SEAT CORDOBA 2002 – Cruise control (CCS), 1.6 l engine Simos/74 kW, engine code letters AUR . Wiring diagrams, Pin Connector, Location

Wiring Diagram SEAT CORDOBA 2002 - Simos control unit - brake light switch - brake pedal switch - clutch pedal switch - cruise control system switch

E45	Cruise control system switch
E227	Cruise control system (CCS) button (Set)
F	Brake light switch
F36	Clutch pedal switch
F63	Brake pedal switch
J361	Simos control unit
J491	Fuel shut-off control unit (Crash)
SB3	Fuse -3- in fuse box
SB20	Fuse -20- in fuse box
TV2	Terminal 30 junction box
T5s	5-pin connector, black, on steering column
T10g	10-pin connector, green, connector point for connector
T10i	10-pin connector, red, connector point for connector
A32	Positive (+) connection (30), in dash panel wiring harness
B163	Positive (+) connection -1- (15), in interior wiring harness
D52	Positive (+) connection (15a), in engine compartment wiring harness
D73	Positive (+) connection (54), in engine compartment wiring harness
D106	Connection -4-, in engine compartment wiring harness
D109	Connection -7-, in engine compartment wiring harness
D118	Connection -16-, in engine compartment wiring harness

Wiring Diagram SEAT CORDOBA 2002 - Simos control unit - accelerator position sender - throttle valve drive (electronic throttle operation)

G79	Accelerator position sender (00777-3131)
G185	Accelerator pedal position sender 2
G186	Throttle valve drive (electronic throttle operation)
G187	Throttle drive angle sender 1 (electronic throttle operation)
G188	Throttle drive angle sender 2 (electronic throttle operation)
J361	Simos control unit
J338	Throttle valve control unit (01165)
T14	14-pin connector, black
T14a	14-pin connector, brown
