| T6e | 6-pin connector, brown, connector point, electronics box, plenum chamber |
| 43 | Earth point, lower part of right A pillar |
| 44 | Earth point, lower part of left A pillar |
| 83 | Earth connection -1-, in front right wiring harness |
| 85 | Earth connection -1-, in engine compartment wiring harness |
| B100 | Earth connection, in interior wiring harness, front right |
| B102 | Earth connection, in interior wiring harness, front left |
| E104 | Earth connection, in dash panel wiring harness (near relay point) |
| E105 | Earth connection, in dash panel wiring harness, left |
| E113 | Earth connection, in dash panel wiring harness, right |
| A | Battery |
| C | Alternator |
| D | Ignition/starter switch |
| J59 | X contact relief relay |
| S204 | Fuse -1- (30) |
| T2ad | 2-pin connector, black, near alternator, in engine compartment, front right |
| T3as | 3-pin connector, black, in centre console |
| A17 | Connection (61), in dash panel wiring harness |
| A32 | Positive (+) connection (30), in dash panel wiring harness |
| A34 | Connection (75x), in dash panel wiring harness |
| * | Models with manual gearbox |
| ** | Models with automatic gearbox |
| *** | Models with petrol engines and 150 A alternator |
| **** | Models with headlight washer system |
| B | Starter |
| F125 | Multi-function switch |
| J207 | Starter inhibitor relay |
| T2ad | 2-pin connector, black, near alternator, in engine compartment, front right |
| T10 | 10-pin connector, blue, connector point, electronics box, plenum chamber |
| T10d | 10-pin connector, red, connector point, electronics box, plenum chamber |
| T10ab | 10-pin connector, black, on gearbox |
| A86 | Connection (50a), in dash panel wiring harness |
| E100 | Connection (multi-function switch), in dash panel wiring harness |
| * | Models with manual gearbox |
| ** | Models with automatic gearbox |
| *** | Models with petrol engines |
| **** | Models with diesel engines |
| H | Horn plate |
| H2 | High tone horn |
| H7 | Low tone horn |
| J4 | Dual tone horn relay |
| S8 | Fuse in fuse carrier |
| T5b | 5-pin connector, yellow, behind steering column switch trim |
| T10v | 10-pin connector, in bumper, front left |
| 44 | Earth point, lower part of left A pillar |
| 108 | Earth connection -2-, in front left wiring harness |
| 129 | Earth connection, in dual tone horn wiring harness |
| A52 | Positive (+) connection 2 (30), in dash panel wiring harness |
| C13 | Positive (+) connection, in dual tone horn wiring harness |
| E104 | Earth connection, in dash panel wiring harness (near relay point) |
| E105 | Earth connection, in dash panel wiring harness, left |
| C10 | Suppression filter |
| D2 | Immobilizer reading coil |
| J248 | Diesel direct injection system control unit |
| J285 | Control unit with display in dash panel insert |
| K2 | Alternator warning lamp |
| K117 | Immobilizer warning lamp |
| T10e | 10-pin connector, green, footwell, right, at wheelhouse, behind carpet |
| T16 | 16-pin connector, connector plug C at V94 |
| T32 | 32-pin connector, blue, on dash panel insert |
| T32a | 32-pin connector, green, on dash panel insert |
| T32b | 32-pin connector, grey, on dash panel insert |
| V94 | Central locking motor with control unit for interior lights switch-off delay and anti-theft alarm system |
| A27 | Connection (speed signal), in dash panel wiring harness |
| E105 | Earth connection, in dash panel wiring harness, left |
| * | Models with diesel engines |
| F66 | Coolant shortage indicator switch |
| G | Fuel gauge sender |
| G1 | Fuel gauge |
| G6 | Fuel pump (pre-supply pump) |
| G169 | Fuel gauge sender 2 |
| J17 | Fuel pump relay |
| J285 | Control unit with display in dash panel insert |
| K16 | Reserve fuel warning lamp |
| K28 | Coolant temperature/coolant shortage warning lamp |
| S1 | Fuse in fuse carrier |
| T32 | 32-pin connector, blue, on dash panel insert |
| T32b | 32-pin connector, grey, on dash panel insert |
| 49 | Earth point, near fuel pump |
| 82 | Earth connection -1-, in front left wiring harness |
| 269 | Earth connection (sender earth) -1-, in dash panel wiring harness |
| # | Sender earth output |
| F1 | Oil pressure switch |
| F9 | Handbrake warning switch |
| F34 | Brake fluid level warning contact |
| J104 | ABS with EDL control unit |
| J285 | Control unit with display in dash panel insert |
| K3 | Oil pressure warning lamp |
| K14 | Handbrake warning lamp |
| K33 | Brake fluid level warning lamp |
| T10a | 10-pin connector, black, connector point, electronics box, plenum chamber |
| T32 | 32-pin connector, blue, on dash panel insert |
| A124 | Connection (handbrake warning), in dash panel wiring harness |
| E105 | Earth connection, in dash panel wiring harness, left |
| E115 | Earth connection (centre console), in dash panel wiring harness |
| * | Models with 8-cylinder and 12-cylinder engines |
| ** | Models with 6-cylinder engines |
| F140 | Switch: Front left belt |
| G17 | Ambient temperature sensor |
| G106 | Ambient temperature indicator |
| J234 | Airbag control unit |
| J285 | Control unit with display in dash panel insert |
| K18 | Trailer operation warning lamp |
| K65 | Left turn signal warning lamp |
| K75 | Airbag warning lamp |
| K94 | Right turn signal warning lamp |
| K163 | Belt switch warning lamp |
| S1 | Fuse in fuse carrier |
| T10e | 10-pin connector, green, footwell, right, at wheelhouse, behind carpet |
| T32 | 32-pin connector, blue, on dash panel insert |
| T32a | 32-pin connector, green, on dash panel insert |
| 269 | Earth connection (sender earth) -1-, in dash panel wiring harness |
| B102 | Earth connection, in interior wiring harness, front left |
| E103 | Connection (15a), in dash panel wiring harness, right |
| * | Models with trailer coupling |
| ** | Models with belt warning |
| F129 | Air conditioner pressure switch |
| J135 | Radiator fan 3rd speed relay |
| J285 | Control unit with display in dash panel insert |
| K32 | Brake pad/lining warning lamp |
| N12 | Brake pad/lining wear indicator, right (shear element) |
| N13 | Brake pad/lining wear indicator, left (shear element) |
| T4ad | 4-pin connector, black, in engine compartment, left |
| T4ae | 4-pin connector, black, in engine compartment, right |
| T32 | 32-pin connector, blue, on dash panel insert |
| T32b | 32-pin connector, grey, on dash panel insert |
| 83 | Earth connection -1-, in front right wiring harness |
| C11 | Connection, in radiator fan wiring harness |
| D55 | Connection (brake wear indicator, left), in engine compartment wiring harness |
| * | Models with 6-cylinder and 8-cylinder petrol engines |
| ** | Models with 6-cylinder and 8-cylinder TDI engines and 12-cylinder petrol engines |
| E87 | Control and display unit for air conditioner |
| J285 | Control unit with display in dash panel insert |
| J489 | Radio wave clock receiver |
| L19 | Gear selector light bulb |
| L96 | +/- Display illumination (automatic gearbox) |
| L120 | Shelf illumination |
| L121 | Cup holder illumination |
| L122 | Coin holder illumination |
| T4v | 4-pin connector, black, on dash panel insert |
| T6t | 6-pin connector, red, footwell, right, at wheelhouse, behind carpet |
| T10e | 10-pin connector, green, footwell, right, at wheelhouse, behind carpet |
| T10g | 10-pin connector, black, near selector lever console |
| T32 | 32-pin connector, blue, on dash panel insert |
| T32b | 32-pin connector, grey, on dash panel insert |
| Y2 | Digital clock |
| Y8 | Radio wave controlled clock |
| A37 | Connection (58a), in dash panel wiring harness |
| E115 | Earth connection (centre console), in dash panel wiring harness |
| L11 | Connection -3-, in air conditioner wiring harness |
| * | Models with automatic gearbox |
| ** | Models with radio wave controlled clock |
| E87 | Control and display unit for air conditioner |
| J217 | Automatic gearbox control unit |
| J220 | Motronic control unit |
| J248 | Diesel direct injection system control unit |
| J285 | Control unit with display in dash panel insert |
| J364 | Additional heater control unit |
| J494 | Diesel direct injection system control unit 2 |
| R64 | Auxiliary heating radio wave receiver |
| T6w | 6-pin connector, black, on additional heater control unit |
| T10 | 10-pin connector, blue, connector point, electronics box, plenum chamber |
| T16a | 16-pin connector, diagnosis connection |
| T32a | 32-pin connector, green, on dash panel insert |
| T32b | 32-pin connector, grey, on dash panel insert |
| A76 | Connection (diagnosis wire K), in dash panel wiring harness |
| E105 | Earth connection, in dash panel wiring harness, left |
| * | Models with petrol engines |
| ** | Models with 6-cylinder diesel engines |
| *** | Models with 8-cylinder diesel engines |
| **** | Models with automatic gearbox |
| # | Models with auxiliary heater |
| J104 | ABS with EDL control unit |
| J234 | Airbag control unit |
| J285 | Control unit with display in dash panel insert |
| J401 | Navigation system with CD drive control unit |
| J431 | Headlight range control, control unit |
| J446 | Parking aid control unit |
| J453 | Multi-function steering wheel control unit |
| J502 | Tyre pressure monitor control unit |
| R | Radio |
| T8 | 8-pin connector, black, radio connector III |
| T8n | 8-pin connector, black, on navigation control unit (A) |
| T10e | 10-pin connector, green, footwell, right, at wheelhouse, behind carpet |
| T15 | 15-pin connector, black, in centre console |
| T32 | 32-pin connector, blue, on dash panel insert |
| A76 | Connection (diagnosis wire K), in dash panel wiring harness |
| B159 | Connection (diagnosis), in interior wiring harness |
| V40 | Connection (diagnosis wire K), in communication systems wiring harness |
| * | Models with multi-function steering wheel |
| ** | Models with dynamic headlight range control |
| *** | Models with ultrasonic parking aid |
| # | Models with electrical tyre pressure monitoring |
| ## | Navigation system 'NS Low' |
| G266 | Oil level thermo sender |
| J285 | Control unit with display in dash panel insert |
| K1 | Main beam warning lamp |
| K4 | Side light warning lamp |
| K34 | Brake light warning lamp |
| S8 | Fuse in fuse carrier |
| T3az | 3-pin connector, in engine compartment, front right |
| T10 | 10-pin connector, blue, connector point, electronics box, plenum chamber |
| T10a | 10-pin connector, black, connector point, electronics box, plenum chamber |
| T32 | 32-pin connector, blue, on dash panel insert |
| T32a | 32-pin connector, green, on dash panel insert |
| 83 | Earth connection -1-, in front right wiring harness |
| 85 | Earth connection -1-, in engine compartment wiring harness |
| * | Models with petrol engines (does not apply to 12-cylinder engines) |
| ** | Models with diesel engines |
| *** | Models with 12-cylinder petrol engines (AZC) |
| E87 | Control and display unit for air conditioner |
| E256 | TCS/ESP button |
| G2 | Coolant temperature sender |
| G3 | Coolant temperature gauge |
| G62 | Coolant temperature sender |
| J248 | Diesel direct injection system control unit |
| J285 | Control unit with display in dash panel insert |
| R | Radio |
| T8 | 8-pin connector, black, radio connector III |
| T10a | 10-pin connector, black, connector point, electronics box, plenum chamber |
| T15 | 15-pin connector, black, in centre console |
| T32 | 32-pin connector, blue, on dash panel insert |
| T32b | 32-pin connector, grey, on dash panel insert |
| 269 | Earth connection (sender earth) -1-, in dash panel wiring harness |
| A19 | Connection (58s), in dash panel wiring harness (switch illumination) |
| * | Models with petrol engines |
| ** | Models with 8-cylinder diesel engines |
| E38 | Intermittent wiper control |
| E91 | Function selection switch |
| E92 | Reset button |
| F189 | Tiptronic switch |
| J285 | Control unit with display in dash panel insert |
| K37 | Windscreen washer fluid level warning lamp |
| T5f | 5-pin connector, red, in selector lever console |
| T6i | 6-pin connector, brown, behind steering column switch trim |
| T10g | 10-pin connector, black, near selector lever console |
| T32a | 32-pin connector, green, on dash panel insert |
| T32b | 32-pin connector, grey, on dash panel insert |
| A8 | Positive (+) connection (58d), in dash panel wiring harness (display illumination) |
| E104 | Earth connection, in dash panel wiring harness (near relay point) |
| * | Models with automatic gearbox |
| E272 | Function selection switch II, in centre console |
| J104 | ABS with EDL control unit |
| J285 | Control unit with display in dash panel insert |
| J347 | Ultra-sonic sensor control unit |
| J541 | Coolant shut-off valve relay |
| K47 | ABS warning lamp |
| K86 | Traction control system warning lamp |
| T10s | 10-pin connector, black, footwell, right, at wheelhouse, behind carpet |
| T16 | 16-pin connector, connector plug C at V94 |
| T32a | 32-pin connector, green, on dash panel insert |
| T32b | 32-pin connector, grey, on dash panel insert |
| V94 | Central locking motor with control unit for interior lights switch-off delay and anti-theft alarm system |
| 269 | Earth connection (sender earth) -1-, in dash panel wiring harness |
| A49 | Connection -1-, in dash panel wiring harness |
| S21 | Connection -5-, in central locking wiring harness |
| * | Models with navigation system 'NS Low' |
| ** | Models with telematics |
| # | Does not apply to models for Japan |
| F120 | Anti-theft alarm system contact switch, bonnet |
| F123 | Tailgate/boot lid contact switch for anti-theft alarm |
| G21 | Speedometer |
| G22 | Speedometer sender (Hall sender, on gearbox) |
| J285 | Control unit with display in dash panel insert |
| T10 | 10-pin connector, blue, connector point, electronics box, plenum chamber |
| T10s | 10-pin connector, black, footwell, right, at wheelhouse, behind carpet |
| T16 | 16-pin connector, connector plug C at V94 |
| T32b | 32-pin connector, grey, on dash panel insert |
| V94 | Central locking motor with control unit for interior lights switch-off delay and anti-theft alarm system |
| 85 | Earth connection -1-, in engine compartment wiring harness |
| 98 | Earth connection, in tailgate/boot lid wiring harness |
| 102 | Earth connection, in gearbox wiring harness |
| E113 | Earth connection, in dash panel wiring harness, right |
| S2 | Connection, in central locking wiring harness |
| * | Models with manual gearbox |
| ** | Models with automatic gearbox |
| F2 | Door contact switch, driver's side |
| J285 | Control unit with display in dash panel insert |
| J453 | Multi-function steering wheel control unit |
| T10m | 10-pin connector, grey, footwell, right, at wheelhouse, behind carpet |
| T10s | 10-pin connector, black, footwell, right, at wheelhouse, behind carpet |
| T12 | 12-pin connector, connector plug A at V94 |
| T16 | 16-pin connector, connector plug C at V94 |
| T32 | 32-pin connector, blue, on dash panel insert |
| T32b | 32-pin connector, grey, on dash panel insert |
| V94 | Central locking motor with control unit for interior lights switch-off delay and anti-theft alarm system |
| R3 | Connection (door contact switch, right and left), in electric window/central locking system and door contact switch wiring harness |
| * | Vehicles with multi-function steering wheel, only applies to models equipped with telephone/mobile phone without CAN bus |
| E87 | Control and display unit for air conditioner |
| J285 | Control unit with display in dash panel insert |
| J401 | Navigation system with CD drive control unit |
| J446 | Parking aid control unit |
| R94 | Navigation interface |
| T6ap | 6-pin connector, yellow, on navigation unit |
| T12a | 12-pin connector, on operating electronics control unit, navigation |
| T32a | 32-pin connector, green, on dash panel insert |
| A121 | Connection (high bus), in dash panel wiring harness |
| A122 | Connection (low bus), in dash panel wiring harness |
| A146 | Connection (convenience CAN bus, high), in dash panel wiring harness |
| A147 | Connection (convenience CAN bus, low), in dash panel wiring harness |
| A148 | Connection (navigation CAN bus, high), in dash panel wiring harness |
| A149 | Connection (navigation CAN bus, low), in dash panel wiring harness |
| • | CAN bus (data wire) |
| * | Models with ultra-sonic parking aid system |
| ** | Models with navigation system 'NS Low' |
| *** | Models with radio navigation system (RNS-D) |
| G85 | Steering angle sender |
| J104 | ABS with EDL control unit |
| J220 | Motronic control unit |
| J248 | Diesel direct injection system control unit |
| T10d | 10-pin connector, red, connector point, electronics box, plenum chamber |
| A121 | Connection (high bus), in dash panel wiring harness |
| A122 | Connection (low bus), in dash panel wiring harness |
| • | CAN bus (data wire) |
| * | Models with petrol engines |
| ** | Models with 6-cylinder diesel engines |
| *** | Models with 8-cylinder diesel engines |
| E45 | Cruise control system switch |
| E87 | Control and display unit for air conditioner |
| J402 | Operating electronics control unit, navigation |
| S2 | Fuse in fuse carrier |
| S4 | Fuse in fuse carrier |
| S5 | Fuse in fuse carrier |
| S6 | Fuse in fuse carrier |
| T3as | 3-pin connector, brown, in centre console |
| T6t | 6-pin connector, red, footwell, right, at wheelhouse, behind carpet |
| T26c | 26-pin connector, black, on operating electronics control unit, navigation |
| A2 | Positive (+) connection (15), in dash panel wiring harness |
| A74 | Connection (15a, fuse 6), in dash panel wiring harness |
| B163 | Positive (+) connection -1- (15), in interior wiring harness |
| E114 | Connection (air conditioner - 15a), in dash panel wiring harness |
| V23 | Positive (+) connection (15a), in navigation wiring harness |
| * | Models with cruise control system |
| ** | Models with radio navigation system (RNS-D) |
| E1 | Lighting switch |
| E2 | Turn signal switch |
| E4 | Headlight dipper/flasher switch |
| E19 | Parking light switch |
| J2 | Hazard warning light relay |
| J20 | Hazard warning light relay, trailer operation |
| S3 | Fuse in fuse carrier |
| T3ar | 3-pin connector, black, at turn signal switch |
| T14 | 14-pin connector, purple, behind steering column switch trim |
| E105 | Earth connection, in dash panel wiring harness, left |
| * | Models with trailer coupling |
| E3 | Hazard warning light switch |
| J234 | Airbag control unit |
| J526 | Telephone/telematics control unit |
| S1 | Fuse in fuse carrier |
| S6 | Fuse in fuse carrier |
| S8 | Fuse in fuse carrier |
| S10 | Fuse in fuse carrier |
| T6t | 6-pin connector, red, footwell, right, at wheelhouse, behind carpet |
| T10o | 10-pin connector, connector plug B at V94 |
| T16 | 16-pin connector, connector plug C at V94 |
| V94 | Central locking motor with control unit for interior lights switch-off delay and anti-theft alarm system |
| Z4 | Heated exterior mirror, driver's side |
| Z5 | Heated exterior mirror, front passenger's side |
| Z20 | Heater element, left washer jet |
| Z21 | Heater element, right washer jet |
| A80 | Connection -1- (X), in dash panel wiring harness |
| A125 | Connection (crash signal), in dash panel wiring harness |
| E113 | Earth connection, in dash panel wiring harness, right |
| E115 | Earth connection (centre console), in dash panel wiring harness |
| * | Models with telephone/telematics |
| M5 | Turn signal bulb, front left |
| M7 | Turn signal bulb, front right |
| M18 | Side turn signal bulb, left |
| M19 | Side turn signal bulb, right |
| T6d | 6-pin connector, white, footwell, right, at wheelhouse, behind carpet |
| 82 | Earth connection -1-, in front left wiring harness |
| 83 | Earth connection -1-, in front right wiring harness |
| 108 | Earth connection -2-, in front left wiring harness |
| A5 | Positive (+) connection (right turn signal), in dash panel wiring harness |
| A6 | Positive (+) connection (left turn signal), in dash panel wiring harness |
| W6 | Connection (left turn signal), in rear wiring harness |
| W7 | Connection (right turn signal), in rear wiring harness |
| J123 | Bulb monitoring device |
| M1 | Side light bulb, left |
| M29 | Dipped beam bulb, left |
| M30 | Main beam bulb, left |
| S1 | Fuse in fuse carrier |
| S5 | Fuse in fuse carrier |
| T10x | 10-pin connector, black, on left headlight |
| 44 | Earth point, lower part of left A pillar |
| 82 | Earth connection -1-, in front left wiring harness |
| A95 | Connection -1- (56a), in dash panel wiring harness |
| C1 | Positive (+) connection (58L), in front left wiring harness |
| E104 | Earth connection, in dash panel wiring harness (near relay point) |
| J123 | Bulb monitoring device |
| M3 | Side light bulb, right |
| M31 | Dipped beam bulb, right |
| M32 | Main beam bulb, right |
| S2 | Fuse in fuse carrier |
| S6 | Fuse in fuse carrier |
| T10y | 10-pin connector, black, on right headlight |
| 43 | Earth point, lower part of right A pillar |
| 83 | Earth connection -1-, in front right wiring harness |
| 611 | Earth connection, on fuel tank filler neck |
| A95 | Connection -1- (56a), in dash panel wiring harness |
| C2 | Positive (+) connection (58R), in front left wiring harness |
| E108 | Connection (right-hand parking light), in dash panel wiring harness |
| E116 | Connection (56a, right), in dash panel wiring harness |
| E102 | Headlight range control adjuster |
| J123 | Bulb monitoring device |
| L54 | Headlight range control adjuster light bulb |
| S3 | Fuse in fuse carrier |
| S4 | Fuse in fuse carrier |
| T10x | 10-pin connector, black, on left headlight |
| T10y | 10-pin connector, black, on right headlight |
| V48 | Headlight range control motor, left |
| V49 | Headlight range control motor, right |
| A51 | Connection (56), in dash panel wiring harness |
| C17 | Connection (56b) -1-, in front lighting wiring harness |
| E113 | Earth connection, in dash panel wiring harness, right |
| N1 | Connection (G), in headlight range control wiring harness |
| N2 | Connection -1-, in headlight range control wiring harness |
| * | Models with headlight washer system |
| J123 | Bulb monitoring device |
| M2 | Tail light bulb, right |
| M4 | Tail light bulb, left |
| M6 | Turn signal bulb, rear left |
| M8 | Turn signal bulb, rear right |
| M9 | Brake light bulb, left |
| M10 | Brake light bulb, right |
| M25 | High level brake light bulb |
| T6d | 6-pin connector, white, footwell, right, at wheelhouse, behind carpet |
| T10e | 10-pin connector, green, footwell, right, at wheelhouse, behind carpet |
| 98 | Earth connection, in tailgate/boot lid wiring harness |
| A18 | Connection (54), in dash panel wiring harness |
| B104 | Earth connection (rear right), in interior wiring harness |
| B108 | Earth connection, in interior wiring harness, rear right |
| B109 | Earth connection, in interior wiring harness, rear left |
| W13 | Connection (58L), in rear wiring harness |
| W14 | Connection (58R), in rear wiring harness |
| W27 | Positive (+) connection (58), in tail light wiring harness |
| E7 | Fog light switch |
| J512 | Fog lights/rear fog light control unit |
| L22 | Fog light bulb, left |
| L23 | Fog light bulb, right |
| T10v | 10-pin connector, in bumper, front left |
| T18 | 18-pin connector, blue, on fog lights control unit |
| 108 | Earth connection -2-, in front left wiring harness |
| 125 | Earth connection -3-, in headlight wiring harness |
| C21 | Connection (+), in front fog light wiring harness |
| C25 | Connection (fog light), in front lighting wiring harness |
| E113 | Earth connection, in dash panel wiring harness, right |
| E115 | Earth connection (centre console), in dash panel wiring harness |
| E18 | Rear fog light switch |
| J512 | Fog lights/rear fog light control unit |
| L46 | Rear fog light bulb, left |
| S5 | Fuse in fuse carrier |
| T10m | 10-pin connector, grey, footwell, right, at wheelhouse, behind carpet |
| T18 | 18-pin connector, blue, on fog lights control unit |
| X | Number plate light |
| 98 | Earth connection, in tailgate/boot lid wiring harness |
| A88 | Connection (rear fog light), in dash panel wiring harness |
| B205 | Connection (fog lights), in interior wiring harness |
| E115 | Earth connection (centre console), in dash panel wiring harness |
| W4 | Connection -1- (rear fog light), in rear wiring harness |
| F | Brake light switch |
| F47 | Cruise control system brake pedal switch (diesel direct injection system) |
| J104 | ABS with EDL control unit |
| J220 | Motronic control unit |
| J248 | Diesel direct injection system control unit |
| L15 | Ashtray light bulb |
| L28 | Cigarette lighter light bulb |
| S3 | Fuse in fuse carrier |
| S4 | Fuse in fuse carrier |
| S7 | Fuse in fuse carrier |
| S9 | Fuse in fuse carrier |
| S10 | Fuse in fuse carrier |
| U1 | Cigarette lighter |
| B235 | Positive (+) connection -4- (15a), in interior wiring harness |
| E30 | Connection (87a), in engine wiring harness |
| E104 | Earth connection, in dash panel wiring harness (near relay point) |
| E109 | Connection (30, central electrics), in dash panel wiring harness |
| E113 | Earth connection, in dash panel wiring harness, right |
| E115 | Earth connection (centre console), in dash panel wiring harness |
| * | Models with petrol engines |
| ** | Models with 6-cylinder diesel engines |
| *** | Models with 8-cylinder diesel engines |
| # | See Current Flow Diagram: Diesel engines |
| E22 | Intermittent wiper switch |
| E87 | Control and display unit for air conditioner |
| F77 | Windscreen washer fluid warning contact |
| J31 | Automatic intermittent wash/wipe relay |
| S10 | Fuse in fuse carrier |
| V5 | Windscreen washer pump |
| 83 | Earth connection -1-, in front right wiring harness |
| A12 | Positive (+) connection (75 aw), in dash panel wiring harness |
| D64 | Positive (+) connection (53c), in engine compartment wiring harness |
| E15 | Heated rear window switch |
| E87 | Control and display unit for air conditioner |
| J31 | Automatic intermittent wash/wipe relay |
| T6t | 6-pin connector, red, footwell, right, at wheelhouse, behind carpet |
| V | Windscreen wiper motor |
| V11 | Headlight washer system pump |
| Z1 | Heated rear window |
| 75 | Earth point, rear pillar, right |
| 83 | Earth connection -1-, in front right wiring harness |
| E104 | Earth connection, in dash panel wiring harness (near relay point) |
| E105 | Earth connection, in dash panel wiring harness, left |
| * | Models with headlight washer system |
| F4 | Reversing light switch |
| F125 | Multi-function switch |
| M16 | Reversing light bulb, left |
| M17 | Reversing light bulb, right |
| S1 | Fuse in fuse carrier |
| T6e | 6-pin connector, brown, connector point, electronics box, plenum chamber |
| T10 | 10-pin connector, blue, connector point, electronics box, plenum chamber |
| T10a | 10-pin connector, black, connector point, electronics box, plenum chamber |
| T10m | 10-pin connector, grey, footwell, right, at wheelhouse, behind carpet |
| T10o | 10-pin connector, connector plug B at V94 |
| V94 | Central locking motor with control unit for interior lights switch-off delay and anti-theft alarm system |
| 98 | Earth connection, in tailgate/boot lid wiring harness |
| A87 | Connection (reversing light), in dash panel wiring harness |
| B115 | Positive (+) connection (30, central electrics), in interior wiring harness |
| B182 | Connection (reversing light), in interior wiring harness |
| Q11 | Positive (+) connection (30 a), in electric window/central locking and door contact switch wiring harness |
| * | Models with manual gearbox |
| ** | Models with automatic gearbox |
| # | Models with 6-cylinder engines |
| ## | Models with 8-cylinder engines |
| E150 | Interior locking switch, driver's side |
| E164 | Luggage compartment release switch |
| J245 | Sliding sunroof adjustment control unit |
| J347 | Ultra-sonic sensor control unit |
| S3 | Fuse in fuse carrier |
| S5 | Fuse in fuse carrier |
| S6 | Fuse in fuse carrier |
| S7 | Fuse in fuse carrier |
| S9 | Fuse in fuse carrier |
| T6ad | 6-pin connector, black, on sliding sunroof adjustment control unit |
| T10o | 10-pin connector, connector plug B at V94 |
| V94 | Central locking motor with control unit for interior lights switch-off delay and anti-theft alarm system |
| 43 | Earth point, lower part of right A pillar |
| B104 | Earth connection (rear right), in interior wiring harness |
| B115 | Positive (+) connection (30, central electrics), in interior wiring harness |
| B119 | Connection (30a, steering column/belt height adjustment), in interior wiring harness |
| Q12 | Positive (+) connection (30 a), in electric window/central locking and door contact switch wiring harness |
| Q33 | Positive (+) connection (30az), in electric window wiring harness |
| F2 | Door contact switch, driver's side |
| F10 | Rear left door contact switch |
| J348 | Entry and footwell lighting relay |
| T6k | 6-pin connector, green, under driver's seat |
| T10o | 10-pin connector, connector plug B at V94 |
| V94 | Central locking motor with control unit for interior lights switch-off delay and anti-theft alarm system |
| W9 | Left footwell light |
| W30 | Door warning lamp, driver's side |
| W31 | Front left entry light |
| W33 | Rear left entry light |
| W37 | Door warning lamp, rear left |
| W45 | Rear left footwell light |
| B100 | Earth connection, in interior wiring harness, front right |
| B101 | Earth connection (front passenger's door), in interior wiring harness |
| B113 | Connection (30a), in interior wiring harness, left |
| B129 | Connection (interior light, 31 L), in interior wiring harness |
| R2 | Connection (door contact switch, left), in electric window/central locking and door contact switch wiring harness |
| R28 | Connection -2- (door contact switch), in rear wiring harness |
| F3 | Door contact switch, front passenger's side |
| F11 | Rear right door contact switch |
| F298 | Rear left vanity mirror contact switch |
| F299 | Rear right vanity mirror contact switch |
| T2cr | 2-pin connector, black, near interior light, front |
| T6l | 6-pin connector, green, under front passenger's seat |
| W10 | Right footwell light |
| W32 | Front right entry light |
| W34 | Rear right entry light |
| W36 | Door warning lamp, front passenger's side |
| W38 | Door warning lamp, rear right |
| W46 | Rear right footwell light |
| W49 | Rear left illuminated vanity mirror |
| W50 | Rear right illuminated vanity mirror |
| B109 | Earth connection, in interior wiring harness, rear left |
| B113 | Connection (30a), in interior wiring harness, left |
| R1 | Connection (door contact switch, right), in electric window/central locking and door contact switch wiring harness |
| R9 | Connection (door contact switch), in rear wiring harness |
| * | Only applies to long wheelbase versions with sunroof |
| E26 | Glove box light switch |
| E39 | Rear electric window isolation switch |
| E224 | Airbag disabling key switch, front passenger's side |
| L32 | Rear cigarette lighter light bulb |
| L48 | Rear ashtray light bulb, left |
| L49 | Rear ashtray light bulb, right |
| L90 | Glove box lock illumination |
| L120 | Shelf illumination |
| T5m | 5-pin connector, at glove box |
| T10m | 10-pin connector, grey, footwell, right, at wheelhouse, behind carpet |
| U9 | Cigarette lighter, rear |
| W6 | Glove box light |
| B100 | Earth connection, in interior wiring harness, front right |
| B102 | Earth connection, in interior wiring harness, front left |
| B104 | Earth connection (rear right), in interior wiring harness |
| B106 | Earth connection (driver's door/1), in interior wiring harness |
| B116 | Connection (58s), in interior wiring harness |
| B117 | Connection (58a, right), in interior wiring harness |
| B126 | Connection (87, driver's door), in interior wiring harness |
| Q14 | Connection (isolation switch), in electric window/central locking and door contact switch wiring harness |
| F147 | Vanity mirror contact switch, driver's side |
| F148 | Vanity mirror contact switch, front passenger's side |
| J91 | Reading lamp relay |
| T12 | 12-pin connector, connector plug A at V94 |
| V94 | Central locking motor with control unit for interior lights switch-off delay and anti-theft alarm system |
| W3 | Luggage compartment light |
| W14 | Illuminated vanity mirror, front passenger's side |
| W18 | Luggage compartment light, left |
| W20 | Illuminated vanity mirror, driver's side |
| 54 | Earth point, battery cover |
| B104 | Earth connection (rear right), in interior wiring harness |
| B108 | Earth connection, in interior wiring harness, rear right |
| B100 | Earth connection, in interior wiring harness, front right |
| B109 | Earth connection, in interior wiring harness, rear left |
| B135 | Connection -1- (15a), in interior wiring harness |
| W15 | Connection -1- (luggage compartment light), in rear wiring harness |
| Y5 | Connection (87), in interior light wiring harness |
| * | Only applies to long wheelbase versions with sunroof |
| T4ac | 4-pin connector, on reading lights switch |
| T6aa | 6-pin connector, connector 1, on interior light, front |
| T6ab | 6-pin connector, near interior mirror |
| T6ac | 6-pin connector, brown, connector 2, on interior light, front |
| T6aq | 6-pin connector, brown, on interior light, rear |
| W | Interior light, front |
| W11 | Reading lamp, rear left |
| W12 | Reading lamp, rear right |
| W13 | Front passenger reading lamp |
| W19 | Reading lamp, driver's side |
| W43 | Rear interior light |
| Y7 | Automatic anti-dazzle interior mirror |
| A29 | Connection (interior light), in dash panel wiring harness |
| B104 | Earth connection (rear right), in interior wiring harness |
| B109 | Earth connection, in interior wiring harness, rear left |
| * | Models with automatic anti-dazzle interior mirror |
Čeština
Dansk
Deutsch
Ελληνικά
English
Español
Suomi
Français
Français
עברית
Hrvatski
Magyar
Italiano
日本語
한국어
Nederlands
Polski
Português
Português
Română
Русский
Slovenčina
Slovenščina
Svenska
Türkçe
中文 (中国)
