| A | Battery |
| B | Starter |
| C | Alternator |
| C1 | Voltage regulator |
| J59 | X contact relief relay |
| K | Dash panel insert |
| T2bo | 2-pin connector, on alternator |
| T2v | 2-pin connector, near battery |
| T6e | 6-pin connector, (brown) next to relay plate |
| T32a | 32-pin connector, on dash panel insert |
| 1 | Earth strap, battery body |
| 49 | Earth point, near battery |
| 500 | Screw connection -1- (30), on relay plate |
| 501 | Screw connection -2- (30), on relay plate |
| D26 | Positive connection (B+), in alternator wiring harness |
| P1 | Positive connection (30), in fuse holder/battery |
| E30 | Air conditioner switch |
| F18 | Radiator fan thermo-switch |
| F163 | A/C Cut-Out Thermal Switch |
| J209 | Fresh air blower and radiator fan relay |
| J301 | Air conditioning system control unit |
| J382 | 1AV control unit (injection system) |
| S4 | Cooling system fan motor - 1st speed fuse (40A) |
| T1ae | Single conector, on A/C Cut-Out Thermal Switch |
| T1af | Single conector, on A/C Cut-Out Thermal Switch |
| T3c | 3-pin connector, on radiator fan thermo-switch |
| T6f | 6-pin connector, (red) next to relay plate |
| T6p | 6-pin connector, (brown) behind shelf - front passenger's side |
| T7d | 7-pin connector, on air conditioning system control unit |
| T8k | 8-pin connector, behind dash panel, centre |
| T9b | 9-pin connector, on fresh air blower and radiator fan relay |
| T45a | 45-pin connector, on 1AV control unit (injection system) |
| L2 | Connection in air conditioner wiring harness |
| A138 | Connection -2-, in dash panel wiring harness |
| C55 | Positive connection (30a), in front left wiring harness |
| E9 | Fresh air blower switch |
| E159 | Fresh air/air recirculating flap switch |
| J301 | Air conditioning system control unit |
| N24 | Fresh air blower with overheating fuse series resistor |
| T4l | 4-pin connector, on Fresh/recirculating air flap control motor |
| T5t | 5-pin connector, on fresh air blower switch |
| T5u | 5-pin connector, on Fresh air blower with overheating fuse series resistor |
| T7d | 7-pin connector, on air conditioning system control unit |
| V154 | Fresh/recirculating air flap control motor |
| L6 | Connection -2-, in evaporator housing unit wiring harness |
| L8 | Connection -4-, in evaporator housing unit wiring harness |
| L78 | Connection, in fresh air blower wiring harness |
| E1 | Lighting switch |
| J32 | Air conditioning system relay |
| J301 | Air conditioning system control unit |
| K | Dash panel insert |
| L16 | Fresh air controls light bulb |
| S10 | Air conditioning fuse (25A) |
| S224 | Forced ventilation/ fuse (25A) |
| T2bm | 2-pin connector, on fresh air blower |
| T6f | 6-pin connector, (red) next to relay plate |
| T7d | 7-pin connector, on air conditioning system control unit |
| T8k | 8-pin connector, behind dash panel, centre |
| T9a | 9-pin connector, on air conditioning system relay |
| T17a | 17-pin connector, on light switch |
| T32a | 32-pin connector, on dash panel insert |
| V2 | Fresh air blower |
| 44 | Earth point, lower part of left A-pillar |
| 81 | Earth connection -1-, in dash panel wiring harness |
| 97 | Earth connection -1-, in air conditioner wiring harness |
| A4 | Positive connection (58b), in dash panel wiring harness |
| A61 | Positive connection (X), in instrument panel wiring harness |
| A99 | Connection -1- (87), in dash panel wiring harness |
| F129 | Air conditioner pressure switch |
| J17 | Fuel pump relay |
| J365 | Air conditioning system switch-off relay |
| J382 | 1AV control unit (injection system) |
| N25 | Air conditioning system magnetic coupling |
| T1e | Single connector, on air conditioning system magnetic coupling |
| T4e | 4-pin connector, on air conditioner pressure switch |
| T6f | 6-pin connector, (red) next to relay plate |
| T6p | 6-pin connector, (brown) behind shelf - front passenger's side |
| T9d | 9-pin connector, on air conditioning system switch-off relay |
| T9e | 9-pin connector, on fuel pump relay |
| T45a | 45-pin connector, on 1AV control unit (injection system) |
| 44 | Earth point, lower part of left A-pillar |
| 82 | Earth connection -1-, in front left wiring harness |
| E43 | Connection (87), in injection system wiring harness |
| J101 | Radiator fan 2nd speed relay |
| N39 | Radiator fan series resistor |
| S9 | Cooling system fan motor - 2nd speed fuse (40A) |
| T2bn | 2-pin connector, on radiator fan |
| T3d | 3-pin connector, near headlight, left |
| T9c | 9-pin connector, on radiator fan 2nd speed relay |
| V7 | Radiator fan |
| 44 | Earth point, lower part of left A-pillar |
| 108 | Earth connection -2-, in front left wiring harness |
| 502 | Screw connection -1- (30a), on relay plate |
| C11 | Connection in radiator fan wiring harness |
| C54 | Connection (fan stage II), in front left wiring harness |
