Электросхема быстрого подогрева для Audi A3 2.0T 2010
Электросхема быстрого подогрева для Audi A3 2.0T 2010 - Список элементов:
- Fuse 5a
- Fuse panel c
- G638 (behind right kick panel)
- Left washer nozzle heater (if equipped) (in left side of plenum chamber)
- Right washer nozzle heater (if equipped) (in right side of plenum chamber)
Электросхема стеклоочистителя, дворников и омывателя для Audi A3 2.0T 2010
Электросхема стеклоочистителя, дворников и омывателя для Audi A3 2.0T 2010 - Список элементов:
- (behind left kick panel) g44
- 16a
- 32a
- 41a
- Bpy
- Computer data lines system
- Except bpy
- Fuse 1 fuse 16 30a
- Fuse 10a
- Fuse 15a
- Fuse 17 fuse 6 5a
- Fuse 30a
- Fuse 31 fuse 19 30a
- Fuse 47 fuse 26 30a
- Fuse 5a
- Fuse panel b (integrated in engine compt e-box)
- Fuse panel c
- G44 (behind left kick panel)
- G61 (on left "c" pillar)
- G638 (behind right kick panel)
- G655 (on left headlight)
- Headlamp washer pump
- Headlight washer relay (on 5-position fuse/relay carrier)
- Hot at all times
- Instrument cluster control module
- Instrument cluster system
- Nca
- Power distribution system
- Rain/light recognition sensor (w/ automatic head & taillight control) (on interior rearview mirror)
- Rear window wiper motor (center of cargo area lid)
- Steering column electronic systems control module (under steering column)
- T20b
- T40
- T52a
- T52b
- T52c
- Vehicle electrical system control module (below left side of dash)
- W/ hill hold assist
- W/o hill hold assist
- Windshield & rear window washer pump
- Windshield washer fluid level sensor
- Windshield wiper/washer switch
- Wiper motor control module (integral to windshield wiper motor)
