| E9 | Fresh air blower switch |
| L16 | Fresh air control light bulb |
| N24 | Fresh air blower with overheating fuse series resistor |
| T1h | Single connector, on fresh air blower series resistor |
| T2 | 2-pin connector, on fresh air blower switch |
| T4 | 4-pin connector, on fresh air blower switch |
| T6 | 6-pin connector, on fresh air blower switch |
| T8b | 8-pin connector, behind dash panel |
| V2 | Fresh air blower |
| 33 | Earth point, behind dash panel, right |
| 81 | Earth connection -1-, in dash panel wiring harness |
| G | Fuel gauge sender |
| G1 | Fuel gauge |
| G2 | Coolant temperature sender |
| G3 | Coolant temperature gauge |
| H11 | Oil pressure warning buzzer |
| J285 | Control unit with display in dash panel insert |
| K28 | Coolant temperature/coolant shortage warning lamp |
| T1k | Single connector, for seat belt warning |
| T24 | 24-pin connector, on engine left |
| T28 | 28-pin connector, on dash panel insert |
| T28a | 28-pin connector, on engine left |
| * | Only models with diesel engine |
| ** | Only models with petrol engine |
| F2 | Door contact switch, driver's side |
| F3 | Door contact switch, front passenger's side |
| F160 | Door contact switch rear |
| J152 | Warning buzzer for side light, above the relay plate |
| T1c | Single connector, behind dash panel, left |
| T3e | 3-pin connector, behind dash panel, left |
| T5m | 5-pin connector, near right tail light |
| T5o | 5-pin connector, in tailgate/bootlid |
| TV5 | Terminal 15a junction box, above the relay plate |
| W | Interior light, front |
| W13 | Front passenger reading lamp |
| W43 | Rear interior light, luggage compartment |
| 86 | Earth connection -1-, in rear wiring harness |
| 98 | Earth connection, in tailgate/bootlid wiring harness |
| W9 | Positive (+) connection (30), in rear wiring harness |
| W22 | Connection (door contact switch), in rear wiring harness |
| W34 | Connection -2- (door contact switch), in rear wiring harness |
| * | Only models with diesel engines |
| ** | Only models with petrol engine |
| L28 | Cigarette lighter light bulb |
| R | Radio |
| R11 | Aerial |
| T1i | Single connector, behind dash panel |
| T2e | 2-pin connector, behind dash panel, left |
| T2f | 2-pin connector |
| T2g | 2-pin connector |
| T2h | 2-pin connector |
| T2i | 2-pin connector |
| T5a | 2-pin connector, behind dash panel |
| T6b | 6-pin connector, behind dash panel |
| T8 | 8-pin connector, on radio |
| T16 | 16-pin connector, self-diagnosis connection in left lower console |
| TV9 | Terminal 58 junction box, above the relay plate |
| TV14 | Terminal for self-diagnosis, behind relay plate |
| 30 | Earth point -1-, next to relay plate |
| 81 | Earth connection -1-, in wiring harness |
| 86 | Earth connection -1-, in rear wiring harness |
| A3 | Positive (+) connection (58), in dash panel wiring harness |
| E15 | Heated rear window switch |
| H1 | Horn |
| J4 | Dual tone horn relay |
| K10 | Heated rear window warning lamp |
| L39 | Heated rear window switch bulb |
| T2j | 2-pin connector, in engine compartment, front |
| T5m | 5-pin connector, near right tail light |
| Z1 | Heated rear window |
| 129 | Earth connection, in dual tone horn wiring harness |
| 287 | Earth connection, in rear lid pre-wiring wiring harness |
| C13 | Positive (+) connection, in dual tone horn wiring harness |
| E22 | Intermittent wiper switch |
| E34 | Rear wiper switch |
| H | Horn plate |
| J30 | Rear window wiper/washer relay |
| T1f | Single connector, on rear window wiper/washer relay |
| T3c | 3-pin connector, in tailgate/bootlid, near wiper motor |
| T4c | 4-pin connector, behind steering column switch trim |
| T5f | 5-pin connector, behind steering column switch trim |
| T5m | 5-pin connector, near right tail light |
| T5o | 5-pin connector, in tailgate/bootlid |
| T7b | 7-pin connector, behind steering column switch trim |
| V12 | Rear window wiper motor |
| V59 | Windscreen and rear window washer pump |
| 80 | Earth connection -1-, in instruments wiring harness |
| 98 | Earth connection, in tailgate/bootlid wiring harness |
| * | Only Variant |
| E3 | Hazard warning light switch |
| J2 | Hazard warning light relay |
| K6 | Hazard warning light system warning lamp |
| T8c | 8-pin connector, on hazard warning light switch |
| W6 | Glove box light |
| 81 | Earth connection -1-, in dash panel wiring harness |
| A2 | Positive (+) connection (15), in dash panel wiring harness |
| B12 | Connection (49), in steering column switch wiring harness |
| * | Without cigarette lighter |
| ** | With cigarette lighter |
| L1 | Twin filament bulb for headlight, left |
| L2 | Twin filament bulb for headlight, right |
| M1 | Side light bulb, left |
| M3 | Side light bulb, right |
| M5 | Turn signal bulb, front left |
| M7 | Turn signal bulb, front right |
| M18 | Side turn signal bulb, left |
| M19 | Side turn signal bulb, right |
| T3b | 3-pin connector, behind dash panel, left |
| T4a | 4-pin connector, near headlight, left |
| T4b | 4-pin connector, near headlight, right (not fitted on all engine variants) |
| T8d | 8-pin connector, near headlight, right (not fitted on all engine variants) |
| 12 | Earth point, in engine compartment, left |
| 85 | Earth connection -1-, in engine compartment wiring harness |
| 119 | Earth connection -1-, in headlight wiring harness |
| C17 | Connection (56b) -1-, in front lighting wiring harness |
| D57 | Connection (right turn signal), in engine compartment wiring harness |
| D58 | Connection (left turn signal) -1-, in engine compartment wiring harness |
| F | Brake light switch |
| L20 | Rear fog light bulb |
| M6 | Turn signal bulb, rear left |
| M8 | Turn signal bulb, rear right |
| M16 | Reversing light bulb, left |
| M17 | Reversing light bulb, right |
| M21 | Brake and tail light bulb, left |
| M22 | Brake and tail light bulb, right |
| M25 | High level brake light bulb (qty. 10) |
| T5n | 5-pin connector, near left tail light |
| 59 | Earth point, near left tail light |
| 60 | Earth point -2-, near right tail light |
| 87 | Earth connection -2-, in rear wiring harness |
| 287 | Earth connection, in rear lid pre-wiring wiring harness |
| W1 | Positive (+) connection (54), in rear wiring harness |
| E1 | Lighting switch |
| E20 | Switches and instruments, lighting control |
| E23 | Front and rear fog light switch |
| K4 | Side light warning lamp |
| K13 | Rear fog light warning lamp |
| L9 | Lighting switch light bulb |
| T15 | 15-pin connector, on lighting switch |
| A32 | Positive (+) connection (30), in dash panel wiring harness |
| A51 | Positive (+) connection (56), in dash panel wiring harness |
| A88 | Positive (+) connection (rear fog light), in dash panel wiring harness |
| F4 | Reversing light switch |
| T5n | 5-pin connector, near left tail light |
| T5p | 5-pin connector, in tailgate/bootlid |
| X | Number plate light |
| 287 | Earth connection, in rear lid pre-wiring wiring harness |
| 87 | Earth connection -2-, in rear wiring harness |
| 98 | Earth connection, in tailgate/bootlid wiring harness |
| A4 | Positive (+) connection (58b), in dash panel wiring harness |
| W11 | Connection (58), in tailgate/bootlid wiring harness |
| E102 | Headlight range control adjuster |
| T6b | 6-pin connector, behind dash panel |
| T8d | 8-pin connector, near headlight, right |
| V48 | Headlight range control motor, left |
| V49 | Headlight range control motor, right |
| 119 | Earth connection -1-, in headlight wiring harness |
