Wiring Diagram AUDI A8 2002 - Steering wheel with Tiptronic - dual tone horn relay - horn plate



Wiring Diagram AUDI A8 2002 - Steering wheel with Tiptronic - dual tone horn relay - horn plate https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Download PDF file
E221Operating unit in steering wheel
F138Airbag coil connector
HHorn plate
H2High tone horn
H7Low tone horn
J4Dual tone horn relay
J234Airbag control unit
N95Airbag igniter, driver's side
S8Fuse in fuse carrier
T2bm2-pin connector, yellow, electronics box in footwell, front right
T5b5-pin connector, yellow, behind steering column switch trim
T10v10-pin connector, in bumper, front left
   44 Earth point, lower part of left A pillar
   108 Earth connection -2-, in front left wiring harness
   129 Earth connection, in dual tone horn wiring harness
   A52 Positive (+) connection 2 (30), in dash panel wiring harness
   C13 Positive (+) connection, in dual tone horn wiring harness
   E105 Earth connection, in dash panel wiring harness, left
Short circuit bridge becomes effective when connector is unplugged.

Wiring Diagram AUDI A8 2002 - Steering wheel with Tiptronic - operating unit in steering wheel



Wiring Diagram AUDI A8 2002 - Steering wheel with Tiptronic - operating unit in steering wheel https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Get access to all wiring diagrams of the carDownload PDF file
E221Operating unit in steering wheel
F189Tiptronic switch
J217Automatic gearbox control unit
J285Control unit with display in dash panel insert
T5g5-pin connector, black, in selector lever console
T5l5-pin connector, black, behind steering column switch trim
T1010-pin connector, blue, connector point, electronics box, plenum chamber
T10b10-pin connector, yellow, connector point, electronics box, plenum chamber
T10g10-pin connector, black, near selector lever console
T32b32-pin connector, grey, on dash panel insert
   44 Earth point, lower part of left A pillar
   A19 Connection (58s), in dash panel wiring harness (switch illumination)
   E105 Earth connection, in dash panel wiring harness, left
