SEAT AROSA 2000 – Front electric windows . Wiring diagrams, Pin Connector, Location

  1. Home
  2. >SEAT
  3. >SEAT AROSA
  4. >SEAT AROSA 2000
  5. >SEAT AROSA 2000 ALL WIRING DIAGRAMS - ENGLISH

Download PDF file

Wiring Diagram SEAT AROSA 2000 - Battery - ignition/starter switch - relief relay for x contact



Wiring Diagram SEAT AROSA 2000 - Battery - ignition/starter switch - relief relay for x contact https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Obtenha acesso a todos os diagramas de fiação do carroDownload PDF file
ABattery (00532)
BStarter
DIgnition/starter switch
E19Parking light switch
J59Relief relay for x contact
J429Central locking control unit
S163Fuse -2- (30), in fuse holder/battery
S229Fuse in fuse box
T7a7 way connector
T2323 way connector
T2424 way connector
  1 Earthing strap, battery - body
  2 Earthing strap, gearbox - body
  B106 Earth connection (driver's door 1), in interior wiring loom
  B158 Connection (S), in interior wiring harness
  B163 Positive connection -1- (15), in interior wiring harness
  B164 Positive connection -2- (15a), in interior wiring harness

Wiring Diagram SEAT AROSA 2000 - Window lifter switches in driver's door - front left window lifter motor - window lifter relay



Wiring Diagram SEAT AROSA 2000 - Window lifter switches in driver https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Obtenha acesso a todos os diagramas de fiação do carroDownload PDF file
E41Front right window lifter switch
J51Window lifter relay
L53Bulb for illuminating window lifter switch
S43Window lifter thermofuse
T10g10-pin connector, at bottom left A pillar
V14Left window lifter motor
  57 Earth point, rear left pillar
  205 Earth connection, in driver's door cabling wiring loom
  B106 Earth connection (driver's door/1), in interior wiring loom
  B110 Connection (30, window lifters), in interior wiring loom
  B157 Positive connection (30), in interior wiring loom
  R10 Positive connection -1- (30), in driver's door cabling wiring loom

Wiring Diagram SEAT AROSA 2000 - Window lifter switches and driver's door - window lifter switch in passenger's door - front right window lifter motor



Wiring Diagram SEAT AROSA 2000 - Window lifter switches and driver https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Obtenha acesso a todos os diagramas de fiação do carroDownload PDF file
E81Front passenger's window lifter switch (in driver's door)
E107Window lifter switch (in passenger's door)
L53Bulb for illuminating window lifter switches
T10g10-pin connector, at bottom left A pillar
T10h10-pin connector, at bottom left A pillar
T10i10-pin connector, at bottom left A pillar
V15Right window lifter motor
  205 Earth connection, in front passenger's door cabling wiring loom
  B110 Connection (30, window lifters), in right interior wiring loom
  R10 Positive connection -1- (30), in driver's door cabling wiring loom
