VW JETTA NF 2013 – Multifunction steering wheel . Wiring diagrams, Pin Connector, Location

Wiring Diagram VW JETTA NF 2013 - Multifunction buttons on left in steering wheel - Airbag coil connector and return ring with slip ring - Horn plate - Multifunction steering wheel control unit - Fuse 6 on fuse holder C

E440	Multifunction buttons on left in steering wheel
F138	Airbag coil connector and return ring with slip ring
H	Horn plate
J453	Multifunction steering wheel control unit
SC6	Fuse 6 on fuse holder C
T4c	4-pin connector
T12	12-pin connector
T16y	16-pin connector
44	Earth point, lower part of left A-pillar
234	Earth connection in steering column switch wiring harness
367	Earth connection 2, in main wiring harness
605	Earth point, on top end of steering column
B278	Positive connection 2 (15a) in main wiring harness

Wiring Diagram VW JETTA NF 2013 - Multifunction buttons on right in steering wheel - Airbag coil connector and return ring with slip ring - Airbag control unit - Multifunction steering wheel control unit - Onboard supply control unit - Driver side airbag igniter

E441	Multifunction buttons on right in steering wheel
F138	Airbag coil connector and return ring with slip ring
J234	Airbag control unit
J453	Multifunction steering wheel control unit
J519	Onboard supply control unit
N95	Driver side airbag igniter
T4c	4-pin connector
T12	12-pin connector
T16y	16-pin connector
T50	50-pin connector
T73	73-pin connector
T73b	73-pin connector
B528	Connection 1 (LIN bus) in main wiring harness
*	Only models with "High" equipment (AW1)
*2	Only models with "Low" equipment (AW0)
*3	From July 2014
