Wiring Diagram VW LUPO 2001 - Alternator - starter
| A | Battery |
| B | Starter |
| C | Alternator |
| C1 | Voltage regulator |
| J53 | Starter motor relay |
| J59 | X-contact relief relay |
| J514 | Electronic manual gearbox control unit |
| J532 | Voltage stabiliser |
| SA1 | Fuse 1 on battery fuse holder |
| SA2 | Fuse 2 on battery fuse holder |
| SA3 | Fuse 3 on battery fuse holder |
| SA4 | Fuse 4 on battery fuse holder |
| SB33 | Fuse 33 on fuse holder |
| T10d | 10-pin connector, red, coupling station under relay carrier |
| T10i | 10-pin connector, green, coupling station under relay carrier |
| T10m | 10-pin connector, brown, coupling station under relay carrier |
| T12 | 12-pin connector |
| T14 | 14-pin connector, on left in engine compartment |
| T68 | 68-pin connector |
| 500 | Screw connection 1 (30), on relay plate |
| 501 | Screw connection 2 (30), on relay plate |
| 502 | Screw connection 1 (30a), on relay plate |
| A20 | Positive connection (15a), in dash panel wiring harness |
| A32 | Positive connection (30), in dash panel wiring harness |
| B111 | Positive connection 1 (30a), in interior wiring harness |
| B150 | Positive connection 2 (30a), in interior wiring harness |
Wiring Diagram VW LUPO 2001 - Diesel direct injection system control unit - terminal 30 voltage supply relay - accelerator position sender - kickdown switch - idling speed switch
| F8 | Kickdown switch |
| F60 | Idling speed switch |
| G79 | Accelerator position sender |
| J248 | Diesel direct injection system control unit, centre in plenum chamber |
| J317 | Terminal 30 voltage supply relay, on relay carrier |
| SB23 | Fuse 23 on fuse holder |
| SB37 | Fuse 37 on fuse holder |
| T6c | 6-pin connector, on left under dash panel |
| T10d | 10-pin connector, red, coupling station under relay carrier |
| T10i | 10-pin connector, green, coupling station under relay carrier |
| T121 | 121-pin connector |
| A32 | Positive connection (30), in dash panel wiring harness |
| F25 | Connection 1, in diesel direct injection system wiring harness |
Wiring Diagram VW LUPO 2001 - Diesel direct injection system control unit - engine speed sender - coolant temperature sender - intake manifold pressure sender - intake manifold temperature sender - immobilizer control unit
| G2 | Coolant temperature sender |
| G28 | Engine speed sender |
| G62 | Coolant temperature sender |
| G71 | Intake manifold pressure sender |
| G72 | Intake manifold temperature sender |
| J248 | Diesel direct injection system control unit, centre in plenum chamber |
| J362 | Immobilizer control unit, on left behind dash panel |
| T3g | 3-pin connector, on front of engine |
| T8b | 8-pin connector |
| T10d | 10-pin connector, red, coupling station under relay carrier |
| T10i | 10-pin connector, green, coupling station under relay carrier |
| T14 | 14-pin connector, on left in engine compartment |
| T121 | 121-pin connector |
| 10 | Earth point, in plenum chamber |
| F27 | Connection (screening), in diesel direct injection wiring harness |
| * | Not with all levels of equipment |
Wiring Diagram VW LUPO 2001 - Diesel direct injection system control unit - unit injector valves - Hall sender (camshaft position sender)
| F268 | Auxiliary heating heater element contact switch |
| G40 | Hall sender (for camshaft position) |
| J248 | Diesel direct injection system control unit, centre in plenum chamber |
| N240 | Unit injector valve, No. 1 cylinder |
| N241 | Unit injector valve, No. 2 cylinder |
| N242 | Unit injector valve, No. 3 cylinder |
| T3l | 3-pin connector, on front of engine |
| T4 | 4-pin connector, centre behind dash panel |
| T8l | 8-pin connector, on left of cylinder head |
| T10d | 10-pin connector, red, coupling station under relay carrier |
| T10u | 10-pin connector, behind dash panel |
| T121 | 121-pin connector |
| F26 | Connection 2, in diesel direct injection system wiring harness |
| D101 | Connection 1, in engine compartment wiring harness |
Wiring Diagram VW LUPO 2001 - Diesel direct injection system control unit - air mass meter - exhaust gas recirculation valve - charge pressure control solenoid valve - variable intake manifold flap changeover valve
| G70 | Air mass meter |
| J248 | Diesel direct injection system control unit, centre in plenum chamber |
| N18 | Exhaust gas recirculation valve |
| N75 | Charge pressure control solenoid valve |
| N239 | Variable intake manifold flap changeover valve |
| T10i | 10-pin connector, green, coupling station under relay carrier |
| T121 | 121-pin connector |
| F26 | Connection 2, in diesel direct injection system wiring harness |
Wiring Diagram VW LUPO 2001 - Diesel direct injection system control unit - high heat output and low heat output relays - auxiliary heater element
| J248 | Diesel direct injection system control unit, centre in plenum chamber |
| J359 | Low heat output relay, on relay carrier |
| J360 | High heat output relay, on relay carrier |
| S276 | Heater element fuse 1 |
| S277 | Heater element fuse 2 |
| S278 | Heater element fuse 3 |
| T121 | 121-pin connector |
| Z35 | Auxiliary heating heater element |
| A1 | Positive connection (30a), in dash panel wiring harness |
| D98 | Connection (glow plugs), in engine compartment wiring harness |
| F26 | Connection 2, in diesel direct injection system wiring harness |
Wiring Diagram VW LUPO 2001 - Diesel direct injection system control unit - fuel temperature sender - crankcase breather heater element
| G81 | Fuel temperature sender |
| J104 | ABS control unit with EDL |
| J248 | Diesel direct injection system control unit, centre in plenum chamber |
| J514 | Electronic manual gearbox control unit |
| N79 | Crankcase breather heater breather |
| T10s | 10-pin connector, grey, coupling station under relay carrier |
| T25 | 25-pin connector |
| T68 | 68-pin connector |
| T121 | 121-pin connector |
| 12 | Earth point, on left in engine compartment |
| 119 | Earth connection 1, in headlight wiring harness |
| D159 | Connection (high bus), in engine compartment wiring harness |
| D160 | Connection (low bus), in engine compartment wiring harness |
| F26 | Connection 2, in diesel direct injection system wiring harness |
Wiring Diagram VW LUPO 2001 - Diesel direct injection system control unit - brake light switch - brake pedal switch for diesel direct injection system
| F | Brake light switch |
| F47 | Brake pedal switch for diesel direct injection system |
| J234 | Airbag control unit |
| J248 | Diesel direct injection system control unit, centre in plenum chamber |
| J491 | Fuel shut-off control unit for crash |
| J514 | Electronic manual gearbox control unit |
| SB15 | Fuse 15 on fuse holder |
| SB24 | Fuse 24 on fuse holder |
| SB32 | Fuse 32 on fuse holder |
| T10 | 10-pin connector, white, coupling station under relay carrier |
| T10c | 10-pin connector, blue, coupling station under relay carrier |
| T10d | 10-pin connector, red, coupling station under relay carrier |
| T10i | 10-pin connector, green, coupling station under relay carrier |
| T10j | 10-pin connector, yellow, coupling station under relay carrier |
| T68 | 68-pin connector |
| T75 | 75-pin connector |
| T121 | 121-pin connector |
| 76 | Earth point, near selector mechanism |
| A18 | Connection (54), in dash panel wiring harness |
| A27 | Connection (speed signal), in dash panel wiring harness |
| B102 | Earth connection, in front left interior wiring harness |
Wiring Diagram VW LUPO 2001 - Glow plug relay - speedometer sender - oil pressure switch - engine glow plugs
| F1 | Oil pressure switch |
| G22 | Speedometer sender (Hall sender on gearbox) |
| D | Ignition/starter switch |
| SB28 | Fuse 28 on fuse holder |
| SB29 | Fuse 29 on fuse holder |
| J52 | Glow plug relay, on relay carrier |
| T8d | 8-pin connector, on left in engine compartment |
| T10b | 10-pin connector, black, coupling station under relay carrier |
| T10d | 10-pin connector, red, coupling station under relay carrier |
| T10i | 10-pin connector, green, coupling station under relay carrier |
| T14 | 14-pin connector, on left in engine compartment |
| Q6 | Engine glow plugs |
| A2 | Positive connection (15), in dash panel wiring harness |
| A27 | Connection (speed signal), in dash panel wiring harness |
| B149 | Positive connection 2 (15a), in interior wiring harness |
Wiring Diagram VW LUPO 2001 - Dash panel insert - fuel gauge sender - coolant temperature/coolant shortage indicator - optical and acoustic oil pressure warning
| G | Fuel gauge sender |
| G32 | Coolant shortage indicator sender |
| H3 | Warning buzzer |
| J285 | Control unit with display in dash panel insert |
| K3 | Oil pressure warning lamp |
| K28 | Coolant temperature/coolant shortage warning lamp |
| T10b | 10-pin connector, black, coupling station under relay carrier |
| T10c | 10-pin connector, blue, coupling station under relay carrier |
| T10d | 10-pin connector, red, coupling station under relay carrier |
| T14 | 14-pin connector, on left in engine compartment |
| T32 | 32-pin connector, blue |
| 12 | Earth point, on left in engine compartment |
| 120 | Earth connection 2, in headlight wiring harness |
| A27 | Connection (speed signal), in dash panel wiring harness |
Wiring Diagram VW LUPO 2001 - Dash panel insert - coolant temperature display - fuel gauge - rev. counter - speedometer - alternator warning lamp - self-diagnosis connection - data bus diagnostic interface
| K2 | Alternator warning lamp |
| G1 | Fuel gauge |
| G3 | Coolant temperature display |
| G5 | Rev. counter |
| G21 | Speedometer |
| J285 | Control unit with display in dash panel insert |
| J533 | Data bus diagnosis interface, in dash panel insert |
| K29 | Glow period warning lamp |
| K105 | Reserve fuel warning lamp |
| T16 | 16-pin connector, centre in dash panel, self-diagnosis connection |
| T32 | 32-pin connector, blue |
| T32a | 32-pin connector, green |
| A27 | Connection (speed signal), in dash panel wiring harness |
| A76 | Connection (K-diagnosis wire), in dash panel wiring harness |
| A121 | Connection (high bus), in dash panel wiring harness |
| A122 | Connection (low bus), in dash panel wiring harness |
| * | Revolution signal from engine control unit |
