Электросхемы СИСТЕМА КРУИЗКОНТРОЛЯ Lexus GS 300 2000

СИСТЕМА КРУИЗКОНТРОЛЯ

Электросхема системы круизконтроля для Lexus GS 300 2000

Электросхема системы круизконтроля для Lexus GS 300 2000 https://portal-diagnostov.com/license.html
https://portal-diagnostov.com/license.html Automotive Electricians Portal FZCO Automotive Electricians Portal FZCO
Получить доступ ко всем электросхемам автомобиляDownload PDF file

Электросхема системы круизконтроля для Lexus GS 300 2000 - Список элементов:

  • (behind ecu box)
  • (engine harn, left side of engine)
  • (engine harn, top left side of engine)
  • (in ecu box)
  • (left cylinder head)
  • (left kick panel) j/6 c
  • (right cylinder head)
  • +b1
  • +bm
  • A/t indicator light switch
  • Accel position sensor (top center of engine)
  • Batt
  • Braided
  • C12
  • C13
  • Cancel
  • Ccs
  • Cl+
  • Cl-
  • Combination meter
  • Computer data lines system
  • Cpu
  • Cruise control switch
  • Cruise ind
  • Data link connector 1
  • Driver side j/b
  • Driver side junction block
  • E01
  • E02
  • E03
  • Efi fuse 25a
  • Efi relay
  • Engine control module (left side of engine compt, in ecu box)
  • Engine room relay block 1
  • Eom
  • Etcs fuse 15a
  • G102 (left front strut tower)
  • G104 (left rear corner of engine compt)
  • G112
  • G112 (left cylinder head)
  • G120
  • G200
  • Gauge fuse 10a
  • Ge01
  • Hot at all times
  • Hot in on or start
  • Ign fuse 5a
  • Igsw
  • J/c 1 (in ecu box)
  • J/c 11 (left side of dash)
  • J/c 14 (behind left side of dash)
  • J/c 17 (behind right side of dash)
  • J/c 2 (in ecu box)
  • J/c 3
  • J/c 3 (in ecu box)
  • J/c 5 (in engine room relay block 2)
  • J/c 7 (behind left kick panel)
  • J/c 9 (behind left side of dash)
  • J/c4
  • Main
  • Me01
  • Mpx2
  • Mrel
  • Pnk
  • Res/ acc
  • Set/ coast
  • Sti-
  • Stop fuse 15a
  • Stoplight switch (on brake pedal bracket)
  • Stp
  • Throttle control motor (on throttle body)
  • Throttle position sensor (on throttle body)
  • Vpa
  • Vpa2
  • Vta
  • Vta2
