D | Ignition/starter switch |
E87 | Control and display unit for air conditioner |
F129 | Air conditioner pressure switch |
J126 | Fresh air blower control unit |
T10p | 10-pin connector, behind dash panel, right |
T12a | 12-pin connector, behind dash panel, right |
V2 | Fresh air blower |
V42 | Temperature sensor blower |
Z20 | Heater element, left washer jet |
Z21 | Heater element, right washer jet |
44 | Earth point, lower part of left A-pillar |
A2 | Positive (+) connection (15), in dash panel wiring harness |
A98 | Positive (+) connection -4- (30a), in dash panel wiring harness |
B135 | Connection (15a), in interior wiring harness |
B156 | Positive (+) connection -4- (30a), in interior wiring harness |
L2 | Connection, in air conditioner wiring harness |
L59 | Positive (+) connection (30), in heater unit wiring harness |
E18 | Rear fog light switch |
E87 | Control and display unit for air conditioner |
F14 | Coolant temperature warning switch (overheating) |
J218 | Combi-processor in dash panel insert |
K4 | Side light warning lamp |
T12a | 12-pin connector, behind dash panel, right |
T16 | 16-pin connector, black, in console (diagnostic connector) |
T32 | 32-pin connector, blue, on dash panel insert |
T32a | 32-pin connector, green, on dash panel insert |
V94 | Central locking motor with control unit for interior lights switch-off delay and anti-theft alarm system |
277 | Earth connection -3-, in interior wiring harness |
A76 | Connection (diagnosis wire K), in dash panel wiring harness |
A108 | Connection (engine speed signal), in dash panel wiring harness |
B117 | Connection (58a, right), in interior wiring harness |
B145 | Positive (+) connection (58b), in interior wiring harness |
D99 | Connection (coolant temperature), in engine compartment wiring harness |
E87 | Control and display unit for air conditioner |
G92 | Control motor potentiometer, temperature flap |
G112 | Control motor potentiometer, central flap |
G113 | Control motor potentiometer, air flow flap |
G114 | Control motor potentiometer, footwell/defroster flap |
J220 | Motronic control unit |
J248 | Diesel direct injection system control unit |
J361 | Simos control unit |
T6 | 6-pin connector, red, in plenum chamber |
T10p | 10-pin connector, behind dash panel, right |
V68 | Temperature flap control motor |
V70 | Central flap control motor |
V71 | Air flow flap control motor |
V85 | Footwell/defroster flap control motor |
97 | Earth connection -1-, in air conditioner wiring harness |
L31 | Connection (5V), in air conditioner wiring harness |
* | Applies to engine codes AGN and AGU only |
** | Applies to engine codes AEH only |
*** | Applies to engine codes AGR only |
E87 | Control and display unit for air conditioner |
G17 | Ambient temperature sensor |
G56 | Dash panel temperature sensor |
G89 | Fresh air intake duct temperature sensor |
G107 | Sunlight penetration photosensor |
G192 | Vent temperature sender, footwell |
J220 | Motronic control unit |
J248 | Diesel direct injection system control unit |
J361 | Simos control unit |
T10 | 10-pin connector, white, in plenum chamber |
T10p | 10-pin connector, behind dash panel, right |
T12a | 12-pin connector, behind dash panel, right |
97 | Earth connection -1-, in air conditioner wiring harness |
112 | Earth connection -2-, in air conditioner wiring harness |
249 | Earth connection -2-, in interior wiring harness |
A45 | Connection (engine speed signal), in dash panel wiring harness |
* | Applies to engine codes AGN and AGU only |
** | Applies to engine codes AEH only |
*** | Applies to engine codes AGR only |
A | Battery |
F18 | Radiator fan thermo-switch |
F54 | Radiator fan thermo-switch |
J293 | Radiator fan control unit |
N25 | Air conditioning system magnetic coupling |
S133 | Fuse 3 |
S164 | 3 in fuse box/battery |
T2g | 2-pin connector, near compressor |
T3e | 3-pin connector, black, on main fuse box/battery |
T4b | 4-pin connector, in engine compartment, left |
V7 | Radiator fan |
12 | Earth point, in engine compartment, left |
188 | Earth connection -3-, in air conditioner wiring harness |
D50 | Positive (+) connection (30), in engine compartment wiring harness |
L5 | Connection -1-, in air conditioner wiring harness |
L6 | Connection -2-, in air conditioner wiring harness |
L7 | Connection -3-, in air conditioner wiring harness |
L8 | Connection -4-, in air conditioner wiring harness |
