Электросхемы Стартер Генератор Dodge Colt 1994

Стартер Генератор

Электросхема Генератора для Dodge Colt 1994

Электросхема Генератора для Dodge Colt 1994 - Список элементов:

• (left side of dash)
• (right side of engine compt)
• 30a
• 80a
• A25
• Abs control unit pin 41 (w/ 1.8l)
• Acc
• B09
• B40
• B55
• B61
• B62
• Charge indicator
• Engine compartment relay box
• Fusible link 1
• Fusible link 3
• Fusible link 5 40a
• G101 (front right fender)
• G120 (right side of engine, on transaxle)
• Generator
• Ignition switch
• Instrument cluster
• Junction block
• Lock
• Multi- purpose fuse 3 10a
• Red
• Relay
• Start
• Starter (starting system) battery
• W/ 1.5l engine
• W/ 1.8l engine

Электросхема стартера для Dodge Colt 1994

Электросхема стартера для Dodge Colt 1994 - Список элементов:

• (center of dash) g206
• A/t
• A28
• A29
• A69
• Acc
• Auto-cruise control unit pin 1 (1.8l)
• B07
• B40
• B62
• B63
• Battery
• Buzzer assembly pin 10
• Clutch pedal position switch (behind dash)
• Engine compt relay box (right side of engine compt)
• Engine control module pin 51
• Engine control module pin 71 (1994)
• Fusible link 5 40a
• G101 (front right fender)
• G120 (right side of engine on transaxle)
• Ignition switch
• Junction block (below left dash)
• Lock
• M/t
• Park/neutral position switch (right engine compartment, at transaxle linkage)
• Passenger compartment relay box (below instrument cluster)
• Start
• Starter
• Starter relay
