SKODA SUPERB II 2014 – Radio navigation system with TV tuner / radio navigation system with TV tuner and CD changer, (7L6), (L0L), As of May 2011 . Wiring diagrams, Pin Connector, Location

    HomeSKODASKODA SUPERB IISKODA SUPERB II 2014SKODA SUPERB II 2014 ALL WIRING DIAGRAMS - ENGLISH
Download PDF file

Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - fuse holder B on the E box



Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - fuse holder B on the E boxGet access to all wiring diagrams of the carDownload PDF file
J503Control unit with display for radio and navigation system
J519Vehicle voltage control unit
J532Voltage stabiliser
S258Navigation system fuse
SB8Fuse 8 on fuse holder B
T8o8-pin connector, on control unit with display for radio and navigation system (black)
T12r12-pin connector, at voltage stabiliser
T40a40-pin connector, at the E box
  477 Earth connection (audio), in main wiring harness
  687 Earth point 1 on the middle tunnel
  B614 Positive connection 23 (30a) in main wiring harness
  B685 Positive connection 25 (30a) in main wiring harness
*1not valid for 3.6 ltr./191 kW
*2see current flow diagram engine
*3depending on equipment
*4Optional equipement
for vehicles with CD changer

Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - roof aerial



Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - roof aerialGet access to all wiring diagrams of the carDownload PDF file
J503Control unit with display for radio and navigation system
J519Vehicle voltage control unit
R50Navigation system aerial
R65Telephone aerial
R216Roof aerial
*1valid for tailgate
*2valid for Combi
*3only with digital reception
*4Optional equipement

Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - CD changer



Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - CD changerGet access to all wiring diagrams of the carDownload PDF file
J503Control unit with display for radio and navigation system
J519Vehicle voltage control unit
R41CD changer
T12j12-pin connector, at CD changer
T12l12-pin connector, on control unit with display for radio and navigation system (blue)
  A46 Positive connection (30, from radio) in dash panel wiring harness
  V14 Connection (screening), in CD changer wiring harness
for vehicles with CD changer

Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - front loudspeaker - telephone microphone



Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - front loudspeaker - telephone microphoneGet access to all wiring diagrams of the carDownload PDF file
J412Mobile telephone operating electronics control unit
J503Control unit with display for radio and navigation system
J519Vehicle voltage control unit
R20Treble loudspeaker, front left
R21Bass loudspeaker, front left
R22Treble loudspeaker, front right
R23Bass loudspeaker, front right
R38Telephone microphone
T4ba4-pin connector, at bass loudspeaker, front left
T4bb4-pin connector, at bass loudspeaker, front right
T8p8-pin connector, on control unit with display for radio and navigation system (brown)
T12o12-pin connector, on control unit with display for radio and navigation system (green)
T28a28-pin connector, on the left A-pillar
T28b28-pin connector, on the right A-pillar
T54b54-pin connector, at mobile telephone operating electronics control unit
*Optional equipement
for vehicles with telephone preinstallation 2

Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - Rear loudspeaker



Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - Rear loudspeakerGet access to all wiring diagrams of the carDownload PDF file
J503Control unit with display for radio and navigation system
J519Vehicle voltage control unit
J650Multimedia system control unit
R7DVD player
R14Treble loudspeaker, rear left
R15Bass loudspeaker, rear left
R16Treble loudspeaker, rear right
R17Bass loudspeaker, rear right
R199Connection for external audio sources
T4bc4-pin connector, at bass loudspeaker, rear left
T4bd4-pin connector, at bass loudspeaker, rear right
T8p8-pin connector, on control unit with display for radio and navigation system (brown)
T12l12-pin connector, on control unit with display for radio and navigation system (blue)
T28c28-pin connector, on the left B-pillar
T28d28-pin connector, on the right B-pillar
for vehicles with connection for external audio sources / multimedia socket MEDIA-IN / DVD player

Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - TV tuner



Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - TV tunerGet access to all wiring diagrams of the carDownload PDF file
J503Control unit with display for radio and navigation system
J519Vehicle voltage control unit
R78TV tuner
T26c26-pin connector, on control unit with display for radio and navigation system (black)
T54a54-pin connector, on TV tuner
  320 Earth connection (screening 1, TV) in communication wiring harness

Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - TV tuner



Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - TV tunerGet access to all wiring diagrams of the carDownload PDF file
J503Control unit with display for radio and navigation system
J519Vehicle voltage control unit
R78TV tuner
T26c26-pin connector, on control unit with display for radio and navigation system (black)
T54a54-pin connector, on TV tuner

Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - TV tuner



Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - TV tunerGet access to all wiring diagrams of the carDownload PDF file
J503Control unit with display for radio and navigation system
J519Vehicle voltage control unit
R78TV tuner
T54a54-pin connector, on TV tuner
*1valid for tailgate
*2valid for Combi

Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - mobile telephone - telephone bracket



Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - mobile telephone - telephone bracketGet access to all wiring diagrams of the carDownload PDF file
J503Control unit with display for radio and navigation system
J519Vehicle voltage control unit
R54Mobile telephone
R126Telephone bracket
T12m12-pin connector, at the telephone bracket
T26c26-pin connector, on control unit with display for radio and navigation system (black)
*4Optional equipement

Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - mobile telephone - telephone bracket



Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - mobile telephone - telephone bracketGet access to all wiring diagrams of the carDownload PDF file
J503Control unit with display for radio and navigation system
J519Vehicle voltage control unit
R54Mobile telephone
R126Telephone bracket
T12m12-pin connector, at the telephone bracket
T26c26-pin connector, on control unit with display for radio and navigation system (black)
*4Optional equipement

Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - data bus diagnostic interface - dash panel insert



Wiring Diagram SKODA SUPERB II 2014 - Control unit with display for radio and navigation system - data bus diagnostic interface - dash panel insertGet access to all wiring diagrams of the carDownload PDF file
J119Multi-function display
J285Control unit in dash panel insert
J503Control unit with display for radio and navigation system
J519Vehicle voltage control unit
J533Data bus diagnostic interface
KDash panel insert
T8o8-pin connector, on control unit with display for radio and navigation system (black)
T20c20-pin connector, at data bus diagnostic interface
T32a32-pin connector, at dash panel insert
  B415 Connection 1 (Infotainment CAN bus, High) in main wiring harness
  B421 Connection 1 (Infotainment CAN bus, Low) in main wiring harness
  B708 Connection 1 (CAN bus dash panel insert High) in main wiring harness
  B709 Connection 1 (CAN bus dash panel insert Low) in main wiring harness

Wiring Diagram SKODA SUPERB II 2014 - Rear window aerial 1 - left aerial module - right aerial module - frequency filter for frequency modulation (FM) - heated rear window relay - heated rear window - (valid for tailgate)



Wiring Diagram SKODA SUPERB II 2014 - Rear window aerial 1 - left aerial module - right aerial module - frequency filter for frequency modulation (FM) - heated rear window relay - heated rear window - (valid for tailgate)Get access to all wiring diagrams of the carDownload PDF file
J9Heated rear window relay
J519Vehicle voltage control unit
R108Left aerial module
R109Aerial module, right
R130Rear window aerial 1
R178Frequency filter for frequency modulation (FM) in the negative line
R179Frequency filter for frequency modulation (FM) in the positive line
SC25Fuse 25 on fuse holder C
T1a1-pin connector, in luggage compartment, right
T2t2-pin connector in right luggage compartment (beige)
T2u2-pin connector in right luggage compartment (brown)
T2ah2-pin connector in right luggage compartment (black)
T52b52-pin connector, at onboard supply control unit (white)
Z1Heated rear window
  51 Earth point in luggage compartment, right
  B315 Positive connection 1 (30a) in main wiring harness
  B316 Positive connection 2 (30a) in main wiring harness
*3only with digital reception

Wiring Diagram SKODA SUPERB II 2014 - Side window aerial - left aerial module - right aerial module - (valid for Combi)



Wiring Diagram SKODA SUPERB II 2014 - Side window aerial - left aerial module - right aerial module - (valid for Combi)Get access to all wiring diagrams of the carDownload PDF file
J519Vehicle voltage control unit
R108Left aerial module
R109Aerial module, right
R191Side window aerial
T1d1-pin connector, near the roof aerial
*1right
*2left

Wiring Diagram SKODA SUPERB II 2014 - Rear window aerial 1 - right aerial module - frequency filter for frequency modulation (FM) - heated rear window relay - heated rear window - (valid for Combi)



Wiring Diagram SKODA SUPERB II 2014 - Rear window aerial 1 - right aerial module - frequency filter for frequency modulation (FM) - heated rear window relay - heated rear window - (valid for Combi)Get access to all wiring diagrams of the carDownload PDF file
J9Heated rear window relay
J519Vehicle voltage control unit
R109Aerial module, right
R130Rear window aerial 1
R179Frequency filter for frequency modulation (FM) in the positive line
SC25Fuse 25 on fuse holder C
T1a1-pin connector, in luggage compartment, right
T2ah2-pin connector in right luggage compartment (black)
T52b52-pin connector, at onboard supply control unit (white)
Z1Heated rear window
  51 Earth point in luggage compartment, right
  B315 Positive connection 1 (30a) in main wiring harness
  B316 Positive connection 2 (30a) in main wiring harness
*3only with digital reception
