VW JETTA 2016 – Radio system, (8DM),(8UY) . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW JETTA
  4. >VW JETTA 2016
  5. >VW JETTA 2016 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW JETTA 2016 - Fuse 4 in fuse holder A - Fuse holder C



Wiring Diagram VW JETTA 2016 - Fuse 4 in fuse holder A - Fuse holder C https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
J532 Voltage stabiliser
SA4 Fuse 4 in fuse holder A
SC Fuse holder C
SC44 Fuse 44 on fuse holder C
SC57 Fuse 57 on fuse holder C
  B111 Positive connection 1 (30a), in interior wiring harness
  B169 Positive connection 1 (30), in interior wiring harness
  B170 Positive connection 2 (30), in interior wiring harness
  B188 Positive connection 5 (30), in interior wiring harness
  B219 Positive connection 4 (30a), in interior wiring harness
  B320 Positive connection 6 (30a) in main wiring harness
  V21 Positive connection (30), in radio - amplifier wiring harness
*Only models with stop/start system
*2Only models with no start/stop system

Wiring Diagram VW JETTA 2016 - Onboard supply control unit - Data bus diagnostic interface - Radio



Wiring Diagram VW JETTA 2016 - Onboard supply control unit - Data bus diagnostic interface - Radio https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
J9 Heated rear window relay
J519 Onboard supply control unit
J533 Data bus diagnostic interface
R Radio
T5c 5-pin connector
T16d 16-pin connector
T20 20-pin connector
T73b 73-pin connector
  A178 Connection (infotainment CAN bus, high), in dash panel wiring harness
  A179 Connection (infotainment CAN bus, low), in dash panel wiring harness
  A225 Connection 2 (infotainment CAN bus, high) in dash panel wiring harness
  A226 Connection 2 (infotainment CAN bus, low) in dash panel wiring harness
  B180 Connection (heated rear window), in interior wiring harness
  B219 Positive connection 4 (30a), in interior wiring harness
  B397 Connection 1 (convenience CAN bus, high), in main wiring harness
  B406 Connection 1 (convenience CAN bus, low), in main wiring harness
  V21 Positive connection (30), in radio - amplifier wiring harness
*Only models with "High" equipment (AW1)
*2Only models with "Low" equipment (AW0)

Wiring Diagram VW JETTA 2016 - Radio - Front left treble loudspeaker - Front left bass loudspeaker - Front right treble loudspeaker - Front right bass loudspeaker



Wiring Diagram VW JETTA 2016 - Radio - Front left treble loudspeaker - Front left bass loudspeaker - Front right treble loudspeaker - Front right bass loudspeaker https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
R Radio
R12 Amplifier
R20 Front left treble loudspeaker
R21 Front left bass loudspeaker
R22 Front right treble loudspeaker
R23 Front right bass loudspeaker
T2co 2-pin connector, Interface for front loudspeaker, on left in dash panel
T2cp 2-pin connector, Interface for front loudspeaker, on right in dash panel
T8g 8-pin connector
T28 28-pin connector
T28a 28-pin connector
T38 38-pin connector
  B101 Connection (positive, front left speaker), in main wiring harness
  B102 Connection (negative, front left speaker), in main wiring harness
  B103 Connection (positive, front right speaker), in main wiring harness
  B104 Connection (negative, front right speaker), in main wiring harness
*see applicable current flow diagram for sound system
*2Only models with no sound system
*3Only models with sound system

Wiring Diagram VW JETTA 2016 - Radio - Rear left treble loudspeaker - Rear left bass loudspeaker - Rear right treble loudspeaker - Rear right bass loudspeaker



Wiring Diagram VW JETTA 2016 - Radio - Rear left treble loudspeaker - Rear left bass loudspeaker - Rear right treble loudspeaker - Rear right bass loudspeaker https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
R Radio
R14 Rear left treble loudspeaker
R15 Rear left bass loudspeaker
R16 Rear right treble loudspeaker
R17 Rear right bass loudspeaker
T8g 8-pin connector
T28b 28-pin connector
T28c 28-pin connector
*According to equipment

Wiring Diagram VW JETTA 2016 - Radio - Aerial - Radio aerial 2 - Left aerial module - Right aerial module - Heated rear window



Wiring Diagram VW JETTA 2016 - Radio - Aerial - Radio aerial 2 - Left aerial module - Right aerial module - Heated rear window https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
R Radio
R11 Aerial
R93 Radio aerial 2
R108 Left aerial module
R109 Right aerial module
R178 Frequency modulation (FM) frequency filter in negative wire
R179 Frequency modulation (FM) frequency filter in positive wire
T16d 16-pin connector
Z1 Heated rear window
  370 Earth connection 5, in main wiring harness
  610 Earth point (audio), front below centre console
  681 Earth point 1, in rear right side panel
*According to equipment
