D | Ignition/starter switch |
F | Brake light switch |
F47 | Brake pedal switch |
J519 | Onboard supply control unit |
SB4 | Fuse 4 on fuse holder B |
SB23 | Fuse 23 on fuse holder B |
SB27 | Fuse 27 on fuse holder B |
SB32 | Fuse 32 on fuse holder B |
T3a | 3-pin connector, grey, on right of bulkhead |
A2 | Positive connection (15), in dash panel wiring harness |
A15 | Positive connection (15), in instrument wiring harness |
A89 | Connection 2 (54) in dash panel wiring harness |
A100 | Connection 2 (87) in dash panel wiring harness |
A104 | Positive connection 2 (15), in dash panel wiring harness |
B170 | Positive connection 2 (30), in interior wiring harness |
* | ⇒ applicable engine Current Flow Diagram |
** | Only models with ESP |
*** | Only models with ABS and TCS |
A | Battery |
J104 | ABS control unit |
J519 | Onboard supply control unit |
S176 | Fuse 4 (30), in battery fuse holder |
S179 | Fuse 7 (30), in battery fuse holder |
S268 | Fuse 10 (30), in battery fuse holder |
T11c | 11-pin connector, blue, on right of bulkhead |
T38 | 38-pin connector |
A89 | Connection 2 (54) in dash panel wiring harness |
D73 | Positive connection (54), in engine compartment wiring harness |
D101 | Connection 1, in engine compartment wiring harness |
G44 | Rear right speed sensor |
G45 | Front right speed sensor |
G46 | Rear left speed sensor |
G47 | Front left speed sensor |
J104 | ABS control unit |
J503 | Control unit with display for radio and navigation |
J519 | Onboard supply control unit |
N99 | Front right ABS inlet valve |
N100 | Front right ABS outlet valve |
N101 | Front left ABS inlet valve |
N102 | Front left ABS outlet valve |
N133 | Rear right ABS inlet valve |
N134 | Rear left ABS inlet valve |
N135 | Rear right ABS outlet valve |
N136 | Rear left ABS outlet valve |
T8 | 8-pin connector |
T8x | 8-pin connector, orange, on right of bulkhead |
T9a | 9-pin connector, yellow, on right of bulkhead |
T38 | 38-pin connector |
J3 | Connection 1, in ABS wiring harness |
J5 | Connection 2, in ABS wiring harness |
J7 | Connection 3, in ABS wiring harness |
J8 | Connection 4, in ABS wiring harness |
* | Only models with navigation system |
G200 | Lateral acceleration sender |
G202 | Yaw rate sender |
G419 | ESP sensor unit |
J104 | ABS control unit |
J106 | ABS solenoid valve relay |
J519 | Onboard supply control unit |
N225 | Vehicle stabilization program switch valve 1 |
N226 | Vehicle stabilization program switch valve 2 |
N227 | Vehicle stabilization program high-pressure valve 1 |
N228 | Vehicle stabilization program high-pressure valve 2 |
T9a | 9-pin connector, yellow, on right of bulkhead |
T38 | 38-pin connector |
V39 | ABS return flow pump |
42 | Earth point, next to steering column |
110 | Earth connection 2, in dash panel wiring harness |
199 | Earth connection 3, in dash panel wiring harness |
439 | Earth connection 3, in dash panel wiring harness |
606 | Earth point, under the centre console near gear stick |
614 | Earth point 2, on right in engine compartment |
* | Only models with ESP |
E20 | Switch and instrument illumination regulator |
E132 | Traction control system switch |
E256 | TCS and ESP button |
E492 | Tyre pressure monitor display button |
J104 | ABS control unit |
J519 | Onboard supply control unit |
L71 | Traction control switch illumination bulb |
L76 | Button illumination bulb |
T8x | 8-pin connector, orange, on right of bulkhead |
T9a | 9-pin connector, yellow, on right of bulkhead |
T38 | 38-pin connector |
110 | Earth connection 2, in dash panel wiring harness |
A4 | Positive connection (58b), in dash panel wiring harness |
A140 | Connection (TCS), in dash panel wiring harness |
* | Depending on vehicle equipment |
G85 | Steering angle sender |
J104 | ABS control unit |
J285 | Control unit in dash panel insert |
J519 | Onboard supply control unit |
K47 | ABS warning lamp |
K155 | ESP and TCS warning lamp |
K220 | Tyre pressure monitor warning lamp |
T8c | 8-pin connector |
T9a | 9-pin connector, yellow, on right of bulkhead |
T11a | 11-pin connector, white, on right of bulkhead |
T16a | 16-pin connector, black |
T32a | 32-pin connector |
T38 | 38-pin connector |
T41 | 41-pin connector |
110 | Earth connection 2, in dash panel wiring harness |
A121 | Connection (high bus), in dash panel wiring harness |
A122 | Connection (low bus), in dash panel wiring harness |
A132 | Connection (TCS/ESP), in dash panel wiring harness |
A140 | Connection (TCS), in dash panel wiring harness |
D159 | Connection (high bus), in engine compartment wiring harness |
D160 | Connection (low bus), in engine compartment wiring harness |
** | Only models with ESP |
*** | Only models with ABS and TCS |
