Wiring Diagram SEAT LEON 2006 - Fresh air blower switch - fresh air and air recirculation flap switch - fresh air and air recirculation warning lamp - fresh air regulator illumination bulb - potentiometer for temperature selection rotary knob
| D | Ignition/starter switch |
| E9 | Fresh air blower switch |
| E159 | Fresh air/air recirculation flap switch |
| J285 | Control unit with display in dash panel insert |
| J361 | Simos control unit |
| G267 | Potentiometer for temperature selection rotary knob |
| K114 | Fresh air and air recirculation warning lamp |
| L16 | Fresh air regulator illumination bulb |
| N24 | Fresh air blower series resistor with overheating fuse |
| V2 | Fresh air blower |
| V154 | Fresh air/recirculated air flap control motor |
| T10v | 10-pin connector, green, in connector protective housing, on left in plenum chamber |
| T10x | 10-pin connector, on air conditioning system |
| |
| 162 | Earth connection, in blower motor wiring harness |
| 503 | Screw connection 2 (75x), on relay plate |
| A2 | Positive connection (15), in dash panel wiring harness |
| A11 | Positive connection (58b), in dash panel wiring harness |
| A20 | Connection (15a), in dash panel wiring harness |
| L48 | Connection (15a), in heater (Thermotronic) operating unit wiring harness |
| L66 | Connection, in heater blower wiring harness |
Wiring Diagram SEAT LEON 2006 - Radiator fan control unit - air conditioning system switch - air conditioning system warning lamp
Wiring Diagram SEAT LEON 2006 - Radiator fan control unit - temperature sender for compressor switch-off - air conditioning system magnetic clutch - radiator fan
| D | Ignition/starter switch |
| G346 | Temperature sender for compressor switch-off |
| J285 | Control unit with display in dash panel insert |
| J293 | Radiator fan control unit |
| N25 | Air conditioning system magnetic coupling |
| V7 | Radiator fan |
| V35 | Right fan for radiator |
| T3b | 3-pin connector, on radiator fan |
| T3c | 3-pin connector, on radiator fan |
| T4l | 4-pin connector, on engine |
| T4m | 4-pin connector, in left engine compartment |
| |
| 193 | Earth connection 1, in coolant fan wiring harness |
| 501 | Screw connection 2 (30), on relay plate |
| A32 | Positive connection (30), in dash panel wiring harness |
| C11 | Connection in radiator fan wiring harness |
| K21 | Connection 1, in radiator fan wiring harness |
Wiring Diagram SEAT LEON 2006 - Radiator fan control unit - radiator fan thermal switch - high pressure sender
SEAT LEON 2006 Overview of coupling station and connections for wiring harness
Overview of coupling station and connections for wiring harness | | | | 1 - | Coupling station in protective housing, in plenum chamber |
| q | With connectors -T10g-, -T10d-, -T10e-, -T10-, -T6l-, -T10h-, |
| 2 - | Coupling station, right B-pillar |
| 3 - | Coupling station on left of C-pillar |
| 4 - | Coupling station on left of A-pillar |
| 5 - | Coupling station in engine compartment, in left wiring harness |
Coupling station in protective housing, in plenum chamber
| 1 - | 10-pin connector -T10g-, grey, automatic gearbox |
| 2 - | 10-pin connector, -T10d-, white, data bus wire, engine control unit, automatic gearbox, Motronic control unit, ABS control unit |
| 3 - | 10-pin connector -T10e-, black, cruise control system, Motronic control unit, engine control unit |
| 4 - | 10-pin connector -T10-, orange, reversing lights, engine control unit, starter, Climatronic control unit, Motronic control unit |
| 5 - | 6-pin connector -T6l-, brown, starter, fuel pump relay, engine control unit |
