FUSES & CIRCUIT BREAKERS Fuses & Circuit Breakers 1990-93 Chrysler Motors

Chrysler New Yorker Fifth Avenue 1993 - IDENTIFICATION

Vehicle has a fuse panel and relay and flasher modules. The fuse access panel is behind glove box door. To remove, pull panel from bottom and slide tabs out from top. Relay and flasher modules are located near fuse block at right lower corner of instrument panel.

Fig. 1: Chrysler New Yorker Fifth Avenue 1993 - Component Locations - Fuse Block Identification

Chrysler New Yorker Fifth Avenue 1993 - FUSE & CIRCUIT BREAKER IDENTIFICATION 1 - 20 Amp

Passing Light

Chrysler New Yorker Fifth Avenue 1993 - 2 - 20 Amp (1990-91)

Vanity & Key Cylinder Lights, Radio/Clock Memory, Stoplight

Feed

Chrysler New Yorker Fifth Avenue 1993 - 20 Amp (1992-93)

Stoplight Feed

Chrysler New Yorker Fifth Avenue 1993 - 3 - 10 Amp

Left Low Beam

Chrysler New Yorker Fifth Avenue 1993 - 4 - 10 Amp

Right Low Beam

Chrysler New Yorker Fifth Avenue 1993 - 5 - 4 Amp

Cluster Illumination, Rear Defogger Switch Light, Radio Illumination, Headlight Switch Illumination, A/C & ATC Control Illumination, PRNDL Illumination, Ashtray Illumination, Incandescent Message Center, Traveler (1992-93).

Chrysler New Yorker Fifth Avenue 1993 - 6 - 20 Amp

Speed Control.

Chrysler New Yorker Fifth Avenue 1993 - 7 - 20 Amp (1990-92); (Blank) (1993)

Power Sun Roof (1990-92). Not used (1993).

Chrysler New Yorker Fifth Avenue 1993 - 8 - 5 Amp

Body Computer, Incandescent Message Center, Mechanical & Electronic Clusters, Speed Control, Security Alarm, Air Bag Module (1992-93), Traveler (1993).

Chrysler New Yorker Fifth Avenue 1993 - 9 - 10 Amp

Cornering Lights, Day/Night Mirror, ATC Control, Rear Window Defogger Switch.

Chrysler New Yorker Fifth Avenue 1993 - 10 - 30 Amp

Blower Motor.

Chrysler New Yorker Fifth Avenue 1993 - 11 - 10 Amp

Back-Up Lights, Radiator Fan Relay.

Chrysler New Yorker Fifth Avenue 1993 - 12 - (Blank) (1990-91); 20 Amp (1992-93)

Door Courtesy, Overhead "C" Pillar Reading, Glove Box, Vanity & Key Lights, Radio/Clock Memory, Body Controller, Electronic Cluster Memory, Vanity Mirrors (1993), Underhood Light (1993).

Chrysler New Yorker Fifth Avenue 1993 - 13 - 20 Amp

Horns, Horn Relay, Cigarette Lighter, Electric Deck Lid Release, Power Antenna, Name Brand Speakers, Security Alarm Module & Light, Deck Lid Pull-Down.

Chrysler New Yorker Fifth Avenue 1993 - 14 - 20 Amp

Park & Taillights, Side Marker & License Lights, Radio Light.

Chrysler New Yorker Fifth Avenue 1993 - 15 - 30 Amp (Circuit Breaker)

Air Suspension-Load Leveling (1990-92), Horn (1993), Cigarette Lighter (1993).

Chrysler New Yorker Fifth Avenue 1993 - 16 - 20 Amp (1990-91)

Door Courtesy Lights, Overhead Lights, "C" Pillar Lights, Glove Box Lights, Vanity & Key Lights.

Chrysler New Yorker Fifth Avenue 1993 - 15 Amp (1992-93)

Radio Amplifier.

Chrysler New Yorker Fifth Avenue 1993 - 17 - 10 Amp

Heated Mirrors.

Chrysler New Yorker Fifth Avenue 1993 - 18 - 20 Amp

Windshield Wipers.

Chrysler New Yorker Fifth Avenue 1993 - 19 - 20 Amp

Turn Signals.

Chrysler New Yorker Fifth Avenue 1993 - 20 - 10 Amp (1990-91)

Radio & Power Antenna, Name Brand Speakers Relay.

Chrysler New Yorker Fifth Avenue 1993 - 10 Amp (1992-93)

Radio.

Chrysler New Yorker Fifth Avenue 1993 - CAUTIONS & WARNINGS AIR BAG SYSTEM

CAUTION:

Disconnect negative battery cable before servicing any air bag system or steering column component. After any repair, turn ignition key to ON position from passenger's side of vehicle (in case of accidental air bag inflation).
