| D | Ignition/starter switch |
| E1 | Light switch |
| G85 | Steering angle sender |
| J285 | Control unit with display in dash panel insert |
| J532 | Voltage stabiliser |
| R | Radio |
| SB11 | Fuse 11 on fuse holder |
| SB16 | Fuse 16 on fuse holder |
| SB42 | Fuse 42 on fuse holder |
| T6 | 6-pin connector |
| T8 | 8-pin connector |
| T12 | 12-pin connector |
| T16 | 16-pin connector, self-diagnosis connection |
| T17 | 17-pin connector |
| T32 | 32-pin connector, blue |
| 76 | Earth point, near selector mechanism |
| A27 | Connection (speed signal), in dash panel wiring harness |
| A76 | Connection (K-diagnosis wire), in dash panel wiring harness |
| B6 | Connection (s), in steering column switch wiring harness |
| B102 | Earth connection, in front left interior wiring harness |
| B145 | Positive connection (58b), in interior wiring harness |
| B246 | Positive connection (30a, stabilised), in interior wiring harness |
| B262 | Positive connection 2 (30a, stabilised), in interior wiring harness |
| R | Radio |
| R2 | Front left loudspeaker |
| R3 | Front right loudspeaker |
| R11 | Aerial |
| R20 | Front left treble loudspeaker in door |
| R22 | Front right treble loudspeaker, in door |
| R24 | Aerial amplifier |
| T1 | Single connector, near roof aerial |
| T8 | 8-pin connector, on radio |
| T8a | 8-pin connector, on radio |
| T10e | 10-pin connector, black, left A-pillar coupling station |
| T10f | 10-pin connector, black, right A-pillar coupling station |
| T18 | 18-pin connector, VDA connection, under front passenger seat |
| T20 | 20-pin connector, on radio |
| V7 | Connection (front left loudspeaker, positive), in loudspeaker wiring harness |
| V8 | Connection (front left loudspeaker, negative), in loudspeaker wiring harness |
| V9 | Connection (front right loudspeaker, positive), in loudspeaker wiring harness |
| V10 | Connection (front right loudspeaker, negative), in loudspeaker wiring harness |
| R | Radio |
| R14 | Rear left treble loudspeaker |
| R15 | Rear left bass loudspeaker |
| R16 | Rear right treble loudspeaker |
| R17 | Rear right bass loudspeaker |
| T8a | 8-pin connector |
| V17 | Connection (rear left loudspeaker, positive), in loudspeaker wiring harness |
| V18 | Connection (rear left loudspeaker, negative), in loudspeaker wiring harness |
| V19 | Connection (rear right loudspeaker, positive), in loudspeaker wiring harness |
| V20 | Connection (rear right loudspeaker, negative), in loudspeaker wiring harness |
