Электросхемы ПОДУШКИ БЕЗОПАСНОСТИ AIR BAG Mercury Villager Estate 2000

ПОДУШКИ БЕЗОПАСНОСТИ AIR BAG

Электросхема подушек безопасности SRS AirBag для Mercury Villager Estate 2000

Электросхема подушек безопасности SRS AirBag для Mercury Villager Estate 2000 - Список элементов:

• driver air bag
• (behind center dash panel) s2101
• (behind right side of dash panel) g201
• (behind top center dash of panel) s202
• (behind top center of dash panel) s260
• (behind top center of dash panel) s271
• (left kick panel) g200
• Air bag diag monitor
• Air bag diag monitor
• Air bag diagnostic monitor (behind center of dash)
• Air bag indicator
• Air bag sliding contact
• Av07
• Av15
• C2013
• C2035 (w/air bag connected) c2048 (w/air bag disconnected)
• C2048
• C2049
• C266a
• C266b
• C266c
• C267c
• Central junction box (behind left side of dash)
• Computer data lines system
• Conventional cluster
• Data link connector (dlc) (partial) (behind left side of dash)
• Driver air bag
• Driver air bag unit
• Electronic cluster
• Fuse 10a
• G201 (behind right side of dash panel)
• Ground
• Hot in run or start
• Ignition
• Instrument cluster
• Left front door ajar sw
• Left front door ajar switch (1: door closed) (2: door open)
• Nca
• Passenger air bag
• Passenger air bag module
• Passsenger air bag
• Ps01
• Ps03
• Ps04
• Ps05
• Ps06
• Ps15
• Ps17
• Ps20
• Ps21
• Ps28
• Pse2
• Resistor a
• Resistor b
• S272 (behind top center of dash panel)
• Shorting bar (for air bag sliding contact)
• Shorting bar connector
• Shorting bar for passenger air bag module (w/air bag connected) (in-line connector c2048 to resistor b) (w/air bag disconnected)
• W/ air bag connected
• W/ air bag disconnected
