Wiring Diagram VW E-GOLF 2015 - Rotary light switch - Cigarette lighter - 12 V socket - 12 V socket 2
| EX1 | Rotary light switch |
| SC40 | Fuse 40 on fuse holder C |
| T3ah | 3-pin connector |
| T3ai | 3-pin connector |
| T10h | 10-pin connector |
| U1 | Cigarette lighter, in front centre console |
| U5 | 12 V socket, in front centre console |
| U18 | 12 V socket 2, in luggage compartment |
| 333 | Earth connection 5, in rear wiring harness |
| A19 | Connection (58d), in dash panel wiring harness |
| B680 | Connection (electric socket), in interior wiring harness |
| * | Only left-hand drive models |
| *2 | According to equipment |
| *3 | Only right-hand drive models |
| *4 | From November 2014 |
| *5 | Only for American markets |
VW E-GOLF 2015 Earth points in front part of vehicle
| Earth points in front part of vehicle |
| 12 | Earth point on left in engine compartment |
| q | Specified torque 20 Nm |
| 656 | Earth point on right headlight |
| q | Specified torque 9 Nm |
| 671 | Earth point 1 on front of left longitudinal member |
| q | Specified torque 9 Nm |
| 673 | Earth point 3 on front of left longitudinal member |
| q | Specified torque 9 Nm |
| 717 | Earth point, on front right of cross member |
| q | Specified torque 9 Nm |
| 778 | Earth point for high-voltage heater (PTC) |
| q | Specified torque 9 Nm |
| 779 | Earth point 1 for power and control electronics for electric drive |
| q | Specified torque 9 Nm |
| 803 | Earth point on cross member for driving motor |
| q | Specified torque 20 Nm |
| 18 | Earth point on cylinder block |
| q | Specified torque 9 Nm |
| 672 | Earth point 2 on front of left longitudinal member |
| q | Specified torque 9 Nm |
| 685 | Earth point 1 on front of right longitudinal member |
| q | Specified torque 9 Nm |
| 777 | Earth point for air conditioner compressor |
| q | Specified torque 9 Nm |
| Earth points in middle part of vehicle |
| 43 | Earth point, lower part of right A-pillar |
| q | Specified torque 9 Nm |
| 44 | Earth point on lower part of left A-pillar |
| q | Specified torque 9 Nm |
| 638 | Earth point on right A-pillar |
| q | Specified torque 9 Nm |
| 684 | Earth point on front of left side member |
| q | Specified torque 9 Nm |
| 689 | Earth point, at front, central in roof |
| q | Specified torque 9 Nm |
| 810 | Earth point on central tube for dash panel, centre left |
| q | Specified torque 9 Nm |
| q | Only left-hand drive models |
| 811 | Earth point on central tube for dash panel, centre right |
| q | Specified torque 9 Nm |
| q | Only right-hand drive models |
| 782 | Earth point 1 on high-voltage battery |
| q | Specified torque 10 Nm |
| 783 | Earth point 2, on high-voltage battery |
| q | Specified torque 10 Nm |
| 790 | Earth point, on front left of underbody |
| q | Specified torque 20 Nm |
| 794 | Earth point 1 in high-voltage battery |
| q | Specified torque 9 Nm |
| 795 | Earth point 2 in high-voltage battery |
| q | Specified torque 9 Nm |
| 820 | Earth point 3, on high-voltage battery |
| q | Specified torque 10 Nm |
| 821 | Earth point 4, on high-voltage battery |
| q | Specified torque 10 Nm |
| 822 | Earth point 5, on high-voltage battery |
| q | Specified torque 20 Nm |
| Earth points in rear part of vehicle |
| 62 | Earth point, right C-pillar |
| q | Specified torque 2 Nm |
| 612 | Earth point, at centre on rear lid |
| q | Specified torque 2 Nm |
| 730 | Earth point 1, on right rear wheel housing |
| q | Specified torque 9 Nm |
| 729 | Earth point, on left rear wheel housing |
| q | Specified torque 9 Nm |
| 731 | Earth point 2, on right rear wheel housing |
| q | Specified torque 9 Nm |
| 791 | Earth point on rear right of underbody |
| q | Specified torque 20 Nm |
| 796 | Earth point 3 in high-voltage battery |
| q | Specified torque 9 Nm |
| 813 | Earth point 4 in high-voltage battery |
| q | Specified torque 9 Nm |
| 823 | Earth point 6, on high-voltage battery |
| q | Specified torque 20 Nm |
