Электросхемы ПРЕДУПРЕЖДАЮЩИЕ СИСТЕМЫ Hyundai Tucson SE 2007

ПРЕДУПРЕЖДАЮЩИЕ СИСТЕМЫ

Электросхема сигнала, С ETACM для Hyundai Tucson SE 2007

Электросхема сигнала, С ETACM для Hyundai Tucson SE 2007 - Список элементов:

• (in center console)
• Anti-theft system
• Auto dr unlock (a/bag)
• B/alarm rly ctrl
• Burglar horn rly ctrl
• Chime bell (below left side of dash, right of steering column)
• Chime bell ctrl
• Code save
• Computer data lines system
• Cruise control system
• Defog rly
• Defog rly ctrl
• Defog sw
• Defog sw input
• Defogger system
• Door ajar ind
• Door locks system
• Dr sw (all)
• Dr warning sw
• Driver seat buckle switch (in seat belt buckle)
• Eng running input
• Etacm (under center console)
• Exterior lights system
• Fog lamp sw
• Fuse 10a
• G01 (under right center of dash)
• G03
• G03 (in center console)
• Gnd
• Hazard rly ctrl
• Head
• Head lmp sw input
• Headlights system
• Hi-scan
• Hood sw
• Hot at all times
• Hot in on
• Hot in on or start
• I/p junction box (under left side of dash, near kick panel)
• I/p-c
• I/p-e
• Instrument cluster
• Int
• Int (time)
• Interior lights system
• J/c f02 (at right kick panel)
• J/c m08 (under left side of dash)
• J/c m09 (under left side of dash)
• J/c m17 (under left side of dash)
• Key hole ill
• Key remind switch
• Left front door switch (left "b" pillar)
• Lf dr sw
• Lf lock/unlock
• Lf unlock sw
• Light switch
• Lock rly
• M13-1
• M13-2
• M13-3
• M15-1
• M20-1
• Mem pwr
• Multi-function switch
• Nca
• Off
• On input
• On/start input
• Park
• Pnk
• Power windows system
• Pwr window rly
• Rear dr lock/unlock
• Red
• Rf dr sw
• Rf lock/unlock
• Rf unlock sw
• Rly ctrl input
• Rly ctrl output
• Room lamp ctrl
• Seat belt ind
• Seat belt sw
• Starting/charging system
• T/gate unlock sw
• Tail gate sw
• Unlock rly
• Vss in
• Washer input
• Wiper rly ctrl
• Wiper/washer system

Электросхема сигнала, без ETACM для Hyundai Tucson SE 2007

Электросхема сигнала, без ETACM для Hyundai Tucson SE 2007 - Список элементов:

• (at right kick panel) j/c f02
• Chime bell
• Chime bell (below left side of dash, right of steering column)
• Defog rly
• Defog rly ctrl
• Defog sw
• Defog sw in
• Defogger system
• Door ajar ind
• Dr warning sw
• Driver seat buckle switch (in seat belt buckle)
• Eng running input
• Exterior lights system
• Fog lamp sw
• Fuse 10a
• G01 (under right center of dash)
• G03 (in center console)
• Gnd
• Head
• Head lmp sw input
• Headlights system
• Hot at all times
• Hot in on
• Hot in on or start
• I/p junction box (under left side of dash, near kick panel)
• I/p-c
• I/p-e
• Instrument cluster
• Int
• Int (time)
• Interior lights system
• J/c m08 (under left side of dash)
• J/c m09 (under left side of dash)
• J/c m17 (under left side of dash)
• Key remind switch
• Left front door switch (left "b" pillar)
• Lf dr sw
• Light switch
• M15-1
• M20-1
• Mem pwr
• Multi-function switch
• Nca
• Off
• On input
• On/start input
• Park
• Pnk
• Red
• Rly ctrl input
• Rly ctrl output
• Seat belt ind
• Seat belt sw
• Starting/charging system
• Tacm (under center console)
• Washer input
• Wiper rly ctrl
• Wiper/washer system

Электросхема системы контроля давления в шинах для Hyundai Tucson SE 2007

Электросхема системы контроля давления в шинах для Hyundai Tucson SE 2007 - Список элементов:

• Computer data lines system
• Cruise control system
• Fuse 10a
• Fuse 15a
• G11 (base of right "b" pillar)
• Hot at all times
• Hot in on or start
• I/p junction box (under left side of dash, near kick panel)
• I/p relay box (top of left kick panel)
• I/p-c
• I/p-d
• I/p-e
• Instrument cluster
• M15-1
• M15-3
• Red
• Tire pressure monitoring module (under rear of center console)
• Tpms ind
• Tpms tread ind
• Windshield defogger relay
