Электросхемы ПРИБОРНАЯ ПАНЕЛЬ Cadillac Eldorado 1994

ПРИБОРНАЯ ПАНЕЛЬ

Электросхема панели приборов для Cadillac Eldorado 1994

Электросхема панели приборов для Cadillac Eldorado 1994 - Список элементов:

• "stop engine" "engine overheated" "check washer fluid" "trunk open" "service ride control"
• "turn signal on"
• (4.9l)
• (4.9l) 3e11 2c1
• (4.9l) 3e16 1b5
• (concours) d8,d9
• (eldorado/ c15,d16 seville)
• (northstar)
• (northstar) 3f5 2a10
• 16 volts
• 1b11 2b11
• 2c12 2a8
• 2c14
• 4.9l
• 4.9l deville only
• 4.9l only
• Acc
• Air bag indicator
• Analog
• Antilock indicator
• Bat
• Battery indicator (canada/ export only)
• Battery indicator control
• Brake ind. ctrl
• Brake indicator
• Brake pressure modulator valve
• Bulb test
• C1 tan
• C10
• C12
• C13
• C14
• C15
• C16
• C2 eldorado/seville w/ analog cluster only
• C2 tan
• C3 nca
• Chime module (behind left side of i/p)
• Chime module control
• Chime module diode
• Coolant level switch (on front of coolant reservoir) (opens when coolant is 1.5l low)
• Coolant temp. indicator (canada/ export only)
• Coolant temp. indicator control
• D10
• D11
• D12 red
• D13
• D15
• Data line
• Data line in/out
• Data link connector
• Diagnostic energy reserve module (below left side of i/p)
• Digital
• Dimming input
• Driver information center
• Driver information center "check brake fluid" "brake fluid switch problem" "service air bag system" "traction disabled" "traction active" "reduced engine power"
• Driver information center "stop engine" "low oil pressure" "engine coolant hot" "check coolant level" "check oil level"
• Ects input
• Electronic brake/ traction control module (center of electronics bay, mounted on "x" brace)
• Engine coolant temperature sensor (top left side of engine)
• Engine metal temp. switch (left rear of engine) (closed above 150 c, 302 f)
• Engine metal temp. switch input
• Engine speed output
• Exterior lights system
• Fasten belts ind. ctrl
• Fasten belts indicator
• Fault input
• Fault output
• Fuel level input
• Fuel level sensor (0 -empty) (170 -full)
• Fuel tank unit (on top of fuel tank)
• Fuse a11 10a
• Fuse a3 10a
• Fuse a5 10a
• Fuse b5 10a
• Fuse block: i/p
• Fuse block: trunk
• G109 (on upper right radiator support)
• G112 (top left side of engine) g119 (lower right front of engine)
• G117 (lower right rear of engine)
• G119 (lower right front of engine)
• G200 (left kick panel)
• G310 (behind right rear seat)
• G404 (left rear corner of trunk)
• Generator
• Generator control/ feedback
• Generator disable connector (top right side of engine)
• Generator feedback
• Ground
• Hazard indicator
• Hazard indicator control
• Headlights system
• Hi beam input
• Hot at all times
• Hot in run
• Hot in run, bulb test or start
• Ign 1
• Ign 3
• Ignition control module (top right rear of engine)
• Ignition switch
• Instrument cluster
• Interior lights system
• Left turn input
• Lock
• Low brake fluid level input
• Low brake fluid switch (closed with low brake fluid level) (on brake fluid reservoir)
• Low washer fluid switch on washer fluid reservoir) (closed with low washer fluid level)
• Malfunction indicator
• Mil ind. ctrl
• Nca
• Northstar
• Northstar only
• Off
• Oil level input
• Oil level switch (lower right front of engine) (opens when oil is 2 quarts low)
• Oil pressure indicator (canada/ export only)
• Oil pressure indicator control
• Oil pressure switch (above oil filter)
• Oil pressure switch input d6
• Park brake switch (open with park brake released)
• Park lamps input
• Pass-key decoder module (in right electronics bay, mounted on board)
• Pnk
• Pnk d
• Power- train control module (behind right side of i/p)
• Powertrain control module (behind right side of i/p)
• Red
• Red l
• Right turn input
• Road sensing suspension module (in right electronics bay, mounted on board)
• Run
• Security ind. ctrl
• Security indicator
• Sensor return
• Sir ind. ctrl
• Speed sensitive suspension module (in right electronics bay, mounted on board)
• Start
• Tachometer input
• Tan
• Theft deterrent module (in left electronics bay, mounted on board)
• Trunk lamp
• Trunk lid latch switch (rear of trunk lid)
• Trunk open input
• Vehicle speed input
• Vehicle speed output
• Vf dimming control
• Warning input
• Warnings system
• Washer fluid level switch input
• With universal theft deterrent only
