FUSES & CIRCUIT BREAKERS FUSES AND CIRCUIT BREAKERS 1995-96 Jaguar

Jaguar XJ12 1995 - IDENTIFICATION FUSE PANEL LOCATION

The electrical systems are protected from short circuits by fuses that are designed to fail to prevent damage to the wire harness. There are five different fuse boxes protecting different groups of circuits. The left and right engine compartment panels are located under the hood on the left and right sides respectively. The left and right passenger compartment panels are located behind the left and right side heelboards. The luggage compartment fuse panel is located inside the trunk on the right side. A list of the protected circuits fuse ratings is given on the back of each fuse box cover. In addition to these, there are in-line fuses protecting various other circuits in vehicle.

Jaguar XJ12 1995 - FUSE AND RELAY PANEL LOCATIONS

Fig. 1: Jaguar XJ12 1995 - Component Locations - Engine Compartment Fuse & Relay Locations

Fig. 2: Jaguar XJ12 1995 - Component Locations - Passenger Compartment Fuse & Relay Locations

Fig. 3: Jaguar XJ12 1995 - Component Locations - Luggage Compartment Fuse & Relay Locations

Jaguar XJ12 1995 - LEFT FUSE PANEL IDENTIFICATION

Fig. 4: Jaguar XJ12 1995 - Component Locations - Left Engine Compartment Fuse Panel ID

WARNING:

Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.

• F1 - 25 Amp (Clear) Heated Windshield - Right Side
• F2 - 10 Amp (Red) LH High Beam
• F3 - 25 Amp (Clear) Starter Solenoid
• F4 - 10 Amp (Red) LH Low Beam
• F5 - 10 Amp (Red) LH Side Marker Lamps, LH Turn Signal, LH Flasher
• F6 - 20 Amp (Yellow) Windshield Wiper
• F7 - Not Used
• F8 - 15 Amp (Lt. Blue) Water Pump (Air Conditioning)
• F9 - Not Used
• F10 - 10 Amp (Red) Horn 1
• F11 - 30 Amp (Lt. Green) Cooling Fans (Series/Parallel)
• F12 - Not Used
• F13 - Not Used
• F14 - 10 Amp (Red) Horn 2
• F15 - 25 Amp (Clear) Heated Windshield - Left Side
• F16 - Not Used
• F17 - 30 Amp (Lt. Green) Cooling Fans (Series)
• F18 - 10 Amp (Red) LH Fog Lamp

Jaguar XJ12 1995 - RIGHT FUSE PANEL IDENTIFICATION

Fig. 5: Jaguar XJ12 1995 - Component Locations - Right Engine Compartment Fuse Panel ID

WARNING:

Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.

• F1 - Not Used
• F2 - 10 Amp (Red) RH High Beam
• F3 - Not Used
• F4 - 10 Amp (Red) RH Low Beam
• F5 - 10 Amp (Red) RH Side Marker Lamps, RH Turn Signal, RH Flasher
• F6 - 5 Amp (Tan) Engine Control Module (ECM)
• F7 - 25 Amp (Clear) Ignition Coils (6.0L)
• F8 - 10 Amp (Red) Air Conditioning Clutch
• F9 - Not Used
• F10 - 5 Amp (Tan) Generator, Front Lighting Control Module RH, A/C Clutch, Windshield Wash, Headlamp Power Wash Heaters & Relays
• F11 - 20 Amp (Yellow) Engine Management System Relay Supply Injectors
• F12 - 10 Amp (Red) Engine Management System (EMS), Starter Relay, Fuel Injection Relay, Engine Management Sensing (6.0L)
• F13 - 10 Amp (Red) Windshield Washer Pump
• F14 - 10 Amp (Red) Lambda Heaters, Idle Speed Control Valve (6.0L)
• F15 - Not Used
• F16 - 10 Amp (Red) Air Pump Control, Solenoid Vacuum Valve (6.0L)
• F17 - 30 Amp (Lt. Green) Headlamp Power Wash Pump
• F18 - 10 Amp (Red) RH Fog Lamp

Jaguar XJ12 1995 - LEFT PASSENGER COMPARTMENT PANEL IDENTIFICATION

Fig. 6: Jaguar XJ12 1995 - Component Locations - Left Passenger Compartment Fuse Panel ID

• F1 - Not Used
• F2 - 10 Amp (Red) Heated Door Mirrors
• F3 - 15 Amp (Lt. Blue) Seat Motors - RH Side
• F4 - 15 Amp (Lt. Blue) Seat Motors - RH Side
• F5 - 10 Amp (Red) Instrument Pack
• F6 - 5 Amp (Tan) Seat Control Modules (SCM's), Low Power Door Switch Pack, Power Mirror Motors
• F7 - 30 Amp (Lt. Green) ABS Pump (Via ABS/TC Control Module)
• F8 - Not Used
• F9 - 20 Amp (Yellow) Cigar Lighters
• F10 - 5 Amp (Tan) Cruise Control
• F11 - 20 Amp (Yellow) A/C Blower - LH
• F12 - 5 Amp (Tan) Instrument Pack
• F13 - 15 Amp (Lt. Blue) Steering Column - Electric Power Tilt/Axial Operation
• F14 - 10 Amp (Red) Automatic Transmission Ignition Supply
• F15 - 30 Amp (Lt. Green) LH Power Window Lift (Front & Rear)
• F16 - 5 Amp (Tan) ABS Ignition Supply
• F17 - Not Used
• F18 - 10 Amp (Red) A/C Supply

Jaguar XJ12 1995 - RIGHT PASSENGER COMPARTMENT PANEL IDENTIFICATION

Fig. 7: Jaguar XJ12 1995 - Component Locations - Right Passenger Compartment Fuse Panel ID

• F1 - 15 Amp (Lt. Blue) Central Door Locking, Deadlocking
• F2 - 5 Amp (Tan) Transmission Interlock Relay, Key-in-Switch Solenoid Relay, Center Console Switch Pack, Interior Lighting Switch
• F3 - 15 Amp (Lt. Blue) Seat Motors - LH Side
• F4 - 15 Amp (Lt. Blue) Seat Motors - LH Side
• F5 - 5 Amp (Tan) Automatic Transmission Control Module (TCM)
• F6 - Not Used
• F7 - 30 Amp (Lt. Green) ABS System/Traction Control Control Module (ABS/TC CM)
• F8 - 10 Amp (Red) Interior Lights
• F9 - 25 Amp (Clear) Seat Heaters
• F10 - 5 Amp (Tan) Data Link Connector, Fuel Pump Relay Coil
• F11 - 20 Amp (Yellow) A/C Blower - RH
• F12 - 10 Amp (Red) Air Conditioning, Seat Control Modules (SCM's), Mirror Heaters Relay, Power Assisted Steering
• F13 - Not Used
• F14 - 10 Amp (Red) Mirrors, Heated Rear Window, Cigar Lighter, Rear Lighting Control Module, High Mounted Stop Lamp
• F15 - 30 Amp (Lt. Green) RH Power Window Lift (Front & Rear)
• F16 - 10 Amp (Red) Windshield Wiper System, Front Screen Heaters, Front Front Lighting Control Module - LH, Water Pump Relay, Headlamp Leveling, Clock
• F17 - 15 Amp (Lt. Blue) Air Bag
• F18 - 15 Amp (Lt. Blue) Sunroof

Jaguar XJ12 1995 - LUGGAGE COMPARTMENT FUSE PANEL IDENTIFICATION

Fig. 8: Jaguar XJ12 1995 - Component Locations - Luggage Compartment Fuse Panel Identification

• F1 - 25 Amp (Clear) Power Amplifier- Radio/Cassette & Compact Disc Player
• F2 - 5 Amp (Tan) Tail Lamp - LH, Number Plate Lamp - LH
• F3 - 15 Amp (Lt. Blue) Back-up Lights, Stop Lamp - LH, Turn Indicator LH
• F4 - 10 Amp (Red) Security System
• F5 - 10 Amp (Red) Body Processor Unit (BPU)
• F6 - 5 Amp (Tan) Data Link Connector, Radio Telephone
• F7 - 30 Amp (Lt. Green) Fuel Pump
• F8 - 15 Amp (Lt. Blue) Luggage Compartment Remote Release, Aerial, Radio/Cassette & Compact Disc Player Memory Feed
• F9 - 15 Amp (Lt. Blue) Rear Fog Guard Lamps, Stop Lamp - RH, Turn Indicator RH
• F10 - 5 Amp (Tan) Radio/Cassette & Compact Disc Player Control Relay
• F11 - 25 Amp (Clear) Caravan/Trailer Module
• F12 - 5 Amp (Tan) Accessories and Telephone Control Relay
• F13 - 10 Amp (Red) Accessories
• F14 - Not Used
• F15 - 25 Amp (Clear) Heated Rear Window
• F16 - 5 Amp (Tan) Air Bag Warning
• F17 - Not Used
• F18 - 5 Amp (Tan) Tail Lamp RH Side, License Plate Lamp - RH

Jaguar XJ12 1995 - CAUTIONS & WARNINGS SUPPLEMENTAL RESTRAINT SYSTEM (AIR BAG)

NOTE:

See the AIR BAGS article in the ACCESSORIES/SAFETY EQUIPMENT Section.

Modifications or improper maintenance, including incorrect removal and installation of the Supplemental Restraint System (SRS), can adversely affect system performance. DO NOT cover, obstruct or change the steering wheel horn pad in any way, as such action could cause improper function of the system. Use only plain water when cleaning the horn pad. Solvents or cleaners could adversely affect the air bag cover and cause improper deployment of the system.

WARNING:

To avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAGS article in ACCESSORIES/SAFETY EQUIPMENT.

CAUTION:

Disconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation

Jaguar XJ12 1995 - BATTERY WARNING

WARNING:

When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION section.

Jaguar XJ12 1995 - REPLACING BLOWN FUSES

Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.

Jaguar XJ12 1995 - ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS

WARNING:

Many solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component.

Jaguar XJ12 1995 - RADIATOR FAN

WARNING:

Keep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off.
