Wiring Diagram VW JETTA 2016 - Fuse 1 in fuse holder A - Fuse 4 in fuse holder A - Fuse 53 on fuse holder C
| A | Battery |
| B | Starter |
| C | Alternator |
| SA | Fuse holder A |
| SA1 | Fuse 1 in fuse holder A |
| SA4 | Fuse 4 in fuse holder A |
| SC53 | Fuse 53 on fuse holder C |
| 508 | Threaded connection (30) on E-box |
| B111 | Positive connection 1 (30a), in interior wiring harness |
| B118 | Connection (driver side seat adjustment), in interior wiring harness |
| B169 | Positive connection 1 (30), in interior wiring harness |
Wiring Diagram VW JETTA 2016 - Driver seat lumbar support adjustment switch - Driver seat lumbar support longitudinal adjustment motor - Driver seat lumbar support height adjustment motor
| E176 | Driver seat lumbar support adjustment switch |
| T4bg | 4-pin connector |
| T4bh | 4-pin connector |
| T4n | 4-pin connector, in driver seat armrest |
| T6ah | 6-pin connector |
| T10c | 10-pin connector, under driver seat |
| V125 | Driver seat lumbar support longitudinal adjustment motor |
| V129 | Driver seat lumbar support height adjustment motor |
| 44 | Earth point, lower part of left A-pillar |
| 96 | Earth connection 1, in seat heating wiring harness |
| * | Only models with seat heating |
| *2 | Only models with no seat heating |
