Wiring Diagram VW LUPO 2001 - Battery - ignition/starter switch - X contact relief relay
| A | Battery |
| B | Starter |
| D | Ignition/starter switch |
| J53 | Starter motor relay |
| J59 | X contact relief relay, on relay plate |
| J514 | Electronic manual gearbox control unit |
| T10i | 10-pin connector, green, connector point under relay carrier |
| T10t | 10-pin connector, violet, connector point under relay carrier |
| T68 | 68-pin connector |
| 1 | Earth strap, battery - body |
| 3 | Earth strap, engine - body |
| 500 | Screw connection -1- (30), on relay carrier |
| 501 | Screw connection -2- (30), on relay carrier |
| A32 | Positive (+) connection (30), in dash panel wiring harness |
| A40 | Positive (+) connection-1-(30), in instruments wiring harness |
| B151 | Positive (+) connection -3- (30a), in interior wiring harness |
Wiring Diagram VW LUPO 2001 - Voltage stabiliser
| J514 | Electronic manual gearbox control unit |
| J532 | Voltage stabiliser, behind left B pillar trim |
| SB18 | Fuse -11- in fuse box |
| T10m | 10-pin connector, brown, connector point under relay carrier |
| T12 | 12-pin connector |
| T16 | 16-pin connector, in dash panel centre, self-diagnosis connection |
| T68 | 68-pin connector |
| 249 | Earth connection -2-, in interior wiring harness |
| A76 | Connection (diagnosis wire K), in dash panel wiring harness |
| B135 | Connection -1- (15a), in interior wiring harness |
| B151 | Positive (+) connection -3- (30a), in interior wiring harness |
| B245 | Stabilised positive (+) connection (15a), in interior wiring harness |
| B246 | Stabilised positive (+) connection (30a), in interior wiring harness |
Wiring Diagram VW LUPO 2001 - Dash panel insert - speedometer - odometer display
| G21 | Speedometer |
| G22 | Speedometer sender, in gearbox |
| J248 | Diesel direct injection system control unit |
| J285 | Control unit with display in dash panel insert |
| J514 | Electronic manual gearbox control unit |
| J533 | Data bus diagnostic interface, in dash panel insert |
| SB16 | Fuse -16- in fuse box |
| SB27 | Fuse -27- in fuse box |
| T8d | 8-pin connector, in engine compartment, left |
| T10b | 10-pin connector, black, connector point under relay carrier |
| T10s | 10-pin connector, green, connector point under relay carrier |
| T32 | 32-pin connector, blue |
| T32a | 32-pin connector, green |
| T68 | 68-pin connector |
| T121 | 121-pin connector |
| Y4 | Odometer display |
| A76 | Connection (diagnosis wire K), in dash panel wiring harness |
| A121 | Connection (high bus), in dash panel wiring harness |
| A122 | Connection (low bus), in dash panel wiring harness |
| B6 | Connection (S), in steering column switch wiring harness |
| B135 | Connection -1- (15a), in interior wiring harness |
Wiring Diagram VW LUPO 2001 - Dash panel insert - tailgate/boot lid open warning lamp - rev. counter - digital clock - warning buzzer - alternator warning lamp
| C | Alternator |
| G5 | Rev. counter |
| H3 | Warning buzzer |
| J248 | Diesel direct injection system control unit |
| J285 | Control unit with display in dash panel insert |
| J514 | Electronic manual gearbox control unit |
| K2 | Alternator warning lamp |
| K105 | Reserve fuel warning lamp |
| K127 | Tailgate/boot lid open warning lamp |
| L75 | Digital display illumination |
| T5d | 5-pin connector, in rear lid pre-wiring wiring harness |
| T10c | 10-pin connector, blue, connector point under relay carrier |
| T10d | 10-pin connector, red, connector point under relay carrier |
| T14 | 14-pin connector, in engine compartment, left |
| T32 | 32-pin connector, blue |
| T68 | 68-pin connector |
| T121 | 121-pin connector |
| Y2 | Digital clock |
| 120 | Earth connection -2-, in headlight wiring harness |
| A27 | Connection (speed signal), in dash panel wiring harness |
| * | Speed signal from engine control unit |
Wiring Diagram VW LUPO 2001 - Dash panel insert - brake system warning lamp - main beam warning lamp - brake fluid level warning contact - rear fog light warning lamp - turn signal warning lamps
| F9 | Handbrake warning switch |
| F34 | Brake fluid level warning contact |
| J29 | Diode |
| J285 | Control unit with display in dash panel insert |
| K1 | Main beam warning lamp |
| K13 | Rear fog light warning lamp |
| K65 | Left turn signal warning lamp |
| K94 | Right turn signal warning lamp |
| K118 | Brake system warning lamp |
| T10b | 10-pin connector, black, connector point under relay carrier |
| T32 | 32-pin connector, blue |
| 76 | Earth point, near selector mechanism |
| 81 | Earth connection -1-, in dash panel wiring harness |
| A5 | Positive (+) connection (right turn signal), in dash panel wiring harness |
| A6 | Positive (+) connection (left turn signal), in dash panel wiring harness |
| A59 | Connection (sender), in instruments wiring harness |
| A88 | Connection (RFL), in dash panel wiring harness |
Wiring Diagram VW LUPO 2001 - Handbrake warning lamp control unit - handbrake warning lamp - cigarette lighter
| F259 | Selector lever detector switch for stopped |
| J514 | Electronic manual gearbox control unit |
| J534 | Handbrake warning lamp control unit, on relay carrier |
| K14 | Handbrake warning lamp |
| L28 | Cigarette lighter light bulb |
| SB21 | Fuse -21- in fuse box |
| SB25 | Fuse -25- in fuse box |
| SB46 | Fuse -46- in fuse box |
| T5a | 5-pin connector |
| T10t | 10-pin connector, violet, connector point under relay carrier |
| T10m | 10-pin connector, brown, connector point under relay carrier |
| T68 | 68-pin connector |
| U1 | Cigarette lighter |
| 76 | Earth point, near selector mechanism |
| 81 | Earth connection, in front left interior wiring harness |
| 278 | Earth connection -4-, in interior wiring harness |
| A59 | Connection (sender), in instruments wiring harness |
| A115 | Connection (Handbrake warning), in dash panel wiring harness |
| B102 | Earth connection, in front left interior wiring harness |
Wiring Diagram VW LUPO 2001 - Hazard warning light switch - turn signal relay - front turn signals
| E3 | Hazard warning light switch |
| J1 | Turn signal relay |
| K6 | Hazard warning light system warning lamp |
| M5 | Turn signal bulb, front left |
| M7 | Turn signal bulb, front right |
| M18 | Side turn signal bulb, left |
| M19 | Side turn signal bulb, right |
| SB7 | Fuse -7- in fuse box |
| SB14 | Fuse -14- in fuse box |
| T7a | 7-pin connector, on turn signal relay |
| T10b | 10-pin connector, black, connector point under relay carrier |
| T10c | 10-pin connector, blue, connector point under relay carrier |
| 131 | Earth connection -2-, in engine compartment wiring harness |
| 278 | Earth connection -4-, in interior wiring harness |
| A5 | Positive (+) connection (right turn signal), in dash panel wiring harness |
| A6 | Positive (+) connection (left turn signal), in dash panel wiring harness |
Wiring Diagram VW LUPO 2001 - Turn signal switch - headlight dipper/flasher switch - parking light switch - headlight front left
| E2 | Turn signal switch |
| E4 | Headlight dipper/flasher switch |
| E19 | Parking light switch |
| L1 | Twin filament bulb for headlight, left |
| M1 | Side light bulb, left |
| SB4 | Fuse -4- in fuse box |
| SB13 | Fuse -13- in fuse box |
| SB44 | Fuse -44- in fuse box |
| T5 | 5-pin connector |
| T7 | 7-pin connector |
| T8e | 8-pin connector, on headlight, left |
| T10c | 10-pin connector, blue, connector point under relay carrier |
| 119 | Earth connection -1-, in headlight wiring harness |
| 131 | Earth connection -2-, in engine compartment wiring harness |
| A5 | Positive (+) connection (right turn signal), in dash panel wiring harness |
| A6 | Positive (+) connection (left turn signal), in dash panel wiring harness |
| B167 | Connection (56b), in interior wiring harness |
Wiring Diagram VW LUPO 2001 - Right headlight front - headlight range control
| L2 | Twin filament bulb for headlight, right |
| M3 | Side light bulb, right |
| SB5 | Fuse -5- in fuse box |
| SB12 | Fuse -12- in fuse box |
| SB45 | Fuse -45- in fuse box |
| T8e | 8-pin connector, on headlight, left |
| T8f | 8-pin connector, on headlight, right |
| T10b | 10-pin connector, black, connector point under relay carrier |
| T10c | 10-pin connector, blue, connector point under relay carrier |
| V48 | Headlight range control motor, left |
| V49 | Headlight range control motor, right |
| 119 | Earth connection -1-, in headlight wiring harness |
| 131 | Earth connection -2-, in engine compartment wiring harness |
| A51 | Connection (56), in dash panel wiring harness |
| B247 | Connection -2- (56b), in interior wiring harness |
Wiring Diagram VW LUPO 2001 - Switches and instruments - lighting control - tail light left - brake light left - turn signal rear left - reversing light left - reversing light switch - rear fog light
| E20 | Switches and instruments - lighting control |
| E102 | Headlight range control adjuster |
| F4 | Reversing light switch |
| L46 | Rear fog light bulb, left |
| L54 | Headlight range control adjuster light bulb |
| M6 | Turn signal bulb, rear left |
| M16 | Reversing light bulb, left |
| M21 | Brake and tail light bulb, left |
| SB9 | Fuse -9- in fuse box |
| T6b | 6-pin connector |
| T6d | 6-pin connector |
| T10 | 10-pin connector, white, connector point under relay carrier |
| T10d | 10-pin connector, red, connector point under relay carrier |
| 12 | Earth point, in engine compartment, left |
| 59 | Earth point, near left tail light |
| A5 | Positive (+) connection (right turn signal), in dash panel wiring harness |
| A6 | Positive (+) connection (left turn signal), in dash panel wiring harness |
| A87 | Connection (RL), in dash panel wiring harness |
| B109 | Earth connection, in rear left interior wiring harness |
| W1 | Positive (+) connection (54), in rear wiring harness |
Wiring Diagram VW LUPO 2001 - Tail light right - brake light right - turn signal rear right - reversing light right - brake light switch - high level brake light - number plate light
| F | Brake light switch |
| M8 | Turn signal bulb, rear right |
| M17 | Reversing light bulb, right |
| M22 | Brake and tail light bulb, right |
| M25 | High level brake light bulb (18 LED's) |
| SB2 | Fuse -2- in fuse box |
| SB15 | Fuse -15- in fuse box |
| T6c | 6-pin connector |
| T10 | 10-pin connector, white, connector point under relay carrier |
| X | Number plate light |
| A5 | Positive (+) connection (right turn signal), in dash panel wiring harness |
| A18 | Connection (54), in dash panel wiring harness |
| A52 | Positive (+) connection (30a), in interior wiring harness |
| B109 | Earth connection, in rear left interior wiring harness |
| W1 | Positive (+) connection (54), in rear wiring harness |
| W2 | Positive (+) connection (58), in rear wiring harness |
Wiring Diagram VW LUPO 2001 - Lighting switch
| E1 | Lighting switch |
| E23 | Front and rear fog light switch |
| L9 | Lighting switch light bulb |
| SB43 | Fuse -43- in fuse box |
| T17 | 17-pin connector |
| B145 | Positive (+) connection (58b), in interior wiring harness |
Wiring Diagram VW LUPO 2001 - Interior light front - door contact switch driver's/front passenger's side
| F2 | Door contact switch, driver's side |
| F3 | Door contact switch, front passenger's side |
| J29 | Diode, near connector point left A pillar entwined in wiring harness |
| J514 | Electronic manual gearbox control unit |
| R | Radio |
| SB10 | Fuse -10- in fuse box |
| SB42 | Fuse -42- in fuse box |
| T5x | 5-pin connector, interior light coupling point |
| T8 | 8-pin connector, on radio |
| T10e | 10-pin connector, black, connector point, left A pillar |
| T10f | 10-pin connector, black, connector point, right A pillar |
| T10m | 10-pin connector, brown, connector point under relay carrier |
| T68 | 68-pin connector |
| W | Interior light, front |
| 59 | Earth point, near left tail light |
| 277 | Earth connection -3-, in interior wiring harness |
| B154 | Connection -1- (DC), in interior wiring harness |
Wiring Diagram VW LUPO 2001 - Immobilizer - horn plate - horn
| D2 | Immobilizer reading coil |
| H | Horn plate |
| H1 | Horn |
| J248 | Diesel direct injection system control unit |
| J362 | Immobilizer control unit, behind the dash panel, left |
| SB19 | Fuse -19- in fuse box |
| SB28 | Fuse -28- in fuse box |
| SB29 | Fuse -29- in fuse box |
| SB33 | Fuse -33- in fuse box |
| T3 | 3-pin connector |
| T7 | 7-pin connector |
| T10 | 10-pin connector, white, connector point under relay carrier |
| T10d | 10-pin connector, red, connector point under relay carrier |
| T10k | 10-pin connector, black, on immobilizer control unit |
| T121 | 121-pin connector |
| 76 | Earth point, near selector mechanism |
| A15 | Positive (+) connection (15), in instruments wiring harness |
| A20 | Connection (15a), in dash panel wiring harness |
| B149 | Positive (+) connection -2- (15a), in interior wiring harness |
Wiring Diagram VW LUPO 2001 - Heated rear window switch - heated rear window
| E15 | Heated rear window switch |
| E165 | Tailgate/boot lid release switch |
| J511 | Consumer switch-off relay, on relay carrier |
| J514 | Electronic manual gearbox control unit |
| K10 | Heated rear window warning lamp |
| L39 | Heated rear window switch bulb |
| SB48 | Fuse -48- in fuse box |
| T3a | 3-pin connector |
| T5c | 5-pin connector, in rear lid pre-wiring wiring harness |
| T5f | 5-pin connector, in tailgate/boot lid |
| T6 | 6-pin connector |
| T10t | 10-pin connector, violet, connector point under relay carrier |
| T68 | 68-pin connector |
| Z1 | Heated rear window |
| 59 | Earth point, near left tail light |
| 98 | Earth connection, in tailgate/boot lid wiring harness |
| 218 | Earth connection -1-, in tailgate/boot lid wiring harness |
| A20 | Connection (15a), in dash panel wiring harness |
| A34 | Connection (75x), in dash panel wiring harness |
| B173 | Positive (+) connection -2- (X), in interior wiring harness |
Wiring Diagram VW LUPO 2001 - Fresh air blower switch - fresh air/air recirculating flap switch - fresh air blower - fresh/recirculating air flap control motor
| E9 | Fresh air blower switch |
| E159 | Fresh air/air recirculating flap switch |
| K114 | Fresh air/air recirculation warning lamp |
| L16 | Fresh air controls light bulb |
| N24 | Fresh air blower with overheating fuse series resistor |
| SB26 | Fuse -26- in fuse box |
| SB49 | Fuse -49- in fuse box |
| T4 | 4-pin connector, behind dash panel, centre |
| T4e | 4-pin connector |
| T6a | 6-pin connector |
| T8g | 8-pin connector |
| V2 | Fresh air blower |
| V154 | Fresh/recirculating air flap control motor |
| 76 | Earth point, near selector mechanism |
| 162 | Earth connection, in blower motor wiring harness |
Wiring Diagram VW LUPO 2001 - Intermittent wiper switch - rear wiper switch - automatic intermittent wash/wipe relay - windscreen wiper motor - windscreen and rear window washer pump
| E22 | Intermittent wiper switch |
| E34 | Rear wiper switch |
| J31 | Automatic intermittent wash/wipe relay, on relay plate |
| SB50 | Fuse -50- in fuse box |
| T4a | 4-pin connector |
| T5e | 5-pin connector |
| T5i | 5-pin connector |
| T10 | 10-pin connector, white, connector point under relay carrier¹) |
| T10b | 10-pin connector, black, connector point under relay carrier¹) |
| V | Windscreen wiper motor |
| V59 | Windscreen and rear window washer pump |
| A36 | Connection (75a), in dash panel wiring harness |
| A155 | Connection -2- (86), in dash panel wiring harness |
Wiring Diagram VW LUPO 2001 - Rear window wiper motor - heater elements for washer jets - fog light
| L22 | Fog light bulb, left |
| L23 | Fog light bulb, right |
| SB6 | Fuse -6- in fuse box |
| T2 | 2-pin connector, black, in plenum chamber, left |
| T2a | 2-pin connector, black, on bonnet, left |
| T2b | 2-pin connector, black, on bonnet, right |
| T5c | 5-pin connector, in rear lid pre-wiring wiring harness |
| T5f | 5-pin connector, in tailgate/boot lid |
| T10b | 10-pin connector, red, connector point under relay carrier |
| V12 | Rear window wiper motor |
| Z20 | Heater element, left washer jet |
| Z21 | Heater element, right washer jet |
| D59 | Connection (fog light), in engine compartment wiring harness |
Can't find your car? Check -> DiagnostData.com!
Русский
