Электросхемы ВНУТРЕННЕЕ ОСВЕЩЕНИЕ Hyundai Accent GS 2012

ВНУТРЕННЕЕ ОСВЕЩЕНИЕ

Электросхема подсветки для Hyundai Accent GS 2012

Электросхема подсветки для Hyundai Accent GS 2012 - Список элементов:

• (5dr: at left side of luggage panel)
• (5dr: at right side of luggage panel)
• 4dr
• 5dr
• Auto cut relay
• Auto cut rly ctrl
• Bcm
• Bcm (under center of dash)
• Center room lamp
• Door
• Door open ind
• Driver door sw
• Driver door switch (on left "b" pillar)
• Fr11
• Gf01 (at left "c" pillar)
• Gm02 (top left side of dash)
• Hot at all times
• I/p junction box (behind left side of dash)
• I/p-b
• I/p-f
• Instrument cluster
• Left rear door switch (4dr: at left "c" pillar)
• Lh rear door sw
• Luggage room lamp
• M01-a
• M01-b
• M01-c
• M04-a
• M04-b
• Mf11
• Mf21
• Micom
• Mr01
• Off
• Open switch
• Overhead console lamp (w/ sunglass cap) map lamp (w/o sunglass cap)
• Pass door sw
• Passenger door switch (on right "b" pillar)
• Pnk
• Power connector
• Red
• Rh rear door sw
• Right rear door switch (4dr: at right "c" pillar)
• Room lamp ctrl
• Room lp 1 fuse 10a
• Room lp 2 fuse 10a
• Room lp ctrl
• Tail gate switch (left center of tailgate)
• Trunk lid switch
• Trunk open ind
• Trunk room lamp
• W/ sunglass cap
• W/o
• W/o sunglass cap

Электросхема подсветки приборов для Hyundai Accent GS 2012

Электросхема подсветки приборов для Hyundai Accent GS 2012 - Список элементов:

• (behind left side of dash) j/c jma
• (center of dash) a/c control module
• (top left side of dash)
• A/c switch (canada)
• A/t
• Atm shift lever switch ill
• Audio
• Auto
• Auto a/c
• Aux & usb jack
• Bcm (under center of dash)
• Canada
• Eco switch
• Esc off switch
• Front deicer switch (canada)
• Gm01 (center of dash)
• Gm03
• Gnd
• Hazard switch
• Head
• Hot at all times
• Hot in on or start
• I/p junction box (behind left side of dash)
• I/p-b
• I/p-c
• Ig1 1 fuse 10a
• Ill(+)
• Ill(-)
• Instrument cluster
• Light sw
• M01-b
• M01-l
• M02-r
• M04-a
• M04-b
• M11-a
• M33-a
• Manual a/c
• Multifunction switch
• Multifunction switch (remote control)
• Off
• On/start in
• Rear defogger switch
• Rheostat
• Svc load
• Tail
• Tail lamp relay
• Tail lp rh fuse 10a
• Tail lp rly ctrl
• Tail lp sw in
• Usa
• W/ bcm
• W/o bcm
