SKODA SUPERB II 2008 – Telephone preinstallation 2, As of March 2008 . Wiring diagrams, Pin Connector, Location

Wiring Diagram SKODA SUPERB II 2008 - Mobile telephone operating electronics control unit - telephone microphone - data bus diagnostic interface - fuse holder B on the E box

J412	Mobile telephone operating electronics control unit
J519	Vehicle voltage control unit
J533	Data bus diagnostic interface
R38	Telephone microphone
SB9	Fuse 9 on fuse holder B
T20c	20-pin connector, at data bus diagnostic interface
T40a	40-pin connector, at the E box
T54b	54-pin connector, at mobile telephone operating electronics control unit
477	Earth connection (audio), in main wiring harness
687	Earth point 1 on the middle tunnel
B415	Connection 1 (Infotainment CAN bus, High) in main wiring harness
B421	Connection 1 (Infotainment CAN bus, Low) in main wiring harness

Wiring Diagram SKODA SUPERB II 2008 - Mobile telephone operating electronics control unit - mobile telephone - telephone bracket

J412	Mobile telephone operating electronics control unit
J503	Control unit with display for radio and navigation system
J519	Vehicle voltage control unit
R	Radio
R54	Mobile telephone
R126	Telephone bracket
T12m	12-pin connector, at the telephone bracket
T12n	12-pin connector, at radio (green)
T12o	12-pin connector, on control unit with display for radio and navigation system (green)
T54b	54-pin connector, at mobile telephone operating electronics control unit
477	Earth connection (audio), in main wiring harness
*1	for vehicles with telephone bracket

Wiring Diagram SKODA SUPERB II 2008 - Mobile telephone operating electronics control unit - mobile telephone - telephone bracket - telephone aerial - aerial for Bluetooth

J412	Mobile telephone operating electronics control unit
J519	Vehicle voltage control unit
R54	Mobile telephone
R65	Telephone aerial
R126	Telephone bracket
R152	Aerial for Bluetooth
R216	Roof aerial
*1	for vehicles with telephone bracket
*2	for vehicles without telephone bracket
*3	on certain vehicles, depending upon the type of the mobile telephone operating electronics control unit
