Электросхемы БЛОКИРОВКИ СЕЛЕКТОРА СТОЯНОЧНЫЙ ТОРМОЗ Hyundai Genesis 4.6 2011

БЛОКИРОВКИ СЕЛЕКТОРА СТОЯНОЧНЫЙ ТОРМОЗ

Электрорсхема стояночного тормоза ручника для Hyundai Genesis 4.6 2011

Электрорсхема стояночного тормоза ручника для Hyundai Genesis 4.6 2011 - Список элементов:

• (behind right side
• +5v30d
• B-can transceiver
• Battery pwr
• Body unit 3 fuse 10a
• Brake fluid level sensor (on brake fluid reservoir)
• C-can high
• C-can low
• C-can transceiver
• Cluster fuse 10a
• Computer data lines system
• E/r junction box
• E/r-e2b
• Ef31
• Electric parking brake (epb) module (left rear wheelwell)
• Em31
• Epb & avh switch
• Epb 1 fuse 15a
• Epb 2 fuse 15a
• Epb ind
• Epb switch
• Ff02
• Ge03 (left front of engine compt)
• Gf08
• Gm05 (right side of dash)
• Ground
• High
• Hot at all times
• Hot in on or start
• I/p-lhc
• I/p-lhe
• I/p-lhg
• Ill
• Instrument cluster
• Interior lights system
• Ipm (instrument panel module) (left side of dash)
• Joint connector jeb (left kick panel)
• Joint connector jfla (left "c" pillar)
• Left i/p junction box
• Low
• M11-a
• M11-b
• M40-b
• Mcu
• Mf11
• Mf21
• Of rear seat)
• On/start input
• Parking brake ind
• Parking brk sig
• Pnk
• Pwr gnd
• Red
• Shift resistor
• Sw 1
• Sw 2
• Sw 4
• Sw 5

Электросхема блокировки селектора и замка зажигания для Hyundai Genesis 4.6 2011

Электросхема блокировки селектора и замка зажигания для Hyundai Genesis 4.6 2011 - Список элементов:

• 2nd
• Bcm (under left side of dash)
• Detent
• F53-a
• Gm04 (under left side of dash)
• Gr01 (in tailgate)
• Icm relay box (under left center of dash)
• Ill
• Interior lights system
• J/c jm05 (under left end of dash)
• Left pinch switch (at left top corner of tailgate)
• Local
• M04-b
• M04-c
• M04-d
• M08-a
• Nca
• O/s handle sw
• Open flash
• Open/close sw
• Pnk
• Power latch 1 (center of of tailgate)
• Power tail gate on/off switch
• Power tail gate relay
• Power tail gate switch
• Primary
• Pwr t/gate sw
• R02-a
• Red
• Right pinch switch (at right top corner of tailgate)
• Smart key control module
• T/gate latch
• T/gate open
• T/gate rly ctrl
• Tail gate handle switch
• Tail gate handle switch & license lamp
• Tail gate lamp
