VW JETTA 2016 – Radio navigation system RNS 315 . Wiring diagrams, Pin Connector, Location

Wiring Diagram VW JETTA 2016 - Fuse 4 in fuse holder A - Fuse holder C

J532	Voltage stabiliser
SA4	Fuse 4 in fuse holder A
SC	Fuse holder C
SC44	Fuse 44 on fuse holder C
SC57	Fuse 57 on fuse holder C
B111	Positive connection 1 (30a), in interior wiring harness
B169	Positive connection 1 (30), in interior wiring harness
B170	Positive connection 2 (30), in interior wiring harness
B188	Positive connection 5 (30), in interior wiring harness
B219	Positive connection 4 (30a), in interior wiring harness
B320	Positive connection 6 (30a) in main wiring harness
V21	Positive connection (30), in radio - amplifier wiring harness
*	Only models with stop/start system
*2	Only models with no start/stop system

J503	Control unit with display for radio and navigation
J519	Onboard supply control unit
J533	Data bus diagnostic interface
R14	Rear left treble loudspeaker
R15	Rear left bass loudspeaker
R20	Front left treble loudspeaker
R21	Front left bass loudspeaker
T8g	8-pin connector
T16d	16-pin connector
T20	20-pin connector
T28	28-pin connector
T28b	28-pin connector
T73b	73-pin connector
A178	Connection (infotainment CAN bus, high), in dash panel wiring harness
A179	Connection (infotainment CAN bus, low), in dash panel wiring harness
A225	Connection 2 (infotainment CAN bus, high) in dash panel wiring harness
A226	Connection 2 (infotainment CAN bus, low) in dash panel wiring harness
B219	Positive connection 4 (30a), in interior wiring harness
B397	Connection 1 (convenience CAN bus, high), in main wiring harness
B406	Connection 1 (convenience CAN bus, low), in main wiring harness
V21	Positive connection (30), in radio - amplifier wiring harness
*	According to equipment
*2	Only models with "High" equipment (AW1)
*3	Only models with "Low" equipment (AW0)

J503	Control unit with display for radio and navigation
R12	Amplifier
R16	Rear right treble loudspeaker
R17	Rear right bass loudspeaker
R22	Front right treble loudspeaker
R23	Front right bass loudspeaker
R38	Telephone microphone
T2k	2-pin connector
T8g	8-pin connector
T12e	12-pin connector
T28a	28-pin connector
T28c	28-pin connector
T38	38-pin connector
*	According to equipment
*2	see applicable current flow diagram for sound system
*3	see applicable current flow diagram for telephone systems

J9	Heated rear window relay
J503	Control unit with display for radio and navigation
RX5	Roof aerial
R11	Aerial
R50	GPS aerial
R93	Radio aerial 2
R108	Left aerial module
R109	Right aerial module
R170	Satellite aerial
R178	Frequency modulation (FM) frequency filter in negative wire
R179	Frequency modulation (FM) frequency filter in positive wire
T5c	5-pin connector
T16d	16-pin connector
Z1	Heated rear window
370	Earth connection 5, in main wiring harness
610	Earth point (audio), front below centre console
681	Earth point 1, in rear right side panel
B180	Connection (heated rear window), in interior wiring harness
*	Only for American markets
*2	According to equipment
*3	Only models with "High" equipment (AW1)
*4	Only models with "Low" equipment (AW0)
