A | Battery |
B | Starter |
C | Alternator |
C1 | Voltage regulator |
D | Ignition/starter switch |
F18 | Radiator fan thermal switch |
J59 | X-contact relief relay |
SA1 | Fuse -1- (30) on battery fuse holder |
SA2 | Fuse -2- (30) on battery fuse holder |
SA7 | Fuse -7- (30) on battery fuse holder |
T3b | 3-pin connector, on radiator fan |
T4g | 4-pin connector, black |
T5 | 5-pin connector, near starter |
T10a | 10-pin connector, green, coupling station below relay plate |
T10d | 10-pin connector, red, coupling station below relay plate |
V7 | Radiator fan |
1 | Earth strap, battery - body |
12 | Earth point, on left in engine compartment |
167 | Earth connection -4-, in engine compartment wiring harness |
500 | Screw connection -1- (30), on relay plate |
501 | Screw connection -2- (30), on relay plate |
506 | Screw connection -3- (30), on relay plate |
D | Ignition/starter switch |
G28 | Engine speed sender |
J448 | 4AV/4CV (injection system) control unit |
N152 | Ignition transformer |
P | Spark plug connector |
Q | Spark plugs |
SB32 | Fuse -32- on fuse box |
SB34 | Fuse -34- on fuse box |
T4b | 4-pin connector, black |
T5h | 5-pin connector, black, in engine compartment, front left |
T10a | 10-pin connector, green, connector point under relay carrier |
T10c | 10-pin connector, blue, connector point under relay carrier |
T14 | 14-pin connector, black, on cylinder head, left |
T14a | 14-pin connector, brown, on cylinder head, left |
T80 | 80-pin connector |
12 | Earth point, in engine compartment, left |
283 | Earth connection -2-, in engine prewiring wiring harness |
B163 | Connection -1- (15), in interior wiring harness |
B165 | Connection -2- (15), in interior wiring harness |
D101 | Connection -1-, in engine wiring harness |
F60 | Idling switch |
G42 | Intake air temperature sender |
G69 | Throttle valve potentiometer |
G71 | Intake manifold pressure sender |
G88 | Throttle valve positioner potentiometer |
J293 | Radiator fan control unit |
J338 | Throttle valve control unit |
J448 | 4AV/4CV (injection system) control unit |
T8h | 8-pin connector, black |
T14 | 14-pin connector, black, on cylinder head, left |
T14a | 14-pin connector, brown, on cylinder head, left |
T80 | 80-pin connector |
V60 | Throttle valve positioner |
220 | Earth connection (sender earth), in engine wiring harness |
283 | Earth connection -2-, in engine prewiring wiring harness |
* | Only models with air conditioner |
G2 | Coolant temperature sender |
G40 | Hall sender |
G62 | Coolant temperature sender |
G65 | High pressure sender |
J293 | Radiator fan control unit |
J448 | 4AV/4CV (injection system) control unit |
N30 | Injector, cylinder 1 |
N31 | Injector, cylinder 2 |
N32 | Injector, cylinder 3 |
N33 | Injector, cylinder 4 |
SB3 | Fuse -3- on fuse box |
T3 | 3-pin connector, on cylinder head, left |
T5h | 5-pin connector, on cylinder head, left |
T10a | 10-pin connector, green, connector point under relay carrier |
T14 | 14-pin connector, black, on cylinder head, left |
T14a | 14-pin connector, brown, on cylinder head, left |
T80 | 80-pin connector |
10 | Earth point, in plenum chamber |
283 | Earth connection -2-, in engine prewiring wiring harness |
D61 | Connection (air conditioner), in engine compartment wiring harness |
D95 | Connection (injectors), in engine compartment wiring harness |
* | Only models with air conditioner |
G39 | Lambda probe |
J104 | ABS with EDL control unit |
J217 | Automatic gearbox control unit |
J234 | Airbag control unit, behind console |
J362 | Immobilizer control unit |
J448 | 4AV/4CV (injection system) control unit |
N18 | Exhaust gas recirculation valve |
N79 | Heater element (crankcase breather) |
N80 | Activated charcoal filter system solenoid valve 1 |
SB30 | Fuse -30- on fuse box |
T4f | 4-pin connector, black, on cylinder head, left |
T5h | 5-pin connector, black, in engine compartment |
T10 | 10-pin connector, white, connector point under relay carrier |
T10c | 10-pin connector, blue, connector point under relay carrier |
T10d | 10-pin connector, red |
T10s | 10-pin connector, grey |
T14a | 14-pin connector, brown |
T80 | 80-pin connector |
Z19 | Lambda probe heater |
A121 | Connection (high bus), in dash panel wiring harness |
A122 | Connection (low bus), in dash panel wiring harness |
D52 | Positive (+) connection (15a), in engine compartment wiring harness |
G61 | Knock sensor I |
J17 | Fuel pump relay |
J234 | Airbag control unit, behind console |
J448 | 4AV/4CV control unit (injection system) |
SB31 | Fuse -31- on fuse holder |
SB37 | Fuse -37- on fuse holder |
T2 | 2-pin connector, black, in engine compartment |
T10b | 10-pin connector, black, coupling station below relay plate |
T10d | 10-pin connector, red, coupling station below relay plate |
T10x | 10-pin connector, yellow, coupling station below relay plate |
T14 | 14-pin connector, black, on left of cylinder head |
T75 | 75-pin connector |
T80 | 80-pin connector |
W | Front interior light |
76 | Earth point, near selector mechanism |
200 | Earth connection (screening), in engine compartment wiring harness |
A40 | Positive connection -1- (30), in instruments wiring harness |
A125 | Connection (crash signal), in dash panel wiring harness |
B102 | Earth connection, in front left interior wiring harness |
B150 | Positive connection -2- (30a), in interior wiring harness |
* | Applies only when fitted with airbag and central locking |
** | Applies only when fitted with airbag but not central locking |
G | Fuel gauge sender |
G6 | Fuel pump |
G22 | Speedometer sender (Hall sender on gearbox) |
G32 | Coolant shortage indicator sender |
J362 | Immobilizer control unit |
SB1 | Fuse -1- on fuse holder |
SB40 | Fuse -40- on fuse holder |
T5h | 5-pin connector, black |
T10a | 10-pin connector, green, coupling station below relay plate |
T10b | 10-pin connector, black, coupling station below relay plate |
T10d | 10-pin connector, red, coupling station below relay plate |
T14 | 14-pin connector, black, on left of cylinder head |
T14a | 14-pin connector, brown, on left of cylinder head |
10 | Earth point, in plenum chamber |
50 | Earth point, on left in luggage compartment |
201 | Earth connection -5-, in engine compartment wiring harness |
281 | Earth connection -1-, in engine pre-wiring wiring harness |
A99 | Connection -1- (87), in dash panel wiring harness |
B109 | Earth connection, in rear left interior wiring harness |
B149 | Positive connection -2- (15a), in interior wiring harness |
F1 | Oil pressure switch |
G1 | Fuel gauge |
G3 | Coolant temperature gauge |
G5 | Rev. counter |
H11 | Oil pressure warning buzzer |
J285 | Control unit with display in dash panel insert |
K2 | Alternator warning lamp |
K3 | Oil pressure warning lamp |
K28 | Coolant temperature/coolant shortage warning lamp |
K105 | Reserve fuel warning lamp |
T10a | 10-pin connector, green, connector point under relay carrier |
T10d | 10-pin connector, red, connector point under relay carrier |
T14 | 14-pin connector, black, on cylinder head, left |
T32 | 32-pin connector, blue |
A27 | Connection (speed signal), in dash panel wiring harness |
