AUDI A8 2002 – Electrically operated rear roller blind . Wiring diagrams, Pin Connector, Location

Wiring Diagram AUDI A8 2002 - Electrically operated rear roller blind

E94	Heated driver's seat adjuster
E149	Rear roller blind switch
J262	Rear roller blind control unit
L77	Rear roller blind switch illumination
S10	Fuse in fuse carrier
T2l	2-pin connector, connection for rear roller blind motor
T3aa	3-pin connector, black, under rear seat, right
T10m	10-pin connector, grey, footwell, right, at wheelhouse, behind carpet
V91	Rear roller blind motor
43	Earth point, lower part of right A-pillar
B100	Earth connection, in interior wiring harness, front right
B104	Earth connection (rear right), in interior wiring harness
B115	Positive (+) connection (30, central electrics), in interior wiring harness
B116	Connection (58s), in interior wiring harness

D	Ignition/starter switch
J285	Control unit with display in dash panel insert
S4	Fuse in fuse carrier
T6t	6-pin connector, red, footwell, right, at wheelhouse, behind carpet
T32b	32-pin connector, grey, on dash panel insert
A2	Positive (+) connection (15), in dash panel wiring harness
A19	Connection (58s), in dash panel wiring harness (switch illumination)
B163	Positive (+) connection -1- (15), in interior wiring harness
W8	Connection(15a), in rear wiring harness
