SCHEMA ELETTRICO - AUTORADIO - Fiat BRAVO 1.9 JTD 16v
COMPONENTI - AUTORADIO - Fiat BRAVO 1.9 JTD 16v
Codice componenti | Denominazione | Riferimento all’operazione |
B002 | CENTRALINA DI DERIVAZIONE SOTTO PLANCIA | |
B099 | SCATOLA MAXI FUSE SU BATTERIA | - |
C038 | MASSA SU TUNNEL CENTRALE | - |
D020 | GIUNZIONE PLANCIA/POSTERIORE | - |
D030 | GIUNZIONE PORTA ANTERIORE SINISTRA | - |
D031 | GIUNZIONE PORTA ANTERIORE DESTRA | - |
D035 | GIUNZIONE PORTA POSTERIORE SINISTRA | - |
D036 | GIUNZIONE PORTA POSTERIORE DESTRA | - |
D047 | GIUNZIONE CONTATTO SPIRALATO | |
H001 | COMMUTATORE DI ACCENSIONE | |
M001 | BODY COMPUTER | |
P020 | AUTORADIO | |
P025 | ALIMENTATORE ANTENNA | |
P030 | ALTOPARLANTE POSTERIORE SINISTRO | |
P031 | ALTOPARLANTE POSTERIORE DESTRO | |
P035 | ALTOPARLANTE SU PORTA ANTERIORE LATO GUIDA | |
P036 | ALTOPARLANTE SU PORTA ANTERIORE LATO PASSEGGERO | |
P045 | ALTOPARLANTE TWEETER ANTERIORE LATO GUIDA | |
P046 | ALTOPARLANTE TWEETER ANTERIORE LATO PASSEGGERO |
LOCALIZZAZIONE COMPONENTI - AUTORADIO - Fiat BRAVO 1.9 JTD 16v
Codice componenti | Denominazione | Riferimento all’operazione |
B002 | CENTRALINA DI DERIVAZIONE SOTTO PLANCIA | |
B099 | SCATOLA MAXI FUSE SU BATTERIA | - |
C038 | MASSA SU TUNNEL CENTRALE | - |
D020 | GIUNZIONE PLANCIA/POSTERIORE | - |
D030 | GIUNZIONE PORTA ANTERIORE SINISTRA | - |
D031 | GIUNZIONE PORTA ANTERIORE DESTRA | - |
D035 | GIUNZIONE PORTA POSTERIORE SINISTRA | - |
D036 | GIUNZIONE PORTA POSTERIORE DESTRA | - |
D047 | GIUNZIONE CONTATTO SPIRALATO | |
H001 | COMMUTATORE DI ACCENSIONE | |
M001 | BODY COMPUTER | |
P020 | AUTORADIO | |
P025 | ALIMENTATORE ANTENNA | |
P030 | ALTOPARLANTE POSTERIORE SINISTRO | |
P031 | ALTOPARLANTE POSTERIORE DESTRO | |
P035 | ALTOPARLANTE SU PORTA ANTERIORE LATO GUIDA | |
P036 | ALTOPARLANTE SU PORTA ANTERIORE LATO PASSEGGERO | |
P045 | ALTOPARLANTE TWEETER ANTERIORE LATO GUIDA | |
P046 | ALTOPARLANTE TWEETER ANTERIORE LATO PASSEGGERO |
DESCRIZIONE - AUTORADIO - Fiat BRAVO 1.9 JTD 16v
La vettura e dotata di un impianto autoradio composto da:- autoradio (con lettore CD / MP3);- altoparlanti anteriori: woofer e tweeter collocati nelle porte;- altoparlanti posteriori collocati nelle porte;- cavi di collegamento dell''autoradio con gli altoparlanti stessi;- antenna stilo con supporto montato nella zona posteriore del tetto con relativo cavo coassiale di collegamento.E'' inoltre possibile installare un sofisticato impianto HIFI dotato di altoparlanti specifici ad alta fedelta e amplificatore esternoLa radio e un nodo della rete CAN attraverso la quale scambia informazioni con il Body Computer e le altre unita elettroniche.L''autoradio e dotata di un sistema di antifurto realizzato con il collegamento della radio su rete CAN con il Body Computer; gestisce anche il controllo del volume legato alla velocita vettura: e infatti previsto l''incremento ed il decremento del volume in rapporto alla velocita vettura: tale informazione giunge al nodo autoradio via CAN.Alcune versioni sono dotate di una serie di pulsanti posti sul volante: questi consentono di "duplicare" alcuni comandi che vengono acquisiti in modo analogico dalla autoradio stessa.
DESCRIZIONE FUNZIONALE - AUTORADIO - Fiat BRAVO 1.9 JTD 16v
L''autoradio P20 e alimentata direttamente (7 del connettore A) dalla batteria tramite la linea del fusibile F39 della centralina sottoplancia B2 .Il pin 8 del connettore A e invece a massa.Al pin 1 e 3 del connettore A giunge la linea CAN con la quale l''autoradio P20 si collega al Body Computer M1 e agli altri nodi del sistema.Al Body Computer M1 si collegano i comandi radio sul volante, tramite il "contatto spiralato" D47: al pin 27 del connettore H di M1 gungono i segnali dei pulsanti posti alla destra del volante, mentre al pin 15 del connettore H di M1 gungono i segnali dei pulsanti posti alla sinistra del volante.Il Body Computer M1 e alimentato direttamente dalla batteria dalla linea protetta dal maxifuse d B99 al pin 18 del connettore F di interfaccia con la centralina sottoplancia B2; la alimentazione sotto chiave (INT) giunge al pin 9 del connettore F di interfaccia con la centralina B2.Dal connettore B di P20 escono i cavi con i segnali verso gli altoparlanti:- pin 5 e 6 agli altoparlanti anteriori lato sinistro P35 e P45;- pin 3 e 4 agli altoparlanti anteriori lato destro P36 e P46);- pin 7 e 8 all'' altoparlante posteriore sinistro P30;- pin 1 e 2 all'' altoparlante posteriore destro P31.L''antenna P25 e collegata alla radio per mezzo dell''apposito cavo coassiale.
