Mercedes-Benz CLK500 2003 - 2003-04 ELECTRICAL Fuses & Circuit Breakers - 209 Chassis (Except Cabriolet)
Mercedes-Benz CLK500 2003 - IDENTIFICATION
NOTE: | The following table identifies applicable models covered in this article. |
Mercedes-Benz CLK500 2003 MODEL IDENTIFICATION
Model (Year) | Chassis Number | Engine Number |
CLK320 Coupe (2003-04) | 209.365 | 112.955 |
CLK500 Coupe (2003-04) | 209.375 | 113.968 |
CLK55 AMG Coupe (2004) | 209.376 | 113.987 |
Mercedes-Benz CLK500 2003 - FUSE & RELAY IDENTIFICATION
NOTE: | The vehicle's electrical systems are protected by an assortment of fuses and relays. Protective fuses should only be replaced by fuses of correct rating. |
Mercedes-Benz CLK500 2003 - Locating Fuse & Relay Panels
Fuse box (F34) located in the left interior of the cockpit. See Fig. 1 . The front prefuse box (F32) is located in the right rear of engine compartment. See Fig. 2 . Signal Register And Selection Module (SAM) modules with fuses and relays are located as follows: Mercedes-Benz CLK500 2003 - Component Locations -
- Left rear of engine compartment - Front SAM control module with fuse and relay module (N10/1). See Fig. 3 .
- Trunk left - Rear SAM control module with fuse and relay module (N10/2). See Fig. 4 .
https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO
Fig. 1: Mercedes-Benz CLK500 2003 - Component Locations - Locating Interior Fuse Box
https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO 모든 배선 다이어그램에 액세스하십시오.
Fig. 2: Mercedes-Benz CLK500 2003 - Component Locations - Locating Front Prefuse Box
https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO 모든 배선 다이어그램에 액세스하십시오.
Fig. 3: Mercedes-Benz CLK500 2003 - Component Locations - Locating Front SAM Control Module With Fuse & Relay Module
https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO 모든 배선 다이어그램에 액세스하십시오.
Fig. 4: Mercedes-Benz CLK500 2003 - Component Locations - Locating Rear SAM Control Module With Fuse & Relay Module
Mercedes-Benz CLK500 2003 - FUSE ASSIGNMENTS Front Prefuse Box
For location of fuses and fuse assignments, see Fig. 5 .
https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO 모든 배선 다이어그램에 액세스하십시오.
Fig. 5: Mercedes-Benz CLK500 2003 - Component Locations - Identifying Location & Fuse Assignments Of Front Prefuse Box
Mercedes-Benz CLK500 2003 - Front SAM Control Module With Fuse & Relay Module
For fuse locations, see Fig. 6 . For fuse assignments, see Fig. 7 - Fig. 9 .
https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO 모든 배선 다이어그램에 액세스하십시오.
Fig. 6: Mercedes-Benz CLK500 2003 - Component Locations - Identifying Front SAM Control Module Fuses & Relays
https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO 모든 배선 다이어그램에 액세스하십시오.
Fig. 7: Mercedes-Benz CLK500 2003 - Component Locations - Fuse Assignments Front SAM Control Module With Fuse & Relay Module (1 Of 3)
https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO 모든 배선 다이어그램에 액세스하십시오.
Fig. 8: Mercedes-Benz CLK500 2003 - Component Locations - Fuse Assignments Front SAM Control Module With Fuse & Relay Module (2 Of 3)
https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO 모든 배선 다이어그램에 액세스하십시오.
Fig. 9: Mercedes-Benz CLK500 2003 - Component Locations - Fuse Assignments Front SAM Control Module With Fuse & Relay Module (3 Of 3)
Mercedes-Benz CLK500 2003 - Interior Fuse Box Fuse Assignments
For fuse locations, see Fig. 10 . For fuse assignments, see Fig. 11 and Fig. 12 .
https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO 모든 배선 다이어그램에 액세스하십시오.
Fig. 10: Mercedes-Benz CLK500 2003 - Component Locations - Identifying Interior Fuse Box Fuses & Relays
https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO 모든 배선 다이어그램에 액세스하십시오.
Fig. 11: Mercedes-Benz CLK500 2003 - Component Locations - Fuse Assignments Interior Fuse Box (1 Of 2)
https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO 모든 배선 다이어그램에 액세스하십시오.
Fig. 12: Mercedes-Benz CLK500 2003 - Component Locations - Fuse Assignments Interior Fuse Box (2 Of 2)
Mercedes-Benz CLK500 2003 - Rear SAM Control Module With Fuse & Relay Box
For fuse locations, see Fig. 13 . For fuse assignments, see Fig. 14 and Fig. 15 .
https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO 모든 배선 다이어그램에 액세스하십시오.
Fig. 13: Mercedes-Benz CLK500 2003 - Component Locations - Identifying Rear SAM Module Fuses & Relays
https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO 모든 배선 다이어그램에 액세스하십시오.
Fig. 14: Mercedes-Benz CLK500 2003 - Component Locations - Fuse Assignments Rear SAM Control Module With Fuse & Relay Module (1 Of 2)
https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO 모든 배선 다이어그램에 액세스하십시오.
Fig. 15: Mercedes-Benz CLK500 2003 - Component Locations - Fuse Assignments Rear SAM Control Module With Fuse & Relay Module (2 Of 2)
Mercedes-Benz CLK500 2003 - RELAY ASSIGNMENTS Front SAM Control Module With Fuse & Relay Module
For relay locations, see Fig. 6 . For relay assignments, see Fig. 16 .
https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO 모든 배선 다이어그램에 액세스하십시오.
Fig. 16: Mercedes-Benz CLK500 2003 - Component Locations - Identifying Front SAM Module Relay Assignments
Mercedes-Benz CLK500 2003 - Rear SAM Control Module With Fuse & Relay Module
For relay locations, see Fig. 13 . For relay assignments, see Fig. 17 .
https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html
Automotive Electricians Portal FZCO
Automotive Electricians Portal FZCO 모든 배선 다이어그램에 액세스하십시오.
Fig. 17: Mercedes-Benz CLK500 2003 - Component Locations - Identifying Rear SAM Module Relay Assignments
Mercedes-Benz CLK500 2003 - WIRING DIAGRAMS
NOTE: | For wiring diagrams, see appropriate SYSTEM WIRING DIAGRAMS article in ELECTRICAL. |
