiring harness
  A99 Connection 1 (87), in dash panel wiring harness

Wiring Diagram VW GOL 2007 - Light switch - headlight dipper/flasher switch - fog light switch - fog light warning lamp



Wiring Diagram VW GOL 2007 - Light switch - headlight dipper/flasher switch - fog light switch - fog light warning lamp https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
E1Light switch
E4Headlight dipper/flasher switch
E7Fog light switch
KDash panel insert
L9Light switch illumination bulb
K17Fog light warning lamp
SA27Fuse 27 on fuse holder A
T5a5-pin connector, on headlight dipper/flasher switch
T16d16-pin connector, black, next to relay plate
T16e16-pin connector, brown, next to relay plate
T17a17-pin connector, on light switch
T32a32-pin connector, on dash panel insert
  44 Earth point, lower part of left A-pillar
  81 Earth connection 1, in dash panel wiring harness
  A19 Connection (58d), in dash panel wiring harness
  A37 Connection (58a), in dash panel wiring harness

Wiring Diagram VW GOL 2007 - Rear fog light bulb - left fog light bulb - right fog light bulb



Wiring Diagram VW GOL 2007 - Rear fog light bulb - left fog light bulb - right fog light bulb https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
L20Rear fog light bulb
L22Left fog light bulb
L23Right fog light bulb
M1Front left side marker bulb
M3Front right side marker bulb
SA25Fuse 25 on fuse holder A
SA26Fuse 26 on fuse holder A
T2bz2-pin connector, on the front right side marker bulb
T2c2-pin connector, on right fog light bulb
T2ca2-pin connector, on left side light bulb
T2d2-pin connector, on left fog light bulb
T5l5-pin connector, on left tail light
T16c16-pin connector, yellow, next to relay plate
  44 Earth point, lower part of left A-pillar
  86 Earth connection 1, in rear wiring harness
  108 Earth connection 2, in front left wiring harness
  A3 Positive connection (58), in dash panel wiring harness
  A84 Connection (58L), in dash panel wiring harness
  C69 Front left connection (fog light) in main wiring harness
*only for Saveiro
**only for Gol
