Электросхемы СИСТЕМА АНТИБЛОКИРОВОЧНОЙ ТОРМОЗНОЙ СИСТЕМЫ ABS Hyundai Tucson GLS 2005

СИСТЕМА АНТИБЛОКИРОВОЧНОЙ ТОРМОЗНОЙ СИСТЕМЫ ABS

Электросхема антиблокировочной тормозной системы АБС (ABS), С ESP для Hyundai Tucson GLS 2005

Электросхема антиблокировочной тормозной системы АБС (ABS), С ESP для Hyundai Tucson GLS 2005 - Список элементов:

• (top right side of steering column)
• 2.0l
• 2.7l
• Abs fusible link 1 40a
• Abs fusible link 2 40a
• Abs ind
• Abs ind ctrl
• Abs pump motor
• Abs solenoid
• Brake ind
• Brake switch
• C130-1
• C135 (2.0l)
• C30-4
• C35 (2.7l)
• C35 (2.7l) c135 (2.0l)
• Can (high)
• Can (low)
• Computer data lines system
• Cruise control system
• Data link connector (below left side of dash)
• Diagnosis
• E/r fuse & relay box (left front corner of eng compt)
• Ecm (2.7l) pcm (2.0l) (under left side of dash)
• Esp control module (right front corner of engine compt)
• Esp ind ctrl
• Esp off ind ctrl
• Esp switch
• Esp switch on
• Fuse 10a
• Fuse 15a
• G sensor sig
• G-sensor (under center console)
• G-yaw sensor (under center console)
• G01 (under right center of dash)
• G08 (left of blower motor)
• Gnd
• Ground
• Hot at all times
• Hot in on or start
• I/p junction box (under left side of dash)
• I/p-a
• I/p-c
• I/p-e
• I/p-g
• Instrument cluster
• Instrument cluster system
• Interior lights system
• J/c c35 (2.7l) c135 (2.0l) (lower right side of dash)
• Left front wheel sensor (left front hub assembly)
• Left rear wheel sensor (left rear hub assembly)
• M15-1
• M15-3
• Multipurpose check connector (right front corner of engine compt)
• Nca
• Note: esp control module contains: esp solenoids, abs solenoids & abs pump motor
• On/start input
• Pnk
• Power
• Pressure sensor (on brake master cylinder)
• Red
• Right front wheel sensor (right front hub assembly)
• Right rear wheel sensor (on right rear wheel hub assembly)
• Self test
• Sig
• Signal
• Steering ang sens 1
• Steering ang sens 2
• Steering ang sens gnd
• Steering ang sens n
• Steering angle sensor
• Stop lamp switch
• Stop lamp switch (brake pedal bracket)
• Tcs ind
• Tcs off ind
• Wheel speed input
• Yaw sensor power
• Yaw sensor sig

Электросхема антиблокировочной тормозной системы АБС (ABS), без ESP для Hyundai Tucson GLS 2005

Электросхема антиблокировочной тормозной системы АБС (ABS), без ESP для Hyundai Tucson GLS 2005 - Список элементов:

• "g" sensor (under center console)
• (2.0l) (2.7l)
• Abs control module (right front corner of engine compt)
• Abs fusible link 1 40a
• Abs fusible link 2 40a
• Abs ind
• Abs ind ctrl
• Abs pump motor
• Abs/tcs solenoids
• Brake ind
• C130-1
• C135 (2.0l)
• C30-4
• C35 (2.7l)
• Can (high)
• Can (low)
• Data link connector (below left side of dash)
• Diagnosis
• E/r fuse & relay box (left front corner of engine compt)
• Ecm (2.7l) pcm (2.0l) (under left side of dash)
• Engine controls system
• Fuse 10a
• Fuse 15a
• G sensor
• G01 (under right center of dash)
• G08 (left of blower motor)
• Ground
• Hot at all times
• Hot in on or start
• I/p junction box (under left side of dash)
• I/p-a
• I/p-c
• I/p-e
• I/p-g
• Instrument cluster
• Instrument cluster system
• Interior lights system
• J/c
• J/c m08
• J/c m09
• Left front wheel sensor (left front hub assembly)
• Left rear wheel sensor (left rear hub assembly)
• M15-1
• M15-3
• Multipurpose check connector (right front corner of eng compt)
• Nca
• Note: abs control module contains: abs solenoids, tcs solenoids & abs pump motor
• On/start input
• Pnk
• Red
• Right front wheel sensor (right front hub assembly)
• Right rear wheel sensor (right rear hub assembly)
• Stop lamp sw
• Stop lamp switch (brake pedal bracket)
• Tcs ind
• Tcs ind ctrl
• Tcs off ind
• Tcs off ind ctrl
• Tcs sw "on"
• Tcs switch
• Vss
• Wheel speed input
