VW JETTA 2016 – Adjustable seat . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >VW
  3. >VW JETTA
  4. >VW JETTA 2016
  5. >VW JETTA 2016 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram VW JETTA 2016 - Fuse holder A



Wiring Diagram VW JETTA 2016 - Fuse holder A https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
A Battery
B Starter
C Alternator
SA1 Fuse 1 in fuse holder A
SA4 Fuse 4 in fuse holder A
S44 Driver seat adjustment thermal fuse 1
SA Fuse holder A
T10c 10-pin connector, under driver seat
  508 Threaded connection (30) on E-box
  B111 Positive connection 1 (30a), in interior wiring harness
  B169 Positive connection 1 (30), in interior wiring harness
  B171 Positive connection 3 (30), in interior wiring harness
  B467 Connection 3, in main wiring harness
  M1 Positive connection 1 (30), in seat adjustment wiring harness

Wiring Diagram VW JETTA 2016 - Seat longitudinal adjustment button - Rake adjustment button - Seat height adjustment button - Backrest adjustment button - Driver seat longitudinal adjustment motor - Driver seat backrest adjustment motor - Driver seat height adjustment motor - Seat rake adjustment motor



Wiring Diagram VW JETTA 2016 - Seat longitudinal adjustment button - Rake adjustment button - Seat height adjustment button - Backrest adjustment button - Driver seat longitudinal adjustment motor - Driver seat backrest adjustment motor - Driver seat height adjustment motor - Seat rake adjustment motor https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
E418 Seat longitudinal adjustment button
E421 Rake adjustment button
E424 Seat height adjustment button
E425 Backrest adjustment button
T4i 4-pin connector
T4o 4-pin connector
T4q 4-pin connector
T4s 4-pin connector
T6g 6-pin connector
T10t 10-pin connector
V28 Driver seat longitudinal adjustment motor
V45 Driver seat backrest adjustment motor
V138 Driver seat height adjustment motor
V231 Seat rake adjustment motor
  96 Earth connection 1, in seat heating wiring harness
  M1 Positive connection 1 (30), in seat adjustment wiring harness

Wiring Diagram VW JETTA 2016 - Backrest adjustment button 2 - Front passenger seat backrest adjustment motor



Wiring Diagram VW JETTA 2016 - Backrest adjustment button 2 - Front passenger seat backrest adjustment motor https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
E796 Backrest adjustment button 2
T4bq 4-pin connector
T6bs 6-pin connector
T8b 8-pin connector
T10c 10-pin connector, under driver seat
T10d 10-pin connector, under front passenger seat
V46 Front passenger seat backrest adjustment motor
  43 Earth point, lower part of right A-pillar
  44 Earth point, lower part of left A-pillar
  96 Earth connection 1, in seat heating wiring harness
  145 Earth connection 3, in seat heating wiring harness
