Электросхемы ЦЕНТРАЛЬНЫЙ ЗАМОК Ford Ranger 2000

ЦЕНТРАЛЬНЫЙ ЗАМОК

Электросхема центрального замка для Ford Ranger 2000

Электросхема центрального замка для Ford Ranger 2000 - Список элементов:

• (behind dash, right of steering column) relay box
• (behind left kick panel) g200
• (dlc) in
• (main harn, near breakout for generic electronic module)
• (rear of vehicle, near breakout for black 8-pin connector, under left rear of vehicle)
• All lock relay
• All unlock relay
• Anti-theft disable
• Anti-theft door ajar input
• Battery junction box (left rear of engine compt)
• C221
• C222
• C409
• C410
• Central juntion box (behind left side of dash)
• Data link connector (dlc) (fastened to bottom of dash, near steering column)
• Door disarm input
• Driver unlock relay
• Drvr door ajar
• Exterior lights system
• Fuel sys/ anti-theft mini fuse 9 20a
• Fuse 15a
• Fuse 7.5a
• G108 (left side of upper radiator support)
• G200 (behind left kick panel)
• Generic electronic module (gem)/ central timer module (ctm) (behind center of dash)
• Ground
• Horn rly out
• Horns system
• Hot at all times
• Hot in acc or run
• Left door ajar switch
• Left door lock actuator
• Left door lock switch
• Left rear door ajar switch
• Lock
• Lock in/out
• Park lp rly ctrl
• Pass door ajar
• Pwr (bat)
• Pwr (ign)
• Remote anti-theft personality (rap) module (in left rear corner of cab)
• Right door ajar switch
• Right door lock actuator
• Right door lock switch
• Right rear door ajar switch
• S116
• S200 (main harn, near breakout for passenger air bag)
• S201
• S205
• S225 (main harn, near breakout for generic electronic module)
• S238
• S244
• S270 (main harn, near breakout to generic electronic module)
• S271
• S280
• S300
• S401
• S500
• S600
• Unlk
• Unlock drv's dr
• Unlock in/out
• W/o anti-theft system only
