Электросхемы Система Фар Hyundai Santa Fe GLS 2010

Система Фар

Электросхема фар, С автолампы для Hyundai Santa Fe GLS 2010

Электросхема фар, С автолампы для Hyundai Santa Fe GLS 2010 - Список элементов:

• Auto
• Auto light & photo sensor (top of dash)
• Auto light sensor
• Auto lt sw
• Bcm (below left side of dash)
• Clg-a
• Ctrl in
• Ctrl out
• Dimmer/ passing switch
• E/r junction box (left rear of engine compt)
• Exterior lights system
• Flash
• Fr fog fuse 10a
• Fr fog lp relay
• Front fog lamp switch
• Ge01 (behind left side of front bumper)
• Ge02 (behind right side of front bumper)
• Gm01 (behind main instrument cluster)
• Gm03 (behind center of dash)
• Gnd
• H/lp fuse 10a
• H/lp hi fuse 20a
• H/lp hi ind fuse 10a
• H/lp hi relay
• H/lp lo lh fuse 15a
• H/lp lo lh relay
• H/lp lo rh fuse 15a
• H/lp lo rh relay
• Hd beam ind ctrl
• Hdlp hi rly
• Hdlp lo rly
• Hdlp sw
• Head
• High
• High beam ind
• Hot at all times
• Hot in on
• Ill
• Ind
• Instrument cluster
• Interior lights system
• Left front fog lamp
• Left headlamp
• Light switch
• Low
• M13-a
• M13-b
• M13-d
• M15-a
• M20-l
• Multi-function switch
• Off
• Park
• Park head
• Pcm (3.5l) (left rear of engine compt)
• Pnk
• Pwr
• Red
• Right front fog lamp
• Right headlamp
• Sig
• Tail lamp relay
• U/h-b
• U/h-d
• W/ ac inverter
• W/ drl
• W/o ac inverter
• W/o drl

Электросхема фар, С DRL для Hyundai Santa Fe GLS 2010

Электросхема фар, С DRL для Hyundai Santa Fe GLS 2010 - Список элементов:

• A/t
• Bcm (below left side of dash)
• Ctrl in
• Ctrl out
• Dimmer/ passing switch
• Drl fuse 20a
• Drl gnd
• Drl relay
• Drl resistor (right front of engine compt)
• Drl rly ctrl
• E/r junction box (left rear of engine compt)
• Exterior lights system
• Flash
• Foot brake switch
• Fr fog fuse 10a
• Fr fog relay
• Front fog lamp switch
• Ge01 (behind left side of front bumper)
• Ge02 (behind right side of front bumper)
• Gm01 (behind main instrument cluster)
• H/lp fuse 10a
• H/lp hi fuse 20a
• H/lp hi ind fuse 10a
• H/lp hi relay
• H/lp hi rly
• H/lp lo lh fuse 15a
• H/lp lo lh relay
• H/lp lo rh fuse 15a
• H/lp lo rh relay
• Hdlp lo rly
• Hdlp sw
• Head
• Hi ind ctrl
• High
• High beam ind
• Hot at all times
• Hot in on
• I/p junction box
• I/p-g
• I/p-h
• Icm relay box (below left side of dash)
• Icm-b
• Ill
• Ind
• Instrument cluster
• Interior lights system
• Left front fog lamp
• Left headlamp
• Light switch
• Low
• M/t
• M13-a
• M13-b
• M13-c
• M13-d
• M15-a
• M20-l
• Multi-function switch
• Nca
• Off
• Park
• Parking brake switch (on base of parking brake lever)
• Parking brk sw
• Pnk
• Red
• Right front fog lamp
• Right headlamp
• System
• Tail lamp relay
• U/h-b
• U/h-d
• W/ ac inverter
• W/o ac inverter

Электросхема фар, без DRL для Hyundai Santa Fe GLS 2010

Электросхема фар, без DRL для Hyundai Santa Fe GLS 2010 - Список элементов:

• (left rear of engine compt)
• Bcm (below left side of dash)
• Clg-a
• Ctrl in
• Ctrl out
• Dimmer/ passing switch
• E/r junction box (left rear of engine compt)
• Exterior lights system
• Flash
• Fr fog fuse 10a
• Fr fog lp relay
• Front fog lamp switch
• Ge01 (behind left side of front bumper)
• Ge02 (behind right side of front bumper)
• Gm01 (behind main instrument cluster)
• Gm03 (behind center of dash)
• H/lp fuse 10a
• H/lp hi fuse 20a
• H/lp hi ind fuse 10a
• H/lp hi relay
• H/lp lo lh fuse 15a
• H/lp lo lh relay
• H/lp lo rh fuse 15a
• H/lp lo rh relay
• Hdlp lo rly
• Hdlp sw
• Head
• High
• High beam ind
• Hot at all times
• Hot in on
• Ill
• Ind
• Instrument cluster
• Interior lights system
• Left front fog lamp
• Left headlamp
• Light switch
• Low
• M13-b
• M13-d
• M15-a
• M20-2
• M20-l
• Multi-function switch
• Off
• Park
• Pcm (3.5l)
• Pnk
• Red
• Right front fog lamp
• Right headlamp
• Tail lamp relay
• U/h-b
• U/h-d
• W/ ac inverter
• W/o ac inverter
