Электросхема быстрого подогрева для Audi A4 2.0T 2012
Электросхема быстрого подогрева для Audi A4 2.0T 2012 - Список элементов:
- Fuse 35a
- Fuse carrier
- Fuse panel c
- G639 (behind left kick panel)
- Left washer nozzle heater
- Right washer nozzle heater
- T17l
- T17m
- T17n
- T32b
- Vehicle electrical system control module (under left side of dash)
Электросхема стеклоочистителя, дворников и омывателя для Audi A4 2.0T 2012
Электросхема стеклоочистителя, дворников и омывателя для Audi A4 2.0T 2012 - Список элементов:
- 12a
- 14a
- Automatic dimming interior rearview mirror
- Computer data lines system
- Fuse 15a
- Fuse 30a
- Fuse 35a
- Fuse 5a
- Fuse carrier
- Fuse carrier 1
- Fuse carrier 3
- Fuse panel c
- Fuse panel d (lower right side of dash)
- G639 (behind left kick panel)
- G654 (top of right "d" pillar)
- G687 (left side of center tunnel)
- Headlamp washer pump (if equipped)
- Hot at all times
- Instrument cluster control module
- Nca
- Rain/light recognition sensor
- Rear window wiper motor (wagon)
- Relay/fuse panel f (right side of luggage compt)
- Steering column electronic systems control module (on steering column, behind steering wheel)
- T16b
- T17l
- T17m
- T17n
- T32b
- T3c
- Vehicle electrical system control module (under left side of dash)
- Wagon
- Windshield washer fluid level sensor
- Windshield washer pump
- Windshield wiper intermittent mode switch
- Wiper control module (left rear of engine compt, in plenum chamber)
