VW POLO 2013 – Window wash/wipe system and heated rear window . Wiring diagrams, Pin Connector, Location
Wiring Diagram VW POLO 2013 - Battery - Starter - Alternator - Voltage regulator - Onboard supply control unit https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO A Battery B Starter C Alternator C1 Voltage regulator J519 Onboard supply control unit J623 Engine control unit S162 Fuse 1 (30), in battery fuse holder S163 Fuse 2 (30), in battery fuse holder S269 Fuse 11 (30), in battery fuse holder T1e Single connector T2r 2-pin connector, near dual-tone horns T2s 2-pin connector T3c 3-pin connector, on left in engine compartment T6k 6-pin connector, on left in engine compartment T11b 11-pin connector, on left in engine compartment T12a 12-pin connector, on left in engine compartment T18a 18-pin connector
Wiring Diagram VW POLO 2013 - Ignition/starter switch - Onboard supply control unit D Ignition/starter switch E19 Parking light switch J519 Onboard supply control unit T8c 8-pin connector T18a 18-pin connector T41a 41-pin connector B163 Positive connection 1 (15), in interior wiring harness B169 Positive connection 1 (30), in interior wiring harness B172 Positive connection 4 (30), in interior wiring harness B491 Positive connection (75), in interior wiring harness
Wiring Diagram VW POLO 2013 - Intermittent wiper regulator - X-contact relief relay - Onboard supply control unit E38 Intermittent wiper regulator E102 Headlight range control regulator J59 X-contact relief relay J519 Onboard supply control unit T6l 6-pin connector T6o 6-pin connector T16b 16-pin connector T16e 16-pin connector, near relay carrier T18a 18-pin connector T41a 41-pin connector 238 Earth connection 1, in interior wiring harness 249 Earth connection 2, in interior wiring harness 278 Earth connection 4, in interior wiring harness 284 Earth connection 6, in interior wiring harness * Diagnostic connection *2 Squareback *3 Saloon
Wiring Diagram VW POLO 2013 - Onboard supply control unit - Rear window wiper motor - Windscreen and rear window washer pump J519 Onboard supply control unit T2g 2-pin connector T4i 4-pin connector T5g 5-pin connector, behind rear left side trim, near wheel arch T5h 5-pin connector, in rear lid T5i 5-pin connector, in rear lid T12a 12-pin connector, on left in engine compartment (low box) T18a 18-pin connector V12 Rear window wiper motor V59 Windscreen and rear window washer pump 98 Earth connection, in rear lid wiring harness 287 Earth connection, in rear lid feeder wiring harness B498 Connection 1 (53c), in interior wiring harness B605 Connection 1, in interior wiring harness * Squareback *2 Saloon
Wiring Diagram VW POLO 2013 - Heated rear window button - Onboard supply control unit - Heated rear window switch illumination bulb - Heated rear window E229 Hazard warning lights button E230 Heated rear window button J519 Onboard supply control unit L39 Heated rear window switch illumination bulb T1m Single connector T1n Single connector T5d 5-pin connector T5f 5-pin connector T5g 5-pin connector, behind rear left side trim, near wheel arch T5i 5-pin connector, in rear lid T6c 6-pin connector T6d 6-pin connector T6e 6-pin connector Z1 Heated rear window 279 Earth connection 5, in interior wiring harness 285 Earth connection 7, in interior wiring harness 299 Earth connection 14, in interior wiring harness B180 Connection (heated rear window), in interior wiring harness * Saloon
Wiring Diagram VW POLO 2013 - Onboard supply control unit - Windscreen wiper motor E102 Headlight range control regulator J519 Onboard supply control unit T4o 4-pin connector T5d 5-pin connector T5f 5-pin connector T6c 6-pin connector T6g 6-pin connector, on left in engine compartment T6l 6-pin connector T12a 12-pin connector, on left in engine compartment T16b 16-pin connector T16e 16-pin connector, near relay carrier T18a 18-pin connector V Windscreen wiper motor 296 Earth connection 11, in interior wiring harness B116 Connection (58d), in interior wiring harness B159 Connection (diagnosis), in interior wiring harness B165 Positive connection 2 (15), in interior wiring harness B492 Positive connection 3 (15), in interior wiring harness * Diagnostic connection
Wiring Diagram VW POLO 2013 - Onboard supply control unit J519 Onboard supply control unit SA1 Fuse 1 in fuse holder A SA10 Fuse 10 in fuse holder A SA16 Fuse 16 in fuse holder A SA20 Fuse 20 in fuse holder A SA26 Fuse 26 in fuse holder A SA29 Fuse 29 in fuse holder A T16e 16-pin connector, near relay carrier T18a 18-pin connector B162 Connection (75a), in interior wiring harness B188 Positive connection 5 (30), in interior wiring harness B231 Positive connection 5 (30a), in interior wiring harness B493 Connection (75x), in interior wiring harness * Diagnostic connection
Wiring Diagram VW POLO 2013 - Control unit in dash panel insert - Onboard supply control unit - Dash panel insert VW POLO 2013 Engine control unit J623 – Next to the battery-Arrow-
A - Engine control unit -J623-
B/C - 80-pin connector, in the engine control unit -T80a-
– In the lower left-side of the engine compartment -Arrow-
A - Radiator fan control unit -J293-
B - 6-pin connector in the radiator fan control unit -T6ak-
C - 4-pin connector in the radiator fan control unit -T4aa-
– In the centre of the engine compartment-Arrow-
A - Automatic gearbox control unit -J217-
B/C - 80-pin connector, in the automatic gearbox control unit -T80b-
– In the centre panel, below the radio system-Arrow-
A - Air conditioning control unit -J301-
B - 5-pin connector in the Air conditioning control unit -T5l/T5m-
C - 16-pin connector in the Air conditioning control unit -T16c-
D - 2-pin connector in the Air conditioning control unit -T2bo-
– In the centre panel, below the radio system-Arrow-
A - Climatronic control unit -J255-
B - 20-pin connector, in the Climatronic control unit -T20a-
C - 12-pin connector, in the Climatronic control unit -T12j-
D - 16-pin connector, in the Climatronic control unit -T16g-
– Next to the steering column-Arrow-
A - Central control unit for convenience system -J393-
B - 12-pin connector in the central control unit for convenience system -T12b-
C - 23-pin connector in the central control unit for convenience system -T23a-
D - 12-pin connector in the central control unit for convenience system -T12c-
– To the left of the steering wheel-Arrow-
A - Multifunction steering wheel control unit -E221-
B - 6-pin connector in the multifunction steering wheel control unit -T6be-
– To the left of the dash panel-Arrow-
A - Instrument cluster indicator control unit -J285-
B - 32-pin connector, in the control unit with instrument cluster indicator -T32a-
1 - Immobilizer reading coil
7 - CAN-bus "Low" Terminal
8 - CAN-bus "High" Terminal
9 - CAN-bus "High" Terminal - convenience -
10 - CAN-bus "Low" Terminal - convenience -
11 - Parking light switch
- Turn light/flashing light switch
- Manual switch for headlights/low beams and headlight flashing
- Windscreen wiper delay relay switch (intermittent operation)
- Multifunction indicator call button
12 - Parking light switch
- Turn light/flashing light switch
- Manual switch for headlights/low beams and headlight flashing
- Windscreen wiper delay relay switch (intermittent operation)
- Multifunction indicator call button
16 - Low coolant level indicator sensor
17 - Immobilizer reading coil
20 - Front left seat belt switch
21 - Handbrake control switch
22 - Oil level warning contact
24 - Onboard electric network control unit
27 - Parking light switch
- Turn light/flashing light switch
- Manual switch for headlights/low beams and headlight flashing
- Windscreen wiper delay relay switch (intermittent operation)
- Multifunction indicator call button
30 - Window washing water level sensor
31 - External temperature sensor, sensor earth point
C - 8-pin connector, in the control unit with instrument cluster indicator -T8a-
1 - Brake pad wearing indicator
4 - Terminal 58R, right parking light
6 - Terminal 58L, left parking light
– Under the centre console-Arrow-
A - Airbag control unit -J234-
B - 50-pin connector in the airbag control unit -T50a-
– To the right of the engine compartment-Arrow-
A - ABS control unit -J104-
B - 38-pin connector, in the ABS control unit -T38a-
– Behind the left boot lateral lining-Arrow-
A - Parking assist control unit -J446-
B - 12-pin connector in the parking assist control unit -T12f-
C - 16-pin connector in the parking assist control unit -T16a-
– Behind the right boot lateral lining-Arrow-
A - Parking assist control unit -J446-
B - 12-pin connector in the parking assist control unit -T12f-
C - 16-pin connector in the parking assist control unit -T16a-
– In the air tray, to the centre and the right, next to the glove compartment-Arrow-
A - Air conditioner regulator and control unit -J127-
B - 6-pin connector in the natural air fan control unit -T6al-
– Behind the glove compartment-Arrow-
A - Interactive system control unit -J879-
B - 16-pin connector in the interactive system control unit -T16d-
– Next to the steering column, to the left-Arrow-
A - Cleaning and lighting function control unit -J917-
B - 12-pin connector, in the cleaning and lighting function control unit -T12k-
C - 16-pin connector, in the cleaning and lighting function control unit -T16i-
– To the left of the engine compartment-Arrow-
A - Power steering control unit -J500-
B - 3-pin connector in the driver seat heating control unit -Vazio-
C - 2-pin connector in the driver seat heating control unit -T2ct-
D - 4-pin connector in the driver seat heating control unit -T4ai-
– Next to the internal rear-view mirror, on the ceiling-Arrow-
A - Sunroof movement control unit -J245-
B - 6-pin connector in the sunroof movement control unit -T6bb-
C - 6-pin connector, in the sunroof movement regulator -T6bc-
– In the relay plate, behind the dash board, to the left-Arrow-
A - Mirror memory control unit -J267-
B - 18-pin connector, in the mirror memory control unit -T18c-
– In the relay plate, to the left of the dash board-Arrow-
A - Onboard network control unit -J519-
B - 16-pin connector in the onboard network control unit -T16b-
2 - CAN-bus "Low" Terminal
3 - CAN-bus "Low" Terminal
5 - CAN-bus "High" Terminal
6 - CAN-bus "High" Terminal
7 - Windscreen wiper delay relay switch (intermittent operation)
8 - Windscreen wiper delay relay switch (intermittent operation)
10 - Left turn signal/flashing light switch
11 - Instrument cluster indicator control unit
12 - Turn light/flashing light switch
13 - Contact switch in the engine compartment lid / front lid for the alarm system
C - 6-pin connector in the onboard network control unit -T6q-
2 - Tailgate unlocking switch
5 - Tailgate remote unlocking switch
6 - Tailgate unlocking switch
D - 18-pin connector in the onboard network control unit -T18a-
3 - Rear right central locking unit
4 - Passenger-side central locking unit
6 - Driver-side open door switch
9 - Generator (Alternator)
13 - Rear left central locking unit
16 - Windscreen wiper motor
17 - Horn activator contact ring
18 - Windscreen wiper delay relay
E - 6-pin connector in the onboard network control unit -Vazio-
F - 18-pin connector in the onboard network control unit -T18b-
1 - Terminal 31 - (Only for export vehicles)
- Empty - (Only for Brazil vehicles)
9 - CAN-bus "Low" Terminal - Convenience
12 - CAN-bus "High" Terminal - Convenience
13 - Terminal 31 - (Only for export vehicles)
- Empty - (Only for Brazil vehicles)
G - 6-pin connector in the onboard network control unit -T6c-
3 - Warning switch lighting
4 - Rear window heating system switch
5 - Rear window heating switch light lamp
H - 5-pin connector in the onboard network control unit -T5f-
I - 5-pin connector in the onboard network control unit -T5d-
4 - Windscreen wiper motor
5 - Windscreen wiper motor
J - 6-pin connector in the onboard network control unit -T6t-
1 - Switch to adjust rear-view mirrors
- Switch to adjust rear-view mirrors
2 - External driver-side rear-view mirror defogger
4 - External passenger-side rear-view mirror defogger
K - 6-pin connector in the onboard network control unit -T6m-
L - 6-pin connector in the onboard network control unit -T6u-
5 - Tailgate unlocking motor
– Next to the internal lighting-Arrow-
A - Mirror memory control unit -J347-
B - 8-pin connector, in the mirror memory control unit -T8d-
VW POLO 2013 Ground cable, battery-body-Arrow- VW POLO 2013 Engine compartment earth points Engine compartment earth points
1 Ground cable, battery-body
12 Engine comp. left earth points
29 Earth points next to the ABS control unit
67 Earth point to the left of the front cross strut.
80 Earth point 1 in the dash panel harness
Ground cable, battery-body-Arrow-
Earth points to the left of the engine comp.-Arrow-
Earth points next to the ABS control unit-Arrow-
Earth point to the left of the front cross strut.-Arrow A-
Earth point to the centre of the front cross strut-Arrow B-
Vehicle interior earth points
42 Earth point next to the steering column
606 Earth point under the central console, next to the selector lever
Earth point next to the steering column-Arrow-
Earth point under the central console, next to the selector lever-Arrow-
Earth points in the rear vehicle area (Hatch)
50 Left boot earth points
Left boot earth points-Arrow -
Earth points in the rear vehicle area (Sedan)
51 Right boot earth points
Right boot earth points-Arrow -
VW POLO 2013 Relay plate to the left, behind the dashboard Relay plate to the left, behind the dashboard
2 - Relief relay 2 of contact X -J339-2)
3 - Main relay for electric drive -J437-3)
5 - Starter relay 2 -J695-4)
7 - Cold start device relay -J41-5)
12 - Fuel input relay -J643-
