Wiring Diagram - PREPARATION FOR CELLULAR TELEPHONE - Fiat DUCATO 2.8 JTD 8V fino a 02/05
Components - PREPARATION FOR CELLULAR TELEPHONE - Fiat DUCATO 2.8 JTD 8V fino a 02/05
| Component code | Description | Reference to the assembly |
| B002 | JUNCTION UNIT UNDER DASHBOARD | - |
| B099 | MAXI FUSE BOX ON BATTERY | - |
| B101 | OPTIONAL JUNCTION UNIT UNDER THE DASHBOARD | - |
| C020 | PASSENGER SIDE DASHBOARD EARTH | - |
| D016 | ADDITIONAL DASHBOARD/LEFT FRONT DOOR COUPLING | - |
| D017 | ADDITIONAL DASHBOARD/RIGHT FRONT DOOR COUPLING | - |
| D075 | RADIO PHONE COUPLING | - |
| D097 | SHORT CIRCUITING COUPLING | - |
| D160 | DASHBOARD/OPTIONAL DASHBOARD COUPLING | - |
| D165 | OPTIONAL DASHBOARD/OPTIONAL COURTESY LIGHT COUPLING | - |
| H001 | IGNITION SWITCH | |
| H090 | SWITCH CONTROL PANEL | 5,505A |
| M120 | Connect front panel | - |
| P026 | HANDSFREE MICROPHONE | - |
| P035 | SPEAKER ON FRONT DOOR LEFT | 5570T |
| P036 | SPEAKER IN RIGHT FRONT DOOR | 5570T |
| P037 | LEFT FRONT SPEAKER IN DASHBOARD | - |
| P038 | RIGHT FRONT SPEAKER IN DASHBOARD | - |
| - |
Component location - PREPARATION FOR CELLULAR TELEPHONE - Fiat DUCATO 2.8 JTD 8V fino a 02/05
| Component code | Description | Reference to the assembly |
| B002 | JUNCTION UNIT UNDER DASHBOARD | - |
| B099 | MAXI FUSE BOX ON BATTERY | - |
| B101 | OPTIONAL JUNCTION UNIT UNDER THE DASHBOARD | - |
| C020 | PASSENGER SIDE DASHBOARD EARTH | - |
| D016 | ADDITIONAL DASHBOARD/LEFT FRONT DOOR COUPLING | - |
| D017 | ADDITIONAL DASHBOARD/RIGHT FRONT DOOR COUPLING | - |
| D075 | RADIO PHONE COUPLING | - |
| D097 | SHORT CIRCUITING COUPLING | - |
| D160 | DASHBOARD/OPTIONAL DASHBOARD COUPLING | - |
| D165 | OPTIONAL DASHBOARD/OPTIONAL COURTESY LIGHT COUPLING | - |
| H001 | IGNITION SWITCH | |
| H090 | SWITCH CONTROL PANEL | 5,505A |
| M120 | Connect front panel | - |
| P026 | HANDSFREE MICROPHONE | - |
| P035 | SPEAKER ON FRONT DOOR LEFT | 5570T |
| P036 | SPEAKER IN RIGHT FRONT DOOR | 5570T |
| P037 | LEFT FRONT SPEAKER IN DASHBOARD | - |
| P038 | RIGHT FRONT SPEAKER IN DASHBOARD | - |
| - |
Description - PREPARATION FOR CELLULAR TELEPHONE - Fiat DUCATO 2.8 JTD 8V fino a 02/05
The cell phone predisposition consists of a junction to which a specific handsfree kit can be connected. This junction is connected to CONNECT, which manages transmission signals to and from the cell phone fitted to the kit. The power supply to the cell phone predisposition comes directly from the battery and via the ignition. Both lines are protected by dedicated fuses housed in the optional and basic underfacia junction unit.The microphone is located in the front courtersy light and is also managed by CONNECT.Voice signals are distributed to speakers housed in the front doors and facia.The cell phone predisposition junction also supplies a +LIGHTS signal, sent by the control panel when the side lights are turned on.
Operational Description - PREPARATION FOR CELLULAR TELEPHONE - Fiat DUCATO 2.8 JTD 8V fino a 02/05
Junction D075 receives power directly from the battery - al pin 9 - from a line protected by fuse F34, located in optional underfacia junction unit B101. The ignition-operated power supply reaches pin 7 via a line protected by fuse F27 housed in junction unit B002.Pin 8 receives a side light activation control from control panel H090 - pin 12 connector C.Pins 1, 3, 4 are connected to CONNECT M120 and manage phone signal input/output.CONNECT M120 controls P026 (located in the front courtesy light), via pins 9 and 18 of connector D. CONNECT M120 distributes the voice signal to speakers P035, P036, P037, P038 from connector A.
