Automotive Electricians Portal FZCO Schaltplan - AUTORADIO - Fiat ULYSSE 2.2 16V JTD fino a 04/03
Bauteile - AUTORADIO - Fiat ULYSSE 2.2 16V JTD fino a 04/03
Bauteil-Nr. | Bezeichnung | Bezug zur Baugruppe |
C015 | Masseanschluss Armaturenbrett Fahrerseite | - |
C020 | Masse Armaturenbrett Beifahrerseite | - |
C022 | Masse Armaturenbrett Mitte | - |
D020 | Verbindung Armaturenbrett/hinten | - |
D030 | Verbindung Vordertur links | - |
D031 | Verbindung Vordertur rechts | - |
E050 | Instrumententafel | 5560B |
M001 | Body Computer | 5505A |
M093 | Elektronik Knoten Lenkrad (NVO) | 5550A |
M140 | Elektronik Kontrollleuchten und Kilometerzahler (NSO) | - |
M172 | Knoten Multifunktionsbildschirm | - |
P020 | Autoradio | - |
P025 | Versorgung/Antennenverstarker | - |
P035 | Lautsprecher auf Vordertur links | 5570T |
P036 | Lautsprecher auf Vordertur rechts | 5570T |
P045 | Hochtoner vorne links | 5570T |
P046 | Hochtoner vorne rechts | 5570T |
P047 | Hochtoner hinten links | 5570T |
P048 | Hochtoner hinten rechts | 5570T |
P075 | CD-Leser/Wechsler | - |
P120 | Lautsprecher seitlich hinten links | - |
P121 | Lautsprecher seitlich hinten rechts | - |
Einbaulage Bauteile - AUTORADIO - Fiat ULYSSE 2.2 16V JTD fino a 04/03
Bauteile - AUTORADIO - Fiat ULYSSE 2.2 16V JTD fino a 04/03
Bauteil-Nr. | Bezeichnung | Bezug zur Baugruppe |
C015 | Masseanschluss Armaturenbrett Fahrerseite | - |
C020 | Masse Armaturenbrett Beifahrerseite | - |
C022 | Masse Armaturenbrett Mitte | - |
D020 | Verbindung Armaturenbrett/hinten | - |
D030 | Verbindung Vordertur links | - |
D031 | Verbindung Vordertur rechts | - |
E050 | Instrumententafel | 5560B |
M001 | Body Computer | 5505A |
M093 | Elektronik Knoten Lenkrad (NVO) | 5550A |
M140 | Elektronik Kontrollleuchten und Kilometerzahler (NSO) | - |
M172 | Knoten Multifunktionsbildschirm | - |
P020 | Autoradio | - |
P025 | Versorgung/Antennenverstarker | - |
P035 | Lautsprecher auf Vordertur links | 5570T |
P036 | Lautsprecher auf Vordertur rechts | 5570T |
P045 | Hochtoner vorne links | 5570T |
P046 | Hochtoner vorne rechts | 5570T |
P047 | Hochtoner hinten links | 5570T |
P048 | Hochtoner hinten rechts | 5570T |
P075 | CD-Leser/Wechsler | - |
P120 | Lautsprecher seitlich hinten links | - |
P121 | Lautsprecher seitlich hinten rechts | - |
Beschreibung - AUTORADIO - Fiat ULYSSE 2.2 16V JTD fino a 04/03
Das Fahrzeug ist fur den Einbau eines Autoradios vorbereitet.Zu den Vorbereitungsteilen gehoren:Stromversorgungskabel des Radios,vordere Hochleistungslautsprecher mit getrennten Hochtonern,hintere Hochleistungslautsprecher mit getrennten Hochtonern,Verbindungskabel vom Radio zu den Lautsprechern,eine hinten auf dem Dach angebrachte Antenne, die uber ein Koaxialkabel mit dem Autoradio verbunden ist.
Das Autoradio erhalt Strom mit dem Zundschlussel auf M bzw. direkt aus der Batterie (fur die Speicherung von Sendern, Sicherheitscodes usw.).Die wichtigsten Radiobedienelemente befinden sich nochmals am Lenkrad, damit der Fahrer das Radio bedienen kann, ohne die Hande vom Lenkrad zu nehmen.Das Autoradio wird wie ein Knoten des CAN-Netzes behandelt und ist mit dem Body Computer, der Instrumententafel und dem Multifunktionsbildschirm verbunden, wo die Informationen bezuglich des Radios angezeigt werden.Ein CD-Wechsler nimmt bis zu 6 CDs auf, die mit den Radiobedienungen ausgewahlt werden konnen. Der CD-Wechsler befindet sich im Handschuhfach.Je nach Ausstattung werden au?erdem geliefert:AUTORADIO mit CD-Leser, wie zuvor beschrieben,Einrichtung "CONNECT Nav" (mit Navigation durch Symbole),Einrichtung "CONNECT Nav +" (mit Navigation durch Karten).
Alle Einzelheiten mit Funktionsbeschreibung des Autoradios enthalt die ?BETRIEBS- UND WARTUNGSANLEITUNG?.
Funktionsbeschreibung - AUTORADIO - Fiat ULYSSE 2.2 16V JTD fino a 04/03
Der Knoten Body Computer M001 liefert die direkte Stromversorgung von Pin 1 des Steckers D zum Autoradio P020 - Pin 7 des Steckers A - uber die mit der Sicherung F11 vom Body Computer geschutzte Leitung. Die Stromversorgung "hinter dem Schlussel" wird von Pin 4 des Steckers D an Pin 6 des Steckers A von P020 uber die mit der Sicherung F07 vom Body Computer geschutzte Leitung angelegt.Von den Pins 2 und 3 des Steckers A kommuniziert das Autoradio uber das CAN-Netz mit dem Knoten Elektronik Kontrollleuchten und Kilometerzahler N140 - an den Pins 6 und 3 - und mit der Instrumententafel E050.An 4 des Steckers A erhalt erhalt es die Stromversorgung fur das CAN-Netz vom Knoten Body Computer M001, von Pin 3 des Steckers D, von der durch die Sicherung F20 geschutzten Leitung.Das Autoradio P020 ist an Pin 5 des Steckers A mit der Antenne P025 (geschaltete Stromversorgung) und an Pin 8 mit Masse verbunden.Uber den Stecker B ist das Autoradio P020 mit den verschiedenen Lautsprechern im Fahrzeug verbunden:von den Pins 1 und 2 zu den Lautsprechern P048 (Hochtoner hinten rechts) und P121 (Lautsprecher hinten rechts),von den Pins 3 und 4 zu den Lautsprechern P036 (Lautsprecher an der rechten Vordertur) und P046 (Hochtoner vorne rechts),von den Pins 5 und 6 zu den Lautsprechern P035 (Lautsprecher an der linken Vordertur) und P045 (Hochtoner vorne links),von den Pins 7 und 8 zu den Lautsprechern P047 (Hochtoner hinten links) und P120 (Lautsprecher hinten links am Seitenteil).
Uber den Stecker C ist das Autoradio P020 mit dem CD-Wechsler P075 verbunden. Die Pins 13, 14 und 17 werden fur den Datenaustausch uber das CAN-Netz verwendet. Von den Pins 15 und 16 liefert das Autoradio P020 dem CD-Wechsler die Bezugsmasse bzw. die direkte Stromversorgung von der Batterie. Die Pins 19 und 20 sind die Audio-Eingange links bzw. rechts. Pin 18 ist die Bezugsmasse fur den Audiokanal.Uber den Knoten Lenkrad M093 konnen einige Funktionen des Autoradios uber die Bedienungen am Lenkrad betatigt werden. Die Informationen dazu werden vom Knoten Lenkrad M093 an den Knoten Body Computer uber das CAN-Netz geschickt, das die beiden Elektroniken verbindet.Der Knoten Lenkrad M093 erhalt die Stromversorgung (Pin 5 des Steckers A) uber die Leitung mit der Sicherung F11, die sich im Knoten Body Computer M001 befindet; Dieser wird uber CAN (Pin 6 des Steckers A) von der mit der Sicherung F16 im Knoten Body Computer M001 geschutzten Leitung mit Strom versorgt.Ebenfalls uber das CAN-Netz erfolgt der Informationsaustausch zwischen dem Knoten Instrumententafel E050, dem Autoradio P020 und dem Multifunktionsbildschirm M172.MASSE ARMATURENBRETT FAHRERSEITE
