DescrizioneLa climatizzazione della vettura viene realizzata attraverso il gruppo convogliatore/distributore con riscaldatore, e controllata agendo sulle due manopole di comando poste sulla plancia; ciascuna manopola svolge una doppia funzione: una con la ghiera esterna, una con la manopola vera e propria posta al centro:la ghiera della manopola di sinistra comanda in modo meccanico lo sportello di miscelazione tra aria calda e fredda; la manopola interna regola con un comando elettrico la ventilazione dell'aria a quattro differenti velocita;flessibile, l'apertura degli sportelli che regolano la distribuzione dei flussi di aria; la manopola interna comanda, sempre in modo meccanico, l'inserimento della funzione di "ricircolo". Per maggiori dettagli 2393527Descrizioni e Funzionamento5020RISCALDATORE Sul gruppo comandi e presente anche il pulsante rosso delle luci di emergenza 2394007VedereE2020LUCI DIREZIONE / EMERGENZA e un pulsante per l'inserimento del lunotto termico, con relativo le di funzione inserita 2394065VedereE3030SBRINAMENTO LUNOTTO E SPECCHI RETROVISORI . Il ventilatore e alimentato da una linea protetta da uno specifico fusibile e comandato da uno specifico teleruttore della centralina vano motore.Il comando per le differenti velocita dell'elettroventilatore e realizzato grazie ad un partitore resistivo, protetto da un apposito termo-fusibile per eventuali sovratemperature.Il gruppo comandi e alimentato da una linea "sottochiave' protetta da un fusibile della centralina sottoplancia.
Descrizione funzionale L'elettroventilatore N85 e alimentato "sotto chiave' (INT/A) dalla linea protetta dal fusibile F31 della centralina sottoplancia B2 e controllata dal teleruttore T8 e del fusibile specifico F8 della centralina vano motore B1 . La manopola di comando H81 comanda il ventilatore alle differenti velocita attraverso il regolatore O30 il segnale di comando- segnale di massa varia a seconda della posizione della manopola e attraversa o meno le resistenze del regolatore O30 determinando quattro differenti segnali in tensione per l'elettroventilatore N85 che gira a 4 differenti velocita .
0Stacco201Riattacco21Aprire il coperchio vano motoree scollegare la batteria.1. Svitare il dado.2. Spostare il ritegno.3. Rimuovere la batteria con cautela.2050795
5530B22
0Stacco201Riattacco212395406-5530B10BATTERIA - S.R.2395409-5530B52SUPPORTO/CESTELLO batteria - S.R.Aprire il coperchio vano motore1. Scollegare la connessione elettrica (1a) dal morsetto negativodelle batteria (1b).2. Scollegare la connessione elettrica dalla scocca.3. Scollegare la connessione elettrica dalla scatola cambio.4. Recuperare il cavo di massa batteria.2050796
5530B36
0Stacco201Riattacco21Posizionare la vettura su pontedi sollevamento.Sollevare la vettura.1. Svitare il dado (1a) e scollegare le connessioni elettriche (1b,1c) dal motorino di avviamento.2050797
5530B52
0Stacco201Riattacco212395406-5530B10BATTERIA - S.R.1. Aprire le fascette di ritegno e liberare i cablaggi.2. Rimuovere il piano d'appoggio batteria (2a) disimpegnando lasua tubazione di scarico (2b) dal foro di passaggio (2c). 3. Svitare le viti.4. Rimuovere il cestello batteria.2050799
5530B60
0Stacco201Riattacco21Aprire il coperchio vano motore.1. Svitare il dado.2. Disimpegnare il bottone di ritegno con l'apposito attrezzo.3. Rimuovere la cinghia.2050800
0Stacco201Riattacco212395632-7040A37COPERCHIETTO accessofusibili su plancia portastrumenti - S.R.1. Scollegare le connessioni elettriche (1a, 1b, 1c, 1d, 1e, 1f).2. Svitare la vite di fissaggio staffa.3. Spostare leggermente la staffa (3a) del rivestimento planciae svitare la vite (3b).4. Svitare le altre viti di fissaggio gruppo body computer/centralinadi derivazione.5. Spostare leggermente gruppo body computer/centralina di derivazione.6. Scollegare le connessioni elettriche (6a, 6b, 6c).7. Recuperare il gruppo body computer/centralina di derivazione.2050752
0Stacco201Riattacco21Scollegare la connessione elettricadel motorino ricircolo.1. Svitare le quattro viti (1a) e rimuovere il gruppo presa aria(1b).2050708
5040C20
0Stacco201Riattacco211. Svitare le sei viti (1a) e separare il gruppo riscaldatore/distribuzionearia (1b) dal gruppo evaporatore (1c). 2050710
0Stacco201Riattacco211. Operando sotto il lato destro del rivestimento plancia, scollegarela connessione elettrica.2. Svitare le viti di fissaggio dell'elettroventilatore.3. Estrarre l'elettroventilatore.2050713
5040C44
0Stacco201Riattacco211. Operando sotto il lato destro del rivestimento plancia, scollegarela connessione elettrica.2. Svitare la vite (2a) e rimuovere il variatore(2b).2050714
5040C54
0Stacco201Riattacco211. Svitare le tre viti e rimuovere il riparo tubi acqua.2050715
