Wiring Diagram VW SAVEIRO 2011 - Battery - starter - alternator - voltage regulator
| A | Battery |
| B | Starter |
| C | Alternator |
| C1 | Voltage regulator |
| T2bo | 2-pin connector, on alternator |
| T2v | 2-pin connector, near battery |
| T16c | 16-pin connector, brown, next to relay plate |
| 1 | Earth strap, battery - body |
| 49 | Earth point, near battery |
| D26 | Positive connection (B+), in alternator wiring harness |
| P1 | Positive connection (30), in fuse holder on battery |
Wiring Diagram VW SAVEIRO 2011 - Ignition/starter switch - X-contact relief relay - terminal 30 wiring junction
| D | Ignition/starter switch |
| F4 | Reversing light switch |
| J59 | X-contact relief relay |
| R | Radio |
| SA14 | Fuse 14 on fuse holder A |
| SA21 | Fuse 21 on fuse holder A |
| SA32 | Fuse 32 on fuse holder A |
| T2ax | 2-pin connector, on reversing light switch |
| T6a | 6-pin connector, on X-contact relief relay |
| T7c | 7-pin connector, on ignition/starter switch |
| T8h | 8-connector, on radio |
| T16f | 16-pin connector, black, behind the glove compartment |
| TV2 | Terminal 30 wiring junction |
| A2 | Positive connection (15), in dash panel wiring harness |
| A40 | Positive connection (30), in dash panel wiring harness |
| A49 | Connection 1, in dash panel wiring harness |
| A99 | Connection 1 (87), in dash panel wiring harness |
Wiring Diagram VW SAVEIRO 2011 - Light switch - light switch illumination bulb
| E1 | Light switch |
| L9 | Light switch illumination bulb |
| L23 | Right fog light bulb |
| SA26 | Fuse 26 on fuse holder A |
| SA27 | Fuse 27 on fuse holder A |
| T2c | 2-pin connector, on right fog light bulb |
| T16e | 16-pin connector, grey, next to relay plate |
| T17a | 17-pin connector, on light switch |
| A19 | Connection (58d), in dash panel wiring harness |
| C69 | Front left connection (fog light) in main wiring harness |
Wiring Diagram VW SAVEIRO 2011 - Turn signal switch - headlight dipper/flasher switch - turn signal relay
| E2 | Turn signal switch |
| E3 | Hazard warning light switch |
| E4 | Headlight dipper/flasher switch |
| J1 | Turn signal relay |
| SA28 | Fuse 28 on fuse holder A |
| SA29 | Fuse 29 on fuse holder A |
| T5a | 5-pin connector, on headlight dipper/flasher switch |
| T7b | 7-pin connector, on turn signal switch |
| T8a | 8-connector, on hazard warning light switch |
| T9a | 9-pin connector, on turn signal relay |
| T16a | 16-pin connector, behind driver storage compartment |
| 135 | Earth connection 2, in dash panel wiring harness |
| A1 | Positive connection (30a), in dash panel wiring harness |
| A95 | Connection 1 (56a), in dash panel wiring harness |
| A157 | Connection (49a), in dash panel wiring harness |
Wiring Diagram VW SAVEIRO 2011 - Rear right turn signal bulb - right brake and tail light bulb - number plate right
| L28 | Cigarette lighter illumination bulb |
| L42 | Socket illumination bulb |
| M8 | Rear right turn signal bulb |
| M22 | Right brake and tail light bulb |
| T1at | Single pin connector, on socket illumination bulb |
| T1b | Single pin connector, on cigarette lighter illumination bulb |
| T1at | Single pin connector, on socket illumination bulb |
| T2bv | 2-pin connector, on number plate light |
| T2bw | 2-pin connector, on number plate light |
| T2cb | 2-pin connector, behind side trim on left, near wheel housing |
| T5m | 5-pin connector, on right tail light |
| T16b | 16-pin connector, black, next to relay plate |
| X | Number plate light |
| 44 | Earth point, lower part of left A-pillar |
| 196 | Earth connection 3, in rear wiring harness |
| 260 | Earth connection, in tail lights wiring harness |
| 218 | Earth connection 1, in rear lid wiring harness |
| A37 | Connection (58a), in dash panel wiring harness |
| W11 | Connection (58), in rear lid wiring harness |
Wiring Diagram VW SAVEIRO 2011 - Left headlight twin filament bulb/left sealed beam insert - right headlight twin filament bulb/right sealed beam insert - front left turn signal bulb - front right turn signal bulb
| L1 | Left headlight twin filament bulb/left sealed beam insert |
| L2 | Right headlight twin filament bulb/right sealed beam insert |
| M1 | Front left side marker bulb |
| M5 | Front left turn signal bulb |
| M7 | Front right turn signal bulb |
| SA30 | Fuse 30 on fuse holder A |
| SA31 | Fuse 31 on fuse holder A |
| T2a | 2-pin connector, on the front left turn signal bulb |
| T2b | 2-pin connector, on turn signal bulb |
| T2ca | 2-pin connector, on the front left side marker bulb |
| T3w | 3-pin connector, on right headlight twin filament bulb/left sealed beam insert |
| T3x | 3-pin connector, on right headlight twin filament bulb/right sealed beam insert |
| T16b | 16-pin connector, black, next to relay plate |
| T16c | 16-pin connector, brown, next to relay plate |
| T16e | 16-pin connector, black, next to relay plate |
| 108 | Earth connection 2, in front left wiring harness |
| A5 | Positive connection (right turn signal), in dash panel wiring harness |
| A6 | Positive connection (left turn signal), in dash panel wiring harness |
| A9 | Positive connection (56b), in instrument panel wiring harness |
Wiring Diagram VW SAVEIRO 2011 - Control unit in dash panel insert - dash panel insert - main beam warning lamp - right turn signal warning lamp - front right side marker bulb
| J285 | Control unit in dash panel insert |
| K | Dash panel insert |
| K1 | Main beam warning lamp |
| K2 | Alternator warning lamp |
| K94 | Right turn signal warning lamp |
| M3 | Front right side marker bulb |
| SA25 | Fuse 25 on fuse holder A |
| T2bz | 2-pin connector, on the front right side marker bulb |
| T16b | 16-pin connector, black, next to relay plate |
| T16c | 16-pin connector, behind glove compartment, front passenger side |
| T32a | 32-pin connector, on control unit in dash panel insert |
| 44 | Earth point, lower part of left A-pillar |
| 81 | Earth connection 1, in dash panel wiring harness |
| 108 | Earth connection 2, in front left wiring harness |
| A3 | Connection (58), in dash panel wiring harness |
| A215 | Connection 2 (56a), in dash panel wiring harness |
Wiring Diagram VW SAVEIRO 2011 - Rear left turn signal bulb - left brake and tail light bulb
| M6 | Rear left turn signal bulb |
| M21 | Left brake and tail light bulb |
| T5l | 5-pin connector, on left tail light |
| T16b | 16-pin connector, red, next to relay plate |
| 308 | Earth connection 2, in tail lights wiring harness |
| A84 | Connection (58L), in dash panel wiring harness |
VW SAVEIRO 2011 ABS control unit J104
| ABS control unit -J104- |
|
| Designation of connector: |
| A - | ABS control unit -J104- |
| B - | 31-pin connector, on ABS control unit -T31a- |
|
|
| Designation of connector: |
| A - | Airbag control unit -J234- |
| B - | 75-pin connector, on ABS control unit -T75a- |
|
|
| Designation of connector: |
| A - | Control unit with display in dash panel insert -J285- |
| B - | 32-pin connector, on control unit with display in dash panel insert -T32a- |
| 1 - | Vacant |
| 2 - | Engine control unit |
| 3 - | Terminal 15a |
| 4 - | Terminal R |
| 5 - | Fuel gauge sender |
| 6 - | Airbag control unit |
| 7 - | Terminal 31 |
| 8 - | Coolant temperature sender |
| 9 - | Terminal 31 |
| 10 - | Oil pressure switch |
| 11 - | Engine control unit |
| 12 - | Terminal 61 |
| 13 - | Engine control unit |
| 14 - | Terminal 75 |
| 15 - | Terminal 58 |
| 16 - | Terminal 58 |
| 17 - | Radio |
| 18 - | Radio |
| 19 - | ABS control unit |
| 20 - | Immobilizer control unit |
| 21 - | Radio |
| 22 - | Terminal L |
| 23 - | Terminal 30 |
| 24 - | Terminal 31 |
| 25 - | Terminal K |
| 26 - | Speedometer sender |
| 27 - | Engine control unit |
| 28 - | Speedometer sender |
| 29 - | Brake system monitoring |
| 30 - | Terminal 56a |
| 31 - | Terminal 58d |
| 32 - | Terminal 58d |
| B - | 32-pin connector, on control unit with display in dash panel insert -T32a- |
Note
| for models with 1.0 l Flex engine, 1.0 l and 1.4 l petrol engines only, from March 2008 |
| 1 - | Terminal 30 |
| 2 - | Terminal 31 |
| 3 - | Turn signal |
| q | only for Gol Phoenix |
| 4 - | Terminal CAN-Bus high |
| 5 - | Terminal CAN-Bus low |
| 6 - | Vacant |
| 7 - | Radio |
| 8 - | Radio |
| 9 - | Radio |
| 10 - | Terminal 61 |
| 11 - | Terminal 56a |
| 12 - | ABS control unit |
| 13 - | Airbag control unit |
| 14 - | Brake system monitoring |
| 15 - | Immobilizer control unit |
| 16 - | Immobilizer control unit |
| 17 - | Terminal 15 |
| 18 - | Terminal 31 |
| 19 - | Vacant |
| 20 - | Terminal 31 |
| 21 - | CAN Shield |
| 22 - | Fuel gauge sender |
| 23 - | Oil pressure switch |
| 24 - | S-contact |
| 25 - | Speedometer sender |
| 26 - | Terminal K |
| 27 - | Terminal L |
| 28 - | Vacant |
| 29 - | Terminal 75 |
| 30 - | Terminal 58d |
| 31 - | Terminal 58d |
| 32 - | Terminal R |
Note
|
|
| Designation of connector: |
| A - | Control unit with display in dash panel insert -J285- |
| B - | 32-pin connector, on control unit in dash panel insert -T32a- |
| 1 - | Speedometer sender |
| 2 - | Vacant |
| 3 - | Terminal 15 |
| 4 - | Terminal R |
| 5 - | Fuel gauge sender |
| 6 - | Airbag control unit |
| 7 - | Terminal 31 |
| 8 - | Coolant temperature sender |
| 9 - | Terminal 31 |
| 10 - | Oil pressure switch |
| 11 - | Engine control unit |
| 12 - | Terminal 61 |
| 13 - | Engine control unit |
| 14 - | Terminal 75 |
| 15 - | Oil pressure switch |
| 16 - | Immobilizer control unit |
| 17 - | Radio |
| 18 - | Radio |
| 19 - | ABS control unit |
| 20 - | Terminal 58d |
| 21 - | Radio |
| 22 - | Coolant shortage indicator sender |
| 23 - | Terminal 30 |
| 24 - | Terminal 31 |
| 25 - | Terminal K |
| 26 - | Terminal 58 |
| 27 - | Engine control unit |
| 28 - | Speedometer sender |
| 29 - | Brake system monitoring |
| 30 - | Terminal 56a |
| 31 - | Terminal L |
| 32 - | Terminal 56 |
|
|
| Designation of connector: |
| A - | Convenience system central control unit -J393- |
| B - | 12-pin connector, on convenience system central control unit -T12c- |
| C - | 23-pin connector, on convenience system central control unit -T23a- |
| D - | 12-pin connector, on convenience system central control unit -T12b- |
|
|
| Designation of connector: |
| A - | Engine control unit -J623- |
| B/C - | 80-pin connector, on engine control unit -T80a- |
|
|
| Designation of connector: |
| A - | Air conditioning system control unit -J301- |
| B - | 5-pin connector, on air conditioning system control unit -T5d- |
| C - | 7-pin connector, on heater control unit -T7d- |
|
|
| Designation of connector: |
| A - | Immobilizer control unit -J362- |
| B - | 8-pin connector, on immobilizer control unit -T8g- |
| C - | 2-pin connector, on immobilizer control unit -T2bp- |
|
|
| Designation of connector: |
| A - | Alarm system control unit -J85- |
| B - | 22-pin connector, on alarm system control unit -T22a- |
